TRENDnet User’s Guide

Cover Page

TRENDnet User’s Guide

able of contents

Table of Contents

Table of Contents ............................................................................ 2

Product Overview ........................................................................... 4

Package Contents .......................................................................................................... 4

Features ......................................................................................................................... 4

Product Hardware Features........................................................................................... 5

Application Diagram ...................................................................................................... 7

Router Setup ................................................................................... 7

Creating a Home Network ............................................................................................. 7

Router Installation ......................................................................................................... 8

Connect additional wired devices to your network ..................................................... 12

Wireless Networking and Security ................................................. 12

How to choose the type of security for your wireless network .................................. 12

Secure your wireless network ..................................................................................... 13

Connect wireless devices to your router ..................................................................... 15

Connect wireless devices using WPS ........................................................................... 15

Basic ............................................................................................. 17

Access your router management page ........................................................................ 17

Network Status ............................................................................................................ 17

Wireless settings .......................................................................................................... 18

Guest Network ............................................................................................................. 19

Steps to improve wireless connectivity ....................................................................... 21

Parental Control ........................................................................................................... 21

Doman/URL Filters ............................................................................................. 22

IP Filters (LAN Client Filters) .............................................................................. 22

MAC Address Filters ........................................................................................... 22

ADVANCED ................................................................................... 23

Change your router IP address .................................................................................... 23

Set up the DHCP server on your router ....................................................................... 24

Set up DHCP reservation ............................................................................................. 24

Manually configure your Internet connection ............................................................ 25

Clone a MAC address ................................................................................................... 25

Add static routes to your router .................................................................................. 26

IPv6 Internet Connection Settings ............................................................................... 27

Prioritize traffic using QoS (Quality of Service) ........................................................... 28

Advanced wireless settings ......................................................................................... 29

Multiple SSID ..................................................................................................... 29

Wireless bridging using WDS (Wireless Distribution System) ........................... 31

Additional wireless settings ............................................................................... 32

Set your router date and time ..................................................................................... 33

Create schedules ......................................................................................................... 33

Access Control ............................................................................................................. 34

Open a device on your network to the Internet .......................................................... 35

DMZ ................................................................................................................... 35

Virtual Server ..................................................................................................... 35

Special Applications ........................................................................................... 36

Gaming............................................................................................................... 37

Enable/disable Application Layer Gateways (ALG) ...................................................... 38

Enable/disable UPnP on your router ........................................................................... 39

Using External USB Storage ........................................................... 39

Samba Network File Server ......................................................................................... 39

FTP (File Transfer Protocol) Server .............................................................................. 40

Properly Eject USB device ............................................................................................ 41

Print Share Utility Installation ....................................................... 42

Windows Installation ................................................................................................... 42

MAC OS X Installation .................................................................................................. 43

TRENDnet User’s Guide

able of contents

Launching the Utility .................................................................................................... 44

Utility Main Window .................................................................................................... 44

Configure Server .......................................................................................................... 45

Connect ........................................................................................................................ 45

Disconnect ................................................................................................................... 45

Sending a Request to Connect ..................................................................................... 46

Connect to a Printer..................................................................................................... 47

Auto-Connect Printer ................................................................................................... 48

Connect to a Scanner ................................................................................................... 48

Router Maintenance & Monitoring ................................................ 49

Change your router login password ............................................................................ 49

Change your device name ........................................................................................... 49

Change your device URL .............................................................................................. 50

Identify your network on the Internet ......................................................................... 50

Allow remote access to your router management page ............................................. 51

Reset your router to factory defaults .......................................................................... 51

Router Default Settings ............................................................................................... 52

Backup and restore your router configuration settings .............................................. 52

Upgrade your router firmware .................................................................................... 53

Reboot your router ...................................................................................................... 54

Allow/deny ping requests to your router from the Internet ....................................... 54

Check the router system information ......................................................................... 55

Router Management Page Structure ............................................. 59

Technical Specifications ................................................................ 60

Troubleshooting ........................................................................... 62

Appendix ...................................................................................... 63

TRENDnet User’s Guide

TEW-

818DRU

Product Overview

TEW-818DRU

Package Contents

In addition to your router, the package includes:

x CD-ROM (Utility and User’s Guide)

x Multi-Language Quick Installation Guide

x Network cable Ethernet Cable (1.5m / 5ft.)

x Power Adapter (12V, 2A)

If any package contents are missing or damaged, please contact the retail store, online

retailer, or reseller/distributor from which the product was purchased.

