User Guide

Startup guide
Xperia® T2 Ultra
D5316
1279-8618.1
Welcome
Important Information
Before you use your device, please read the
Important
Information
provided in your device regarding warranty,
safety and handling information.
Assembly
Please use the SIM card included in the box. This new
card will allow you to use the Wi-Fi Calling feature, ISIS
Mobile Wallet™ feature and other enhanced device
features.
For help transferring contacts from your previous SIM
card, please ask a retail store representative to help you.
To insert the micro SIM card
1
2
3
5
4
To insert a memory card
Basics
Overview
14
5
8
9
10
2
7
6
3
11 1312
17
16
15
14
1. Front camera lens
2. Proximity sensor/
Light sensor
3. Charging light/
Notification light
4. Speaker
5. Headset jack
6. Micro SIM card slot
cover
7. Power key
8. Volume/Zoom key
9. Camera key
10. Microphone
11. Main camera lens
12. Camera light
13. Second microphone
14. Charger/USB port cover
15. NFC™ detection area
16. Memory card slot cover
17. Loudspeaker
Use the accessories provided with your device, or
other compatible accessories for optimal
performance.
Turning on the device
Make sure that the battery is charged for at least 30
minutes before you turn on the device for the first time.
To turn on the device
1Press and hold down the power key until the
device vibrates.
2Wait a while for the device to start.
Waking up the screen
To activate the screen
•Briefly press the power key .
To unlock the screen
•Place a finger on the lower part of the screen and
swipe up or down.
Setting up your
device
What is Android™?
Android is your device's operating system. Since
Android is developed by Google™, your device is
preloaded with several Google™ services, such as
Google Maps™ and Google™ web search. To use
some of the services provided by Google™, you need
a Google account.
Android provides backup options through Gmail™
account sync to restore contacts, Wi-Fi settings, and
app data to/from Android devices.
Google™ account
With a Google™ account, you can use Gmail™ to send
emails, Hangouts™ to chat with friends, and Google
Play™ to download applications and games, music,
movies and books.
To set up a Google™ account on your device
1From your Home screen, tap .
2Find and tap Settings > Add account > Google.
3Follow the registration wizard to create a Google™
account, or sign in if you already have an account.
You can also sign in to or create a Google™
account from the setup guide the first time you
start your device. Or you can go online and create
an account at
www.google.com/accounts
.
Basic settings
The first time you start your device, a setup guide
explains basic device functions and helps you enter
essential settings. You can also access the setup guide
later.
To access the setup guide manually
1From the Home screen, tap .
2Tap Settings > Setup guide.
Transferring content
to your new device
Transferring content (such as contacts, messages,
photos and video clips) to your new device can
sometimes be complicated, but help is available. You
can transfer content from several device brands,
including iPhone, Samsung, HTC and Nokia. You
need:
•An Internet-connected PC or Apple® Mac®
computer.
•A USB cable for your old device.
•A USB cable for your new Android™ device.
•Your old device and new Android™ device.
Get started transferring your
contacts
Sony's migration wizard, called Xperia Transfer™,
helps reduce the barriers that consumers face when
moving the content (contacts, photos, video clips,
messages, music and more) from their old phone to
their new Xperia® smartphone and is part of the latest
versions of the PC Companion and Bridge for Mac
software.
If you are a PC user, use the PC Companion program
to transfer your contacts. It's free, and the installation
files are already saved on your new device. PC
Companion also offers a range of other features,
including help to update your device software. For
Apple® Mac® computer users, the Sony™ Bridge for
Mac application is available to help you transfer your
contacts. It's also free and downloadable from
www.sonymobile.com/support
.
To install PC Companion
1New device: Turn on your new Android™ device and
connect it to a PC using a USB cable.
2New device: Tap Install to install PC Companion on
the PC.
3Computer: If a popup window appears to notify you
about available PC software, select
Run Startme.exe
.
