Regulatory Information for Symbol MC9090
Rev 8.0 4thMarch 2005
1. Regulatory Information
All Symbol devices are designed to be compliant with rules and regulations in locations they are sold
and will be labeled as required.
Regulatory Information is available in French, Italian, German, Spanish (Spain), Portuguese,
Japanese, Korean, Russian and simplified Chinese. Please see following website:
http://www.symbol.com/services/manuals/ and look for your specific product.
Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol
Technologies, could void the user’s authority to operate the equipment.
CAUTION:
Only use Symbol approved and UL Listed accessories, battery packs and battery chargers.
Do NOT attempt to charge damp/wet mobile computers or batteries. All components must be dry
before connecting to an external power source.
Radio Modules
The device contain approved radio module(s). These module(s) are identified below.
Symbol Modular RLAN radio card, Type:21-21160
Symbol MC9090 Bluetooth radio, Type: MC9090
Products equipped with Bluetooth® Wireless Technology
This product contains Bluetooth Complimentary Subsystems:
BT ID:Bxxxxx
BT ID:Bxxxxx
2. Country Approvals
Regulatory markings are applied to the device signifying the radio (s) are approved for use in the
following countries: United States, Canada, Australia, Japan and Europe 1,2.
Please refer to the Symbol Declaration of Conformity (DoC) for details of other country markings.
This is available at http://www2.symbol.com/doc/.
Note 1: For 2.4GHz Products: Europe includes, Austria, Belgium, Czech Republic, Croatia, Cyprus,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovak
Republic, Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
Note 2: The use of 5GHz RLAN’s has varying restrictions of use; please refer to the Symbol
Declaration of Conformity (DoC) for details.
Operation of the device without regulatory approval is illegal.
![](/img.php?id=550254&img=bg2.png)
Regulatory Information for Symbol MC9090
Rev 8.0 4thMarch 2005
3. Health and Safety Recommendations
Ergonomic Recommendations
Caution: In order to avoid or minimize the potential risk of ergonomic injury follow the
recommendations below. Consult with your local Health & Safety Manager to ensure that you are
adhering to your company’s safety programs to prevent employee injury.
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
Vehicle Installation
RF signals may affect improperly installed or inadequately shielded electronic systems in motor
vehicles (including safety systems). Check with the manufacturer or its representative regarding your
vehicle. You should also consult the manufacturer of any equipment that has been added to your
vehicle.
An air bag inflates with great force. DO NOT place objects, including either installed or portable
wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle
wireless equipment is improperly installed and the air bag inflates, serious injury could result.
Position your device within easy reach. Be able to access your device without removing your eyes
from the road.
Note: Connection to an alert device that will cause a vehicle horn to sound or lights to flash, on
receipt of a call on public roads, is not permitted.
Safety on the Road
Do not take notes or use the device while driving. Jotting down a “to do” list or flipping through your
address book takes attention away from your primary responsibility, driving safely.
When driving a car, driving is your first responsibility - Give full attention to driving. Check the laws
and regulations on the use of wireless devices in the areas where you drive. Always obey them.
![](/img.php?id=550254&img=bg3.png)
Regulatory Information for Symbol MC9090
Rev 8.0 4thMarch 2005
Warni Warnings for Use of Wireless Devices
Please observe all warning notices with regard to the usage of wireless devices.
Potentially Hazardous Atmospheres
You are reminded of the need to observe restrictions on the use of radio devices in fuel depots,
chemical plants etc. and areas where the air contains chemicals or particles (such as grain, dust, or
metal powders) and any other area where you would normally be advised to turn off your vehicle
engine.
Safety in Aircraft
Switch off your wireless device whenever you are instructed to do so by airport or airline staff. If your
device offers a ‘flight mode’ or similar feature, consult airline staff as to its use in flight.
Pacemakers
Pacemaker manufacturers recommended that a minimum of 15cm (6 inches) be maintained between
a handheld wireless device and a pacemaker to avoid potential interference with the pacemaker.
These recommendations are consistent with independent research and recommendations by
Wireless Technology Research.
Persons with Pacemakers:
• Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned
ON
• Should not carry the device in a breast pocket
• Should use the ear furthest from the pacemaker to minimise the potential for interference.
• If you have any reason to suspect that interference is taking place, turn OFF your device
Other Medical Devices
Please consult your physician or the manufacturer of the medical device, to determine if the operation
of your wireless product may interfere with the medical device.
