Sunbeam I85R Transmitter Unit of the Remote Bedding Control User Manual
Sunbeam Products, Inc. Transmitter Unit of the Remote Bedding Control
Sunbeam >
User Manual
1
User Manual
WARMING PRODUCTS
IMPORTANT INSTRUCTIONS-
DO NOT DESTROY
As with all electrical products, misuse of product or failure to
properly follow the instructions may cause overheating, fire, or
personal injury. Please read the product label and all of the
instructions before using your warming product.
1 Do not use this warming product with an infant, a child, an
incapacitated person, a paraplegic, a quadriplegic, a diabetic,
one insensitive to heat such as a person with poor blood
circulation, or anyone who cannot clearly understand the
instructions and/or operate the controls.
2 Do not use with damaged cords. Damaged cords can lead to
fire. Do not trap, fold, cross, or pinch cords between bed slats,
mattress, or springs, or against walls, footboards, or bed frame.
3 Do not dry clean this warming product. Cleaning liquid may
damage the insulation of the heating element. Improper
laundering may cause problems with the heating wire which can
lead to fire.
4 Do not pinch, flex, or expose the heating wire to rubbing. A
damaged heating wire may result in possible overheating or fire.
5 Turn off the control for the warming product when not using.
6 Keep control away from an open window.
7 Do not use pins; they may damage the electric wiring.
8 Be sure this blanket/mattress pad/throw is used only on an AC
supply current circuit of 110-120 volts. Do not use with an
extension cord.
9 Excissive heating may result from folding blanket, when in
actual use.
10 Keep all dogs, cats, and other pets away from this warming
product. This is an electrical appliance that they can damage
or be injured by.
11 Do not use blanket/mattress pad on a waterbed, sofa, bunk
bed, or mechanically adjustable bed and do not use throw on a
waterbed, bunkbed, or mechanically adjustable bed.
12 Do not use another electronic heating device in conjunction
with your warming product.
13 Use the proper size blanket/mattress pad for your bed. For
example, use a Twin Size warming blanket on a Twin Size bed.
14 If the following Important Instructions are not followed the
warming product will not operate properly.
15 If you see the warming product operating improperly, unplug it
immediately and call Sunbeam Consumer Service at the 800
number listed under “How to Obtain Warranty Service”.
Warnings and Safeguards
1
Welcome
Thank you for choosing a Sunbeam®warming product.
With your purchase you’ve made a real investment in
your comfort and can look forward to staying warm and
cozy for many cool days to come.
With over 50 years of experience and over 25 million
households using a Sunbeam®warming product, you
can rest comfortably knowing that Sunbeam®is the
brand to trust…for quality and performance.
So get ready for a more restful sleep.
Table of contents
DD Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Warming Blanket . . . . . . . . . . . . . . . . . . . . . . . 2
Mattress Pad . . . . . . . . . . . . . . . . . . . . . . . . . . 3
DD Convertible Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Warming Blanket . . . . . . . . . . . . . . . . . . . . . . . 4
Mattress Pad . . . . . . . . . . . . . . . . . . . . . . . . . . 5
DD 2 Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Warming Blanket . . . . . . . . . . . . . . . . . . . . . . . 6
Mattress Pad . . . . . . . . . . . . . . . . . . . . . . . . . . 7
DD Z Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Warming Blanket . . . . . . . . . . . . . . . . . . . . . . . 8
Mattress Pad . . . . . . . . . . . . . . . . . . . . . . . . . . 9
DD Gradient Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
Warming Blanket . . . . . . . . . . . . . . . . . . . . . . 10
Mattress Pad . . . . . . . . . . . . . . . . . . . . . . . . . 11
DDY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Warming Blanket . . . . . . . . . . . . . . . . . . . . . . 12
Mattress Pad . . . . . . . . . . . . . . . . . . . . . . . . . 13
LED Throw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Auto-off feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Care and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-18
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
How to obtain warranty service . . . . . . . . . . . . . 20
2
DD Remote
Features:
• REMOTE CONTROL – sends heat level control commands to the base unit
and adjusts the blankets warmth accordingly.
• ELECTRONIC DIGITAL CONTROL – for easy setting with backlit LCD
• AUTO-OFF – 10 hour independent auto-off (see page 15)
• 10 TEMPERATURE SETTINGS – select your personal comfort
• PRE-HEAT – for cozy warmth before bedtime
• SOLID STATE – for accurate and consistent heat control
• EASY OPERATION – Electronic digital controller for easy operation
• EASY GRIP – ergonomic control for easy operation
• CORDLESS – no more wires to tangle
• AUDIBLE BEEP – when changing heat settings, on/off setting and
automatic programming selections.
