Motorola reserves the right to make changes to any product to improve
reliability, function, or design.
Motorola does not assume any product liability arising out of, or in
connection with, the application or use of any product, circuit, or
application described herein.
No license is granted, either expressly or by implication, estoppel, or
otherwise under any patent right or patent, covering or relating to any
combination, system, apparatus, machine, material, method, or
process in which Motorola products might be used. An implied license
exists only for equipment, circuits, and subsystems contained in
Motorola products.
Warranty
For the complete Motorola hardware product warranty statement, go
to:http://www.motorola.com/enterprisemobility/warranty.
Patents
This product is covered by one or more patents. For patent information
go to: http://www.motorola.com/enterprisemobility/patents.
Service Information
If you have a problem using the equipment, contact your facility’s
Technical or Systems Support. If there is a problem with the
equipment, they will contact the Motorola Enterprise Mobility Support
at: http://www.motorola.com/enterprisemobility/contactsupport.
For the latest version of this guide go to:
http://www.motorola.com/enterprisemobility/manuals.
Motorola, Inc.
One Motorola Plaza
Holtsville, New York 11742, USA
1-800-927-9626
http://www.motorola.com/enterprisemobility
MOTOROLA and the Stylized M Logo and Symbol and the Symbol logo are
registered in the U.S. Patent and Trademark Office. All other product or
service names are the property of their respective owners.
© Motorola, Inc. 2009
72-132871-01 Revision A — December 2009
Regulatory Guide
MC9090-G RFID
Microsoft® CE® and Windows Mobile® 6 .1
Regulatory Information
This device is approved under the Symbol Technologies brand:
Symbol Technologies, Inc., is the Enterprise Mobility business of
Motorola, Inc. (“Motorola”).
All Motorola/Symbol devices are designed to be compliant with
rules and regulations in locations they are sold and will be labeled
as required.
Local language translations are available at the following website:
http://support.symbol.com
Any changes or modifications to Motorola/Symbol Technologies
equipment, not expressly approved by Motorola/Symbol
Technologies, could void the user’s authority to operate the
equipment.
Radio Devices
This device is an approved radio product. Model: MC9090.
Model Nos: for Regulatory Certifications:
MC9090R1 – Frequency 865.7-867.5 MHz
MC9090R6 – Frequency 902-928 MHz Max
MC9090R8 – Frequency 869.4-869.65 MHz
MC9090R6CN – For China
Bluetooth® Wireless Technology
This device can contain the following Bluetooth® qualified
subsystems:
• BTID: B01825
• BTID: B02413
Power Supply
Use only a Motorola approved power supply, output rated 12 Vdc
and minimum 3.33 A. The power supply is certified to EN60950-1
with SELV outputs. Use of alternative power supply will invalidate
any approval given to this device and may be dangerous.
Wireless Device Country Approvals
Regulatory markings, subject to certification, are applied to the
device signifying the radio(s) is/are approved for use in the
following countries: United States, Canada and Europe 1,2.
Please refer to the Symbol Declaration of Conformity (DoC) for
details of other country markings. This is available at
http://www2.symbol.com/doc/.
Note1: For 2.4GHz or 5GHz Products: Europe includes, Austria,
Belgium, Bulgaria, Czech Republic, Cyprus, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland,
Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta,
Netherlands, Norway, Poland, Portugal, Romania, Slovak
Republic, Slovenia, Spain, Sweden, Switzerland and the United
Kingdom.
Note 2: The use of RFID Devices have varying restrictions of use;
please refer to the Motorola/Symbol Declaration of Conformity
(DoC) for details.
Country Roaming
This device incorporates the International Roaming feature
(IEEE802.11d) which will ensure the product operates on the
correct channels for the particular country of use.
Ad-Hoc Operation (802.11a Only)
Ad-Hoc operation is limited to Channels 36-48 (5150-5250 MHz).
Use of this band is restricted to Indoor Use Only, any other use will
make the operation of this device illegal.
Frequency of Operation – FCC and IC
The use in the UNII (Unlicensed National Information
Infrastructure) band 1 5150-5250 MHz band is restricted to Indoor
Use Only; any other use will make the operation of this device
illegal.
The available channels for 802.11 b/g operation in the US are
Channels 1 to 11. The range of channels is limited by firmware.
