Important information
Sony Consumer Web site
At
www.sonymobile.com/support
there is a support section
where help and tips are only a few clicks away. Here you
will find the latest computer software updates and tips on
how to use your product more efficiently.
Service and support
You have access to a portfolio of exclusive service
advantages such as:
•Global and local Web sites providing support.
•A global network of Contact Centers.
•An extensive network of Sony service partners.
•A warranty period. Learn more about the warranty
conditions in the
Limited Warranty
section.
At
www.sonymobile.com/support
or
www.sonymobile.com/contact
, you can find the latest
support tools and information. For operator-specific
services and features, please contact your network
operator.
You can also contact our Contact Centers or contact your
local dealer. (Calls are charged according to national rates,
including local taxes, unless it is a toll-free number.)
If your product needs service, please contact the dealer
from whom it was purchased, or one of our service
partners. To make a claim under the limited warranty, proof
of purchase is required.
Guidelines for Safe and Efficient Use
Please follow these guidelines. Failure to do so might
entail a potential health risk or product malfunction. If
in doubt as to its proper function, have the product
checked by a certified service partner before charging or
using it.
2
Recommendations for care and safe use of our
products
•Handle with care and keep in a clean and dust-free place.
•Warning! May explode if disposed of in fire.
•Do not use in environments where relevant IP rating
limitations, if applicable, are exceeded (including excess
depths and/or pressures of liquid and/or dust) or expose
to excess humidity.
•For optimum performance, the product should not
be operated in temperatures below -10°C(+14°F) or
above +45°C(+113°F). Do not expose the battery to
temperatures above +60°C(+140°F).
•Do not expose to flames or lit tobacco products.
•Do not drop, throw or try to bend the product.
•Do not paint or attempt to disassemble or modify
the product. Only Sony authorised personnel
should perform service.
•Consult with authorised medical staff and the instructions
of the medical device manufacturer before using the
product near pacemakers or other medical devices or
equipment.
•Discontinue use of electronic devices, or disable the radio
transmitting functionality of the device, where required or
requested to do so.
•Do not use where a potentially explosive atmosphere
exists.
•Do not place the product, or install wireless equipment, in
the area above an air bag in a car.
•Caution: Cracked or broken displays may create sharp
edges or splinters that could be harmful upon contact.
•Do not use a Bluetooth Headset in positions where it is
uncomfortable or will be subject to pressure.
3
Children
Warning! Keep out of the reach of children. Do not
allow children to play with mobile devices or accessories.
They could hurt themselves or others. Products may
contain small parts that could become detached and create
a choking hazard.
Power supply (Charger)
Connect the charger to power sources as marked on the
product. Do not use outdoors or in damp areas. Do not
alter or subject the cord to damage or stress. Unplug the
unit before cleaning it. Never alter the plug. If it does not fit
into the outlet, have a proper outlet installed by an
electrician. When a power supply is connected there is a
small drain of power. To avoid this small energy waste,
disconnect the power supply when the product is fully
charged. Use of charging devices that are not Sony
branded may pose increased safety risks.
Battery
New or idle batteries can have short-term reduced
capacity. Fully charge the battery before initial use. Use for
the intended purpose only. Charge the battery in
temperatures between +5°C(+41°F) and +45°C(+113°F). Do
not put the battery into your mouth. Do not let the battery
contacts touch another metal object. Turn off the product
before removing the battery. Performance depends on
temperatures, signal strength, usage patterns, features
selected and voice or data transmissions. Only Sony
service partners should remove or replace built-in batteries.
Use of batteries that are not Sony branded may pose
increased safety risks. Replace the battery only with
another Sony battery that has been qualified with the
product per the standard IEEE-1725. Use of an unqualified
4
battery may present a risk of fire, explosion, leakage or
other hazard.
Personal medical devices
Mobile devices / devices with radio transmitters may affect
implanted medical equipment. Reduce risk of interference
by keeping a minimum distance of 15 cm(6 inches)
between the Sony product and the medical device. Use the
Sony device at your right ear, when applicable. Do not carry
the device in your breast pocket. Turn off the device if you
suspect interference. For use in proximity to personal
medical devices, please consult a physician and the device
manufacturer.