Pre-heat
1To use the preheat feature, simply press the round “On/Off” button and
then press the “Preheat” button. The preheat function will heat the bed for
a period of 30 minutes.
2To reset the preheat feature, simply press the “On/Off” button OFF.
3To turn back ON repeat step1.
CAUTION: Do not plug main power cord into the wall outlet until you have completely set
up your warming blanket per the instructions.
IF YOU DO NOT FOLLOW THIS SEQUENCE, THE WARMING BLANKET WILL NOT WORK.
• Disconnect power cord from wall before detaching control from warming blanket
• Always make sure cords are NOT trapped or pinched between bed slats, mattress,
springs, against wall, foot board or bed frame. 1Place the warming blanket on the bed with the label side facing outward.
2Plug cord into the module at the bottom of the warming
blanket until the plastic hinges click into place. CAUTION:
Cord must be COMPLETELY CONNECTED. A risk of fire could
result from a loose connection.
3Run the cord under the bed, not between the mattress and box
springs. Avoid any tangling or pinching.
4Place the base unit on the floor under the bed.
5Place the remote control where it is convenient for you.
6Plug warming blanket power cord into a 110-120 volt wall
outlet.
CAUTION: This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electrical shock, this plug is intended to
fit only one way into an outlet. If the plug does not fit in the outlet, reverse
the plug. Do not attempt to force the plug.
6
2
IMPORTANT
2
1
2
3
4
5
6
Set Up WARMING BLANKET
3
Using your Control:
1To turn the control on, simply press the “On/Off” button. The backlit display light will illuminate and begin to warm
at the comfort setting last used.
CAUTION: ALWAYS turn the warming blanket “Off” when not in use.
2To turn the warming blanket OFF simply press the “On/Off” a second time.
Setting the control side (Queen or King blankets only)
The “left” control can operate the left or both sides, and the “right” control can operate the right or both sides. (If
you have a Twin or Full size blanket, the remote control operates the entire blanket.) Each person has complete
control over his/her temperature comfort level for the ultimate in individualized comfort.
You can use one remote control to operate both sides of the blanket (both sides of the blanket will have the same
heat level). Or, you can use two remote controls to set separate heat levels for each side of the blanket.
Installing the Batteries
1Remove the battery compartment door from the back of
the remote control
2Insert three AAA batteries, matching the +and -markings
in the battery compartment to the markings on the
batteries
3Replace the battery compartment door
4If your blanket has two remote controls, repeat steps
1 – 3 to install batteries in the second remote control.
1
3
2
CAUTION: Do not plug main power cord into the wall outlet until you have completely set
up your warming blanket per the instructions.
IF YOU DO NOT FOLLOW THIS SEQUENCE, THE WARMING MATTRESS PAD WILL NOT WORK.
• Disconnect power cord from wall before detaching control from warming mattress pad
• Always make sure cords are NOT trapped or pinched between bed slats, mattress,
springs, against wall, foot board or bed frame. 1Place the warming mattress pad on the bed with the label side facing outward.
2Plug cord into the module at the bottom of the warming
mattress pad until the plastic hinges click into place.
CAUTION: Cord must be COMPLETELY CONNECTED. A risk of fire
could result from a loose connection.
3Run the cord under the bed, not between the mattress and box
springs. Avoid any tangling or pinching.
4Place the base unit on the floor under the bed.
5Place the remote control where it is convenient for you.
6Plug warming mattress pad power cord into a 110-120 volt
wall outlet.
CAUTION: This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electrical shock, this plug is intended to
fit only one way into an outlet. If the plug does not fit in the outlet, reverse
the plug. Do not attempt to force the plug.
6
2
IMPORTANT
2
Set Up WARMING MATTRESS PAD
1
2
3
5
6
WARNING: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate
equipment.
