Link Wireless Telephone System Regulatory Guide
3
Introduction
Your Link Wireless Telephone System (Link WTS) is a state–of-
the-art business communication system that provides wireless tele-
phone communication with the advanced features of your private
telephone system. Base Stations installed throughout the facility
transmit signals between the wireless telephones (handsets) and the
Master Control Unit (MCU). The MCU routes calls between the
Base Stations and the PBX. Handsets will not operate outside the
area covered by this system.
About This Guide
This guide is meant to provide regulatory information about the
Link WTS. Additional documents are available for information
about the Link WTS.
Registered Model Numbers
Link 150: SCA416, SCA408, SCA516, SCC408, SCC416, SCD408,
SCD416, SCE408, SCE416, SCF408, SCF416, SCI408, SCI416,
SCJ408, SCJ416, SCK408, SCK416, SCL408, SCL416, SCM408,
SCM416, SCN408, SCN416, SCO416, SCS416, SCT416, SCX416
Link 3000: JPI300, MCS300
Link Wireless Telephone: 602X
Link Base Stations: RCC400, RCO400, RCU100, RCU200,
RCU201
Link OAI Gateway: MOG400
Chargers: PCS1850, PCD1850, PCQ1850
Battery Packs: PBP0850, PBP1300, PBP1850
Please visit spectralink.com to view regulatory
declarations.
SpectraLink Corporation
4
![](/img.php?id=651002&img=bg5.png)
Link Wireless Telephone System Regulatory Guide
5
Table of Contents
Link 3000 MCU .......................................................... 7
FCC Information .....................................................................7
Industry Canada (IC) Notice .................................................8
Link 150 MCU .......................................................... 11
FCC Information ...................................................................11
Industry Canada (IC) Notice ...............................................12
Base Stations .......................................................... 15
Link 6020 Wireless Telephones ................................ 17
FCC Information ...................................................................17
International Certification Marks .............................. 19
Specific Absorption Rate (SAR) Information ...................20
Chargers .................................................................. 23
SpectraLink Corporation
6
![](/img.php?id=651002&img=bg7.png)
Link Wireless Telephone System Regulatory Guide
7
Link 3000 MCU
FCC Information
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undes-
ired operation.
FCC Registration Numbers:
Link 3000: IYGUSA-33400-PX-E
Ringer Equivalence:
Link 3000: 0.3B
SpectraLink Corporation
Link 3000
Made in the USA
This equipment complies with Part 68 of the FCC Rules. On the
back of this equipment is a label that contains, among other infor-
mation, the FCC Registration Number and Ringer Equivalence
Number (REN) for this equipment. If requested, this information
must be given to the telephone company.
This equipment uses RJ-21 connectors.
The REN is useful to determine the quantity of devices you may
connect to your telephone line and still have all of those devices
ring when your number is called. In most, but not all, areas, the
sum of the RENs of all devices connected to one line should not
exceed five (5.0). To be certain of the number of devices you may
connect to your line, as determined by the REN, you should con-
tact your local telephone company to determine the maximum
REN for your calling area.
SpectraLink Corporation
8
If your telephone equipment causes harm to the telephone net-
work, the telephone service may discontinue your service tempo-
rarily. If possible, they will notify you in advance. But if advance
notice isn’t practical, you will be notified as soon as possible. You
will be informed of your right to file a complaint with the FCC.
If you experience trouble with this telephone equipment, please
contact SpectraLink Corporation for information on obtaining
service or repairs.
SpectraLink Corporation
5755 Central Avenue
Boulder, CO 80301
303 440 5330
800 775 5330
support@spectralink.com
The telephone company may ask that you disconnect this equip-
ment from the network until the problem has been corrected or
until you are sure that the equipment is not malfunctioning. There
are no user serviceable parts in this equipment.
This equipment may not be used on coin service provided by the
telephone company. Connection to party lines is subject to state
tariffs.
Industry Canada (IC) Notice
The Industry Canada (IC) label identifies certified equipment. This
certification means that the equipment meets telecommunications
network protective, operational, and safety requirements as pre-
scribed in the appropriate Terminal Equipment Technical Require-
ments document(s). The department does not guarantee the
equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is per-
missible to be connected to the facilities of the local telecommuni-
cations company. The equipment must also be installed using an
acceptable method of connection. The customer should be aware
Link Wireless Telephone System Regulatory Guide
9
that compliance with the above conditions may not prevent degra-
dation of service in some situations.
Repairs to certified equipment should be coordinated by a repre-
sentative designated by the supplier. Any repairs or alterations
made by a user to this equipment, or equipment malfunctions, may
give the telecommunications company cause to request the user to
disconnect the equipment.
Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and inter-
nal metallic water pipe system, if present, are connected together.
This precaution may be particularly important in rural areas.
Caution: Users should not attempt to make such connections
themselves, but should contact the appropriate electric inspection
authority, or electrician, as appropriate.
Notice: The Ringer Equivalence Number (REN) assigned to each
terminal device provides as indication of the maximum number of
terminals allowed to be connected to a telephone interface. The
termination of an interface may consist of any combination of
devices.
REN 0.3B
Approval Numbers:
Link 3000: 2128-9508 A
Warranty and Repair Service Center
SpectraLink Corporation
5755 Central Avenue
Boulder, CO 80301
303 440 5330
800 775 5330
support@spectralink.com
SpectraLink Corporation
10
DOC Spread Spectrum Certification
Base Station: Cert. No. 2128K1373 3 17
Wireless Telephone: Cert. No. XXX
![](/img.php?id=651002&img=bgb.png)
Link Wireless Telephone System Regulatory Guide
11
Link 150 MCU
FCC Information
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undes-
ired operation.
FCC Registration Numbers:
Link 150: IYGUSA-33816-PX-E
Ringer Equivalence:
Link 150 Model 3: 0.3B
SpectraLink Corporation
Link 150 MCU
Made in the USA
This equipment complies with Part 68 of the FCC Rules. On the
back of this equipment is a label that contains, among other infor-
mation, the FCC Registration Number and Ringer Equivalence
Number (REN) for this equipment. If requested, this information
must be given to the telephone company.
This equipment uses RJ-21 connectors.
The REN is useful to determine the quantity of devices you may
connect to your telephone line and still have all of those devices
ring when your number is called. In most, but not all, areas, the
sum of the RENs of all devices connected to one line should not
exceed five (5.0). To be certain of the number of devices you may
connect to your line, as determined by the REN, you should con-
tact your local telephone company to determine the maximum
REN for your calling area.
If your telephone equipment causes harm to the telephone net-
work, the telephone service may discontinue your service tempo-
SpectraLink Corporation
12
rarily. If possible, they will notify you in advance. But if advance
notice isn’t practical, you will be notified as soon as possible. You
will be informed of your right to file a complaint with the FCC.
Your telephone company may make changes in its facilities, equip-
ment, operations or procedures that could affect the proper func-
tioning of your equipment. If they do, you will be notified in
advance to give you an opportunity to maintain uninterrupted tele-
phone service.
If you experience trouble with this telephone equipment, please
contact SpectraLink Corporation for information on obtaining
service or repairs.
SpectraLink Corporation
5755 Central Avenue
Boulder, CO 80301
303 440 5330
800 775 5330
support@spectralink.com
The telephone company may ask that you disconnect this equip-
ment from the network until the problem has been corrected or
until you are sure that the equipment is not malfunctioning. There
are no user serviceable parts in this equipment.
This equipment may not be used on coin service provided by the
telephone company. Connection to party lines is subject to state
tariffs.
Industry Canada (IC) Notice
The Industry Canada (IC) label identifies certified equipment. This
certification means that the equipment meets telecommunications
network protective, operational, and safety requirements as pre-
scribed in the appropriate Terminal Equipment Technical Require-
ments document(s). The department does not guarantee the
equipment will operate to the user’s satisfaction.
Link Wireless Telephone System Regulatory Guide
13
Before installing this equipment, users should ensure that it is per-
missible to be connected to the facilities of the local telecommuni-
cations company. The equipment must also be installed using an
acceptable method of connection. The customer should be aware
that compliance with the above conditions may not prevent degra-
dation of service in some situations.
Repairs to certified equipment should be coordinated by a repre-
sentative designated by the supplier. Any repairs or alterations
made by a user to this equipment, or equipment malfunctions, may
give the telecommunications company cause to request the user to
disconnect the equipment.
Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and inter-
nal metallic water pipe system, if present, are connected together.
This precaution may be particularly important in rural areas.
Caution: Users should not attempt to make such connections
themselves, but should contact the appropriate electric inspection
authority, or electrician, as appropriate.
Notice: The Ringer Equivalence Number (REN) assigned to each
terminal device provides as indication of the maximum number of
terminals allowed to be connected to a telephone interface. The
termination of an interface may consist of any combination of
devices.
REN 0.3B
Approval Numbers:
Link 150: 2128-9760 A
SpectraLink Corporation
14
Warranty and Repair Service Center
SpectraLink Corporation
5755 Central Avenue
Boulder, CO 80301
303 440 5330
800 775 5330
support@spectralink.com
DOC Spread Spectrum Certification
Base Station: Cert. No. 2128K1373 3 17
Wireless Telephone: Cert. No. XXX
![](/img.php?id=651002&img=bgf.png)
Link Wireless Telephone System Regulatory Guide
15
Base Stations
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undes-
ired operation.
