Basic usage
The basic usage and interaction with pin ONE.
Written by Kristoffer Eriksson
Updated in the last 15 minutes
Turn on and off
Hold the power button on the left side of the pin for 3s to turn the pin on and off.
Toggle backlight
The backlight of the pin can be toggled in 3-levels by clicking the power button.
Pair
Before usage the pin needs to be paired to the phone. Download one of the apps and follow the
instructions to pair your phone with your pin.
Unpair
The pin can only be paired to one phone at a time. If you want to use the pin with a new phone
you can remove that last pairing by having the pin turned on and hold the power button for 15s
until you see the paring message.
Charing
The pin is charged via MicroUSB. Connect the USB cable to a transformer or computer and
connect the MicroUSB end to your pin. The pin is fully charged in about one hour.
Display e-label
Click the power button quickly 5 times to display the devices e-label.
Forced power off
In the rare occasion that the pin freezes you can force it to turn off by holding the power button
and connecting the MicroUSB cable.
Factory reset (use with care)
The pin can be reseted to factory settings by holding the power button for 30s (until a factory
reset artwork appears). This removes all the data on the pin and should only be used as a last
resort if everything else fails.
Go to Pins Collective
Search for answers...
Pins Collective Help Center
All Collections Pin ONE Basic usage
INFORMATION ABOUT PIN ONE
FCC AND IC INFORMATION:
Any Changes or modifications not
expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment.
This device complies with part 15 of
the FCC Rules. Operation is subject to
the following two conditions: (1) This
device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
Note: This equipment has been tested
and found to comply with the limits
for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful
interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a
particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can
be determined by turning the
equipment offand on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an
outlet on a circuit different from that
to which the
receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
This equipment complies with FCC RF
radiation exposure limits set forth for
an uncontrolled environment. This
transmitter must not be co-located or
operating in conjunction with any
other antenna or transmitter.
FCC ID: 2ANO7-PINONE
IC: 23202-PINONE
ISEDC WARNING:
This device complies with Innovation,
Science, and Economic Development
Canada license-exempt RSS
standard(s). Operation is subject to
the following two conditions:
1. this device may not cause
interference, and
2. this device must accept any
interference, including interference
that may cause undesired
operation of the device.
Radio apparatus containing digital
circuitry which can function separately
from the operation of a transmitter or
an associated transmitter, shall
comply with ICES-003. In such cases,
the labelling requirements of the
applicable RSS apply, rather than the
labelling requirements in ICES-003.
Cet appareil est conforme à la (aux)
norme (s) RSS exempte de licence
d'Innovation, Science et
Développement économique Canada.
Le fonctionnement est soumis aux
deux conditions suivantes:
1. cet appareil ne doit pas causer
d'interférences, et
2. cet appareil doit accepter toute
interférence, y compris les
interférences pouvant provoquer un
fonctionnement indésirable de
l'appareil.
Les appareils radio contenant des
circuits numériques qui peuvent
fonctionner séparément du
fonctionnement d'un émetteur ou
d'un émetteur associé doivent être
conformes à la norme ICES-003. Dans
de tels cas, les exigences d'étiquetage
du RSS applicable s'appliquent, plutôt
que les exigences d'étiquetage de la
norme ICES-003.
Warning:
This Class B digital apparatus complies
with Canadian ICES-003.
The device has been tested and
compliance with SAR limits, users can
obtain Canadian information on RF
exposure and compliance.
CE INFORMATION:
Model: Pin ONE
Operating Temperature: 0-40 °C
Charging Temperature: 5-35 °C
Operating Frequency: 2402-2480MHz
Input: 5V DC 200mA
Max output power: < -5dBm
This device contains a built in lithium
battery, 3,7V, 150mAh.
EU REGULATORY CONFORMANCE
Hereby, Sturgill & Co. AB declares that
this device is in compliance with the
essential requirements and other
relevant provisions of Directive
2014/53/EU.
For the declaration of conformity, visit
the Web site [www.pinscollec-
tive.com/eu-conformity.]
E-LABEL
E-label is displayed by pressing the
power button quickly 5 times when
the pin is turned on.
CONTACT INFORMATION:
Sturgill & CO AB
Folkungagatan 44,
118 26 Stockholm,
Sweden
EU Regulatory Conformance
Hereby, Sturgill & CO AB declares that this
device is in compliance with the essential
requirements and other relevant provisions of
Directive 2014/53/EU.For the declaration of
conformity, visit the Web site
pinscollective.com/certification.
Online manual is available at
pinscollective.com/manual
