Phone Features
· Three-line display
· Headset port
· Ear tone for call waiting/incoming call
· Ringer on/off switch
· Vibrating, visual and audio ring signals
· Volume control
· Call forwarding/transfer
· Redial key
· Roaming
· External calls using gateway
· Unidirectional broadcast message
· Paging
· Dial by name
· Speed dial/address book
· External serial port
· Caller ID
· Battery strength meter
· Signal strength meter
Alpha Keys
FCT Key: ((TBD??))
MENU Key: access set up.
RCL Key: functions as a speed dial and redial key,
listing the last eight numbers dialed.
NAME Key: used to access the directory for dialing
by name.
CLR Key: deletes previous entered characters. Press and 
hold for two seconds and entire entry deletes.
STO Key: used to store numbers in the Recall function.
HOLD key: used to put the caller on hold, and call
waiting access.
Getting Started
The battery included with the NetVISION Phone needs to be charged.
Charge the battery using the dual-slot charging cradle accompanying
the Phone before engaging in continuous use.((Does the battery come
attached and fully charged??))
Charging the Battery
The charging cradle allows users to charge the battery separately or
while attached to the phone. The cradle recharges one battery at a time.
For the quickest charge, remove the battery from the Phone and place in
the rear slot of the cradle. The red LED indicator lights while the battery
charges. The green LED indicator lights for a fully charged battery.
Turning the Phone On
Press and hold SND until an image appears on the screen, about
two seconds.
Turning the Phone Off
Press and hold END until the screen clears, about three seconds.
Indicator Descriptions
The first screen of the NetVISION Phone displays the IP address assigned
to the Phone. The second screen automatically appears after a few
seconds and displays:
·the Phone user name at the top of the display
·the word Idle below the user name if the Phone has associated with a 
 Spectrum24 (S24) access point (AP) or the words No Network if the 
 Phone has not associated with an AP
·the signal strength icon on the left side of the display
·the battery strength icon on the right side of the display
·two telephone icons at the bottom representing the two available lines.
The icons highlight when in use.
The second menu displays: NV Phone
(Status)
Signal StrengthLinesBattery Strength
For Warranty & Service
Information, Call:
1-800-653-5350
Outside North America, contact
your local Symbol representative
FCC Requirements
This device must operate in compliance with
Federal Communications Commission (FCC)
Rules and Regulations Parts 15. See FCC
registration label (located on bottom of
equipment) for FCC registration.
This equipment has been tested and found to
comply with the limits for Class A or Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated in
a commercial environment. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and
used in accordance with the instruction manual,
may cause harmful interference to radio com-
munications. Operation of this equipment in a
residential area is likely to cause harmful
interference in which case the user will be
required to correct the interference at his
own expense.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the 
equipment and receiver.
- Connect the equipment into an outlet on a 
circuit different from that to which the receiver 
is connected.
- Consult the dealer or an experienced 
radio/TV technician for help.
RF Notice
Any changes or modifications to Symbol
Technologies equipment not expressly approved
by Symbol Technologies could void the user's
authority to operate the equipment.
70-XXXXX-01
Copyright © 1998 by Symbol Technologies, Inc. All
Rights Reserved.Symbol and Spectrum24 are
registered trademarks of Symbol Technologies, Inc.
Symbol Technologies, Inc.
One Symbol Plaza
Holtsville, NY 11742-1300
Antenna
