Symbol Technologies 4111CDMA Data Terminal with 3 Radios User Manual

Symbol Technologies Inc Data Terminal with 3 Radios

Regulatory guide

DIAD IV Terminal
Regulatory Information
Patents
This product is covered by one or more of the following U.S. and foreign Patents:
U.S. Patent No. 4,593,186; 4,603,262; 4,607,156; 4,652,750; 4,673,805; 4,736,095;
4,758,717; 4,760,248; 4,806,742; 4,816,660; 4,845,350; 4,896,026; 4,897,532; 4,923,281; 4,933,538;
4,992,717; 5,015,833; 5,017,765; 5,021,641; 5,029,183; 5,047,617; 5,103,461; 5,113,445; 5,130,520;
5,140,144; 5,142,550; 5,149,950; 5,157,687; 5,168,148; 5,168,149; 5,180,904; 5,216,232; 5,229,591;
5,230,088; 5,235,167; 5,243,655; 5,247,162; 5,250,791; 5,250,792; 5,260,553; 5,262,627; 5,262,628;
5,266,787; 5,278,398; 5,280,162; 5,280,163; 5,280,164; 5,280,498; 5,304,786; 5,304,788; 5,306,900;
5,324,924; 5,337,361; 5,367,151; 5,373,148; 5,378,882; 5,396,053; 5,396,055; 5,399,846; 5,408,081;
5,410,139; 5,410,140; 5,412,198; 5,418,812; 5,420,411; 5,436,440; 5,444,231; 5,449,891; 5,449,893;
5,468,949; 5,471,042; 5,478,998; 5,479,000; 5,479,002; 5,479,441; 5,504,322; 5,519,577; 5,528,621;
5,532,469; 5,543,610; 5,545,889; 5,552,592; 5,557,093; 5,578,810; 5,581,070; 5,589,679; 5,589,680;
5,608,202; 5,612,531; 5,619,028; 5,627,359; 5,637,852; 5,664,229; 5,668,803; 5,675,139; 5,693,929;
5,698,835; 5,705,800; 5,714,746; 5,723,851; 5,734,152; 5,734,153; 5,742,043; 5,745,794; 5,754,587;
5,762,516; 5,763,863; 5,767,500; 5,789,728; 5,789,731; 5,808,287; 5,811,785; 5,811,787; 5,815,811;
5,821,519; 5,821,520; 5,823,812; 5,828,050; 5,848,064; 5,850,078; 5,861,615; 5,874,720; 5,875,415;
5,900,617; 5,902,989; 5,907,146; 5,912,450; 5,914,478; 5,917,173; 5,920,059; 5,923,025; 5,929,420;
5,945,658; 5,945,659; 5,946,194; 5,959,285; 6,002,918; 6,021,947; 6,029,894; 6,031,830; 6,036,098;
6,047,892; 6,050,491; 6,053,413; 6,056,200; 6,065,678; 6,067,297; 6,082,621; 6,084,528; 6,088,482;
6,092,725; 6,101,483; 6,102,293; 6,104,620; 6,114,712; 6,115,678; 6,119,944; 6,123,265; 6,131,814;
6,138,180; 6,142,379; 6,172,478; 6,176,428; 6,178,426; 6,186,400; 6,188,681; 6,209,788; 6,209,789;
6,216,951; 6,220,514; 6,243,447; 6,244,513; 6,247,647; 6,308,061; 6,250,551; 6,295,031; 6,308,061;
6,308,892; 6,321,990; 6,328,213; 6,330,244; 6,336,587; 6,340,114; 6,340,115; 6,340,119; 6,348,773;
6,380,949; 6,394,355; D305,885; D341,584; D344,501; D359,483; D362,453; D363,700; D363,918;
D370,478; D383,124; D391,250;
D405,077; D406,581; D414,171; D414,172; D418,500; D419,548; D423,468; D424,035;
D430,158; D430,159; D431,562; D436,104.
Invention No. 55,358; 62,539; 69,060; 69,187, NI-068564 (Taiwan); No. 1,601,796; 1,907,875; 1,955,269
(Japan); European Patent 367,299; 414,281; 367,300; 367,298; UK 2,072,832; France 81/03938; Italy
1,138,713
rev. 06/02 2003 SYMBOL TECHNOLOGIES, INC. All rights reserved.
Symbol and UPS’ rights and obligations with relation to the DIAD IV product,
including without limitation product liability and license grants, will be in
accordance with Purchase Agreements number: 2001 - 11204 - 01, 2001 -
11204 - 02 and 2001 - 11204 - 03, dated February 13, 2003.
Symbol reserves the right to make changes to any product to improve reliability,
function, or design.
Symbol and the Symbol logo are registered trademarks of Symbol Technologies,
Inc. Other product names mentioned in this manual may be trademarks or
registered trademarks of their respective companies and are hereby
acknowledged.