Health and Safety Recommendations
Ergonomic Recommendations
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
Please observe all warning notices with regard to the usage of
wireless devices.
Potentially Hazardous Atmospheres
You are reminded of the need to observe restrictions on the use of
radio devices in fuel depots, chemical plants etc. and areas where
the air contains chemicals or particles (such as grain, dust, or
metal powders) and any other area where you would normally be
advised to turn off your vehicle engine.
Class 1 Div 2 Product Regulatory Information
The following regulatory statements apply only to the Class 1 Div
2 products. The Class 1 Div 2 products are marked UL Listed
3JDT. This equipment is suitable for use in Class 1 Division 2,
groups A, B, C, and D or non-hazardous locations only. Use only
battery P/N 21-65587-XX or a Motorola approved equivalent. The
Class 1 Div 2 approved headset Part No. 200863-001 is the only
Class 1 Div 2 approved accessory.
WARNING - Explosion Hazard - Do not use headsets, memory
cards or other accessories in any hazardous locations unless they
have been Motorola approved and certified as Class 1 Div 2
devices.
WARNING - Explosion Hazard - Batteries must only be changed
or charged in an area known to be non-hazardous.
WARNING - Explosion Hazard - Components substitution may
impair Class 1, Div 2 suitability.
Pacemakers
Pacemaker manufacturers recommended that a minimum of
15cm (6 inches) be maintained between a handheld wireless
device and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with
independent research and recommendations by Wireless
Technology Research.
Persons with Pacemakers:
• Should ALWAYS keep the device more than 15cm (6 inches)
from their pacemaker when turned ON.
• If you have any reason to suspect that interference is taking
place, turn OFF your device.
Hearing Aids
The wireless device may interfere with some hearing aids. In the
event of interference you may want to consult your hearing aid
supplier to discuss solutions.
Other Medical Devices
Please consult your physician or the manufacturer of the medical
device, to determine if the operation of your wireless product may
interfere with the medical device.
Safety Information
The device complies with Internationally recognized standards
covering Specific Absorption Rate (SAR) related to human
exposure to electromagnetic fields from radio devices.
Reducing RF Exposure – Use Properly
It is advisable to use the device only in the normal operating
position.
Handheld Devices
To comply with FCC RF exposure requirements, this device must
be operated in the hand with a minimum separation distance of 23
cm or more from a person's body. Other operating configurations
should be avoided.
Laser Devices
Complies with Complies with 21CFR1040.10 and 1040.11
except for deviations pursuant to Laser Notice No. 50, dated July
26, 2001, EN60825-1:1994+ A1:2002 +A2:2001, IEC60825-
1:1993+A1:1997+A2:2001.
The laser classification is marked on one of the labels on the
device.
Class 1 Laser devices are not considered to be hazardous when
used for their intended purpose. The following statement is
required to comply with US and international regulations:
Class 2 laser scanners use a low power, visible light diode. As
with any very bright light source, such as the sun, the user should
avoid staring directly into the light beam. Momentary exposure to
a Class 2 laser is not known to be harmful.