Driving
In some cases, vehicle manufacturers may forbid the use of
mobile devices in their vehicles unless a handsfree kit with
an external antenna supports the installation. Check with
the vehicle manufacturer's representative to be sure that a
mobile device or Bluetooth handsfree will not affect the
electronic systems in the vehicle. Full attention should be
given to driving at all times and local laws and regulations
restricting the use of wireless devices while driving must be
observed.
GPS/Location based functions
Some products provide GPS/Location based functions.
Location determining functionality is provided “As is” and
“With all faults”. Sony does not make any representation or
warranty as to the accuracy of such location information.
Use of location-based information by the device may not
be uninterrupted or error free and may additionally be
dependent on network service availability. Please note that
functionality may be reduced or prevented in certain
5
environments such as building interiors or areas adjacent to
buildings.
Caution: Do not use GPS functionality in a manner which
causes distraction from driving.
Emergency calls
Calls cannot be guaranteed under all conditions. Never rely
solely upon Sony mobile devices for essential
communication. Calls may not be possible in all areas, on
all networks, or when certain network services and/or
mobile device features are used. Please note that some
Sony devices are not capable of supporting voice calls,
including emergency calls.
Antenna
Use of antenna devices not marketed by Sony could
damage the mobile device, reduce performance, and
produce Specific Absorption Rate (SAR) levels above the
established limits. Do not cover the antenna with your hand
as this affects call quality, power levels and can shorten
talk and standby times.
Radio Frequency (RF) exposure and Specific
Absorption Rate (SAR)
When the mobile device or Bluetooth handsfree
functionality is turned on, it emits low levels of radio
frequency energy. International safety guidelines have been
developed through periodic and thorough evaluation of
scientific studies. These guidelines establish permitted
levels of radio wave exposure. The guidelines include a
safety margin designed to assure the safety of all persons
and to account for any variations in measurements.
Specific Absorption Rate (SAR) is used to measure radio
frequency energy absorbed by the body when using a
6
mobile device. The SAR value is determined at the highest
certified power level in laboratory conditions, but because
the device is designed to use the minimum power
necessary to access the chosen network, the actual SAR
level can be well below this value. There is no proof of
difference in safety based on difference in SAR value.
Products with radio transmitters sold in the US must be
certified by the Federal Communications Commission
(FCC). When required, tests are performed when the device
is placed at the ear and when worn on the body. For body-
worn operation, the device has been tested when
positioned a minimum of 15 mm from the body without any
metal parts in the vicinity of the device or when properly
used with an appropriate Sony accessory and worn on the
body. When operating with “Hotspot” functionality
engaged, a separation distance of 10 mm was used.
For more information about SAR and radio frequency
exposure, go to:
http://blogs.sonymobile.com/about-us/
sustainability/health-and-safety/sar/
.
Flight mode
Bluetooth and Wireless Local Area Network (WLAN)
functionality, if available in the device, can be enabled in
Flight mode but may be prohibited onboard aircraft or in
other areas where radio transmissions are prohibited. In
such environments, please seek proper authorisation
before enabling Bluetooth or WLAN functionality even in
Flight mode.
Malware
Malware (short for malicious software) is software that can
harm device. Malware or harmful applications can include
viruses, worms, spyware, and other unwanted programs.
While the device does employ security measures to resist
7
such efforts, Sony does not warrant or represent that the
device will be impervious to the introduction of malware.
You can however reduce the risk of malware attacks by
using care when downloading content or accepting
applications, refraining from opening or responding to
messages from unknown sources, using trustworthy
services to access the Internet, and only downloading
content to the mobile device from known, reliable sources.
Accessories
Use only Sony branded original accessories and certified
service partners. Sony does not test third-party
accessories. Accessories may influence RF exposure, radio
performance, loudness, electric safety and other areas.
Third-party accessories and parts may pose a risk to your
health or safety or decrease performance.
Accessible Solutions/Special Needs
In the US, compatible Sony Mobile devices may offer
compatibility with TTY terminals (with use of necessary
accessory). For more information call the Sony Special
Needs Center on 877 878 1996 (TTY) or 877 207 2056
(voice), or go to
http://blogs.sonymobile.com/about-us/
sustainability/accessibility/overview/
.
