TENDA TECHNOLOGY TEL9901G 10/100/1000 MBPS NETWORK INTERFACE CARD User Manual
SHENZHEN TENDA TECHNOLOGY CO., LTD. 10/100/1000 MBPS NETWORK INTERFACE CARD Users Manual
Users Manual
Copyright Statement
is the registered trademark of
Shenzhen Tenda Technology Co., Ltd. Other
trademark or trade name mentioned herein are the
trademark or registered trademark of the company.
Copyright of the whole product as integration,
including its accessories and software, belongs
to Shenzhen Tenda Technology Co., Ltd. Without
the permission of Shenzhen Tenda Technology Co.,
Ltd, individual or party is not allowed to copy,
plagiarize, imitate or translate it into other
languages.
All the photos and product specifications
mentioned in this manual are for references only,
as the upgrading of software and hardware, there
will be changes. And if there are changes, Tenda
is not responsible for informing in advance. If
you want to know more about our products
information, please visit our website at
www.tenda.cn
1
Table of Contents
1 Product Description..................................... 1
1.1 Unpacking ............................................1
1.2 Main Features ....................................1
1.3 Specifications .................................. 3
1.4 LED Indicators ................................ 3
2 Hardware Installation............................ 5
3 Driver Installation ....................................... 6
1
1 Product Description
Thanks for purchasing TENDA TEL9901G 10/100/
1000M auto-Negotiation Gigabit PCI LAN Adapter.
TEL9901G is fully compliant with PCI2.2, support
ACPI power management. TEL9901G is Auto-
Negotiation, supports three transfer rate of
10Mbps, 100Mbps and 1000Mbps. Being able to auto
detect the transfer rate of the networking
devices connected and also support full and half
duplex modes. Besides, TEL9901G also supports
Boot ROM and RPL/PXE.
TENDA TEL9901G supports driver software under
the operation system of Windows 98, Windows ME,
Windows 2000, Windows NT, Windows XP, Windows NT,
Linux and Novell etc.
1.1 Unpacking
This package contains:
10/100/1000Mbps Gigabit PCI LAN Adapter 1
CD Driver 1
User’s Manual 1
Quality-passed Certificate Card 1
Quality Warranty Card 1
1.2 Main Features
TEL9901G is fully compliant with IEEE802.3
10Base-T ， IEEE802.3u 100Base-Tx ， IEEE802.3ab
1000Base-T protocol, supports IEEE802.3x full
duplex flow control, IEEE802.1p priority tag.
And also supports Auto-Negotiation, auto
MDI/MDI-X, simple to configure and economic. It
2
is your best choice for realizing Gigabit
Network to your desktop.
Compliant with IEEE802.3, IEEE802.3u,
IEEE802.3ab standard;
Supports transfer rate of 10Mbps, 100Mbps,
1000Mbps and duplex of 10/100M under full duplex
mode, half duplex, 1000M under full duplex mode.
Supports NWAY Auto-Negotiation, auto detect
transfer rate, duplex mode, and able to select
an optimal network connecting mode and avoid
complex configuration, Plug-and-Play
Supports auto MDI/MDI-X
Supports IEE802.3x Flow Control for full-duplex
mode
Compliant with PCI 2.1, PCI2.2 protocol,
supports 32 bits, 33/66MHz PCI BUS, extremely
low CPU consumption
Supports ACPI power management, enables you to
manage power through modern operating systems
and obtains optimal power management.
Compliant with IEEE802.1Q standard, supports
Tag VLAN, supports IEEE802.1p priority tag.
Supports the transmitting and receiving of
Gigabit Jumbo Frame
Up to 2000Mbps throughput
Integrated big capacity independent
transferring/ receiving FIFO buffering area.
Adopting high integration and high performance
single chipset solution.
Supports Boot ROM, able to realize RPL/PXE while
inserting the appointed Boot ROM.
Abundant driving software supported, almost
supports all the normal operating systems
including WIN NT4.0, WIN98SE, WIN ME, WIN 2000,
WIN XP, NOVELL SERVER/CLIENT,
3
LINUX2.2X/2.4X/2.6X,
MAC OS and Free BSD etc.
1.3 Specifications
Main Features
Protocol
IEEE802.1p IEEE802.1Q
IEEE802.3 IEEE802.3u
IEEE802.3ab IEEE802.3x
BUS Type 32bit 33/66MHZ PCI BUS
Network Interface RJ45
I/O Address System auto assign
Disconnected (IRO) System auto assign
Half/Full Duplex
Transfer Rate
10/20Mbps 100/200Mbps
2000Mbps
Operating
Temperature 0℃~45℃ (32 F ~112 F)
Operating Humidity 10%-90% (non condensing)
Consumption
5 Voltage power input from
the PCI slot of the
main-board, MAX 4 watts
consumption
1.4 LED Indicators
One “FDX”LED ON indicates that TEL9901G is
working under full duplex mode
One “1000”LED Indicates status of 1000Mbps
Link/Act
One “100” LED Indicates status of 100Mbps
Link/Act
4
One “10” LED Indicates status of 10Mbps
Link/Act
Note: When the Link/Act LED is ON, it indicates
that TEL9901G is connected to the network
successfully at the respective transfer rate.
When the Link/Act LED is blinking, it indicates
that TEL9901G is transmitting data.
5
2 Hardware Installation
Please install TEL9901G according to the
following steps:
¾ Shut down your computer, unplug its power
cord and remove the chassis cover.
¾ Insert the contact edge of the DGE-530T card
into the connector of any available PCI Bus
Master expansion slot. Press the card
firmly into the connector such that the
card’s contacts are fully seated in the
connector.
¾ Install the bracket screw that secures the
card to the computer chassis and replace the
computer’s chassis cover.
¾ Connect TEL9901G to the network through Cat.
5 or Cat. 5 enhanced twisted pair cable.
‘
6
3 Driver Installation
Please install the driver according to the
following steps:
¾ Start PC, and insert the CD attached in the
packing. The computer would run the CD
automatically and display Tenda Setup on
the screen. (If the computer is not running
the CD automatically, please double click
the CD and run “TendaSetup.exe” ), please
click the icon of “driver software” to
install the driving software.
¾ Please click “TEL9901G”， select “the
language of driver software” and then click
“Enter” to start installation.
¾ Please select the directory for
installation and click “Next”
¾ Please click “Finish” and you now install
the driver successfully.
7
FCC Statement
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced
radio/TV technician for help.
8
To assure continued compliance, any
changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate this equipment. (Example- use only
shielded interface cables when connecting to
computer or peripheral devices).
FCC Radiation Exposure Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment and it also complies with Part
15 of FCC RF Rules. Operation is subject to
the following two conditions:
1) This device may not cause interference
and
2) This device must accept any interference,
including interference that may cause
undesired operation of the device.
Caution!
The manufacturer is not responsible for any
radio or TV interference caused by
unauthorized modifications to this
equipment. Such modifications could void
the user authority to operate the equipment.
