TCL Communication A026 GSM Quad-band / UMTS Penta-band / LTE Deca-band mobile phone User Manual

DTEK50 STH100-2 Smartphone

Safety and Product Information

Safety information

Before you start using your BlackBerry smartphone (hereinafter referred to as smartphone), review the safety and regulatory information provided in this document. Keep this

document in a safe place so that you can refer to it whenever you need it.

In some countries there may be restrictions on using Bluetooth enabled devices and wireless devices with encryption software. Check with your local authorities for the restrictions

in your area.

Important safety precautions

Use only approved batteries and chargers with your smartphone. Use of batteries or chargers that have not been approved by the manufacturer

exceeding radio frequency exposure standards is a subject of ongoing scientific study.

For more information about the compliance of this smartphone with the FCC radio frequency emission guidelines, visit www.fcc.gov/oet/ea/fccidand

search for the FCC ID for your smartphone listed below.

•DTEK50STH100-2 smartphone (model number RJD211LW): FCC ID 2ACCJA026

Your smartphone is designed to be operated in temperatures between 32 and 95°F (0 and 35°C). Use of your smartphone outside of the recommended

temperature range could cause damage to your smartphone or lithium-ion battery.

Do not rely on your smartphone for emergency communications. The wireless networks that are necessary to make emergency calls or send

messages are not available in all areas, and emergency numbers, such as 911, 112, 119, or 999, might not connect you to emergency services in all

Your smartphone and smartphone accessories are not intended for children. If you allow a child to use or handle your smartphone or smartphone

you experience, or your use of your smartphone causes in others, any disorientation, loss of awareness, twitching, convulsions, or any involuntary

movements, stop using your smartphone immediately and consult a physician. The LED notification light is located on the front of your smartphone,

in the upper-right corner. If your smartphone model has a camera, the camera flash LED aperture is located on the back of your smartphone,

either above or to the right of the camera lens. If you are susceptible to epileptic seizures or blackouts, consult your physician before you use your

smartphone.

Do not use your smartphone while driving unless you are permitted by law to use the smartphone in hands-free mode. Using your smartphone while

driving could put you and others at greater risk of an accident causing serious injury, death, or property loss.

Do not use your smartphone in the presence of gas fumes because it might present a risk of fire or explosion.

Do not dispose of your smartphone in a fire because this might cause an explosion resulting in serious injury, death, or property loss.

Turn o your smartphone on aircrafts. Using your smartphone on an aircraft might aect aircraft instrumentation, communication, and performance;

• Do not attempt to cover or push objects into openings on your smartphone unless instructed to do so in the smartphone documentation supplied by the manufacturer. This action

might cause a short circuit, a fire, or an electric shock.

• Do not use sharp objects on the screen.

• Do not use excessive force on the screen.

• Do not use your smartphone or smartphone accessories near water (for example, near a bathtub or a sink, in a wet basement, or near a swimming pool).

• Do not place your smartphone or smartphone accessories on any unstable surface. The smartphone or smartphone accessories could fall, thereby potentially causing serious

injury to a person and serious damage to the smartphone or smartphone accessory.

• The screen of your smartphone is made of glass. The glass could crack or chip if your smartphone is dropped or force is applied to the glass. If cracked or chipped, do not touch

the glass until the screen has been repaired.

• When using your smartphone, take frequent breaks. If you experience any discomfort in your neck, shoulders, arms, wrists, hands (including thumbs and fingers), or other parts

AC chargers: CBA0059AG4C1, CBA0059AA1C1, CBA0059AA1C6, CBA0059AB2C1, CBA0059AC1C1, CBA0059AJ2C4, CBA0059AB3C1

Use the charging accessories provided with the smartphone or any other the manufacturer approved charging accessories only from the type of power source indicated on the

marking label. Before you use any power supply, verify that the mains voltage is in accordance with the voltage printed on the power supply. Connect the smartphone only to CTIA

certified adapters, products that bear the USB-IF logo, or products that have completed the USB-IF compliance program.

Do not overload power outlets, extension cords, or convenience receptacles because this might result in a risk of fire or electric shock. To reduce the risk of damage to the cord or

the plug, pull the plug rather than the cord when you disconnect the charging accessory from the power outlet or convenience receptacle.

Protect the power cord from being walked on or pinched, particularly at convenience receptacles and the point where the power cord connects to the smartphone. Always route the

power cord in a way that reduces the risk of injury to others, such as tripping or choking. Unplug charging accessories during lightning storms or when not being used. Do not use

charging accessories outside or in any area exposed to the elements.

For more information about connecting the power supply, see the documentation that came with your smartphone.

Do not expose the smartphone and its battery to fire or other external heat sources, such as hot plates, stove tops, space heaters, or ovens, because

this could cause fire or explosion.

