Spectrum 924 Router Plugin Unit User Manual

Kwikset Corporation Router Plugin Unit

User Manual

Bluetooth Enabled Gateway Setup
Bluetooth Enabled Gateway Setup
61844 / 01
Requirements:
• Internet service
• Internet router with
available Ethernet port
• Active Kevo Plus
membership
Requirements:
• Internet service
• Internet router with
available Ethernet port
• Active Kevo Plus
membership
Connect and fully tighten the antenna to the back of the
gateway. Bend the antenna so that it points straight up.
Connect and fully tighten the antenna to the back of the gateway.
Bend the antenna so that it points straight up.
Plug the USB cable’s power jack end into the gateway. Plug
the USB connector into the power adapter. Plug the power
adapter into a power outlet.
Plug the USB cable’s power jack end into the gateway. Plug the USB connector
into the power adapter. Plug the power adapter into a power outlet.
Make sure the lights on the gateway are functioning. See the
Light Ring Colors on page 2. Follow the instructions inside the
Kevo app to congure your gateway.
Make sure the lights on the gateway are functioning. See the Light Ring Colors
chart on page 2. Follow the instructions inside the Kevo app to congure your
gateway.
Once congured, you may control the gateway with the Kevo
app or mykevo.com
Once congured, you may control the gateway with the Kevo app or
mykevo.com.
Plug one end of the Ethernet cable into the gateway.
Plug the other end into your internet router.
Plug one end of the Ethernet cable into the gateway.
Plug the other end into your internet router.
1
3
2
4
©2014 Kwikset Corporation
Color
Color
Reason
Reason
White
White
Booting up
Booting up
Blue
Blue
Normal operation
Normal operation
Red
Red
Not connected to Kevo Plus
Not connected to Kevo Plus
Magenta
Magenta
Not connected to Kevo deadbolt
Not connected to Kevo deadbolt
Australia
Toll Free: 1800 623 118
Email: info@spectrumbrands.com.au
Website: www.spectrumbrands.com.au
Spectrum Brands Australia Pty Ltd
Locked Bag 3004
Braeside, Victoria 3195
Australia
New Zealand
Toll Free: 0800 736 776
Email: service@spectrumbrands.co.nz
Website: www.spectrumbrands.co.nz
Spectrum Brands New Zealand Ltd
PO Box 9817
Newmarket, Auckland 1149
New Zealand
USA & Canada
1-800-327-5625
Chile
56-229382400
Colombia
57-13441460
México
52-8141709475
Australia Warranty
Our goods come with guarantees that cannot be excluded under Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure. The benets provided by this warranty are in addition to all
other rights and remedies in respect of this product which you may have under Australian
Consumer Law or otherwise.
If your product is defective, you can have it repaired or replaced under our Lifetime warranty.
To claim under our warranty, please return the defective item along with the packaging, the
original receipt, your address and your signature by pre paid postage to Spectrum Brands
Australia Pty Ltd at the address on pack at any time following purchase. Spectrum Brands
Australia Pty Ltd will then replace or repair the item and return it to you at our cost.
Light Ring Colors
Light Ring Colors
Kevo Support
Kevo Support
Regulatory Compliance
Regulatory Compliance
This product complies with standards established by the following regulatory bodies:
• Federal Communications Commission (FCC)
• Industry Canada
FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: ( 1 ) this device may not cause harmful interference, and ( 2 ) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT! Changes or modications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
Industry Canada
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: ( 1 ) this device may not cause interference, and ( 2
) this device must accept any interference, including interference that may cause undesired
operation of the device.
Este producto cumple con las normas establecidas por los siguientes organismos
reguladores:
• Comisión Federal de Comunicaciones (FCC)
• Industry Canada
FCC
Este dispositivo cumple con la 15ª parte del reglamento de la FCC. Su funcionamiento
está sujeto a las siguientes dos condiciones: ( 1 ) este dispositivo no deberá causar
ninguna interferencia dañina, y ( 2 ) este dispositivo deberá aceptar cualquier interferencia
recibida, incluyendo aquélla que podría causar un funcionamiento no deseado.
Se realizaron pruebas a este equipo cuyos resultados revelaron que cumple con
los límites establecidos para un dispositivo digital de la Clase B, conforme a la 15ª
parte del reglamento de la FCC. Estos límites han sido impuestos para proporcionar
protección razonable contra interferencias dañinas en una instalación residencial. Este
equipo genera, utiliza y puede irradiar energía de radiofrecuencia y, si no se instala y
utiliza según lo que indican las instrucciones, podría causar interferencia dañina en
radiocomunicaciones. Sin embargo, no hay garantía de que la interferencia no ocurrirá
en determinadas instalaciones. Si este equipo efectivamente causa interferencia en la
recepción de radio o televisión, la cual puede determinarse encendiendo y apagando el
equipo, sugerimos al usuario que intente corregir dicha interferencia tomando una o más
de las siguientes medidas:
• Volver a orientar o ubicar la antena receptora.
• Incrementar la distancia entre el equipo y el recibidor.
• Conectar el equipo a una toma de corriente en un circuito distinto del circuito en el
cual esté conectado el recibidor.
• Consultar con el distribuidor o un técnico de radio y TV con experiencia para obtener
su ayuda.
¡IMPORTANTE! Todo cambio o modicación no aprobado expresamente por el fabricante
podría desautorizar al usuario para operar el equipo.
Industria de Canada
Este dispositivo cumple con las normas de la Industria de Canada licencia-exenta RSS.
Su funcionamiento está sujeto a las siguientes dos condiciones: ( 1 ) este dispositivo
no deberá causar ninguna interferencia dañina, y ( 2 ) este dispositivo deberá aceptar
cualquier interferencia, incluyendo aquélla que podría causar el funcionamiento no
deseado del dispositivo.
www.kwikset.com/kevo/support
Note: It is normal to see red and magenta during rst time setup.
Note: It is normal to see red and magenta during rst time setup.
