Sunitec Enterprise BC010 Bluetooth Speakerphone User Manual
Sunitec Enterprise Co., Ltd. Bluetooth Speakerphone Users Manual
Users Manual
1 3
2
5
4
7
6
1. About Bluetooth Speakerphone
This versatile Bluetooth speakerphone is specially designed for the user to enjoy
the convenience and freedom of wireless communication. This truly handsfree
speakerphone has many applications in the home, oce, or car with any wireless
Bluetooth compatible technologies. It has an advanced built-in microphone
with Digital Sound Processor (DSP) solution for echo cancellation and noise
suppression that gives you impeccable full duplex sound quality.
2. About Bluetooth Technology
Bluetooth wireless technology is set to revolutionise personal connectivity by
providing freedom from wired connections - enabling links and connectivity
between notebook/laptop, mobile phones, portable handheld devices and other
Bluetooth enabled devices within 10 metres. Utilising global sound and digital
data 2.4GHz ISM transmission, it facilitates global communication in a way you
have never dreamed of!
3. Getting to Know Your Bluetooth Speakerphone
To use your Bluetooth speakerphone, please follow these simple steps:
(1) Charge your speakerphone. Prior to using the speakerphone, it is
recommended to charge the battery fully for the rst time. Normal full charge
time is 2 hrs. (approx.)
(2) Place your speakerphone and a Bluetooth-enabled device within 1 metre for
pairing.
(3) Ensure your speakerphone and Bluetooth-enabled device is placed within 10
metres during operation to ensure connectivity. (Obstructions could cause
shorter sensing distances.)
4. Appearance and Function
(1) Speaker
(2) Microphone
(3) LED
(4) Charging Socket (Micro 5-pin USB)
(5) MFB Button (Multi-Function Button)
(6) Volume Increase (V+)
talk time and the standby time) will be extended continuously without any
additional charge required by the car charger.
WARNING: Do not attempt to charge the speakerphone with any charger other
than the one provided. Using another charger may damage or destroy the
speakerphone.
7. Turning ON/OFF the Speakerphone
Power ON: When the speakerphone is in OFF mode, press and hold the “MFB” for
3 seconds until you hear a short beep. The ashing blue LED light indicator comes
on, and then the speakerphone will automatically connect to the mobile phone
which has been paired already.
Power OFF: Speakerphone is under standby mode, press and hold the “MFB”
button for 3 seconds until you hear a short beep. The flashing red LED light
indication goes o.
8. Pairing
Prior to using the speakerphone for the first time, you must pair it with a
Bluetooth-enabled device. The steps below describe pairing instructions for a
typical Bluetooth-enabled mobile phone.
(1) Place the speakerphone and mobile phone no more than 1 metre apart.
(2) Ensure the speakerphone is in the OFF mode.
(3) Press and hold the “MFB” button for 5 seconds until the LED light ashes red
and blue alternatively, indicating it is now ready for pairing.
(4) Activate the Bluetooth function on your mobile phone and search for
accessible Bluetooth devices, referring to your mobile phone user guide for
details if required.
(5) Select “BT Speaker” from the list.
(6) Enter the pre-programmed code “0000” and press “OK” to pair the
speakerphone and the mobile phone. When pairing is completed, the blue
and red LED light will stop ashing, the speakerphone is in the standby mode
with the blue LED light ashing every 3 seconds.
(7) Press “Return” to go back to your mobile phone’s main menu. Place the
mobile phone and the speakerphone within 10 metres sensing distance. You
should now be able to make and receive calls using your speakerphone.
Note: If the pairing cannot be completed within 2 minutes after the pairing mode
is activated, the speakerphone will power OFF automatically. Please repeat the
steps above to pair the speakerphone and mobile phone again.
9. Connection/Link between Speakerphone and Mobile Phone
After pairing is completed, the speakerphone is always in standby mode. Before
you place or answer a call, if the headset icon is not shown on the mobile phone
screen, please follow the steps below to activate the Bluetooth connection/link
through your mobile phone or speakerphone until the headset icon is on the
screen.
(1) On phone: Select the “BT Speaker” from the paired list on your phone screen.
(2) On speakerphone: Short press “MFB” and select “Accept” on the phone screen
to accept connection.
10. Disconnection between Speakerphone and Mobile Phone
When you need to connect your speakerphone with another Bluetooth-enabled
mobile phone, follow the steps below to disconnect the speakerphone with the
pre-paired mobile phone.
(1) Power OFF the speakerphone.
(2) Select “Disconnecting” on the Bluetooth device list of your mobile phone to
remove the connection.
Note: When losing the connection/link, the speakerphone will automatically
power OFF within 15 minutes. The blue LED light will ash twice every 3 seconds
when the speakerphone is not connected with your mobile phone.
11. Using the Speakerphone
(1) Answering a Call
When receiving a phone call, press the “MFB” button once to answer the call.
(2) Ending a Call
Press the “MFB” button once to end a call.
(3) Reject a Call
When you hear the ringing tone, press and hold the “MFB” button for 3
seconds to reject the call.
(4) Voice Dial
If your mobile phone has voice dialing enabled, in standby mode, press the
“MFB” button once and say the voice tag after you hear a beep.
Note: Please make sure to record voice tag into the mobile phone before
When power on the speakerphone, it will automatically search and connect
the last 2 mobile phones that have been connected before.
(4) Reject the Second mobile phone Call
When receiving a second call, press and hold the “MFB” button for 3 seconds
to reject the second mobile phone call.