4
4
DD Convertible
Features:
• ELECTRONIC DIGITAL CONTROL – for easy setting with backlit LCD
• AUTO-OFF – 10 hour independent auto-off (see page 15)
• 10 TEMPERATURE SETTINGS – select your personal comfort
• PRE-HEAT – for cozy warmth before bedtime
• SOLID STATE – for accurate and consistent heat control
• EASY OPERATION – Electronic digital controller for easy operation
• EASY GRIP – ergonomic control for easy operation
• ROOM TEMPERATURE COMPENSATION –
• INTERCHANGEABLE TOP –
Pre-heat
1To use the preheat feature, simply press the round “On/Off” button and
then press the “Preheat” button. The preheat function will heat the bed for
a period of 30 minutes.
2To reset the preheat feature, simply press the “On/Off” button OFF.
3To turn back ON repeat step1.
On/
Off
On/
Off
On/
Off
On/
Off
CAUTION: Do not plug main power cord into the wall outlet until you have completely set up
your warming blanket per the instructions.
IF YOU DO NOT FOLLOW THIS SEQUENCE, THE WARMING BLANKET WILL NOT WORK.
• Disconnect power cord from wall before detaching control from warming blanket
• Always make sure cords are NOT trapped or pinched between bed slats, mattress, springs,
against wall, foot board or bed frame. 1Place the warming blanket on the bed with the label side facing outward.
2Plug cord into the module at the bottom of the warming
blanket until the plastic hinges click into place. CAUTION:
Cord must be COMPLETELY CONNECTED. A risk of fire could
result from a loose connection.
3Run the cord under the bed, not between the mattress and box
springs. Avoid any tangling or pinching.
4For dual control warming blankets, place primary control (label
on back of control) on the same side of the bed as the blanket
label side.
5For single control warming blankets, the control can be placed
on either side of the bed.
6Plug warming blanket power cord into a 110-120 volt wall
outlet.
CAUTION: This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electrical shock, this plug is intended to fit only one way into an
outlet. If the plug does not fit in the outlet, reverse the plug. Do not attempt to force the plug.
6
2
IMPORTANT
2
1
2
3
4
5
6
Set Up WARMING BLANKET
5
Using your Control:
1To turn the control on, simply press the “On/Off” button. The backlit display light will
reset itself by flashing “FF” and then will light showing the previous setting the unit
was set during the last use and will begin to warm.
CAUTION: ALWAYS turn the warming blanket/warming mattress pad “OFF” when
not in use.
2To turn the warming blanket/warming mattress pad OFF simply press the “On/Off”
button.
CAUTION: Do not plug main power cord into the wall outlet until you have completely set
up your warming blanket per the instructions.
IF YOU DO NOT FOLLOW THIS SEQUENCE, THE WARMING MATTRESS PAS WILL NOT WORK.
• Disconnect power cord from wall before detaching control from warming mattress pad
• Always make sure cords are NOT trapped or pinched between bed slats, mattress,
springs, against wall, foot board or bed frame. 1Place the warming mattress pad on the bed with the label side facing outward.
2Plug cord into the module at the bottom of the warming
mattress pad until the plastic hinges click into place.
CAUTION: Cord must be COMPLETELY CONNECTED. A risk of fire
could result from a loose connection.
3Run the cord under the bed, not between the mattress and box
springs. Avoid any tangling or pinching.
4For dual control warming mattress pads, place primary control
(label on back of control) on the same side of the bed as the
blanket label side.
5For single control warming mattress pads, the control can be
placed on either side of the bed.
6Plug warming mattress pad power cord into a 110-120 volt
wall outlet.
CAUTION: This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electrical shock, this plug is intended to fit only one way into an
outlet. If the plug does not fit in the outlet, reverse the plug. Do not attempt to force the plug.
6
2
IMPORTANT
2
Set Up WARMING MATTRESS PAD
On/
Off
On/
Off
On/
Off
On/
Off
1
2
3
4
5
6
6
DD 2
7
8
DD Z
9
10
DD Gradient
11
12
DD Y
13
14
LED Throw
Features:
• 3 TEMPERATURE SETTINGS – select your personal
comfort level
• SILENT OPERATION – no clicking
• SOLID STATE – for accurate and consistent heat control
• EASY OPERATION – electronic controller for easy
operation
• EASY GRIP – ergonomic control for easy operation
• AUTO-OFF – 3 hour independent auto-off
Using your Warming Throw Control:
1To turn the throw on simply press the round gray button. The
indicator light will glow, depending on which setting the warming
throw is set, and the warming throw will begin to warm.
CAUTION: ALWAYS turn the warming throw “OFF” and
disconnect the power cord from the outlet when not in use.