Do not attempt to insert foreign objects into the battery. Do not remanufacture, disassemble, modify, crush, puncture, bend, or shred the battery. If the

battery has been remanufactured, disassembled, modified, crushed, punctured, or altered in any other way, cease use of the battery immediately.

Do not short-circuit the battery or allow metallic or conductive objects to contact the battery terminals.

CAUTION: Do not attempt to remove the battery. The manufacturer specifies batteries for use in smartphones in compliance with IEEE Std 1725. Use of any other batteries might

present a risk of fire, explosion, battery leakage, or other hazard. Please ensure you dispose of used batteries according to the instructions set out in this document.

When this icon appears on your smartphone, there may be a problem with the battery or the battery connection. Try restarting your smartphone. If the

icon still appears, return your smartphone to qualified service personnel for repair.

Driving and walking safely

Do not use your smartphone while walking or engaging in any activity that requires your full attention. Inattention to trac or other pedestrian hazards could result in serious harm,

death, or property loss.

Accessories

Use only those accessories approved by the manufacturer for use with this particular smartphone model. Using any accessories not approved might invalidate any approval or

warranty, might result in the smartphone becoming inoperative, and might be dangerous.

Carrying solutions: Your smartphone might not come with a holster (body-worn accessory). If you wear your smartphone on your body, always put your smartphone in a smartphone

holster equipped with an integrated belt clip supplied or approved by the manufacturer. If you do not use a holster equipped with an integrated belt clip supplied or approved by

the manufacturer when you carry your smartphone, keep your smartphone at least 0.59 in. (15 mm) from your body when the smartphone is transmitting. When using any data

feature of your smartphone (for example, email messages, PIN messages, MMS messages, or browser service), with or without a USB cable, hold your smartphone at least 0.59 in.

(15 mm) from your body. Using accessories that are not supplied by or approved by the manufacturer might cause your smartphone to exceed radio frequency exposure guidelines.

Your smartphone includes a magnetometer. The magnetometer is used by applications such as the Compass. Magnets or devices that contain magnets, such as holsters,

headphones, or monitors, might negatively aect the accuracy of the magnetometer. Do not rely on applications that use the magnetometer to determine your location, particularly

in an emergency situation.

Media

Certain jurisdictions might prohibit or restrict your use of certain features on your smartphone. When taking, processing, or using pictures, obey all laws, regulations, procedures,

and policies, including, without limitation, any applicable copyright, personal privacy, trade secret, or security laws that may be in place in your jurisdiction. Honor the personal

rights of others. Copyright protections might prevent you from copying, modifying, transferring, or forwarding some pictures, music (including ring tones), or other content.

Audio files: Permanent hearing loss might occur if you listen to audio files at high volumes, particularly with headphones. Avoid increasing the volume of your headphones to block

out noisy surroundings. If you experience ringing in your ears or mued speech, consult a physician.

Camera: If your smartphone has a camera, do not aim the camera directly at the sun or any other bright light. Doing so could cause serious damage to your eyes or damage your

your smartphone.

Pacemakers: Consult a physician or the manufacturer of your pacemaker if you have any questions regarding the eect of radio frequency signals on your pacemaker. Verify that

you are using your smartphone in accordance with the safety requirements associated with your particular pacemaker, which might include the following requirements: always

keep your smartphone more than 7.88 inches (20 cm) from the pacemaker when your smartphone is turned on, do not carry your smartphone in your breast pocket, and use the

ear opposite the pacemaker for making and receiving calls on your smartphone to minimize the potential interference. If you have any reason to suspect that interference is taking

place, turn o all wireless connections on your smartphone immediately, stop using your smartphone, and consult a physician.

Hearing aids: Some digital wireless devices might interfere with some hearing aids. In the event of such interference, consult your wireless service provider or contact the

manufacturer of your hearing aid to discuss alternatives.

Your smartphone includes a magnetometer, which is used by applications such as the Compass. If an application that uses the magnetometer causes interference with your hearing

aid, close the application.

connections turned on in an aircraft is unknown. Such use might aect aircraft instrumentation, communication, and performance, might disrupt the network, might otherwise

be dangerous to the operation of the aircraft, and might be illegal. With all wireless connections on your smartphone turned o, use only nonradio based device applications in

accordance with airline regulations for electronic devices.

Dangerous areas

Your smartphone is not an intrinsically safe device and is not suitable for use in hazardous environments, where intrinsically safe devices are required, including without limitation, in the

presence of gas fumes, explosive dust situations, operation of nuclear facilities, aircraft navigation or communication services, air trac control, and life support or weapons systems.

Potentially explosive atmospheres: If you are in any area with a potentially explosive atmosphere, turn o all wireless connections on your smartphone and obey all signs and

instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gasoline or petrol stations; below deck on boats; fuel or

chemical transfer or storage facilities; vehicles using liquefied petroleum gas, such as propane or butane; areas where the air contains chemicals or particles, such as grain, dust, or

There is no guarantee, however, that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning on and turning o the equipment, the user is encouraged to try to correct the interference by one or more of the following measures: reorient

or relocate the receiving antenna, increase the separation between the equipment and receiver, connect the equipment to an outlet on a circuit dierent from that to which the

receiver is connected, or consult the dealer or an experienced radio or TV technician for help.