Scanner Labeling
Laser Labels
In accordance with Clause 5, IEC 825 and EN60825, the following
information is provided to the user:
ENGLISH HEBREW
CLASS 1 CLASS 1 LASER PRODUCT
CLASS 2 LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
DANISH / DANSK ITALIAN / ITALIANO
KLASSE 1 KLASSE 1 LASERPRODUKT CLASSE 1 PRODOTTO AL LASER DI CLASSE 1
KLASSE 2 LASERLYF CLASSE 2 LUCE LASER
SE IKKE IND I STRÅLEN NON FISSARE IL RAGGIOPRODOTTO
KLASSE 2 LASERPRODUKT AL LASER DI CLASSE 2
DUTCH / NEDERLANDS NORWEGIAN / NORSK
KLASSE 1 KLASSE-1 LASERPRODUKT KLASSE 1 LASERPRODUKT, KLASSE 1
KLASSE 2 LASERLICHT KLASSE 2 LASERLYS IKKE STIRR INN I LYSSTRÅLEN
NIET IN STRAAL STAREN LASERPRODUKT, KLASSE 2
KLASSE-2 LASERPRODUKT
FINNISH / SUOMI PORTUGUESE / PORTUGUÊS
LUOKKA 1 LUOKKA 1 LASERTUOTE CLASSE 1 PRODUTO LASER DA CLASSE 1
LUOKKA 2 LASERVALO CLASSE 2 LUZ DE LASER NÃO FIXAR O RAIO LUMINOSO
ÄLÄ TUIJOTA SÄDETTÄ PRODUTO LASER DA CLASSE 2
LUOKKA 2 LASERTUOTE
FRENCH / FRANÇAIS SPANISH / ESPAÑOL
CLASSE 1 PRODUIT LASER DE CLASSE 1 CLASE 1 PRODUCTO LASER DE LA CLASE 1
CLASSE 2 LUMIERE LASER CLASE 2 LUZ LASER
NE PAS REGARDER LE RAYON FIXEMENT NO MIRE FIJAMENTE EL HAZ
PRODUIT LASER DE CLASSE 2 PRODUCTO LASER DE LA CLASE 2
GERMAN / DEUTCH SWEDISH / SVENSKA
KLASSE 1 LASERPRODUKT DER KLASSE 1 KLASS 1 LASERPRODUKT KLASS 1
KLASSE 2 LASERSTRAHLEN KLASS 2 LASERLJUS STIRRA INTE MOT STRÅLEN
NICHT DIREKT IN DEN LASERSTRAHL SCHAUEN LASERPRODUKT KLASS 2
LASERPRODUKT DER KLASSE 2
Batteries
Taiwan - Recycling
EPA (Environmental Protection
Administration) requires dry battery
producing or importing firms in accordance
with Article 15 of the Waste Disposal Act are
required to indicate the recycling marks on the batteries used in
sales, giveaway or promotion. Contact a qualified Taiwanese
recycler for proper battery disposal.
Battery Information
Motorola/Symbol rechargeable battery packs are designed and
constructed to the highest standards within the industry.
However, there are limitations to how long a battery can operate
or be stored before needing replacement. Many factors affect the
actual life cycle of a battery pack, such as heat, cold, harsh
environmental conditions and severe drops.
When batteries are stored over six (6) months, some irreversible
deterioration in overall battery quality may occur. Store batteries at
half of full charge in a dry, cool place, removed from the
equipment to prevent loss of capacity, rusting of metallic parts and
electrolyte leakage. When storing batteries for one year or longer,
they should be charged and discharged at least once a year. If an
electrolyte leakage is observed, avoid any contact with affected
area and properly dispose of the battery. Batteries must be
charged within the 32° to 104° F (0° to +40° C) ambient
temperature range.
Replace the battery when a significant loss of run time is detected.
Standard warranty period for all Symbol batteries is 30 days,
regardless if the battery was purchased separately or included as
part of the mobile computer. For more information on Symbol
batteries, please visit:
http:/mysymbolcare.symbol.com/battery/batbasics1.html.
Battery Safety Guidelines
• The area in which the units are charged should be clear of
debris and combustible materials or chemicals. Particular care
should be taken where the device is charged in a non
commercial environment.
• Follow battery usage, storage, and charging guidelines found
in the user's guide.
• Improper battery use may result in a fire, explosion, or other
hazard.
• To charge the mobile device battery, the battery and charger
temperatures must be between +32 ºF and +104 ºF (0 ºC and
+40 ºC)
• Do not use incompatible batteries and chargers. Use of an
incompatible battery or charger may present a risk of fire,
explosion, leakage, or other hazard. If you have any questions
about the compatibility of a battery or a charger, contact
Motorola Enterprise Mobility support.
• For devices that utilize a USB port as a charging source, the
device shall only be connected to products that bear the USB-
IF logo or have completed the USB-IF compliance program.
• [For WAN devices requiring compliance to IEEE 1725, provide
an explanation of security implementation, per IEEE 1725
clause 10.2.1, that provides a method of authentication that
ensures compatibility between a specific host device and the
battery.]
• Do not disassemble or open, crush, bend or deform, puncture,
or shred.
• Severe impact from dropping any battery-operated device on a
hard surface could cause the battery to overheat.
• Do not short circuit a battery or allow metallic or conductive
objects to contact the battery terminals.
• Do not modify or remanufacture, attempt to insert foreign
objects into the battery, immerse or expose to water or other
liquids, or expose to fire, explosion, or other hazard.
