WMIA-139AG IEEE 802.11a Mini-PCI User’s Maunal
Specification
Product Name 54 Mbps/ 11Mbps Wireless LAN MINIPCI Card
Model Number WMIA-139AG
Host Interface MINIPCI
Dimensions 59.7x50.95x5 mm
Weight 20g
Frequency Band 802.11a
Unlicensed National Information Infrastructure (U-NII) frequency band,
5.15GHz to 5.85GHz (subject to local regulations)
Number of Non-Overlapping
Channels
802.11a
USA and Canada-13
Europe – up to 19, subject to local regulations
Japan – 4
Operating Voltage 3.3V ± 5%
Modulation 802.11a: OFDM;
Data Rate 802.11a
54, 48, 36,24,18,12, 9, 6 Mbps per channel, auto fallback for extended
range; (option : Enhanced proprietary Turbo Mode up to 108 Mbps)
Security 802.11a
64/128/152-bit WEP Encryption, AES
Antenna Interface UFL-CON
Transmitted power
802.11a
please see the output power table for detail.
Receive Sensitivity
802.11a
Nominal Temp Range:
- 6Mbps 10-5 BER @ -90dBm, typical
- 9Mbps 10-5 BER @ -89dBm, typical
- 12Mbps 10-5 BER @ -88dBm, typical
- 18Mbps 10-5 BER @ -87dBm, typical
- 24Mbps 10-5 BER @ -83dBm, typical
- 36Mbps 10-5 BER @ -80dBm, typical
- 48Mbps 10-5 BER @ -74dBm, typical
- 54Mbps 10-5 BER @ -70dBm, typical
802.11a
Max.2W
Continue Tx : 560 mA @ 3.3V
Continue RX : 350 mA @3.3V
Supplied Driver Windows 98SE/ME/NT4.0/2000/XP
Standards IEEE 802.3, IEEE 802.3u, IEEE 802.11a,
draft standard ,Wi-Fi compliant
Warranty 1 year
Temperature Range 0 ~ 50°C (Operating); -20 ~ 85°C (Storing)
Operating Humidity 10% to 85% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing
Operating Range Open Space: Up to 260 m: Indoor: 100 m
The transmission speed varies in the surrounding environment
Network Protocol TCP/IP, IPX, NDIS4, and NDIS5 ,NDIS 5.1
Management Utility Monitor Internet Access Status via UI
EMC certification TBD(FCC part 15C/15.247; ETS 300 328-2; UL; IEC60950; EN
301 489-1,17; prEN50371; CE Mark; TELEC)
System Requirements Laptop PC containing
Æ MINIPCI local bus slot
Æ 64MB memory or greater
Æ 300MHz processor or greater
Microsoft Windows 98 Second Edition/Millennium Edition/2000/NT 4.0
with Service Pack 6,Windows XP
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or modifications not
expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Statement Needed to be Shown on End Product
Since this module is installed inside the end product, the end product should be
affixed a label on visible area showing that this product contain a RF module, and
also its FCC ID.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The OEM integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the users manual of the end
product which integrate this module.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as the 2 conditions above are met, further transmitter testing will not be required. However,
the OEM integrator is still responsible for testing their end-product for any additional compliance
requirements required with this module installed ( for example, LCD TV, AP, Router )
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer
considered valid and the FCC ID can not be used on the final product. In these circumstances, the
OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and
Obtaining a separate FCC authorization.
End Product Labelling
This transmitter module is authorized only for use in devices where the antenna may be installed such
that 20 cm may be maintained between the antenna and users ( for example: LCD TV, AP, Router )
The final end product must be labeled in a visible area with the following:
“ Contains TX FCC ID: RYK-WMIA139AG ”.
Manual Information That Must be Included
The users manual for end users must include the following information in a prominent location “
IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for
this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and
must not be co-located or operating in conjunction with any other antenna or transmitter.”
For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment.