Features

TRENDnet’s AC1900 Dual Band Wireless Router, model TEW-818DRU, is an

extreme performance wireless router. It creates two concurrent wireless

networks—a 1.3 Gigabit Wireless AC network and a 600 Mbps Wireless N

network to connect common wireless devices. Use the high speed USB 3.0 port

and Gigabit Ethernet ports to further expand your network.

Ease of Use

Easy Setup

Get up and running in minutes with the intuitive guided setup

One Touch Connection

Securely connect to the router at the touch of the Wi-Fi Protected Setup (WPS)

button

USB Share Ports

Plug in a flash or storage drive into the 5 Gbps USB 3.0 port or the USB 2.0 port

Multi Language

Multi Language Interface: English, Spanish, French, German, and Russian

Security

Encrypted Wireless

For your security the router arrives pre-encrypted with its own unique password

Guest Network

Create a secure, isolated network for guest internet access only

Parental Controls

Control access to specific websites or types of content

Performance

Next Generation Wireless AC

802.11ac provides uninterrupted HD video streaming in a busy connected home

Simultaneous Dual Band

High speed 1300 Mbps Wireless AC band + 600 Mbps Wireless N

TRENDnet User’s Guide

TEW-

818DRU

Gigabit Ports

Gigabit ports extend high performance wired connections

Wireless Coverage

Whole home wireless coverage for average size homes

Backward Compatible

Compatible with legacy wireless devices

Energy Savings

Embedded GREENnet technology reduces power consumption by up to 50%

Targeted Beamforming

Increased real-time performance by directing stronger wireless to your specific

location

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical

specifications. Actual data throughput and coverage will vary depending on

interference, network traffic, building materials and other conditions. 802.11n 2.4 GHz

TurboQAM speeds requires clients with TurboQAM support.

** Printer Control Center utility installation required for each computer in order to

access the printer

Product Hardware Features

Rear View

x USB 3.0 and USB 2.0 Share Port: Connect a USB storage device to share files across

your network or connect a USB printer to share printers across your network

(Printer Control Center utility required for printer sharing).

x WPS Button (Wi-Fi Protected Setup): Push and hold this button for 5 seconds to

activate WPS. The Power LED will blink when WPS is activated.

x Gigabit LAN Ports 1-4: Connect Ethernet cables (also called network cables) from

your router LAN ports to your wired network devices.

x Gigabit Internet Port: Connect an Ethernet cable from your router Internet port to

your modem.

Reset Button (Located on Bottom)

Gigabit LAN

Ports 1-4

Gigabit Internet

Port

USB 3.0 Share

Port

Power Port

WPS Button

On/Off Power Swi

tch

(EU only)

USB 2.0 Share

Port

TRENDnet User’s Guide

TEW-

818DRU

x On/Off Power Switch: Push the router On/Off power switch to turn your router

“On” (Inner position) or “Off” (Outer position). Available on EU version product

only.

x Power Port: Connect the included power adapter from your router power port and

to an available power outlet.

x Reset Button (Located on Bottom): Press and hold this button for 10 seconds to

reset the router.

Front View

USB 3.0 and USB 2.0 LED: The indicator turns green indicating a USB device is

connected and turns off when there is no USB device connected.

5GHz Wireless (Link/Activity) LED: The indicator turns on solid green when 5GHz

wireless is enabled on your router. The indicator will blink during when data is

transmitted or received by your 5GHz wireless client devices connected to your

router.

2.4GHz Wireless (Link/Activity) LED: The indicator turns on solid green when

2.4GHz wireless is enabled on your router. The indicator will blink when data is

transmitted or received by your 2.4GHz wireless client devices connected to your

router.

LAN Ports 1-4 (Link/Activity) LED: These LED indicators are solid green when the

Gigabit LAN ports 1-4 (Black) are physically connected to your wired network

devices (which are turned on) with a network or Ethernet cable. These LED

indicators will blink green while data is transmitted or received through your

router’s Gigabit LAN ports.

Internet Port (Link/Activity) LED – This LED indicator is solid green when your

router Gigabit Internet port is physically connected to the modem network or

Ethernet port with a network or Ethernet cable (modem turned on). The LED

indicator will be blinking green while data is transmitted or received through the

Gigabit Internet port of your router.

Power/WPS LED: The indicator is solid green when your router is powered on.