This equipment complies with Part 68 of the FCC rules. These
units bear a label which contains the FCC registration number and
ringer equivalence number (REN). If requested, this information
must be provided to the telephone company.
SpectraLink recommends the use of shielded cable
for all external signal connections in order to main-
tain FCC Part 15 emissions requirements.
SpectraLink Corporation
16
![](/img.php?id=651002&img=bg11.png)
Link Wireless Telephone System Regulatory Guide
17
Link 6020 Wireless Telephones
FCC Information
The Link 6020 Wireless Telephone is certified as model number
602X.
FCC registration number Link 602X: IYG602X
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undes-
ired operation.
SpectraLink Corporation
18
![](/img.php?id=651002&img=bg13.png)
Link Wireless Telephone System Regulatory Guide
19
International Certification Marks
Canada
CAN/CSA-C22.2
No. 60950
United States
UL 60950
TUV Rheinland of North America is a
Nationally Recognized Testing Laboratory
(NRTL) in the United States and is accredited
by the Standards Council of Canada to test
and certify products to Canadian National
Standards. Clients can demonstrate compli-
ance for both U.S. and Canadian markets
through a single mark (cTUVus) on their
product(s) which denotes compliance to U.S.
and Canadian National Standards.
United States
Part 15, Part 68
![](/img.php?id=651002&img=bg14.png)
SpectraLink Corporation
20
Specific Absorption Rate (SAR) Information
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends
out radio frequency (RF) signals. In August 1996, the Federal Com-
munications Commissions (FCC) adopted RF exposure guidelines
with safety levels for hand-held wireless phones. Those guidelines
are consistent with the safety standards previously set by both U.S.
and international standards bodies:
• ANSI C95.1 (1992) American National Standards Institute
• NCRP—Report 86 (1986) National Council on Radiation Pro-
tection and Measurements
• ICNIRP (1996) International Commission on Non-Ionizing
Radiation Protection;
• DHWC—Safety Code 6 Department of Health and Welfare
Canada
Those standards were developed by independent scientific organi-
zations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed
to assure the safety of all persons, regardless of age and health. The
exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6W/kg.1 Tests for SAR are con-
ducted using standard operating positions specified by the FCC
with the phone transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is determined at the
highest certified power level, the actual SAR level of the phone
while operating can be well below the maximum value. This is
1. In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The
standard incorporates a substantial margin of safety to give additional protec-
tion for the public and to account for any variations in measurements.
Link Wireless Telephone System Regulatory Guide
21
because the phone is designed to operate at multiple power levels
so as to use only the power required to reach the network. In gen-
eral, the closer you are to a wireless base station antenna, the lower
the power output. Before a phone model is available for sale to the
public, it must be tested and certified to the FCC that it does not
exceed the limit established by the government-adopted require-
ment for safe exposure. The tests are performed in positions and
locations (e.g., at the ear and worn on the body) as required by the
FCC for each model. While there may be differences between the
SAR levels of various phones and at various positions, they all meet
the government requirement for safe exposure. The FCC has
granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model phone is on
file with the FCC and can be found under the Display Grant sec-
tion of http://www.fcc.gov/oet/fccid after searching on FCC ID
IYG602X. Additional information on Specific Absorption Rates
(SAR) can be found on the FCC website at http://www.fcc.gov/
cgb/sar/.
The only authorized headsets that may be utilized with the 602X
are those obtainable from SpectraLink or its reseller partners.
The maximum measured SAR levels of the Link 602X Wireless
Telephone are:
Body (0.223 mW/g) and
Head (0.463 mW/g), 902.4817–927.4826 MHz.
!Handset Operation Normal Position: Hold the
handset as you would any other telephone, with the
earpiece to your ear and speak into the microphone.
The internal antenna is then positioned properly.
SpectraLink Corporation
22
Handset Operation Body-Worn Position: To main-
tain compliance with RF energy exposure guidelines,
if you wear a handset on your body when transmit-
ting, always use the handset with a SpectraLink-sup-
plied accessory as described in the user guide for this
handset. SpectraLink supplies belt clips, holsters and
lanyards for body worn operation. Use of accessories
not supplied by SpectraLink may cause the handset
emissions to exceed RF energy exposure guidelines.
![](/img.php?id=651002&img=bg17.png)
Link Wireless Telephone System Regulatory Guide
23
Chargers
Link Chargers are only authorized for use in the U.S. and Canada.
The correct power supply for your charger will be provided with
the charger.
SpectraLink Corporation
24