2To turn the warming throw OFF simply press the round gray button
through the different settings until the temperature setting lights
are not glowing.
Auto-off
control
CAUTION: Do not plug main power cord into the wall outlet until you have completely set
up your warming blanket per the instructions.
IF YOU DO NOT FOLLOW THIS SEQUENCE, THE WARMING THROW WILL NOT WORK.
• Disconnect power cord from wall before detaching control from warming blanket
• Always make sure cords are NOT trapped or pinched between furniture, walls or chairs.
Module
Control
Power Cord
Flag Tag
Throw Cord
Connector
Throw Cord
Label
When setting up your warming throw, be sure to follow the steps
below in order.
1Locate the warming throw’s information label, located near the
module.
2Firmly plug the warming throw cord into the module until the
plastic hinges on each side click into place.
CAUTION: Cord must be COMPLETELY CONNECTED. A risk of fire
could result from a loose connection.
3Plug warming throw power cord into a 110-120 volt wall outlet.
CAUTION: This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of electrical shock, this plug is intended to fit only one
way into an outlet. If the plug does not fit in the outlet, reverse the plug. Do not attempt to
force the plug.
3
2
IMPORTANT
2
Set Up WARMING THROW
1
2
3
15
Auto-off feature
Auto-off Feature:
The “Auto-Off” feature is designed for safety and conservation of energy by automatically turning your warming
product off after 10 hours of continuous use.
The Auto-off function engages 10 hours from the time the control is turned “On”.
For Dual Control:
Whichever control is turned On first that controls 10 hour Auto-off feature will be initiated. The controls
Auto-off features work independently from each other.
To restart after a power failure:
Press the “On/Off” or “On” button, the blanket/mattress pad will begin to warm.
Note: After a power outage, the “Auto-Off” feature automatically resets the timer.
Auto-off Feature for Throw:
The “Auto-Off” feature is designed for safety and conservation of energy by automatically turning your warming
product off after 3 hours of continuous use.
The Auto-off function engages 3 hours from the time the control is turned “On”.
(Three Hours for
Warming Throw)
16
Taking care of your warming product is easy and safe as long as you follow a few
simple steps.
Caution: Always disconnect the power cord and the blanket/mattress pad/throw
connection cord at the connection end before washing. Carefully follow all washing
instructions or your warming product may shrink and possibly cause a fire hazard.
DO NOT
• DO NOT dry clean your blanket/mattress pad/throw.
Dry cleaning solvents may damage the warming element.
• DO NOT use bleach or cleaning fluids.
• DO NOT use a wringer.
• DO NOT iron the blanket/mattress pad/throw.
• DO NOT use mothballs or sprays of any kind.
• DO NOT turn the blanket/mattress pad/throw on until it is
completely dry.
Machine Washing
1Presoak the blanket/mattress pad/throw for 15 minutes in mild soap
and lukewarm water.
2Wash in mild soap and lukewarm water on the delicate or gentle cycle in the
washer for two minutes. Remember, do not use bleach.
3Rinse in fresh, lukewarm water.
4Spin dry in the washing machine. Then gently stretch to its original size.
Machine Drying
Caution: Do not use commercial dryers or the dryers at your local laundromat. They
get too hot and would damage the wiring of the warming product.
1Preheat the dryer on the low temperature setting for 2 minutes.
2Place blanket/mattress pad/throw into the dryer and tumble dry for
10 minutes at a low temperature.
3Remove the blanket/mattress pad/throw while it is still damp and
gently stretch it to its original size.
4Continue to air dry over a clothesline or a shower rod.
DO NOT use clothespins.
5Warming product must be completely dry before using.
Hand Washing
1Presoak the blanket/mattress pad/throw for 15 minutes in mild soap and
lukewarm water.
2Gently squeeze the soap suds through a few times.
3Rinse in fresh, lukewarm water.
Hand Drying
1Gently stretch the blanket/mattress pad/throw back to its original size.
2Air dry over a clothesline or hang over a shower rod. DO NOT use clothespins.
3Warming product must be completely dry before using.
Care and cleaning
OF YOUR WARMING PRODUCT
17
Frequently asked questions
OF YOUR WARMING PRODUCT
QI have heard that some warming products have Electromagnetic Fields (EMFs).
What is this?