4Computer: Click
Install
to start the installation and
then follow the instructions to complete the
installation.
To install Sony™ Bridge for Mac
1Using your Apple Mac computer, go to
www.sonymobile.com/support
, then search for and
download the Sony™ Bridge for Mac application to a
folder on the computer.
2After the download is complete, open the folder and
double-click the
Sony Bridge for Mac.dmg
file to
start the installation.
3Follow the instructions on your Apple® Mac®
computer to complete the installation.
To transfer content to your new Xperia®
smartphone
1Make sure that PC Companion is installed on your
PC or that Sony™ Bridge for Mac application is
installed on your Apple® Mac® computer.
2Connect your old device to your PC or Apple®
Mac® and back up content following PC Companion
or Bridge for Mac instructions.
3Connect your new Xperia® smartphone to your PC or
Mac using the USB cable that came with the
smartphone.
4Start the PC Companion or Bridge for Mac on your
computer and click Xperia Transfer™. Then the
Welcome screen appears. Click Start.
5Select the content you want to transfer and click
Next. The content of your old device is now
transferred to your Xperia® smartphone.
Backing up content of your
device
Use the Back up & restore application to make
backups of content to a memory card or a USB storage
device. Such backups can be used to restore your
content and some settings in cases where your data
gets lost or deleted.
See the relevant section of the User guide for more
detailed information. An online User guide as well as a
downloadable version is available at
www.sonymobile.com/support
.
Finding your way
Home screen
The Home screen is the starting point for using your
device. You can customise it with applications,
widgets, shortcuts, folders, themes, and wallpaper.
You can also add extra panes.
The Home screen extends beyond the regular screen
display width, so you need to flick left or right to view
content in all of the Home screen's panes.
To go to the Home screen
•Press .
Application screen
The Application screen, which you open from your
Home screen, contains the applications that come pre-
installed on your device as well as the applications you
download.
The Application screen extends beyond the regular
screen width, so you need to flick left and right to view
all content.
To open the Application screen
•From your Home screen, tap .
To open an application
•From your Home screen or the Application screen,
tap the application.
Status and notifications
The status bar at the top of your screen shows what's
going on in your device. For example, new message
and calendar notifications appear here.
Checking notifications and ongoing
activities
You can drag down the status bar to open the
Notification panel and get more information. For
example, you can use the panel to open a new
message or view a calendar event. You can also open
some applications that run in the background, such as
the music player.
To open the Notification panel
•Drag the status bar downwards.
Using the keys
Back
•Go back to the previous screen
•Close the on-screen keypad, a dialog box,
an options menu, the Notification panel, or
an application
Home
•Go to the Home screen
Task
•Tap to open a window showing your most
recently used applications and a small apps
bar
More basics
Calling
To make a call by dialling
1From your Home screen, tap .
2Find and tap Phone.
3Enter the number of the recipient and tap .
To end a call
•Tap .
To answer a call
•Drag to the right across the screen.
MMS and text messaging
To create and send a message
1From your Home screen, tap , then find and tap
.
2Tap .
3Tap , then tap Add recipient and select a contact
from the Contacts list. If the recipient is not listed as
a contact, enter the recipient's number manually and
tap .
4When you are finished adding recipients, tap Done.
5Tap Write message and enter your message text.
6If you want to add a media file, tap and select an
option.
7To send the message, tap Send.
Wi-Fi calling
To use Wi-Fi Calling you should use the SIM card
shipped with your device. A different SIM card may
not work with the Wi-Fi Calling feature. Also, you
must have a 911 emergency address registered
with your account. Log into your account at
www.t-mobile.com
. Go to your profile and click
Customer Info to register your address.
About Wi-Fi Calling
Wi-Fi Calling can improve your coverage and allows
you to make phone calls and send messages over a
Wi-Fi network (when a Wi-Fi network is available).