• Do not leave or store the equipment in or near areas that might
get very hot, such as in a parked vehicle or near a radiator or
other heat source. Do not place battery into a microwave oven
or dryer.
• Battery usage by children should be supervised.
• Please follow local regulations to promptly dispose of used re-
chargeable batteries.
• Do not dispose of batteries in fire.
• Seek medical advice immediately if a battery has been
swallowed.
• In the event of a battery leak, do not allow the liquid to come in
contact with the skin or eyes. If contact has been made, wash
the affected area with large amounts of water and seek
medical advice.
• If you suspect damage to your equipment or battery, contact
Motorola Enterprise Mobility support to arrange for inspection.
Radio Frequency Interference Requirements- FCC
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for
help.
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
CAUTION Only use Motorola approved and UL Listed accessories,
battery packs and battery chargers.
Do NOT attempt to charge damp/wet mobile computers
or batteries. All components must be dry before
connecting to an external power source.
Operation of the device without regulatory
approval is illegal. Select only the country in
which you are using this device. Any other
selection will make the operation of this device
illegal.
CAUTION In order to avoid or minimize the potential risk of
ergonomic injury follow the recommendations below.
Consult with your local Health & Safety Manager to
ensure that you are adhering to your company’s safety
programs to prevent employee injury.
Warnings for Use of Wireless Devices
FCC / EU RF Exposure Guidelines
CAUTION Use of controls, adjustments or performance of
procedures other than those specified herein may result
in hazardous laser light exposure.
CAUTION - CLASS 3R LASER LIGHT WHEN OPEN. AVOID DIRECT EYE EXPOSURE
ATTENTION - LUMIÈRE LASER DE CLASSE 3R, EN CAS D'OUVERTURE. EXPOSITION
DANGEREUSE AU FAISCEAU VORSICHT - LASERLICHT KLASSE 3R, WENN
ABDECKUNG GEÖFFNET. DIREKTE BESTRAHLUNG DER AUGEN VERMEIDEN.
CAUTION Risk of explosion if battery is replaced by an incorrect
type.
Dispose of batteries according to instructions.
Radio Frequency Interference Requirements- Canada
Radio Transmitters
This device complies with RSS 210 of Industry & Science Canada.
Operation is subject to the following two conditions: (1) this device
may not cause harmful interference and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
Label Marking: The Term “IC:” before the radio certification only
signifies that Industry Canada technical specifications were met.
The use of 2.4GHz RLAN’s, for use through the EEA, have the
following restrictions:
• Maximum radiated transmit power of 100 mW EIRP in the
frequency range 2.400 -2.4835 GHz.
• France, outside usage is restricted to 2.4 – 2.454 GHz.
• Italy requires a user license for outside usage.
The use of 5GHz RLANs has varying restrictions for use within the
EEA; please refer to the Symbol Declaration of Conformity (DoC)
for details at http://www2.symbol.com/doc/.
Bluetooth® Wireless Technology for use through the EEA has the
following restrictions:
• Maximum radiated transmit power of 100mW EIRP in the
frequency range 2.400 -2.4835 GHz
• France, outside usage is restricted to 2.4 - 2.454 GHz
• Italy requires a user license for outside usage.
RFID Devices, for use through the EEA, operating in the 869.4 –
869.65 MHz frequency band have the following restrictions:
• Maximum radiated transmit power of 500mW ERP with a 10%
Duty Cycle in the frequency range 869.4 - 869.65MHz.
Statement of Compliance
Motorola/Symbol hereby, declares that this device is in
compliance with the essential requirements and other relevant
provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC.
Declaration of Conformities may be obtained from http://
www2.symbol.com/doc/.
Korea Warning Statement for Class B ITE
Other Countries
Mexico
Restrict Frequency Range to: 2.450 - 2.4835 GHz.
Sri Lanka
Restrict Frequency Range to: 2.400 - 2.430 GHz.
Regulatory Declarations for MC9090 - BRAZIL
NOTE: The certification mark applied to the MC9090 covers the
Restriction of Radiation. This equipment operates on a secondary
basis and the user does not have the right for protection against
harmful interference from other users including same equipment
types. This equipment must not cause interference to systems
operating on primary basis.
For more information consult the website www.anatel.gov.br.