AEMF stands for Electromagnetic Field. This is an electrical field that surrounds any
wire that has current flowing along its length. Although several studies have been
conducted to evaluate the impact, EMFs have not been proven to be harmful. In
any event, Sunbeam has reduced the strength of EMFs in its blankets/mattress
pads/throws to very low levels.
QWhat do I do if my pet chews the cord, I lose my controller, or the controller does
not operate properly?
APlease stop using the warming product immediately. Call our Consumer Service
number listed under How to Obtain Warranty Service and ask for instructions on
how and where to send the warming product.
QMy control feels warm to the touch: Is this a problem?
ANo. The control will feel warm to the touch when functioning properly.
QMy warming product doesn’t operate.
AFollow instructions on the flag tag. Unplug the system from wall outlet. Check that
the control is well connected to the module. Plug the power cord into the wall
outlet to reset the control. Press “On/Off” or “On” and set at the highest setting
and wait 20 minutes. Try this twice. If the system still does not operate, disconnect
the power cord and contact consumer service at the 800 number listed under How
to Obtain Warranty Service.
QWho should NOT use the warming blanket, warming mattress pad, or warming
throw?
AThe following people should NOT use the warming blanket, warming mattress pad,
or warming throw:
• An infant
• A child
• An incapacitated person
• A paraplegic
• A quadriplegic
• A diabetic
• Anyone insensitive to heat
• Anyone who cannot clearly understand the
instructions and/or operate the controls
QWhat do the Underwriters Laboratories (UL) or (ETL) labels mean? What do either
of these labels mean about safety of Sunbeam warming products?
AUnderwriters Laboratories (UL) develops product safety standards for a large range
of products and performs independent tests based on these standards. Products
tested by UL and which have passed all the safety standards are permitted to bear
the UL label. Intertek Testing Services (ETL) is a certified, independent testing
organization that tests products in accordance with UL safety standards and issues
the ETL label for those products that meet the relevant UL standards. All Sunbeam
products are tested to UL standards and bear either the UL or ETL label to indicate
that the product meets or exceeds UL/ETL safety standards for warming products.
18
QMy warming blanket/warming mattress pad/warming
throw doesn’t heat properly.
ACheck to make sure the cord is plugged into the module
and the power cord is firmly connected to the wall outlet.
Check that the control is “On”. If the system still fails to heat, try the following
test to see if it is operating.
1Fold the warming blanket, warming mattress pad, or warming throw 3 times over.
2Connect the control to the module and plug the power cord into an outlet.
3Turn the control to the highest setting and wait five to seven minutes.
4Put your hand between the folds and you should feel the blanket/ mattress
pad/throw warming. Note: Remember, the warming product is not a heating pad.
It will not feel hot to the touch when laid out flat in a normal manner.
Caution: Do not continue the test for more than seven minutes. DO NOT attempt to
make any internal adjustments to this appliance. If you have tried all of the
solutions above and the warming product still doesn’t work, stop using it
immediately, disconnect the power cord and contact our consumer service at the 800
number listed under How to Obtain Warranty Service.
QWhat does “FF” mean on my Electronic Digital Control?
AThe digital controls are designed to notify you in the event that
a problem has been discovered by flashing “FF” on the display.
Follow instructions on the flag tag to reset control. First, check
the blanket/mattress pad for visual damage. If no visual
damage is found, unplug the system from wall outlet. Check
that the control is well connected to the module. Plug the
power cord into the wall outlet. Set the control to “On.” If the
system still does not operate after 2 or 3 times trying to reset, disconnect the
power cord and contact consumer service at 800-892-7684.
QWhat does a flashing light mean on my throw LED control or DD Gradient control?
AThe throw control and DD Gradient control is designed to notify you in the event
that a problem has been discovered by flashing the light on the display. Follow
instructions on the flag tag to reset control. First, check the blanket/mattress
pad/throw for visual damage. If no visual damage is found, unplug the system
from wall outlet. Check that the control is well connected to the module. Plug the
power cord into the wall outlet. Set the control to “On.” If the system still does not
operate after 2 or 3 times trying to reset, disconnect the power cord and contact
consumer service at 800-892-7684.
QI have experienced some shedding of the fabric fibers of my warming
blanket/warming throw, what do I do?
AShedding is normal. If it becomes bothersome, follow the use and care instructions
to wash and dry your warming blanket/warming throw.
FF
Models DD3, DD2,
DDZ, DDW
O
n
/
O
f
f
19
Sunbeam Products Inc. (“Sunbeam”) warrants that for a period stated below from
the date of purchase, this product will be free from defects in material and
workmanship.