Disposal of old electrical and electronic equipment
and battery
This symbol on the electronic product or on its packaging
indicates that the electronic product (including the battery)
should not be treated as household waste. Instead it should
be handed over to the appropriate collection point for the
recycling of electrical and electronic equipment. Do not
attempt to remove internal batteries. Internal batteries shall
India Only
8
be removed only by a waste treatment facility or trained
service professional.
By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the
environment and human health, which could otherwise be
caused by inappropriate waste handling of this product.
The recycling of materials will help to conserve natural
resources. For more detailed information about recycling of
this product, please contact your local city office, your
household waste disposal service or the shop where you
purchased the product, by calling a Sony Contact Center or
at
www.sonymobile.com/recycling
.
Memory card
If the product comes complete with a removable memory
card, it is generally compatible with the handset purchased
but may not be compatible with other devices or the
capabilities of their memory cards. Check other devices for
compatibility before purchase or use. If the product is
equipped with a memory card reader, check memory card
compatibility before purchase or use.
Memory cards are generally formatted prior to shipping. To
reformat the memory card, use a compatible device. Do not
use the standard operating system format when formatting
the memory card on a PC. For details, refer to the operating
instructions of the device or Sony contact center.
SIM card
If your device is equipped with a standard-sized SIM card
slot, inserting an incompatible SIM card (for example, a
micro SIM card, a micro SIM card with a non-Sony adapter,
or a standard SIM card cut into a micro SIM card size) in
the SIM card slot may damage your SIM card or your
device permanently. Sony does not warrant and will not be
9
responsible for any damage caused by use of incompatible
or modified SIM cards.
Warning!
If the device requires an adapter for insertion into the
handset or another device, do not insert the card directly
without the required adapter.
Precautions on memory card use
•Do not expose the memory card to moisture.
•Do not touch terminal connections with your hand or any
metal object.
•Do not strike, bend, or drop the memory card.
•Do not attempt to disassemble or modify the memory
card.
•Do not use or store the memory card in humid or
corrosive locations or in excessive heat such as a closed
car in summer, in direct sunlight or near a heater, etc.
•Do not press or bend the end of the memory card adapter
with excessive force.
•Do not let dirt, dust, or foreign objects get into the insert
port of any memory card adapter.
•Check you have inserted the memory card correctly.
•Insert the memory card as far as it will go into any
memory card adapter needed. The memory card may not
operate properly unless fully inserted.
•We recommend that you make a backup copy of
important data. We are not responsible for any loss or
damage to content you store on the memory card.
•Recorded data may be damaged or lost when you remove
the memory card or memory card adapter, turn off the
power while formatting, reading or writing data, or use the
memory card in locations subject to static electricity or
high electrical field emissions.
10
Protection of personal information
Erase personal data before disposing of the product. To
delete data, perform a master reset. Deleting data from the
memory of the device does not ensure that it cannot be
recovered. Sony does not warrant against recovery of
information and does not assume responsibility for
disclosure of any information even after a master reset.
For Devices Supporting 3D Viewing capabilities
In viewing 3D images shot with this device, if applicable, on
a 3D-compatible monitor, you may experience discomfort
in the form of eye strain, fatigue, or nausea. To prevent
these symptoms, we recommend that you take regular
breaks. However, you need to determine for yourself the
length and frequency of breaks you require, as they vary
according to the individual. If you experience any type of
discomfort, stop viewing the 3D images until you feel
better, and consult a physician as necessary. Also refer to
the operating instructions supplied with the device or
software you have connected or are using with this device.
Note that a child’s eyesight is still at the development stage
(particularly children below the age of 6). Consult a
pediatrician or ophthalmologist before letting your child
view 3D images, and make sure he/she observes the above
precautions when viewing such images.
Loudness warning!
Avoid volume levels that may be harmful to your hearing.
End User Licence Agreement
Software delivered with this device and its media is owned
by Sony Mobile Communications AB, and/or its affiliated
companies and its suppliers and licensors.
11
Sony grants you a non-exclusive limited licence to use the
Software solely in conjunction with the Device on which it is
installed or delivered. Ownership of the Software is not
sold, transferred or otherwise conveyed.
