SoundMAGIC Technology Development ES20BTBLACK ES20BT User Manual
Shenzhen SoundMAGIC Technology Development Co.,LTD ES20BT Users Manual
User Manual
ES
20
BT
①
②
③
④
⑤
⑥
When listening indoors, we recommend using the
ear tips for normal listening, providing quiet listening
to high quality music.
Double Flange Silicone Ear Tips
The provided double-flange silicone ear tips provide even better seal for your ears.
Silicone Ear Tips for Normal Listening
The included ear tips for normal listening
provide noise isolation
Environmental
Sound
Ear
Canal
13.5
ES20BT
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
NOTE:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
1.Reorient or relocate the receiving antenna.
2.Increase the separation between the equipment and receiver.
3.Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4.Consult the dealer or an experienced radio/TV technician for
help.
RF warning statement:
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure
condition without restriction.
1. Startup
Press"Multifunction” for 3 second ,when the lights on ,the device strats up.
2. Shutdown
Press “Multifunction” for 3 second after stratup ,when the lights is off ,the
device shut down(It can’t be done on talking).
3. Pairing
a) the device will turn into pairing status automatically after startup.
b) the blue and red light will twinkle alternately in pairing status.
c) use your phone’s bluetooth to search this device ,you can find
the device named”ES20BT” on your screen ,clink it to finish
pairing ( Input “0000” if it’s necessary as a password).
4. Enjoy music
a) press “Multifunction” to stop music,press it again to resume music.
b) press “V+” twice fast to skip to next stack; hold it will speed up.
c) press “V-”twice fast to skip to prevstack;hold it will go backward.
5. Voice assistant
Press“multifunction” twice fast will start up your phone’s voice assistant
(like Siri)
6.Call
a)Press multifunction to answer the phone ,press it again to end the call
b) Press “multifunction”to answer the third call and hold on the second call at
the same time .
c) Press and hold multifunction for 3 second will end the third call and
resume the second call
8. Volume adjustion
a) Press the “V + ”to increase the volume
b) Press the “V–” to reduce the volume
9. Power-saving mode
This device will shut down automatically if it’s not connected in 5 minutes
10. Charging
The ES20BT uses a lithium-ion polymer battery. Please make it’s power
empty before first charging
a) Please use a computer or USB charge with 5.0V+0.2V output
voltage to charge the device along with the provided USB cable
b) Chargeing time is approximately 2.5 hours
c) The red light will stay on once the device is fully charged
11. Battery warnings
When battery power is less than 10%,the red light will twinkle twice every
5 second. Warning of low-power will be sended to you 3~5 miniate before
the device shut down automatically. The device can be charged anytime.
If the battery is empty,please charge the device as soon as
possible in order to maintain proper battery life
Ear Tip Selection
Your E20BT earphone comes with ear tips in a variety of sizes. Please
choose the right size (pick the size that is most comfortable for you).
Silicone Ear Tips for Sports/Workout
Environmental
Sound
Ear
Canal
The included ear tips for sports/workout features
a continuous groove,
wearing these ear tips
will
not block external sound
For outdoor activities, such as running and cycling,we recommend
using these ear tips, so that you can enjoy music while also be
aware of your surrounding environment, and ensure safety.
IV.Connect with computer ES20BT
Headset connect with computer
Notebook and PC with Bluetooth feature following the setting for Bluetooth headset
Searching and pairing connection
For computer do not integrate with Bluetooth feature，have to use an external Bluetooth
USB Dongle device and install driver for Bluetooth connection
107±2dB@1KHz
Class 2
20 mA
5.5~6h
4~5h
200h
20 Hz~20K Hz
~
Black/Red
2.402~2.480 Ghz
16±10%
ES20BT
User Manual
BLUETOOTH HEADSET
ES20BT
User Manual
BLUETOOTH HEADSET
ES20BT Bluetooth headset
Soft carry case
User manual
USB cable
Normal ear tip
Sport ear tip
Volume+
Multifunction
Volume-
Packing List Features
ES20BT