• Warming Blankets branded Sunbeam®Imperial Court™, Elite™, Dynasty
Nights™, SlumberRest Arctic Dawn™, Nordic Dreams™, Winter Oasis™,
Basic™ and Northern Illusions™, and Sunbeam®The Blanket with a Brain®will
carry a FIVE year limited warranty.
• Warming Blankets branded Sunbeam®Select™ will carry a TWO year limited
warranty.
• Warming Blankets branded Arlington™ will carry a ONE year limited warranty.
• Warming Mattress Pads branded Sunbeam®Palace Comfort™, Winter Sunrise™
and Midnight Retreat™, SlumberRest®Midnight Sun™ and Glacial Retreat™,
and Sunbeam®The Mattress Pad with a Brain®will carry a FIVE year limited
warranty.
• Warming Mattress Pads branded Arlington™ will carry a ONE year limited
warranty.
• Warming Throws branded Sunbeam®Select™, Cuddle-Up™, SlumberRest®
Cuddler™, and Sunbeam®The Throw with a Brain® and Sunbeam®American
Heritage Collection™ will carry a TWO year limited warranty.
• Warming Throws branded Arlington ™, will carry a ONE year warranty.
Sunbeam, at its option, will repair or replace this product or any component of the
product found to be defective during the warranty period. Replacement will be made
with a new or remanufactured product or component. If the product is no longer
available, replacement may be made with a similar product of equal or greater
value. This is your exclusive warranty. This warranty is valid for the original retail
purchaser from the date of initial retail purchase and is not transferable. Keep the
original sales receipt. Proof of purchase is required to obtain warranty performance.
Sunbeam dealers, service centers, or retail stores selling Sunbeam products do not
have the right to alter, modify, or any way change the terms and conditions of this
warranty. This warranty does not cover normal wear of parts or damage resulting
from any of the following: negligent use or misuse of the product, use on improper
voltage or current, use contrary to the operating instructions, disassembly, repair or
alteration by anyone other than Sunbeam or an authorized service center. Further, the
warranty does not cover Acts of God, or Nature, such as fire, flood, hurricanes and
tornadoes. Sunbeam shall not be liable for any incidental or consequential damages
caused by the breach of any express or implied warranty. Except to the extent
prohibited by applicable law, any implied warranty of merchantability or fitness for a
particular purpose is limited in duration to the duration of the above warranty. Some
states, provinces or jurisdictions do not allow the exclusion or limitation of incidental
or consequential damages or limitations on how long an implied warranty lasts, so
the above limitations or exclusion may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that vary from state to state
or province to province.
Limited Warranty
20
How to obtain warranty service:
We’re Here to Help. For any questions you may have about your warming product, please
contact Sunbeam Consumer Service: 1-800-892-7684, or write with product questions to:
SUNBEAM CONSUMER SERVICE
P.O. Box 948389
Maitland, FL 32794-8389
or visit our web site at: www.sunbeambedding.com.
To return your product for repair or replacement:
Please attach a tag to the product (do not use pins) that includes your name, address,
daytime telephone number, and description of the problem. Please include a copy of the
original sales receipt.
Carefully package the product. Please use UPS or Parcel Post, with shipping and insurance
prepaid to: SUNBEAM PRODUCTS, INC.
Blanket Service Station
P.O. Box 469
224 Russell Drive
Waynesboro, MS 39367
DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE.
©2003 Sunbeam® is a registered trademark of Sunbeam Products, Inc.
Distributed by Sunbeam Products, Inc., 2381 Executive Center Drive, Boca Raton, FL 33431
PRODUCT REGISTRATION CARD
Complete the attached registration card and return today
to receive these 3 important benefits:
CONFIRM YOUR WARRANTY:
Your prompt product registration confirms your right to the protection available
under the terms and conditions of your Sunbeam warranty.
PROTECT YOUR PRODUCT:
We will keep the model number and date of purchase of your new Sunbeam
product on file to help you refer to this information when necessary.
HELP US DEVELOP NEW PRODUCTS:
We value your input! Your responses will help us bring you new products
specifically designed to meet your needs.
▲
▲▲
PLEASE FOLD AND SEAL WITH TAPE BEFORE MAILING. DO NOT STAPLE.
