Sysgration WVTX1AP Stand Alone Digital Wireless Transmitter User Manual 1
Sysgration Ltd. Stand Alone Digital Wireless Transmitter 1
User Manual
WVTX1AP
INSTALLATION
Connect to camera
Black Ground Input
Red +12VDC Input
Mounting screws x4
Antenna Aligned Vertically
(Perpendicular to Road)
R
WVTX1AP
Auto Pair
Digital Wireless
Transmitter Module
1. Mount the transmitter using 4 screws in
a safe location to avoid impacts.
2. Connect 12 volts to the red wire and
chassis ground to the black wire.
3. Connect the camera cable.
4. Secure all wires & cables.
technology with Auto-Pair
Digital wireless Transmitter Featuring
ObservationSystems
MA2A1209002-1R
Our wireless technology operates at nearly the same performance level
as a wired system. However, slight delays and signal reductions are possible due
to application or environmental factors.?
To comply with the FCC RF exposure compliance requirements, the antenna(s)
used for this transmitter must be installed to provide a separation distance of at
least 20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter. No change to the antenna or
the device is permitted.
Any change to the antenna or the device could result in the device exceeding the
RF exposure requirements and void user's authority to operate the device.
IMPORTANT NOTE:
Notice 1 :
The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Notice 2:
PATENT PENDING
