Contents

Startup Guide

Startup guide
Xperia™ Tablet Z
SGP511/SGP512
Sony Mobile Communications AB
SE-221 88 Lund, Sweden
www.sonymobile.com
Welcome
Important Information
Before you use your device, please read the
Important
Information
provided in your device regarding warranty,
safety and handling information.
Protecting your device from
water and dust
Your device has IP (Ingress Protection) ratings of IP55 and
IP58. These ratings mean that your device is dust resistant
and is protected against low pressure water stream as well
as against the effects of submersion for 30 minutes in
fresh (non-saline) water up to 1.5 metres deep.
Always firmly attach all covers to ensure the water and
dust resistance of the device. If liquid is detected inside
the device, for example, underneath one of the covers,
your warranty will be void.
Before using your device in water and in dusty conditions,
refer to the relevant section of the User guide for your
device for more detailed information. An online User guide
as well as a downloadable version is available at
www.sonymobile.com/support
.
Assembly
To insert a memory card
1
2
Overview
54
7
6
1 2 3
00440245-162947-5
Model:SGPXXX TYPE:XX-XXXX-XX FCC ID:XXXXX-XXXX IC:XXXXX-XXXXXX 13W41 EFF MADE IN CHINA
8 9 10 11
12
13
1415
1. Front camera
2. Light sensor
3. Charging light/
Notification light
4. Speaker A
5. Speaker B
6. Volume key
7. Power key
8. Microphone
9. Infrared sensor
10. Charger/USB port cover
11. Memory card slot cover
12. Main camera
13. NFC™ detection area
14. Headset jack
15. Charging dock connector
Turning on the device
If it is the first time you turn on your device, make sure
that the battery is charged for at least 30 minutes
before you turn on the device for the first time.
To turn on the device
1Press and hold down the power key until the
device vibrates.
2Wait a while for the device to start.
Waking up the screen
To activate the screen
•Briefly press the power key .
•If Tap to wake up mode is enabled, double-tap the
screen.
To enable Tap to wake up mode, go to the Home
screen, then tap > Settings > Display > Tap to
wake up.
To unlock the screen
•Place a finger on the right part of the screen and
swipe in any direction.
Basic settings
The first time you start your device, a setup guide
explains basic device functions and helps you enter
essential settings. You can also access the setup guide
later.
To access the setup guide manually
1From the Home screen, tap .
2Tap Settings > Setup guide.
Finding your way
Using the keys
Back
•Go back to the previous screen
•Close the on-screen keypad, a dialog box, an
options menu, the Notification panel, or an
application
Home
•Go to the Home screen
Task
•Tap to open a window showing your most
recently used applications and a small apps bar
Home screen
You can customise your Home screen with widgets,
shortcuts, folders, themes, wallpaper and other items. You
can also add more panes to it. You can view content in
other panes of the Home screen by flicking left or right.
The items in the bar at the top of the screen are
always available for quick access.
To go to the Home screen
•Press .
To browse the Home screen
•Flick right or left.
To add a widget to the Home screen
1Touch and hold an empty area on your Home screen
until the device vibrates, then tap Widgets.
2Find and tap the widget that you want to add.
Application screen
The Application screen, which you open from your Home
screen, contains the applications that come pre-installed
on your device as well as the applications you download.
The Application screen extends beyond the regular screen
width, so you need to flick left and right to view all content.
To open the Application screen
•From your Home screen, tap .
Status and notifications
The status bar at the top of your screen shows what's
going on in your device. For example, calendar
notifications appear here.
To open the Notification panel
•Drag the left side of the status bar downwards.
Setting up your device
Accessing settings
View and change settings for your device from the Settings
menu. The Settings menu is accessible from both the
Notification panel and the Application screen.
To access your device settings
1From your Home screen, tap .
2Find and tap Settings.
Connecting to wireless
networks
You can access the Internet wirelessly from your device
using Wi-Fi® technology. This way you can browse the
web and share media files over the same Wi-Fi® network
with other DLNA Certified™ devices, for example, TVs and
computers.
If your company or organisation has a virtual private
network (VPN), you can connect to this network using your
device. You can use a VPN to access intranets and other
internal services at your company.
To turn on Wi-Fi®
1From your Home screen, tap .
2Find and tap Settings.
3Drag the slider beside Wi-Fi to the right to turn on the
Wi-Fi® function.
It may take a few seconds before Wi-Fi® is enabled.
To connect to a Wi-Fi® network automatically
1From your Home screen, tap .
2Find and tap Settings.
3Tap Wi-Fi. All available Wi-Fi® networks are displayed.
4Tap a Wi-Fi® network to connect to it. For secured
networks, enter the relevant password. is displayed
in the status bar once you are connected.
Tap and then tap Scan to search for new available
networks.
Google™ account
With a Google™ account, you can use Gmail™ to send
emails, Hangouts™ to chat with friends, and Google
Play™ to download applications and games, music,
movies and books.
To set up a Google™ account on your device
1From your Home screen, tap .
2Find and tap Settings > Add account > Google.
3Follow the registration wizard to create a Google™
