TENDA TECHNOLOGY S108 8-PORT 10/100MBPS FAST ETHERNET SWITCH User Manual
SHENZHEN TENDA TECHNOLOGY CO., LTD. 8-PORT 10/100MBPS FAST ETHERNET SWITCH Users Manual
Users Manual
5/8 Ports
Gigabit Ethernet Switch
User’s Guide
VER:1.0
1
TABLE OF CONTENTS
1 INTRODUCTION
Unpacking ·················································· 2
Front Panel ················································· 2
Rear Panel ················································ 2
Led Indicators············································· 2
Features······················································ 3
2 PERFORMANCE FEATURES
Performance Features ································· 5
3 INSTALLATION
SWITCH to PC··········································· 6
SWITCH TO SWITCH······························· 6
4 APPENDIX
2
1.1 Unpacking
Open the box and carefully unpacks its
contents. The box should contain the
following items:
• One Gigabit Switch
• One external power adapter
• User’s Guide.
If any item is found missing or damaged,
please contact your dealer for replacement.
1.2 Front Panels
For detail of the LED indicators in the front
panel of the switch, refer to the LED Indicator
section for detailed information about each of
the 5/8 ports switch’s LED indicators.
1.3 Rear Panel
There are 5/8 10/100/1000Mbps RJ45 port Jacks
and one DC Power Jack in.
Attention: Please use power adapter
original from the supplier, otherwise please
consult with the supplier. An improper
adapter may cause permanent damage to
the switch.
1.4 LED Indicators
The LED indicators of the Switch include
Power 、Link/ACT and 1000M. The LED
indicators are used to facilitate monitoring and
troubleshooting of the Switch. The following
shows the LED indicators for the Switch along
with explanation of each indicator.
1 INTRODUCTION
3
1.5 Features
The 5/8-port Gigabit Ethernet Switch provides you
with a high-performance, low-cost, easy-to-use,
seamless and standard upgrade to boost your old
network to 1000Mbps. Increase the speed of your
network server and backbone connections make Gigabit
a reality. Power users in the home, office, workgroup, or
creative production environment can now move large,
LED
Indicator Color Status Description
Green Light This indicates the
Switch is turned
on
POWER
— Extinguish
If this indicator is
not light, check the
AC power
connector to
ensure proper
insertion of the
power cord and
the power switch
is turned on.
Green Light The port is
connected to a
Ethernet station
LINK/
ACT
Green Blinking The port is
transmitting or
receiving data
Green Light
The port is
connected to a
1000Mbps
Ethernet station
I
1000M
— Extinguish
The port is
connected to a
10/100Mbps
Fast Ethernet
station
4
bandwidth-intensive files faster. The 5/8 ports switch
combines large dynamic memory allocation with
store-and forward switching to ensure that the buffer is
effectively allocated for each port, while controlling the
data flow between the transmit and receive nodes to
guarantee against all possible packet loss. It can detect
10M/100M/1000M and full duplex/half duplex mode,
plug-and-play and no configuration is required.
1. Complies with IEEE802.3, IEEE802.3u,
IEEE802.3ab standards
2. NWAY Auto-negotiation support,
Auto-Sense the transmission speed,
half/full duplex, avoiding the complicate
procedure of settings, plug and play.
3. 5/8 ports 10/100/1000M Auto-Sense RJ45
ports supporting Auto-MDI/MDIX
4. Supports IEEE802.3x flow control for
full-duplex model and backpressure for
half-duplex transfer model
5. Provide 10/16G backplance bandwidth,
support non-blocking wire-speed
transfer.
6. Adopt store and forward structure, MAC
address auto learning, integration
2 PERFORMANCE FEATURES
5
2.1 Performance Features
z Convenience receptacle and equipment should
be within 1.82 meters.
z Check power supply to assure safe Connection.
z Affirm to have the ventilation that is enough,
can be very good dissipates heat. Not lay up the
heavy object on switch.
General features
Criterion
IEEE802.3 10BASE-T Ethernet
IEEE802.3u 100BASE-TX/FX Fast Ethernet
IEEE802.3ab Gigabit Ethernet
Protocol CSMA/CD
Topological
structure
Star-network
Network
Twisted-
pair
10BASE-T: Cat. 3 or above UTP/STP
100Base-TX：Cat. 5 UTP/STP
1000Base-T：Cat. 5 or 5e UTP/STP
Port amount 8/5 10/100/1000Mbps ports
Physics and setting features
AC INPUT Externalr power adapter
POWER 5 Watts maximum (5 ports)
8 Watts maximum (8ports)
Temperature Operation:0°C~50°C Storage:-30°C~60°C
Humidity 5%~90% no coagulate
Performance
Transfer mode Store and forward
MAC Address Table 8K
14880pps（10Mbps）per port
148800pps（100Mbps）per port
Packet
Filtering/Forwarding
Rate 1488000pps（1000Mbps）per port
MAC Address
learning
Auto learning and aging
3 INSTALLATION
6
3.1 SWITCH to PC
A PC can be connected to the switch via a
Cat. 5 or. 5e UTP/STP cable. The PC can be
connected to any of the5/8 ports.
3.2 SWITCH TO SWITCH
Like connection with the hub, the
connection is accomplished from any port of
the switch to the 5/8 ports Gigabit switch .
•
The standard RJ-45 receptacle/connector
The standard cable, RJ-45 pin assignment
RJ-45 Connector pin assignment
Pin No. Contact
1 A_TX + (Transmit)
2 A_TX - (Transmit)
3 B_RX + (receive)
4 C_TX+ (Transmit)
5 C_TX+ (Transmit)
6 B_RX - (receive)
7 D_RX - (receive)
8 D_RX - (receive)
4 APPENDIX
7
FCC WARNING
This device complies with Part 15 of the FCC
Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
NOTE 1: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a
8
circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
NOTE 2: The manufacturer is not responsible
for and radio or TV interference caused by
unauthorized modifications to this equipment.
Such modifications could void the user’s
authority to operate the equipment.