FCC / EU RF Exposure Guidelines
Safety Information
The device complies with Internationally recognised standards covering Specific Absorption Rate
(SAR) related to human exposure to electromagnetic fields from radio devices.
Reducing RF Exposure – Use Properly
It is advisable to use the device only in the normal operating position.
Regulatory Information for Symbol MC9090
Rev 8.0 4thMarch 2005
Handheld Devices
This device was tested for typical body-worn operation. Use only Symbol tested and approved belt-
clips, holsters, and similar accessories to ensure FCC Compliance. The use of third-party belt-clips,
holsters, and similar accessories may not comply with FCC RF exposure compliance requirements,
and should be avoided. A minimum separation distance of 2.5 cm or more from a person’s body
should be maintained.
![](/img.php?id=550254&img=bg5.png)
Regulatory Information for Symbol MC9090
Rev 8.0 4thMarch 2005
4. Laser Devices
Complies with 21CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50,
dated July 26, 2001.
EN60825-1:1994+ A1:2002 +A2:2001
IEC60825-1:1993+A1:1997+A2:2001
The laser classification is marked on one of the labels on the device.
Class 1 Laser devices are not considered to be hazardous when used for their intended purpose. The
following statement is required to comply with US and international regulations:
Caution: Use of controls, adjustments or performance of procedures other than those specified
herein may result in hazardous laser light exposure.
Class 2 laser scanners use a low power, visible light diode. As with any very bright light source, such
as the sun, the user should avoid staring directly into the light beam. Momentary exposure to a Class
2 laser is not known to be harmful.
LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
LUMIÈRE LASER
NE PAS REGARDER DANS LE
FAISCEAU
APPAREIL À LASER DE CLASSE 2
![](/img.php?id=550254&img=bg6.png)
Regulatory Information for Symbol MC9090
Rev 8.0 4thMarch 2005
5. Power Supply
Use only a Symbol approved power supply 50-14000-148 output rated 12 Vdc and minimum
3.33 A. The power supply is certified to EN60950-1 with SELV outputs. Use of alternative power supply will
invalidate any approval given to this device and may be dangerous.
6. Batteries
Please follow the local regulations when disposing of re-chargeable batteries.
Taiwan - Recycling
EPA (Environmental Protection Administration) requires dry battery producing or importing firms in accordance
with Article 15 of the Waste Disposal Act are required to indicate the recycling marks on the batteries used in
sales, giveaway or promotion. Contact a qualified Taiwanese recycler for proper battery disposal.
8. Wireless Devices –Countries
Country Roaming
This device incorporates the International Roaming feature (IEEE802.11d) which will ensure the
product operates on the correct channels for the particular country of use.
Ad-Hoc Operation
Ad-Hoc operation is limited to Channels 36-48 (5150-5250 MHz). Use of this band is restricted to
Indoor Use Only, any other use will make the operation of this device illegal.
9. Radio Frequency Interference Requirements-FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
10. Radio Frequency Interference Requirements – Canada
Radio Transmitters
This device complies with RSS 210 of Industry & Science Canada. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Label Marking: The Term "IC:" before the radio certification only signifies that Industry Canada
technical specifications were met.
![](/img.php?id=550254&img=bg7.png)
Regulatory Information for Symbol MC9090
Rev 8.0 4thMarch 2005
11. Marking and European Economic Area (EEA)
The use of 2.4GHz RLAN’s, for use through the EEA, have the following restrictions:
• Maximum radiated transmit power of 100 mW EIRP in the frequency range 2.400 -2.4835 GHz
• France, outside usage is restricted to 2.4 – 2.454 GHz.
• Italy requires a user license for outside usage.
The use of 5GHz RLAN’s has varying restrictions for use within the EEA; please refer to the Symbol
Declaration of Conformity (DoC) for details at http://www2.symbol.com/doc/
Bluetooth® Wireless Technology for use through the EEA has the following restrictions:
• Maximum radiated transmit power of 100mW EIRP in the frequency range 2.400 -2.4835 GHz
• France, outside usage is restricted to 10mW EIRP
• Italy requires a user license for outside usage.
Statement of Compliance
Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential
requirements and other relevant provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC.
Declaration of Conformities may be obtained from http://www2.symbol.com/doc/
Other Countries
Mexico - Restrict Frequency Range to: 2.450 - 2.4835 GHz.
Sri Lanka- Restrict Frequency Range to: 2.400 – 2.430 GHz.