Symbol Technologies, Inc.
One Symbol Plaza
Holtsville, N.Y. 11742-1300
http://www.symbol.com
72-63596-01
Revision B — September 2003
For Vehicle installations and use
1. An air bag inflates with great force. DO NOT place objects, including ei-
ther installed or portable wireless equipment, in the area over the air bag
or in the air bag deployment area. If in-vehicle wireless equipment is im-
properly installed and the air bag inflates, serious injury could result.
2. Position your device within easy reach. Be able to access your device
without removing your eyes from the road.
3. Do not take notes or use the device while driving to the point of distracting
from driving. Reading or Jotting down text takes attention away from your
primary responsibility, driving safely.
Cell Phone/Terminal Warnings
Effect on Vehicles
RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles (including safety systems). Check with the
manufacturer or its representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has been added to your vehicle.
Safety on Aircraft
You are required to switch OFF mobile phones when on board an aircraft as
operation may be dangerous and illegal.
Pacemakers
It is recommended by pacemaker manufacturers that a minimum of 15cm (6
inches) be maintained between a handheld wireless phone and a pacemaker to
avoid any possible interference with the pacemaker. These recommendations
are consistent with independent research and recommendations by Wireless
Technology Research.
Persons with Pacemakers:
• Should ALWAYS keep the device more than 15cm (6 inches) from their
pacemaker when turned ON
• Should not carry the device in a breast pocket
• Should use the ear furthest from the pacemaker to minimise the potential
for interference.
• If you have any reason to suspect that interference is taking place, turn
OFF your device.
Regulatory Information
All Symbol devices are designed to be compliant with rules and regulations in the
countries listed in sections 4.5 of Exhibit 2 of the Agreement and will be labeled as
required.
Any changes or modifications to Symbol Technologies equipment, not expressly
approved by Symbol Technologies, could void the user's authority to operate the
equipment.
Antenna's, use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could cause damage and
may violate regulations.
Radio Modules
This device contains approved radio modules. These modules are identified below.
• Symbol Compact Flash RLAN (11Mbps DSSS) radio card, Type: LA-4137
• Motorola Triband GSM GPRS G18 module, or Motorola CDMA C18 module
• Symbol Bluetooth Module, Type: 21-58466
This device incorporates the International Roaming feature (IEEE802.11d) which will
ensure the product operates on the correct channels for the particular country of use.
This device contains a Bluetooth qualified module, Bluetooth ID: B01039
Health and Safety Recommendations
Ergonomic Recommendations
Caution: Even the best-designed products can be a potential source of injury/illness
if used incorrectly. In order to avoid or minimize risk of ergonomic injury, follow the
general recommendations below. Consult with your local Health & Safety Manager
to ensure that you are meeting your company’s safety programs to prevent employee
injury.
• Reduce or eliminate repetitive motion
• Maintain a neutral posture and avoid awkward positions
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Avoid static exertions
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures
• Take periodic rest breaks.
Hearing Aids
The device may interfere with some hearing aids. In the event of interference
you may want to consult your hearing aid supplier to discuss solutions.
Other Medical Devices
The device transmits radio frequency energy and has the potential to interfere
with inadequately protected medical devices. Consult your physician or the
manufacturer of the device to see if the particular device has sufficient
protection.
It is good practice to turn OFF the device within a hospital or other medical
facility where sensitive medical equipment is in use. In some countries, this is
a legal requirement applying to all mobile phones and related equipment.
Warning Notices
Please observe all warning notices with regard to the usage of mobile phones
and/or terminals.
Potentially Hazardous Atmospheres
You are advised not to use this device at a refuelling point. You are reminded
of the need to observe restrictions on the use of radio devices in fuel depots,
chemical plants etc. and areas where the air contains chemicals or particles
(such as grain, dust, or metal powders) and any other area where you would
normally be advised to turn off your vehicle engine.
FCC RF Exposure Guidelines
Safety Information
The device complies with Internationally recognised standards
covering Specific Absorption Rate (SAR) related to human exposure to
electromagnetic fields from radio devices.
Reducing RF Influence - Use Properly
It is advisable to use the device only in the normal operating position.
Handheld Devices:
This device was tested for typical body-worn operation. The use of third-party
belt-clips, holsters, and similar accessories should not contain metallic
components in its assembly. The use of these accessories that do not satisfy
these requirements may not comply with FCC RF exposure compliance
requirements, and should be avoided.
Laser Devices
Symbol devices using lasers comply with US 21CFR1040.10, and
IEC825-1:1993, EN60825-1:1994+A11:1996. The laser classification
is marked on one of the labels on the device.
Class 1 Laser devices are not considered to be hazardous when used for their
intended purpose. The following statement is required to comply with US and
international regulations:
Caution: Use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous laser light exposure.