Unless your rate plan provides otherwise, Wi-Fi Calling
minutes count the same as T-Mobile cellular calling
minutes on your phone bill.
Settings menu
View and change settings for your device from the
Settings menu.
To access your device settings
1From your Home screen, tap .
2Find and tap Settings.
Wireless Emergency Alert
Wireless Emergency Alert (“WEA”), also known as
Commercial Mobile Alert System (“CMAS”), is a
personalized emergency alert system designed to alert
you of nearby threats or emergencies. Your phone is
capable of receiving three kinds of alert messages:
•Presidential Alerts
•Imminent Threats to Safety Alerts
•Amber Alerts
Your phone notifies you in the following ways:
•Transmit a unique tone
•Vibrate with a unique cadence
•Display the alert message
Opt out of WEA alerts
You cannot turn off the Presidential Alert, but you can
turn off the Imminent Alerts and Amber Alerts. To turn
off:
1From your Home screen, tap , then find and tap
.
2Tap , then tap Settings > Emergency alerts.
3Unmark the relevant checkboxes.
Additional Information
There is no additional charge to receive WEA alerts.
Alerts may not be available: (1) while on active calls; (2)
if a subscriber is outside the TMobile coverage area; or
(3) due to interference concerns. You cannot forward or
reply to WEA alerts. Currently, WEA alerts will only be
in English (no other languages available). Occasionally,
a duplicate of previously received alert may display
again. For more information and FAQs see
www.t-mobile.com/CMAS
.
Troubleshooting
My device is not responding
If your device hangs, or if you cannot restart it
normally, you can force the device to shut down.
To force the device to shut down
1
2
1Detach the cover of the micro SIM card slot.
2Using the tip of a pen or a similar object, press and
hold down the OFF button until the device shuts
down.
Do not use overly sharp objects that could damage
the OFF button.
The device does not recognise my
wired headset
•Make sure the wired headset that you are using
complies to the CTIA standard. Your device supports
the CTIA standard, and may not be fully compatible
with other standards such as OMTP.
•If you have a wireless headset that is compatible with
your device, try using that instead.
My battery runs out quickly
The following tips can help you improve battery life:
•Use STAMINA mode to minimise battery
consumption when the screen is inactive.
•Disable all data connections over mobile networks
to save power when you're not using the Internet.
Doing so does not prevent your device from
transmitting data over other wireless networks.
•Turn off GPS, Bluetooth® and Wi-Fi® connections
when you don't need these features.
•Lower the screen brightness level or turn off X-
Reality for mobile.
Information about
safeguarding
handsets
T-Mobile encourages customers to take appropriate
measures to secure their handsets and invites them to
take advantage of the features available on this
handset to help secure it from theft and/or other
unauthorized access and use. This handset has a
locking function (e.g., user-defined codes or patterns)
that can serve as a first line of defense against
unauthorized use or access to stored information.
Preloaded security applications that allow customers to
track or locate misplaced devices can be found on
several T-Mobile devices. Remote locking and wiping
capabilities are also available to T-Mobile customers
that have elected to subscribe to the Mobile Security
service offered by our partner, Asurion, along with
insurance to help replace lost or stolen devices. Lost or
stolen devices should be immediately reported to T-
Mobile so that proper measures can be taken to
protect accounts. For additional information, visit:
www.t-mobile.com/devicesecurity
and
http://www.t-
mobile.com/Company/PrivacyResources.aspx
.
Mobile Security is a service provided by Asurion
Mobile Applications and is not an insurance
product.
Approved firmware versions
This device will only operate with firmware versions
that have been approved for use by T-Mobile and the
device manufacturer. If unauthorized firmware is placed
on the device it will not function.
Legal information
SonyD5316
Google Play™ is not available in all countries. Some of the services and
features described in this Startup guide are not supported in all countries/
regions or by all networks and/or service providers in all areas. Without
limitation, this applies to the GSM International Emergency Number 112.