Taiwan
English: For EU Customers: All products at the end of their life must be
returned to Motorola for recycling. For information on how to return
product, please go to: http://www.motorola.com/recycling/weee.
Français: Clients de l'Union Européenne : Tous les produits en fin de
cycle de vie doivent être retournés à Motorola pour recyclage. Pour de
plus amples informations sur le retour de produits, consultez : http://
www.motorola.com/recycling/weee.
Bulgarish: За клиенти от ЕС: След края на полезния им живот
всички продукти трябва да се връщат на Motorola за рециклиране.
За информация относно връщането на продукти, моля отидете на
адрес: http://www.motorola.com/recycling/weee.
Español: Para clientes en la Unión Europea: todos los productos
deberán entregarse a Motorola al final de su ciclo de vida para que
sean reciclados. Si desea más información sobre cómo devolver un
producto, visite: http://www.motorola.com/recycling/weee.
Deutsch: Für Kunden innerhalb der EU: Alle Produkte müssen am
Ende ihrer Lebensdauer zum Recycling an Motorola zurückgesandt
werden. Informationen zur Rücksendung von Produkten finden Sie
unter http://www.motorola.com/recycling/weee.
Italiano: per i clienti dell'UE: tutti i prodotti che sono giunti al termine
del rispettivo ciclo di vita devono essere restituiti a Motorola al fine di
consentirne il riciclaggio. Per informazioni sulle modalità di restituzione,
visitare il seguente sito Web: http://www.motorola.com/recycling/weee.
Português: Para clientes da UE: todos os produtos no fim de vida
devem ser devolvidos à Motorola para reciclagem. Para obter
informações sobre como devolver o produto, visite:
http://www.motorola.com/recycling/weee.
Nederlands: Voor klanten in de EU: alle producten dienen aan het
einde van hun levensduur naar Motorola te worden teruggezonden
voor recycling. Raadpleeg http://www.motorola.com/recycling/weee
voor meer informatie over het terugzenden van producten.
Polski: Klienci z obszaru Unii Europejskiej: Produkty wycofane z
eksploatacji nale¿y zwróciæ do firmy Motorola w celu ich utylizacji.
Informacje na temat zwrotu produktów znajduj¹ siê na stronie
internetowej http://www.motorola.com/recycling/weee.
Čeština: Pro zákazníky z EU: Všechny produkty je nutné po skonèení
jejich životnosti vrátit spoleènosti Motorola k recyklaci. Informace o
zpùsobu vrácení produktu najdete na webové stránce:
http://www.motorola.com/recycling/weee.
Eesti: EL klientidele: kõik tooted tuleb nende eluea lõppedes tagastada
taaskasutamise eesmärgil Motorola'ile. Lisainformatsiooni saamiseks
toote tagastamise kohta külastage palun aadressi
http://www.motorola.com/recycling/weee.
Magyar: Az EU-ban vásárlóknak: Minden tönkrement terméket a
Motorola vállalathoz kell eljuttatni újrahasznosítás céljából. A termék
visszajuttatásának módjával kapcsolatos tudnivalókért látogasson el a
http://www.motorola.com/recycling/weee weboldalra.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku življenjske
dobe vrniti podjetju Motorola za reciklažo. Za informacije o vraèilu
izdelka obišèite: http://www.motorola.com/recycling/weee.
Svenska: För kunder inom EU: Alla produkter som uppnått sin
livslängd måste returneras till Motorola för återvinning. Information om
hur du returnerar produkten finns på
http://www.motorola.com/recycling/weee.
Suomi: Asiakkaat Euroopan unionin alueella: Kaikki tuotteet on
palautettava kierrätettäväksi Motorola-yhtiöön, kun tuotetta ei enää
käytetä. Lisätietoja tuotteen palauttamisesta on osoitteessa
http://www.motorola.com/recycling/weee.
Dansk: Til kunder i EU: Alle produkter skal returneres til Motorola til
recirkulering, når de er udtjent. Læs oplysningerne om returnering af
produkter på:
http://www.motorola.com/recycling/weee.
Ελληνικά: Για πελάτες στην Ε.Ε.: Όλα τα προϊόντα, στο τέλος της
διάρκειας ζωής τους, πρέπει να επιστρέφονται στην Motorola για
ανακύκλωση. Για περισσότερες πληροφορίες σχετικά με την επιστροφή
ενός προϊόντος, επισκεφθείτε τη διεύθυνση
http://www.motorola.com/recycling/weee στο Διαδίκτυο.
