Symbol Technologies 4111CDMA Data Terminal with 3 Radios User Manual Professional Letter

CDMA User Positions

SYMBOL TECHNOLOGIES. Symbol Place, Winnersh Triangle, Berkshire, England RG41 5TP

Telephone: +44 (0) 118 945 7000 Fax: +44 (0) 118 945 7500

Web site: www.symbol.com

Registered Office:

Symbol Place, Winnersh Triangle, Berkshire RG41 5TP

Registration No. 1096253 - England

MB/4111-CDMA/Position

EMEA Division

6th January 2004

BABT

34 Molesey Road

WALTON-ON-THAMES

Surrey

KT12 4RQ

4111-CDMA Hand held Data terminal

The 4111-CDMA is a ‘hand held’ data terminal, as per its description it is designed to be

used in the hand.

UPS-BCS5000: Belt Clip

The UPS-BCS5000 is a ‘belt clip’ (Fig 1). The terminal and belt clip is attached to the users

belt as shown in fig 2.

Fig 1

Fig 2

z Page 2 January 7, 2004

UPS-POUCH5000: Holster

The UPS-POUCH5000 is a ‘holster’ designed to be attached the users using the belt clip

located at the rear of the holster (Fig 3). The terminal is placed in the pouch when not in

use (Fig 4).

Fig 3

Fig 4

I trust this clarifies the terminal position

Yours sincerely,

Marco Belli

Symbol Regulatory Compliance
