User Manual
CONFIDENTIAL MATERIAL
1. .......................................... HARDWARE
2. ............................................ NETWORK
3. ...............................................WEBAPP
TECHNICAL OVERVIEW
Spiio Inc.
470 Ramona St.
Palo Alto, CA 94301
Christoffer Thorup
T: (628) 246-5661
M: chris@spiio.com
www.spiio.com
Welcome to spiio
In everything we do, we believe in the next green
revolution. Our service allows horticulture pro-
fessionals all over the world to make data-driven
irrigation decisions and retain full digital control of
millions of plants with the use of real-time data
analytics. Spiio Inc. is based in Palo Alto, CA and
Copenhagen, Denmark.
CONFIDENTIAL MATERIAL
HARDWARE
Conguration
Electric Imp’s BlinkUp is a unique way to to securely
commission, provision and deploy devices. It uses
light binary patterns to allow service technicians
and/or customers to securely connect the device
with the Spiio server using standard smartphones or
tablets. Only authorized personnel can activate the
sensor via the Spiio conguration app.
Battery
Product Model: ....................................... LS17500 CN
Original Manufacturer: ......................................... Saft
Size: .............................................................................A
Technology: ...... Lithium Thionyl Chloride (LiSOCI2)
Voltage: ................................................................. 3.6V
Weight: ................................................................... 86g
Primary Uses: ............... Radio-comms, emergency,
security,tollgates, meters, tracking.
Measurement
The device logs temperature, moisture
and light measurements every hour.
Interaction
The sensor has no physical buttons or other input
methods. The only way to turn on or off the device
is by using Spiio’s dedicated conguration tool.
Scanning the QR code on the device will take you
to spiio.com.
Temperature
Conguration tool
Battery
Light
Moisture
CONFIDENTIAL MATERIAL
NETWORK
Connection
Spiio sensors connect outwards to the server in all
cases. Spiio sensors will attempt connections on port
31314, 993 and 443 (in that order). Spiio sensors
can connect via customer WIFI LAN or an isolated
dedicated Spiio router. If customer LAN is used there
is no need for customers to open any inbound ports.
Connection security
Connections are standard TLS1.2, using ECDHE-
RSA2048-AES128-SHA256 (ie, forward secrecy is
enabled). Embedded CAs verify the keys provided
by each end, and a challenge-response is used to
challenge the unique per-device key to prevent de-
vice impersonation even if TLS keys are leaked.
spiio sensor
On-site
Wi
Spiio Base
Station
Spiio Cloud
OR
CONFIDENTIAL MATERIAL
WEBAPP
User signup
With a veried user account, Spiio’s web-based app
can be accessed on both smartphone and desktop
devices.
All users will be selected and invited by our Clients
for a user signup at app.spiio.com. Once a user signs
up for the rst time, you will see a temporary Demo
Wall. Upon conrmation from Client, Spiio will then
grant access to individual users based on which
green walls they should have access to in the future.
SIGN UP FLOW
Spiio grant
access to user
User signup Demo Access User get access
to the relevant data
DEMO
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