Malti: Għal klijenti fl-UE: il-prodotti kollha li jkunu waslu fl-aħħar tal-
ħajja ta' l-użu tagħhom, iridu jiġu rritornati għand Motorola għar-
riċiklaġġ. Għal aktar tagħrif dwar kif għandek tirritorna l-prodott, jekk
jogħġbok żur: http://www.motorola.com/recycling/weee.
Românesc: Pentru clienţii din UE: Toate produsele, la sfârşitul duratei
lor de funcţionare, trebuie returnate la Motorola pentru reciclare. Pentru
informaţii despre returnarea produsului, accesaţi:
http://www.motorola.com/recycling/weee.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku življenjske
dobe vrniti podjetju Motorola za reciklažo. Za informacije o vračilu
izdelka obiščite: http://www.motorola.com/recycling/weee.
Slovenčina: Pre zákazníkov z krajín EU: Všetky výrobky musia byť po
uplynutí doby ich životnosti vrátené spoločnosti Motorola na recykláciu.
Bližšie informácie o vrátení výrobkov nájdete na:
http://www.motorola.com/recycling/weee.
Lietuvių: ES vartotojams: visi gaminiai, pasibaigus jų eksploatacijos
laikui, turi būti grąžinti utilizuoti į kompaniją „Motorola“. Daugiau
informacijos, kaip grąžinti gaminį, rasite:
http://www.motorola.com/recycling/weee.
Latviešu: ES klientiem: visi produkti pēc to kalpošanas mūža beigām ir
jānogādā atpakaļ Motorola otrreizējai pārstrādei. Lai iegūtu informāciju
par produktu nogādāšanu Motorola, lūdzu, skatiet:
http://www.motorola.com/recycling/weee.
Türkçe: AB Müşterileri için: Kullanım süresi dolan tüm ürünler geri
dönüştürme için Motorola'ya iade edilmelidir. Ürünlerin nasıl iade
edileceği hakkında bilgi için lütfen şu adresi ziyaret edin:
http://www.motorola.com/recycling/weee.
End-user License Agreement
These license terms are an agreement between you and
Motorola, Inc. (“Company”). Please read them. They apply to the
software included on this device. The software also includes any
separate media on which you received the software.
The software on this device includes software licensed by
Company from Microsoft Corporation or its affiliate.
The terms also apply to any
• updates,
• supplements,
• Internet-based services, and
•support services
for this software, unless other terms accompany those items. If so,
those terms apply.
As described below, using some features also operates as your
consent to the transmission of certain standard computer
information for Internet-based services.
By using the software, including use on this device, you accept
these terms. If you do not accept them, do not use the device or
software. Instead, contact Company to determine its return policy
for a refund or credit.
WARNING: If the software contains voice operated technologies,
then operating this software requires user attention. Diverting
attention away from the road while driving can possibly cause an
accident or other serious consequence. Even occasional, short
diversions of attention can be dangerous if your attention is
diverted away from your driving task at a critical time. Company
and Microsoft make no representations, warranties or other
determinations that ANY use of this software is legal, safe, or in
any manner recommended or intended while driving or otherwise
operating a motor vehicle.
If you comply with these license terms, you have the rights below.
1. USE RIGHTS.
You may use the software on the device with which you acquired
the software.
2. ADDITIONAL LICENSING REQUIREMENTS AND/OR USE
RIGHTS.
a.Specific Use. Company designed this device for a specific
use. You may only use the software for that use.
b.Included Microsoft Programs and Additional Required
Licenses. Except as provided below, these license terms
apply to all Microsoft programs included with the software. If
the license terms with any of those programs give you other
rights that do not expressly conflict with these license terms,
you also have those rights.
i. This agreement does not grant you any rights with respect
to the Windows Mobile Device Center, Microsoft ActiveSync
or Microsoft Outlook 2007 Trial which are subject to the
licenses accompanying those items.
c. Speech Recognition. If the software includes speech
recognition component(s), you understand that speech
recognition is an inherently statistical process and that
recognition errors are inherent in the process. Neither
Company nor Microsoft or their suppliers shall be liable for
any damages arising out of errors in the speech recognition
process.
d.Phone Functionality. If the device software includes phone
functionality, all or certain portions of the device software may
be inoperable if you do not have and maintain a service
account with a wireless telecommunication carrier (“Mobile
Operator”), or if the Mobile Operator’s network is not
operating or configured to operate with the device.
