Strattec Security 1008552 Key Fob Transmitter User Manual SAAB Revision B
Strattec Security Corporation Key Fob Transmitter SAAB Revision B
08 User Manual
STRATTEC Security Corporation
FCC ID OHT1008552
IC 5461A-T360S
Page 1 of 6
User Manual Information and Product Description
of the
GMT-360 SAAB Key
General Description of the RF transmitter:
The RF remote control system consists of a RF transmitter.
The Operation Frequency for the RKE function is 315 MHz and will be used as a
portable device.
The RF transmitter is mechanically integrated into the Key Fob Housing.
STRATTEC Security Corporation
FCC ID OHT1008552
IC 5461A-T360S
Page 2 of 6
This transmitter is used to transmit information for locking or unlocking the vehicle by a
unidirectional RF transmission line for normal remote operation by pressing a button.
Intended environment conditions: - 10 degree Celsius to + 55 degree Celsius
In general the following functions are provided:
- Lock door
- Open door
- Panic (alarm)
Label Information:
Model Name: GMT-360 SAAB Key
STRATTEC Security Corporation
FCC ID OHT1008552
IC 5461A-T360S
Page 3 of 6
SAAB KEY 315 MHz (3 Buttons):
Remote Keyless Entry:
The hand-held radio Transmitter allows to lock or unlock the car doors, and activate the panic
alarm within a range of around 100m of the vehicle.
1.) To unlock doors
Press and release the UNLOCK Button on the RF Transmitter once to unlock.
2.) To lock doors
Press and release the LOCK Button on the RF Transmitter once to lock.
3.) Panic Alarm
Press and release the PANIC Button on the RF Transmitter once to turn the Panic Alarm ON
and OFF.
STRATTEC Security Corporation
FCC ID OHT1008552
IC 5461A-T360S
Page 4 of 6
Power Supply:
The RF transmitter is battery powered with 1 Lithium battery CR 2032, supplying +3V
power, which is installed into the back housing facing + side down.
The display in the instrument cluster of the vehicle will inform the user when the battery
of the RF transmitter is getting low (weak). The battery indicator light in the instrument
cluster flashes when the battery voltage level is decreasing to a lower than 2.3 V, the
battery should be replaces.
The minimum operating voltage is approximately 2.1 V. If the voltage drops below 2.1 V
the RF transmitter will not operate and battery needs to be replaced.
Battery:
Replacing the battery:
Remove the screw on the back side of the FOB, and open the battery cover having with
transmitter buttons facing down.
Remove the old battery carefully from the battery compartment.
STRATTEC Security Corporation
FCC ID OHT1008552
IC 5461A-T360S
Page 5 of 6
Replace the new battery +side facing down. Avoid touching the new batteries with fingers, skin
oils may cause battery deterioration. Do not touch the PCB or the battery clip.
WARNING:
This device complies with the Part 15 of the FCC Rules and with the RDSS-210 of Industry
Canada.
Operation is subject to the following two conditions:
(1) this device may cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
WARNING for End User:
Changes or modifications made to this equipment not expressly approved by STRATTEC
Security Corporation may void the FCC authorization to operate the equipment.
STRATTEC Security Corporation
FCC ID OHT1008552
IC 5461A-T360S
Page 6 of 6
This hand-held radio transmitter is primarily used for vehicle remote locking/ unlocking
(Key less entry) applications. It must be kept away from the reach of children. In the
event of RF Failure the key blade can be used to open the vehicle door or trunk.