(5) Answer the Second mobile phone Call
When receiving a second call, press “MFB” button once to end the rst mobile
phone call and answer the second mobile phone call.
13. Low Voltage Protection of Battery
When the voltage of the battery has decreased to 3.3V, the red LED light will ash
every 3 seconds, and the speakerphone will power OFF automatically when the
voltage is under 3.0V.
14. Restore to Default Setting
Please follow the steps below to reset the speakerphone to its original settings
and remove all the previous pairing and connections.
(1) Ensure the speakerphone is in standby mode.
(2) Press and hold both “V+” and “V-” buttons simultaneously for 10 seconds until
the blue and red LED lights ash 5 times, then the speakerphone will resume
standby mode. The speakerphone is now back to it’s original settings, and
after powering ON, the speakerphone will enter pairing mode automatically.
Note: If the speakerphone is connected with a mobile phone before restoring the
default settings, it will enter pairing mode automatically after restored to default.
If the speakerphone is not connected with the mobile phone before restoring the
default settings, it will be in standby mode after restoring the default settings.
15. LED Light Indicators
Speakerphone Status LED Indicator
Power OFF Mode OFF
Power ON Blue LED ash 3 seconds
Power OFF Red LED ash 3 seconds
Standby Mode Blue LED ash once every 3 seconds
using voice dial function. Functionality varies depending on the mobile
phone model. Please refer to your mobile phone user guide for details.
(5) Last Number Re-Dialing
In standby mode, press the “MFB” button twice for last number dialed.
(6) Adjusting the Volume
During a call, press the “V+” or “V-” buttons repeatedly until you reach the
desired volume level.
(8) Transferring Calls
a: Speakerphone to Mobile Phone: During a call, press both “V+” and “V-”
buttons simultaneously, and the call is routed to your mobile phone.
b: Mobile Phone to Speakerphone: Press both “V+” and “V-” buttons
simultaneously to route the call back to the speakerphone.
12. MultiPoint Feature
(1) Activate Multipoint Connection
The default setting of the speakerphone’s multipoint function is OFF. You can
activate the multipoint function for connecting with 2 mobile phones at the
same time.
a. Multipoint ON: Under standby mode, press and hold “V+” button for 3
seconds until you hear a beep.
b. Multipoint OFF: Under standby mode, press and hold “V-” button for
3 seconds until you hear a beep. The speakerphone will turn off the
multipoint function and power off automatically. When power on the
speakerphone again, it will only connect to the last connected Bluetooth
device.
(2) Multipoint Pairing
a. First mobile phone: Pair the speakerphone with one of the Bluetooth-
enabled mobile phones.
b. Second mobile phone: Power OFF the speakerphone. Press and hold
the “MFB” button for 5 seconds to enter pairing mode again to pair and
connect with the second mobile phone.
c. Connect with the rst paired mobile phone to the speakerphone.
(3) Multipoint Connection/Link with 2 Mobile Phones
After the multipoint function is activated, please follow the steps below to
connect with 2 Bluetooth enabled mobile phones at the same time.
Standby (Disconnect Bluetooth
Device) Blue LED ash twice every 3 seconds
Standby-Low Voltage Red LED ash once every 3 seconds
Talk in progress Blue LED ash once every 6 seconds
Pairing in progress The red and blue LED ash on
alternatively
Charging in progress Red LED steady on
Charging completed O
16. Product Specication
Bluetooth Compliance: Bluetooth V2.1+EDR
Operating Frequency Band: 2.4GHz ~ 2.48GHz unlicensed ISM band
Output Power: Class 2, up to 10 meters
Support Proles: HSP and HFP Proles
Support Multiple Paired Device: Memorize paired data of 8 Bluetooth phones
Stand-by Time: Up to 1000 hours / 41 days
Talk Time: Up to 5 hours
Battery Charging Time: About 2 hours, Using solar power about 9 hours
Charger Voltage: DC5.0V, 400mA
Battery: 3.7V 340mA (Rechargeable Li-ion Polymer)
Size: 100L x 48W x 11D mm
Weight: TBD
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
You are cautioned that changes or modications not expressly approved by the
part responsible for compliance could void the user's authority to operate the
equipment.
Sunitec Enterprise Co., Ltd
(7) Volume Decrease (V-)
(8) Solar Panel
5. Recommend Installation Position
It is recommended that the speakerphone is positioned on to the top of the left
side of the windshield as shown in the pictures below:
WARNING: Do not place or store the speakerphone over the area of the
automobiles safety airbag deployment, or it may cause serious injury when a
safety airbag deploys.
6. Charging Your Bluetooth Speakerphone
The Bluetooth speakerphone comes with a built-in rechargeable battery. Prior to
using the speakerphone, it is recommended to charge the battery fully for the rst
time.
Using the car charger
• InsertthecarchargercompletelyintothechargingslotuntiltheLEDash
red, and the speakerphone will be powered o automatically after connected
with charger.
• Normalfullchargetimeis2hours.(approx.),andtheLEDwillashowhen
charge is completed.
Using solar power
• Directthesolarpanelonthebacksideofthespeakerphonetowardsun.
(Please refer to the recommended installation position, as mentioned above.)
• Ifthespeakerphonereceivessucientsunlightfor2hours,youcantalkfor
duration of up to 1 hour. Using solar power charge, the operation time (the
"SOLAR-POWERED"
MULTIPOINT
SPEAKERPHONE
User Manual
BC962S
(1) (7)
(8)
(6)
(3)/(5)
(4)
(2)
2 3 4
5
1
