Sunrex Technology Corp Multi Laser Presenter ML0304
User Manual
ML0304 User Manual
HOW TO USE THE LASER PRESENTER
1. Insert the receiver into the USB port of PC.
2. Your PC operation system will start to install the device
automatically .And you can see the information as below display in your
computer.
3. In Win98/Me operation system you need to follow the instructions on
your screen .During the install process, the O/S may ask you to put
Win98 CD into the CD-ROM.
4. After the installation process is done,the presenter will start
working .
Better than other competition:
1. NO direction and NO level speed precise control.
2. RF (315 or 433 or 900MHZ), Any angle ,reachable distance up to 7 Meters.
3. 256 ID sets and RF-technique to Anti-interference .
4. No matter what PC Off or Battery Out ,The ID will not be loss.
5. Add Page-Up Page-Down Key .
Notice : For trouble shooting
If the presenter is not working :
1. Maybe the battery power is too low , please check your battery .
2. Maybe ID code was not matched ,please link ID.
(1).push the button on receiver side then press “left button” + “right
button” within 10 SEC after the receiver ID button was pressed on the
transmitter side.
Laser Pointer
(1).VR-mouse
(2).mouse middle key
Mouse right key
Page up
Mouse left key
Page down
Laser key
CAUTION
LASER RADIATION. DO NOT STARE INTO THE BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
CLASS II LASER PRODUCT.
NEVER POINT A LASER BEAM INTO A PERSON’S EYES OR VIEW A LASER BEAM DIRECTLY, AS
PROLONGED EXPOSURE CAN BE HAZARDOUS TO THE EYES. MOMENTARY EXPOSURE FROM A LASER
POINTER, SUCH AS AN INADVERTENT SWEEP OF THE LIGHT ACROSS A PERSON'S EYES, MAY CAUSE
TEMPORARY FLASH BLINDNESS SIMILAR TO THE EFFECT OF A CAMERA FLASH BULB. ALTHOUGH THIS
CONDITION IS TEMPORARY, IT CAN BECOME MORE DANGEROUS IF THE EXPOSED PERSON IS ENGAGED
IN A VISION-CRITICAL ACTIVITY SUCH AS DRIVING.
Specifications
Electrical/Presenter
Interface USB
Buttons Mouse (3), Laser (1), Function (1)
Channel Number One
ID Number 256
Battery life Up to 60 days
Input power Two AAA batteries (3 Volt, DC)
Transmission Radio Frequency
Modulation frequency 433 MHz (Europe/Australia) 900 MHz (North America)
Effective distance Up to 23.1 feet (7 m)
Power consumption Mouse – 10 mA, Laser – 18 mA
Standby Mode 0.6 mA (60 mins)
Sleep Mode 10 uA
Compatibility Fully Compatible with PC/AT
Compatibility software Windows® 98/Me/2000/XP operating system
Laser wavelength at
peak emission 645-665 nm
Laser Spot size at
16.5 feet (5 m)
Laser Cw output power 3.5 mW (maximum)
Weight (without battery) 2.1 ounces (60 g)
Dimensions (L x W x H) 5.1 inch x 1.9 inch x 1.3 inch (130 x 47 x 32 mm)
Receiver
Interface USB
Power DC 5V, 500mA Max
Button ID Setting
Weight 0.42 ounces (12 g)
Dimension (L x W x H) 3.15 inch x 0.86 inch x 0.47 inch (80 x 22 x 12 mm)
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the authority to operate
equipment.