PLACE
FIRST-CLASS
STAMP
HERE
PRODUCT REGISTRATION DEPARTMENT
PO BOX 44236
DENVER CO 80201-4236
!802014236365!
Please do not send products or other
correspondence to this address.
021 T
REGISTER ONLINE AT: WWW.SUNBEAMBEDDING.COM
RPOB 9/02
1Initial:
State:
First name: Last name:
Zip code:
Address: (number and street)
City:
Apt number:
Date of your birth:
Including yourself, what is the total number of people
living in your household?
(Examples: 01, 02, 03, 04...)
Month Day Year
Date of birth (month/year) of the other adults and children in
your household:
Male Female
1.2.
1.2.
For your primary residence, do you:
1. Own 2. Rent
16
19
17
20
18
Month Year
Male Female
1.2.
1.2.
Date of purchase:
3
Education:
(Please check which category applies to you):
1. Some high school 3. College degree
2. Completed high school 4. Graduate degree
Your marital status: 1. Married 2. Single
Your gender: 1. Male 2. Female
Month Year
Month Year
Month Year
Month Day Year 15
In the last six (6) months has anyone in your household
purchased any of the following items through the mail and/or
over the internet? A. Mail B. Internet
1. Books/magazines
2. Children’s products
3. Clothes
4. Insurance/financial products
5. Music/video/DVD
6. Travel
7. Other
21
22
24
Please fill-out and return this card within 10 days! 021 T
I use these credit cards:
1. American Express 4. Visa
2. Gas/Retail 5. Other_____________
3. Master Card 6. Do not have credit cards
23
▼
▼
▼
Purchase price: $ .00
PLEASE FOLD AND SEAL WITH TAPE BEFORE MAILING. DO NOT STAPLE.
6
2E-mail address: (EXAMPLE: yourname@yourhost.com)
1. Yes! I want to receive offers or communications from Sunbeam via e-mail.
2. Yes! I want to receive offers or communications that may interest me from other companies via e-mail. I understand this e-mail address
may be shared with and/or combined with information from other sources.
Thank you! We appreciate your responses to this questionnaire. The information you choose to share with us will be used by us and our marketing partners to offer you
product information and other communications that may interest you. If you prefer not to be contacted about these special offers, please check here
Product purchased:
1. Warming blanket 3. Warming throw
2. Warming mattress pad
4
Style number:
5
Store where purchased:
7
Please describe this purchase:
1. A first time purchase
2. A replacement to this brand
3. A replacement of another brand
4. An additional purchase
5. Received as a requested gift
6. Received as a surprise gift
8
What do you consider the most important factors influencing
your decision to purchase this warming product?
1. Color/style 7. Warranty
2. Replacement of existing 8. Auto-off feature
3. Value for price 9. Large number of heat settings
4. Friend/relative’s 10. Energy savings
recommendation 11. Cold weather
5. Advertising 12. Gift for someone else
6. Brand name I trust 13. Other_______________
10
How often do you turn on/plan on turning on your warming product
(using its heating capacity)? (Check all that apply)
B. Once C. Once
A. Everyday a week a month
1. In the winter
2. In the fall
3. In the spring
4. In the summer
11
What is the approximate temperature your home thermostat is set
to through out the night during winter?
1. Under 55 4. 66-70
2. 56-60 5. 71-75
3. 61-65 6. Over 75
12
How often do you purchase this type of product?
1. Received as a gift 4. Every 4-5 years
2. First time purchase 5. Every 6-9 years
3. Every 1-3 years 6. Every 10+ years
13
Which of the following products do you have or plan to own?
1. Warming blanket 3. Electric throw
2. Warming mattress pad
14
We appreciate your responses to this questionnaire and the information you provide will be used by us and our
marketing partners to offer you product information and other communication that may interest you.
This information in no way will have an effect on your warranty terms.
How did you first learn about this product?
1. Inside the store 3. News story-public relations
2. Advertisement 4. Trusted brand
9
Someone in my home participates in the following activities:
(Check all that apply)
1. Crafts 10. Outdoor activities
2. Cultural arts/events 11. Own a pet
3. Do-it-yourself 12. Personal computing
4. Enter sweepstakes/contests 13. Read books
5. Finance/investments 14. Self improvement
6. Fitness/excercising/jogging 15. Sports
7. Gardening 16. Travel
8. Gourmet cooking 17. TV shopping
9. Home decorating 18. Watch sports on TV
RPOB 9/02
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
