User manual
Startup guide
SmartWatch 2
SW2
Sony Mobile Communications AB
SE-221 88 Lund, Sweden
www.sonymobile.com
XXXX-XXXX.1
Basics
Charging
Before using your SmartWatch 2 for the first time, you
need to charge it for approximately 30 minutes. Sony
chargers/USB cables are recommended.
To charge your SmartWatch 2
1Plug one end of the USB cable into the charger or into
the USB port of a computer.
2Plug the other end of the cable into the Micro USB port
of your SmartWatch 2.
A charger may not be included at purchase in all
markets.
Overview
1
7
8
2
3
6
4
5
1. Light sensor
2. Power key
3. Actions key
4. Home key
5. Back key
6. Touchscreen
7. NFC detection area
8. Port for charger/USB cable
Turning on and off
To turn on your SmartWatch 2
•Press and hold down the power key until the
display turns on.
To turn off your SmartWatch 2
•When the display is active, press and hold down the
power key until the display turns off.
Setting up your
SmartWatch 2
The quickest way to get started with your SmartWatch 2 is
by connecting it to your device using NFC. If your device
does not support NFC, you can connect manually.
Setting up using NFC
To save data costs, make sure that your device is
connected to a Wi-Fi® network.
1Device: Make sure that the NFC function is turned on
and that the screen is active and unlocked.
2SmartWatch 2: Turn on your SmartWatch 2.
3If the Smart Connect application is not pre-installed on
your device, place the device over the back of your
SmartWatch 2 so that the NFC detection area of each
device touches each other. Then follow the instructions
that appear on the device's screen to install the Smart
Connect application from Google Play™.
4One-touch pair and connect by placing the device over
the back of your SmartWatch 2 so that the NFC
detection area of each device touches each other.
5Device: Accept the pairing request from SmartWatch 2.
6Device: Follow the instructions to install the SmartWatch
2 application from Google Play™. Then SmartWatch 2
restarts automatically to finish setting up.
Setting up manually
If your device does not support NFC, you can connect
manually using Bluetooth® function.
To set up using the Bluetooth® function
To save data costs, make sure that your device is
connected to a Wi-Fi® network.
1Device: Make sure that you have the Smart Connect
application, which is available on Google Play™,
installed on your device.
2Device: Make sure that the Bluetooth® function is
turned on.
3SmartWatch 2: Turn on your SmartWatch 2.
4Device: Scan for Bluetooth® devices, then select
SmartWatch 2 in the list of available devices.
5Device: Accept the pairing request from SmartWatch
2.
6Device: Follow the instructions to install the
SmartWatch 2 application from Google Play™.
SmartWatch 2 restarts automatically when the
application is installed.
Getting to know your
SmartWatch 2
You can use your SmartWatch 2 as a regular watch and
access most applications when it is not connected to a
device. When it is connected, you get a richer set of
functions.
Installing extra applications
Install extra applications via the Smart Connect application
on the Android™ device to optimise the functionality of
your SmartWatch 2.
To install an extra application
1SmartWatch 2: Find and tap the App recommender icon
.
2SmartWatch 2: Select an application in the list of
recommended applications, then tap View & install.
3Device: When Google Play™ opens, tap install.
4Device: Follow the instructions that appear on the
screen to install the application that you selected. An
icon of the application shows on the screen of
SmartWatch 2 after the installation is completed.
Support on the web
Visit www.sonymobile.com/support to get the most from
your accessory, including Troubleshooting and a User
guide for your SmartWatch 2.
Sony SW2
Prior to use, please read the Important information leaflet
separately provided.
This User guide is published by Sony Mobile Communications AB or its local
affiliated company, without any warranty. Improvements and changes to this User
guide necessitated by typographical errors, inaccuracies of current information, or
improvements to programs and/or equipment, may be made by Sony Mobile
Communications AB at any time and without notice. Such changes will, however,
be incorporated into new editions of this User guide.
All rights reserved.
©Sony Mobile Communications AB, 2013
Publication number: XXXX-XXXX.1
Interoperability and compatibility among Bluetooth® devices varies. Device
generally supports products utilizing Bluetooth spec. 1.2 or higher, and Headset or
Handsfree profile.
Sony is the trademark or registered trademark of Sony Corporation. Bluetooth is
the trademark of the Bluetooth (SIG) Inc. and is used under license. All other
marks are the property of their respective owners. All rights reserved.
All product and company names mentioned herein are the trademarks or
registered trademarks of their respective owners. Any rights not expressly granted
herein are reserved. All other trademarks are property of their respective owners.
Visit www.sonymobile.com for more information.
All illustrations are for illustration only and may not accurately depict the actual
accessory.
Declaration of Conformity for
SW2
We, Sony Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our product
Sony type RD-0050
and in combination with our accessories, to which this
declaration relates is in conformity with the appropriate
standards EN 300 328:V1.7.1, EN 301 489-17:V2.1.1, EN
301 489-3:V1.4.1 and EN 60 950-1:2006
+A11:2009+A1:2010 following the provisions of, Radio
Equipment and Telecommunication Terminal Equipment
directive 1999/5/EC.
Lund, July 2013
Anders Grynge
Director, Head of Global Type Approval
We fulfil the requirements of the R&TTE Directive (1999/5/
EC).
FCC Statement
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Any change or modification not expressly approved by Sony may void the user's
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Statement
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
Avis d’industrie Canada
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne
doit pas produire de brouillage, et, and (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