Please contact your network operator or service provider to determine
availability of any specific service or feature and whether additional access or
usage fees apply.
This Startup guide is published by Sony Mobile Communications AB or its
local affiliated company, without any warranty. Improvements and changes to
this Startup guide necessitated by typographical errors, inaccuracies of
current information, or improvements to programs and/or equipment, may be
made by Sony Mobile Communications AB at any time and without notice.
Such changes will, however, be incorporated into new editions of this Startup
guide.
© 2014 Sony Mobile Communications AB. All rights reserved.
Publication number: 1279-8618.1
Your device has the capability to download, store and forward additional
content, e.g. ringtones. The use of such content may be restricted or
prohibited by rights of third parties, including but not limited to restriction
under applicable copyright laws. You, and not Sony, are entirely responsible
for additional content that you download to or forward from your device. Prior
to your use of any additional content, please verify that your intended use is
properly licensed or is otherwise authorized. Sony does not guarantee the
accuracy, integrity or quality of any additional content or any other third party
content. Under no circumstances will Sony be liable in any way for your
improper use of additional content or other third party content.
This Startup guide may reference services or applications provided by third
parties. Use of such programming or services may require separate
registration with the third party provider and may be subject to additional
terms of use. For applications accessed on or through a third-party website,
please review such websites’ terms of use and applicable privacy policy in
advance. Sony does not warrant or guarantee the availability or performance
of any third-party websites or offered services.
See regulatory information such as the CE mark in the label tray of the
device.
All product and company names mentioned herein are the trademarks or
registered trademarks of their respective owners. Any rights not expressly
granted herein are reserved. All other trademarks are property of their
respective owners.
Visit
www.sonymobile.com
for more information.
All illustrations are for illustration only and may not accurately depict the
actual device.
This product is protected by certain intellectual property rights of Microsoft.
Use or distribution of such technology outside of this product is prohibited
without a license from Microsoft.
Product compliance: This product has been manufactured by or on behalf of
Sony Mobile Communications, Mobilvägen, SE-221 88 Lund, Sweden.
Inquiries related to product compliance based on national legislation shall be
addressed to Sony Mobile Quality Officer, Sony Mobile Communications AB,
Mobilvägen, SE-221 88 Lund, Sweden. For any service or guarantee matters,
please refer to the contact details provided in the separate service or
guarantee documents.
Wi-Fi: Device will not transition between Wi-Fi and the cellular network.
Devices using wireless connections may be vulnerable to unauthorized
attempts to access data and software stored on the device. Plan data
allotment applies to use by connected devices sharing Wi-Fi. Use of
connected devices subject to T-Mobile Terms and Conditions.
Wi-Fi Calling: Wi-Fi connection required; may decrement plan minutes. See
your selected service for details.
Messaging/Data: You will be charged for all messages and data sent by or to
you through the network, regardless of whether or not data is received.
Character length/file size of messages/attachments may be limited. T-Mobile
is not liable for content of messages/attachments or for any failures, delays or
errors in any T-Mobile generated alerts or notifications. Your data session,
plan, or service may be slowed, suspended, terminated, or restricted if you
use your service in a way that interferes with or impacts our network or ability
to provide quality service to other users, if you roam for a significant portion
of your usage, or if you use a disproportionate amount of bandwidth during a
billing cycle. You may not use your plan or device for prohibited uses.
Downloads/Applications: T-Mobile is not responsible for any third party
content or Web site you may be able to access using your phone. Additional
charges may apply; not all downloads available on all phones. You obtain no
rights in downloads; duration of use may be limited and downloads may be
stored solely for use with your phone. T-Mobile is not responsible for any
download lost due to your error. T-Mobile is not responsible for Apps,
including download, installation, use, transmission failure, interruption or
delay, third party advertisements you may encounter while using an App,
alterations any App may make to the functionality of your device, including
any changes that may affect your T-Mobile plan, service, or billing, or any
content or website you may be able to access through an App.