Do not use any means to discover the source code or any
component of the Software, reproduce and distribute the
Software, or modify the Software. You are entitled to
transfer rights and obligations to the Software to a third
party, solely together with the Device with which you
received the Software, provided the third party agrees in
writing to be bound by the terms of this Licence.
This licence exists throughout the useful life of this
Device. It can be terminated by transferring your rights to
the Device to a third party in writing.
Failure to comply with any of these terms and conditions
will terminate the licence immediately.
Sony and its third party suppliers and licensors retain all
rights, title and interest in and to the Software. To the
extent that the Software contains material or code of a third
party, such third parties shall be beneficiaries of these
terms.
This licence is governed by the laws of Sweden. When
applicable, the foregoing applies to statutory consumer
rights.
In the event Software accompanying or provided in
conjunction with your device is provided with additional
terms and conditions, such provisions shall also govern
your possession and usage of the Software.
Export regulations
Export regulations: The device or software may be subject
to import and export regulations of the European Union, the
United States and other countries. You will comply with
these applicable laws and regulations and will obtain and
12
maintain any export and import license required for the
delivery of goods to you under this Agreement. Without
limiting the foregoing, and as an example, you will not
knowingly export or re-export goods to destinations
identified pursuant to Articles in Chapter II of European
Council Regulation (EC) 428/2009 and specifically, and
without limitation, you will also comply with U.S.
government Export Administration Regulations (“EAR”, 15
C.F.R. §§ 730-774, http://www.bis.doc.gov/) administered
by Department of Commerce, Bureau of Industry and
Security and economic sanctions regulations (30 C.F.R. §§
500 et. seq., http://www.treas.gov/offices/enforcement/
ofac/) administered by the U.S. Department of Treasury,
Office of Foreign Assets Control.
Limited Warranty
Sony Mobile Communications AB, SE-221 88 Lund,
Sweden, or its local affiliated company, provides this
Limited Warranty for your mobile device, original accessory
delivered with your mobile device, and/or your mobile
computing product (hereinafter referred to as “Product”).
Should your Product need warranty service, please return it
to the dealer from whom it was purchased, or contact your
local Sony Contact Center (national rates may apply) or visit
www.sonymobile.com
to get further information.
Our warranty
Subject to the conditions of this Limited Warranty, Sony
warrants this Product to be free from defects in design,
material and workmanship at the time of its original
purchase by a consumer. This Limited Warranty will last for
a period of one (1) year as from the original date of
purchase of the Product.
13
What we will do
If, during the warranty period, this Product fails to operate
under normal use and service, due to defects in design,
materials or workmanship, Sony authorised distributors or
service partners, in the country/region* where you
purchased the Product, will, at their option, either repair,
replace or refund the purchase price of the Product in
accordance with the terms and conditions stipulated
herein.
Sony and its service partners reserve the right to charge a
handling fee if a returned Product is found not to be under
warranty according to the conditions below.
Please note that some of your personal settings,
downloads and other information may be lost when your
Sony Product is repaired or replaced. At present, Sony may
be prevented by applicable law, other regulation or
technical restrictions from making a backup copy of certain
downloads. Sony does not take any responsibility for any
lost information of any kind and will not reimburse you for
any such loss. You should always make backup copies of
all the information stored on your Sony Product such as
downloads, calendar and contacts before handing in your
Sony Product for repair or replacement.
Conditions
1. This Limited Warranty is valid only if the original proof of
purchase for this Product issued by a Sony authorised
dealer specifying the date of purchase and serial
number**, is presented with the Product to be repaired or
replaced. Sony reserves the right to refuse warranty
service if this information has been removed or changed
after the original purchase of the Product from the dealer.
2. If Sony repairs or replaces the Product, the repair for the
defect concerned, or the replaced Product shall be
14
warranted for the remaining time of the original warranty
period or for ninety (90) days from the date of repair,
whichever is longer. Repair or replacement may involve
the use of functionally equivalent reconditioned units.
Replaced parts or components will become the property
of Sony.
3. This warranty does not cover any failure of the Product
that is due to:
•Normal wear and tear.
•Use in environments where relevant IP rating limitations,
if applicable, are exceeded (including liquid damage or
the detection of liquid inside the device resulting from
such use).