3. SCOPE OF LICENSE. The software is licensed, not sold. This
agreement only gives you some rights to use the software.
Company and Microsoft reserve all other rights. Unless applicable
law gives you more rights despite this limitation, you may use the
software only as expressly permitted in this agreement. In doing
so, you must comply with any technical limitations in the software
that allow you to use it only in certain ways. You may not:
• work around any technical limitations in the software;
• reverse engineer, decompile or disassemble the software;
• make more copies of the software than specified in this
agreement;
• publish the software for others to copy;
• rent, lease or lend the software; or
• use the software for commercial software hosting services.
Except as expressly provided in this agreement, rights to access
the software on this device do not give you any right to implement
Microsoft patents or other Microsoft intellectual property in
software or devices that access this device.
You may use remote access technologies in the software such as
Remote Desktop Mobile to access the software remotely from a
computer or server. You are responsible for obtaining any licenses
required for use of the protocols to access other software.
4. INTERNET-BASED SERVICES. Microsoft provides Internet-
based services with the software. Microsoft may change or cancel
them at any time.
a.Consent for Internet-Based Services. The software
features described below connect to Microsoft or service
provider computer systems over the Internet. In some cases,
you will not receive a separate notice when they connect. You
may switch off some of these features or not use them. For
more information about these features, visit http://
go.microsoft.com/fwlink/?LinkId=81931.
By using these features, you consent to the transmission
of this information. Microsoft does not use the information to
identify or contact you.
Device Information. The following features use Internet
protocols, which send to the appropriate systems device
information, such as your Internet protocol address, the type of
operating system, browser and name and version of the
software you are using, and the language code of the device
where you installed the software. Microsoft uses this
information to make the Internet-based services available to
you.
•Windows Mobile Update Feature. The Windows Mobile
Update feature provides you the ability to obtain and install
software updates on your device if updates are available.
You may choose not to use this feature. Company and/or
your Mobile Operator may not support this feature or an
update for your device.
•Windows Media Digital Rights Management. Content
owners use Windows Media digital rights management
technology (WMDRM) to protect their intellectual property,
including copyrights. This software and third party software
use WMDRM to play and copy WMDRM-protected content.
If the software fails to protect the content, content owners
may ask Microsoft to revoke the software’s ability to use
WMDRM to play or copy protected content. Revocation does
not affect other content. When you download licenses for
protected content, you agree that Microsoft may include a
revocation list with the licenses. Content owners may require
you to upgrade WMDRM to access their content. Microsoft
software that includes WMDRM will ask for your consent
prior to the upgrade. If you decline an upgrade, you will not
be able to access content that requires the upgrade.
b.Misuse of Internet-based Services. You may not use these
services in any way that could harm them or impair anyone
else’s use of them. You may not use the services to try to gain
unauthorized access to any service, data, account or network
by any means.
5. NOTICES ABOUT THE MPEG-4 VISUAL STANDARD. The
software may include MPEG-4 visual decoding technology. This
technology is a format for data compression of video information.
MPEG LA, L.L.C. requires this notice:
USE OF THIS PRODUCT IN ANY MANNER THAT
COMPLIES WITH THE MPEG-4 VISUAL STANDARD IS
PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO
(A) DATA OR INFORMATION (i) GENERATED BY AND
OBTAINED WITHOUT CHARGE FROM A CONSUMER NOT
THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND
(ii) FOR PERSONAL USE ONLY; AND (B) OTHER USES
SPECIFICALLY AND SEPARATELY LICENSED BY MPEG
LA, L.L.C.
If you have questions about the MPEG-4 visual standard,
please contact MPEG LA, L.L.C., 250 Steele Street, Suite 300,
Denver, CO 80206; www.mpegla.com.
6. DIGITAL CERTIFICATES. The software uses digital certificates
in X.509 format. These digital certificates are used for
authentication.
7. CONNECTIVITY SOFTWARE. Your device package may
include Windows Mobile Device Center or Microsoft ActiveSync
software. If it is included, then you may install and use it in
accordance with the license terms that are provided with it. If no
license terms are provided, then you may install and use only one
(1) copy of the software on a single computer.