Class 2 laser scanners use a low power, visible light diode. As with any very
bright light source, such as the sun, the user should avoid staring directly into
the light beam. Momentary exposure to a Class 2 laser is not known to be
Statement of Compliance
Symbol Technologies, Inc., hereby, declares that this device is in compliance with
the essential requirements and other relevant provisions of Directives 1999/5/EC
,
89/336/EEC and 73/23/EEC. Declaration of Conformities may be obtained from
http://www2.symbol.com/doc/
Other Countries:
Mexico - Restrict Frequency Range to: 2.450 - 2.4835 GHz.
Israel - Restrict Frequency Range to: 2.418 - 2.457 GHz.
Sri Lanka - Restrict Frequency Range to: 2.400 - 2.430 GHz.
S
canner Labeling
In accordance with Clause 5, IEC 825 and EN60825, the following information
is
provided to the user:
ENGLISH
HEBREW
CLASS 1 CLASS 1 LASER PRODUCT
CLASS 2 LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
DANISH / DANSK ITALIAN / ITALIANO
KLASSE 1 KLASSE 1 LASERPRODUKT CLASSE 1 PRODOTTO AL LASER DI CLASSE 1
KLASSE 2 LASERLYF CLASSE 2 LUCE LASER
SE IKKE IND I STRÅLEN NON FISSARE IL RAGGIOPRODOTTO
KLASSE 2 LASERPRODUKT AL LASER DI CLASSE 2
DUTCH / NEDERLANDS NORWEGIAN / NORSK
KLASSE 1 KLASSE-1 LASERPRODUKT KLASSE 1 LASERPRODUKT, KLASSE 1
KLASSE 2 LASERLICHT KLASSE 2 LASERLYS IKKE STIRR INN I LYSSTRÅLEN
NIET IN STRAAL STAREN LASERPRODUKT, KLASSE 2
KLASSE-2 LASERPRODUKT
FINNISH / SUOMI PORTUGUESE / PORTUGUÊS
LUOKKA 1 LUOKKA 1 LASERTUOTE CLASSE 1 PRODUTO LASER DA CLASSE 1
LUOKKA 2 LASERVALO CLASSE 2 LUZ DE LASER NÃO FIXAR O RAIO
LUMINOSO
ÄLÄ TUIJOTA SÄDETTÄ PRODUTO LASER DA CLASSE 2
LUOKKA 2 LASERTUOTE
FRENCH / FRANÇAIS SPANISH / ESPAÑOL
CLASSE 1 PRODUIT LASER DE CLASSE 1 CLASE 1 PRODUCTO LASER DE LA CLASE 1
CLASSE 2 LUMIERE LASER CLASE 2 LUZ LASER
NE PAS REGARDER LE RAYON FIXEMENT NO MIRE FIJAMENTE EL HAZ
PRODUIT LASER DE CLASSE 2 PRODUCTO LASER DE LA CLASE 2
GERMAN / DEUTCH SWEDISH / SVENSKA
KLASSE 1 LASERPRODUKT DER KLASSE 1 KLASS 1 LASERPRODUKT KLASS 1
KLASSE 2 LASERSTRAHLEN KLASS 2 LASERLJUS STIRRA INTE MOT STRÅLEN
NICHT DIREKT IN DEN LASERSTRAHL SCHAUEN LASERPRODUKT KLASS 2
LASERPRODUKT DER KLASSE 2
Radio Frequency Interference Requirements - FCC
Note: This equipment has been tested and found to comp
ly
with the limits for a Class B digital device, pursuant to Part 1
5
of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. Howev
er
there is no guarantee that interference will not occur in a particular installation.
If
this equipment does cause harmful interference to radio or television receptio
n,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to th
e
following two conditions: (1) this device may not cause harmful interference, an
d
(2) this device must accept any interference received, including interference th
at
may cause undesired operation.
Radio Frequency Interference Requirements - Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
Radio Transmitters
This device complies with RSS 210 of Industry & Science Canada. Operation
is
subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received, includin
g
interference that may cause undesired operation.
Label Marking: The Term "IC:" before the radio certification only signifies that
Industry Canada technical specifications were met.
Marking and European Economic Area (EEA)
The use of 2.4GHz RLAN's, for use through the EEA, have the
following restrictions:
• Maximum radiated transmit power of 100 mW EIRP in the frequency rang
e
2.400 -2.4835 GHz
• France, equipment is restricted to 2.4465 -2.4835 GHz frequency range
• Belgium outside usage, the equipment is restricted to 2.460 -2.4835 GHz
frequency range
• Italy requires a user license for outside usage.
Bluetooth for use through the EEA have the following restrictions:
• Maximum radiated transmit power of 10mW EIRP in the frequency range
2.400 -2.4835 GHz
• Belgium outside usage, the equipment is restricted to 2.460 -2.4835 GHz
frequency range
• Italy requires a user license for outside usage

Navigation menu
