MC9000-G Quick Start Guide
http://www.symbol.com/mc9000g
See Product Reference Guide for more information
Trigger
Strap Lanyard
Cable Adapter Module Magnetic Stripe Reader
Stylus
Stored in handle
Battery Insertion
Stylus Removal
Snap-on Accessory Installation
Charging Instructions
Microphone
Optional
Headphone
Jack
Optional
Display
Data
Slow Flash = Normal Charge
= LED Indicator Location
Solid Amber = Full Charge Fast Flash = Charging Error
Power
Data
Power
POST IN WORK AREAPOST IN WORK AREA
Four Slot Spare Battery Charger Single Slot Serial Cradle Four Slot Cradles
Charge-Only Cradle and Ethernet Cradle
Power
Indicator LED Bar
Scan Button
Keypad