Hearing Aid Compatibility: This phone has been tested and rated for use
with hearing aids for some of the wireless technologies that it uses. However,
there may be some newer wireless technologies used in this phone that have
not been tested yet for use with hearing aids. It is important to try the
different features of this phone thoroughly and in different locations, using
your hearing aid or cochlear implant, to determine if you hear any interfering
noise. Consult your service provider or the manufacturer of this phone for
information on hearing aid compatibility. If you have questions about return or
exchange policies, consult your service provider or phone retailer.
FCC Caution: Please notice Sony Mobile did NOT perform the testing of
Hearing Aid Compatibility of VoLTE and VoIP over Wi-Fi for CMRS air
interfaces because the test instrumentation for it was not readily available at
the time testing.
Devices, accessories, and screen images are simulated. See brochures and
Terms and Conditions (including arbitration provision) at T-Mobile.com, for
rate plan information, charges for features and services, and restrictions and
details, including important limitations on availability and reliability of 9-1-1
emergency service when using Wi-Fi Calling.
FCC Caution: This device shall only be assigned to FCC approved access
point when using 5 GHz WLAN for indoor and outdoor operation. This is
because operation in the frequency band 5.15 GHz to 5.25 GHz is only
permitted for indoor use.
FCC Caution: Your device can only connect to an FCC approved access
point when using 5 GHz WLAN for indoor and outdoor operation. This is
because operation in the 5.15 GHz to 5.25 GHz frequency band is only
permitted for indoor use.
To view the CE mark and the FCC ID
2
1
3
4
2
1Make sure your device is turned off, then detach the
cover of the micro SIM card slot.
2Remove the micro SIM card and the card holder.
3Insert a sharp object (such as a pen with a fine tip)
into the hole in the label tray, then drag the tray out
gently at an upwards angle. The FCC ID is now
viewable.
4To view the CE mark, turn the label tray over and
peel away the label.
The FCC ID is not available in all markets.
Our support to you –
Xperia® Care
User guide
A User guide for your device is available at
www.sonymobile.com/support
.
Support in your device
Get user support directly in your device using the
Support application.
To access the Support application
1From your Application screen, find and tap .
2Find and tap the required support item.
Support on the web
Visit
www.sonymobile.com/support
to access a range
of support and get the most from your device.
Customer support
Customer support – if all else fails. Access the relevant
support number at
www.sonymobile.com
by clicking
the Contact us link at the bottom of the page.
Learn more
Learn more about how we can support you with
Xperia® Care at
www.sonymobile.com/support
.
Additional support
For more information and additional support, please
visit
www.t-mobile.com/support
where you can:
•Register for
my.t-mobile.com
to check your minutes,
pay your bill, upgrade your device, and change your
rate plan. Review your device’s User Manual and
troubleshooting FAQs.
•View the latest troubleshooting solutions in the
Support Forums or ask a question of your own.
If you are a new T-Mobile customer and your service
has not yet been activated, call Customer Care at
1-800-937-8997 and a T-Mobile Activation
representative will assist you.
You can also access account and device information
from your device.
1From your Home screen, tap
2Find and tap T-Mobile My Account
Learn more about your device
You can visit the following sites to learn more about
your device:
•Help for Setting Up Your New Android Device:
http://
support.t-mobile.com/docs/DOC-2501
.
•Help for Your Device:
http://support.t-mobile.com/
community/phones_data_devices/android
.
Accessories
Whether you want a charger, a fashionable carrying
case, a Bluetooth® headset, or you just want to browse
for fun extras, T-Mobile is the place to shop for all your
phone accessories.
To purchase accessories for your phone, visit T-
Mobile.com, call 1.800.204.2449, or visit your nearest
T-Mobile store.
Accessory selection subject to change and may vary
by location.
www.sonymobile.com

Navigation menu