US Information Concerning the Federal Communications Commission (“FCC”) Requirements for Hearing Aid Compatibility with Wireless Devices

When wireless devices are used near hearing devices (such as hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices

are more immune than others to this interference, and wireless devices also vary in the amount of interference that they generate.

The wireless telephone industry has developed ratings to assist hearing device users in finding wireless devices that may be compatible with their hearing devices. Not all wireless

devices have been rated. Wireless devices that are rated will have the rating displayed on the box together with other relevant approval markings.

The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device is vulnerable to interference, you may not be able to

wireless devices. T4 is the better or higher of the two ratings. (Note that not all hearing devices have telecoils in them.)

Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health professional may help you find results for your

hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from wireless devices.

For more information about the actions that the FCC has taken with regard to hearing aid compatibility with wireless devices and other steps that the FCC has taken to ensure that

individuals with disabilities have access to telecommunications services, visit www.fcc.gov/cgb/dro.

EU regulatory conformance

The manufacturer hereby declares that this smartphone is in compliance with the essential requirements and other relevant provisions of Radio Equipment Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the following internet address: http://www.blackberrymobile.com/EU_doc/.

The description of accessories and components, including software, which allow the radio equipment to operate as intended, can be obtained in the full text of the EU declaration

of conformity at the following internet address: http://www.blackberrymobile.com/EU_doc/.

Specific details about compliance to the standards and regulatory bodies for your smartphone may be obtained from the manufacturer.

To view FCC ID, ISEDC Certification Number, model, and compliance information for your smartphone, swipe down from the top of the screen once using two fingers, or twice using

one finger. Tap Settings > About phone > Regulatory approvals.

Product information: DTEK50STH100-2 smartphone

Mechanical properties:

• Weight: approximately 4.76 oz (135 g) including lithium-ion battery

• Size (L x W x H): 5.8 x 2.9 x 0.29 in. (147 x 72.5 x 7.4 mm)

• 3-GB memory, 16-GB application storage, microSD card slot

Power specifications:

Nonremovable, rechargeable lithium-ion battery

Power class: Class 1 (DCS 1800, PCS 1900), Class 3 (UMTS, LTE), Class 4 (GSM 850) as defined in GSM 5.05, Class 4 (GSM 900) as defined in GSM 02.06, Class E2 (GSM 850,

GSM 900, DCS 1800, PCS 1900)

Transmitting frequency: 703 to 733 MHz, 824 to 849 MHz, 830 to 840 MHz, 832 to 862 MHz, 880 to 915 MHz, 1710 to 1785 MHz, 1850 to 1910 MHz, 1920 to 1980 MHz, 2555

to 2655 MHz, 2500 to 2570 MHz, 2570 to 2620 MHz

Receiving frequency: 758 to 803 MHz, 791 to 821 MHz, 869 to 894 MHz, 875 to 885 MHz, 925 to 960 MHz, 1805 to 1880 MHz, 1930 to 1990 MHz, 2110 to 2170 MHz, 2300 to

2400 MHz, 2555 to 2655 MHz, 2570 to 2620 MHz, 2620 to 2690 MHz

Wi-Fi network radio specifications:

Wireless LAN standard: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Transmitting and receiving frequency for IEEE 802.11a/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n: 2.412 to 2.472 GHz <20 dBm

Transmitting and receiving frequency for IEEE 802.11a/IEEE 802.11ac/IEEE 802.11n: 5.180 to 5.825 GHz <17 dBm

Supported modes: reader/writer, card emulation, peer-to-peer

Legal notice

Trademarks, including but not limited to BLACKBERRY and EMBLEM Design, are the trademarks or registered trademarks of BlackBerry Limited and used under license by TCL

Communication Ltd.

Bluetoothis a trademark of Bluetooth SIG. CTIA - The Wireless Associationis a trademark of CTIA - The Wireless Association. GSM is a trademark of the GSM MOU Association.

IEEE802.11a, 802.11b, 802.11g, and 802.11n are trademarks of the Institute of Electrical and Electronics Engineers, Inc. Wi-Fi is a trademark of the Wi-Fi Alliance. All other

trademarks are the property of their respective owners. This documentation including all documentation incorporated by reference herein such as documentation provided or made

available on the Manufacturer website is provided “as is” and without condition, endorsement, guarantee, representation or warranty, or liability of any kind by the manufacturer

and its aliated companies, all of which are expressly disclaimed to the maximum extent permitted by applicable law in your jurisdiction.

Manufacturer: TCL Communication Ltd.