•Misuse or failure to use in accordance with the Sony
instructions for use and maintenance of the Product.
Nor does this warranty cover any failure of the Product
due to accident, software or hardware modification or
adjustment, or acts of God.
A rechargeable battery can be charged and discharged
more than a hundred times. However, it will eventually
wear out – this is not a defect and corresponds to normal
wear and tear. When the talk-time or standby time is
noticeably shorter, it is time to replace the battery. Sony
recommends that you use only batteries and chargers
approved by Sony.
Minor variations in display brightness and colour may
occur between devices. There may be tiny bright or dark
dots on the display. It occurs when individual dots have
malfunctioned and can not be adjusted. Two defective
pixels are deemed acceptable.
Minor variations in camera image appearance may
occur between devices. This is nothing uncommon and is
not regarded as a defective camera module.
15
4. Since the cellular system on which the Product is to
operate is provided by a carrier independent from Sony,
Sony will not be responsible for the operation, availability,
coverage, services or range of that system.
5. This warranty does not cover Product failures caused by
installations, modifications, or repair or opening of the
Product performed by a non-Sony authorised person.
6. The warranty does not cover Product failures which have
been caused by use of accessories or other peripheral
devices which are not Sony branded original accessories
intended for use with the Product.
Sony disclaims any and all warranties, whether express or
implied, for failures caused to the Product or peripheral
devices as a result of viruses, trojan horses, spyware, or
other malicious software. Sony strongly recommends that
you install appropriate virus protection software on your
Product and any peripheral devices connected to it, as
available, and update it regularly, to better protect your
device. It is understood, however, that such software will
never fully protect your Product or its peripheral devices
and Sony disclaims all warranties, whether express or
implied, in case of failure by such antivirus software to
fulfil its intended purpose.
7. Tampering with any of the seals on the Product will void
the warranty.
8. THERE ARE NO EXPRESS WARRANTIES, WHETHER
WRITTEN OR ORAL, OTHER THAN THIS LIMITED
WARRANTY. ALL IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL SONY OR
ITS LICENSORS BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY NATURE
16
WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOST
PROFITS OR COMMERCIAL LOSS TO THE FULL
EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY
LAW.
Some countries/states do not allow the exclusion or
limitation of incidental or consequential damages, or
limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to you.
The warranty provided does not affect the consumer’s
statutory rights under applicable legislation in force, nor the
consumer’s rights against the dealer arising from their
sales / purchase contract.
Country specific terms
If you have purchased your Product in a country member of
the European Economic Area (EEA) or in Switzerland or the
Republic of Turkey, and such Product was intended for sale
in the EEA or in Switzerland or in Turkey, you can have your
Product serviced in any EEA country or in Switzerland or in
Turkey, under the warranty conditions prevailing in the
country in which you require servicing, provided that an
identical Product is sold in such country by an authorised
Sony distributor. To find out if your Product is sold in the
country you are in, please call the local Sony Contact
Center. Please observe that certain services may not be
available outside the country of original purchase, for
example, due to the fact that your Product may have an
interior or exterior which is different from equivalent models
sold in other countries. Please note in addition that it may
sometimes not be possible to repair SIM-locked Products.
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. If you purchased your
product in Australia, you are entitled to a replacement or
refund for a major failure and compensation for any other
17
reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not
amount to a major failure. For warranty service in Australia,
please contact 1300 650 050 or Sony Service Centre, 189
Woodville Road Villawood NSW 2163.
** In some countries/regions additional information (such
as a valid warranty card) may be requested.
Trademarks, acknowledgements and copyright
©2014 Sony Mobile Communications AB and its affiliated
entities. All rights reserved.
Xperia is a trademark or registered trademark of Sony
Mobile Communications AB.
Sony is a trademark or a registered trademark of Sony
Corporation.
Bluetooth is a trademark or a registered trademark of
Bluetooth SIG Inc. and any use of such mark by Sony is
under license.
All product and company names mentioned herein are the
trademarks or registered trademarks of their respective
owners.
Any rights not expressly granted herein are reserved. Visit
www.sonymobile.com
for more information.
18
www.sonymobile.com
Sony Mobile Communications AB
221 88 Lund, Sweden
1222-9266.11

Navigation menu