account, or sign in if you already have an account.
You can also sign in to or create a Google™ account
from the setup guide the first time you start your
device. Or you can go online and create an account at
www.google.com/accounts
.
Downloading from Google
Play™
You can download all kinds of applications from
Google Play™, including free applications.
To open Google Play™
1From the Home screen, tap .
2Find and tap Play Store .
To download a free application
1In Google Play™, find an item you wish to download
by browsing categories, or by using the search
function.
2Tap the item to view its details, and follow the
instructions to complete the installation.
About Email
You can handle several email accounts at the same
time using the Email application, including corporate
Microsoft Exchange Active Sync accounts. Emails you
receive to your Gmail™ account can be accessed on
your device from both the Email and the Gmail™
applications.
To set up an email account
1From your Home screen, tap .
2Find and tap Email.
3Follow the instructions that appear on the screen to
complete the setup.
For some email services, you may need to contact
your email service provider for information on
detailed settings for the email account.
Troubleshooting
My device is not responding
If your device hangs, or if you cannot restart it normally,
you can force the device to shut down.
To force the device to shut down
1Press and hold down both the volume up key and the
power key for 10 seconds.
2After your device vibrates three times, release the keys.
The device turns off automatically.
Legal information
To view the CE mark
SonySGP511/SGP512
Google Play™ is not available in all countries. Some of the services and features
described in this Startup guide are not supported in all countries/regions or by all
networks and/or service providers in all areas. Without limitation, this applies to
the GSM International Emergency Number 112. Please contact your network
operator or service provider to determine availability of any specific service or
feature and whether additional access or usage fees apply.
This Startup guide is published by Sony Mobile Communications AB or its local
affiliated company, without any warranty. Improvements and changes to this
Startup guide necessitated by typographical errors, inaccuracies of current
information, or improvements to programs and/or equipment, may be made by
Sony Mobile Communications AB at any time and without notice. Such changes
will, however, be incorporated into new editions of this Startup guide.
© 2013 Sony Mobile Communications AB. All rights reserved.
Your device has the capability to download, store and forward additional content,
e.g. ringtones. The use of such content may be restricted or prohibited by rights of
third parties, including but not limited to restriction under applicable copyright
laws. You, and not Sony, are entirely responsible for additional content that you
download to or forward from your device. Prior to your use of any additional
content, please verify that your intended use is properly licensed or is otherwise
authorized. Sony does not guarantee the accuracy, integrity or quality of any
additional content or any other third party content. Under no circumstances will
Sony be liable in any way for your improper use of additional content or other third
party content.
This Startup guide may reference services or applications provided by third
parties. Use of such programming or services may require separate registration
with the third party provider and may be subject to additional terms of use. For
applications accessed on or through a third-party website, please review such
websites’ terms of use and applicable privacy policy in advance. Sony does not
warrant or guarantee the availability or performance of any third-party websites or
offered services.
See regulatory information such as the CE mark in the label tray of the device.
All product and company names mentioned herein are the trademarks or
registered trademarks of their respective owners. Any rights not expressly granted
herein are reserved. All other trademarks are property of their respective owners.
Visit
www.sonymobile.com
for more information.
All illustrations are for illustration only and may not accurately depict the actual
device.
This product is protected by certain intellectual property rights of Microsoft. Use
or distribution of such technology outside of this product is prohibited without a
license from Microsoft.
Product compliance: This product has been manufactured by or on behalf of Sony
Mobile Communications, Mobilvägen, SE-221 88 Lund, Sweden. Inquiries related
to product compliance based on national legislation shall be addressed to Sony
Mobile Quality Officer, Sony Mobile Communications AB, Mobilvägen, SE-221 88
Lund, Sweden. For any service or guarantee matters, please refer to the contact
details provided in the separate service or guarantee documents.
Our support to you –
Xperia™ Care
User guide
A User guide for your device is available at
www.sonymobile.com/support
.
Support in your device
Get user support directly in your device using the Help
application.
To access the Support application
1From your Home screen, tap .
2Find and tap .
Support on the web
Visit
www.sonymobile.com/support
to access a range of
support and get the most from your device.
Customer support
Customer support – if all else fails. Access the relevant
support number at
www.sonymobile.com
by clicking the
Contact us link at the bottom of the page.
Learn more
Learn more about how we can support you with Xperia™
Care at
www.sonymobile.com/support
.
www.sonymobile.com

Navigation menu