8. NETWORK ACCESS. If you are using a network, such as an
employer network, the network administrator may limit features or
functionality on your device.
9. PRODUCT SUPPORT. Contact Company for support options.
Refer to the support number provided with the device.
10. LINKS TO THIRD PARTY WEBSITES. If the software
provides links to third party websites, those links are provided to
you only as a convenience, and the inclusion of any link does not
imply an endorsement of the third party website by Microsoft.
11. BACKUP COPY. You may make one backup copy of the
software. You may use it only to reinstall the software on the
device.
12. PROOF OF LICENSE. If you acquired the software on the
device, or on a disc or other media, a genuine Certificate of
Authenticity label with a genuine copy of the software identifies
licensed software. To be valid, this label must be affixed to the
device, or included on or in Company’s software packaging. If you
receive the label separately, it is not valid. You should keep the
label on the device or packaging to prove that you are licensed to
use the software. To identify genuine Microsoft software, see http:/
/www.howtotell.com.
13. TRANSFER TO A THIRD PARTY. You may transfer the
software only with the device, the Certificate of Authenticity label,
and these license terms directly to a third party. Before the
transfer, that party must agree that these license terms apply to
the transfer and use of the software. You may not retain any
copies of the software including the backup copy.
14. NOT FAULT TOLERANT. The software is not fault tolerant.
Company installed the software on the device and is responsible
for how it operates on the device.
15. RESTRICTED USE. The Microsoft software was designed for
systems that do not require fail-safe performance. You may not
use the Microsoft software in any device or system in which a
malfunction of the software would result in foreseeable risk of
injury or death to any person. This includes operation of nuclear
facilities, aircraft navigation or communication systems and air
traffic control.
16. NO WARRANTIES FOR THE SOFTWARE. The software is
provided “as is”. You bear all risks of using it. Microsoft gives no
express warranties, guarantees or conditions. Any warranties you
receive regarding the device or the software do not originate from,
and are not binding on, Microsoft or its affiliates. When allowed by
your local laws, Company and Microsoft exclude implied
warranties of merchantability, fitness for a particular purpose and
non-infringement.
17. LIABILITY LIMITATIONS. You can recover from Microsoft and
its affiliates only direct damages up to fifty U.S. Dollars (U.S.
$50.00), or equivalent in local currency. You cannot recover any
other damages, including consequential, lost profits, special,
indirect or incidental damages.
This limitation applies to:
• anything related to the software, services, content (including
code) on third party internet sites, or third party programs, and
• claims for breach of contract, breach of warranty, guarantee or
condition, strict liability, negligence, or other tort to the extent
permitted by applicable law.
It also applies even if Microsoft should have been aware of the
possibility of the damages. The above limitation may not apply to
you because your country may not allow the exclusion or limitation
of incidental, consequential or other damages.
18. EXPORT RESTRICTIONS. The software is subject to United
States export laws and regulations. You must comply with all
domestic and international export laws and regulations that apply
to the software. These laws include restrictions on destinations,
end users and end use. For additional information, see
www.microsoft.com/exporting.
Software Support
Motorola wants to ensure that customers have the latest release
of entitled software at the time of product purchase.
To confirm that you Motorola Enterprise Mobility device shipped
with the latest release of entitled software, visit:
http://www.motorola.com/enterprisemobility/support.
Check for the latest software from Software Downloads > Product
Line/Product > Go.
If your device does not have the latest entitled software release as
of your product purchase date, please e-mail a request to
Motorola at: entitlementservices@motorola.com.
You must include the following essential device information with
your request:
• Model number
• Serial number
• Proof of purchase
• Title of the software download you are requesting.
If it is determined by Motorola that your device is entitled to the
latest software release, you will receive an e-mail containing a link
directing you to a Motorola website to download the appropriate
software.
Marking and European Economic Area (EEA)
기 종 사 용 자 안 내 문
B급 기기
( 가정용
방송통신기기 )
이 기기는 가정용 (B 급 ) 으로 전자파적합등록을 한
기기로서 주로 가정에서 사용하는 것을 목적 으로
하며 , 모든 지역에서 사용할 수 있습니다 .
Waste Electrical and Electronic Equipment
(WEEE)
