Summer Infant 962R Baby Monitor (Monitor Unit) User Manual 29620 SideBySide Quick Start Guide 24Nov2016
Summer Infant, Inc. Baby Monitor (Monitor Unit) 29620 SideBySide Quick Start Guide 24Nov2016
Users Manual
Zoom
Press the zoom button to toggle
between No zoom, zoom 1x, zoom
2x and zoom 3x. The zoom level is
indicated as an icon on the
top-right hand corner.
For understanding additional Menu features including: delete camera, and add camera,
plese refer to the user’s guide.
QUICK START GUIDE
USING THE HANDHELD (continued) 3
Summer Infant, Inc. 1275 Park East Drive Woonsocket, RI 02895 1 800 268-6237 11/16
Sound Activated Lights
The LED light bar on the top of the
handheld will light up as it picks up
noises. Softer sounds will light up
the amber LEDs. Louder noises will
light up the red LEDs.
Video On/Off
Turn off the handheld’s video by
pressing the VIDEO button. The
screen will go dark. This feature
allows you to preserve battery life
when not plugged into A/C
adapter. The audio feature will
remain activated allowing you to
monitor sounds. Press the button
again to resume video monitoring.
Talk-back
Press and hold the talk-back button to activate the talk-back feature.
Release the button to end talk-back mode.
Press the nightlight button again to change the nightlight color to red.
Red light helps soothe infants to sleep. This color is prominent in the
sunset, natures very own way of telling your little one it’s time to go to
sleep. An added bonus: young baby’s find red light soothing as it is a
familiar color to them– it’s the only color light your baby was able to see
in the womb.
Nightlight
Press the nightlight button on the
handheld to activate the soft glow
nightlight on the camera. The light
will glow blue. Blue light acts as a
soothing soft glow nightlight.
Nightlights are comforting to little
ones, especially toddlers who
become scared in a pitch black
room.
The nightlight can be turned
on or off from the camera
by pressing the
ON/OFF/Nightlight button.
Adjusting Brightness
Adjust the handheld screen
brightness by pressing the
“POWER/MENU ” button, and
brightness is selected from the
menu. Use the left and right
arrow buttons to adjust the
brightness.
VIEW CAM
SCAN
BRIGHTNESS
DELETE CAM
ADD CAM
VIEW CAM
SCAN
BRIGHTNESS
DELETE CAM
ADD CAM
/ MENU
Split/Quad Screen Viewing
Press the Split/Quad Screen button
to view more than one room at once.
Audio is only transmitted from one room
in this mode. Manually press left/right or
up/down arrow buttons to hear other
rooms. The room with the audio will
have a blue box around it.
Note: Zoom and Pan/Tilt are not
accessible while in split-screen mode.
Press camera control button to exit
Split/Quad screen mode.
Selecting Camera to View
Step 1: Power on the Handheld and press the “POWER/MENU ” button.
Step 2: Using the “DOWN ” button, select “View Cam”.
Step 3: Use the “LEFT /RIGHT ” buttons to select an available
camera (blue color indicates powered-on, within-range, or paired
cameras).
Step 4: Press “CAMER CONTROL ” button to confirm selection.
Step 5: The video will appear on the handheld screen.
/ MENU
/ MENU
Scanning Camera
Step 1: Power on the Handheld and press the “POWER/MENU ” button.
Step 2: Using the “DOWN ” button, select “SCAN” and press
“CAMER CONTROL ” button.
Step 3: Scanning cameras will begin, it will cycle through each active
camera every 8 seconds.
Step 4: To stop scanning, press the “POWER/MENU ” button.
/ MENU
/ MENU
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment .This equipment should be installed and operated with
minimum distance 20cm between the radiator& your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
ISEDC Warning
This device complies with Innovation, Science, and Economic Development Canada
licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Innovation, Sciences et Développement
économique Canada applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement
The device is compliance with RF exposure guidelines, users can obtain Canadian information on RF
exposure and compliance.The minimum distance from body to use the device is 20cm.
Le présent appareil est conforme
Après examen de ce matériel aux conformité ou aux limites d’intensité de champ RF,
les utilisateurs peuvent sur l’exposition aux radiofréquences et la conformité and compliance d’acquérir
les informations correspondantes. La distance minimale du corps à utiliser le dispositif est de 20cm.