Otherwise if this LED indicator is off, there is no power to your router. The

indicator will also blink when WPS is activated. The LED will stop blinking and

remain solid green automatically once WPS process is completed.

USB Share Port

5GHz Wireless LED

2.4GHz Wireless LED

LAN Ports 1-

4 LEDs

Internet Port LED

Power/WPS LED

TRENDnet User’s Guide

TEW-

818DRU

Application Diagram

The router is installed near the modem (typically supplied by your ISP “Internet Service Provider”)

and physically connected to it from the router’s Internet port to the modem’s network port which

connects to the Internet. 2.4GHz wireless signals from the router are broadcasted to wireless

clients such as laptops (with wireless capability) and the less congested 5GHz wireless signals from

the router are broadcasted to other wireless client devices such as TVs, game consoles, or media

bridges thereby providing Internet access for all wireless client devices, for faster 11ac

connection.

Router Setup

Creating a Home Network

What is a network?

A network is a group of computers or devices that can communicate with each other. A

home network of more than one computer or device also typically includes Internet

access, which requires a router.

A typical home network may include multiple computers, a media player/server, a

printer, a modem, and a router. A large home network may also have a switch,

additional routers, access points, and many Internet-capable media devices such as TVs,

game consoles, and Internet cameras.

x Modem: Connects a computer or router to the Internet or ISP (Internet Service

Provider).

x Router: Connects multiple devices to the Internet.

x Switch: Connect several wired network devices to your home network. Your router

has a built-in network switch (the LAN port 1-4). If you have more wired network

devices than available Ethernet ports on your router, you will need an additional

switch to add more wired connections.

How to set up a home network

1. For a network that includes Internet access, you’ll need:

x Computers/devices with an Ethernet port (also called network port) or wireless

networking capabilities.

x A modem and Internet service to your home, provided by your ISP (modem

typically supplied by your ISP).

x A router to connect multiple devices to the Internet.

2. Make sure that your modem is working properly. Your modem is often provided by

your Internet Service Provider (ISP) when you sign up for Internet service. If your

modem is not working contact your ISP to verify functionality.

3. Set up your router. See “How to setup your router” below.

4. To connect additional wired computers or wired network devices to your network,

see “Connect additional wired devices to your network” on page 12.

5. To set up wireless security on your router, see “Wireless Networking and Security” on

page 12.

How to setup your router

Refer to the Quick Installation Guide or continue to the next section “Router

Installation” on page 8 for more detailed installation instructions.

Where to find more help

In addition to this User’s Guide, you can find help below:

x http://www.trendnet.com/support (documents, downloads, and FAQs are available

from this Web page)

TRENDnet User’s Guide

TEW-

818DRU

Router Installation

Before you install

Many Internet Service Providers (ISPs) allow your router to connect to the Internet

without verifying the information fields listed below. Skip this section for now and if

your router cannot connect to the Internet using the standard installation process, come

back to this page and contact your ISP to verify required ISP specification fields listed

below.

1. Obtain IP Address Automatically (DHCP)

Host Name (Optional)

MAC Address: ___:___:___:___:___:___ Enter your PC’s MAC address (Optional)

DNS Servers Address 1: _____. _____._____._____ (Optional)

DNS Servers Address 2: _____. _____._____._____ (Optional)

2. Static/Fixed IP address

MAC Address: ___:___:___:___:___:___ Enter your PC’s MAC address (Optional)

IP Address: _____. _____._____._____ (e.g. 215.24.24.129)

Subnet Mask: _____. _____._____._____

Default Gateway IP Address: _____. _____._____._____

DNS Servers Address 1: _____. _____._____._____

DNS Servers Address 2: _____. _____._____._____

3. PPPoE to obtain IP automatically

User Name: _________

Password: ________________

4. PPTP

Type (Dynamic IP/DHCP or Static IP)

PPTP Server: _____________________ (IP address)

IP Address: _____. _____._____._____ (e.g. 215.24.24.129)

Subnet Mask:_____. _____._____._____

Default Gateway:_____. _____._____._____

Server IP: _____. _____._____._____

DNS Servers Address 1: _____. _____._____._____

DNS Servers Address 2: _____. _____._____._____

User Name: _________

Password: ________________

5. L2TP

Type (Dynamic IP/DHCP or Static IP)

L2TP Server: _____________________ (IP address)

IP Address: _____. _____._____._____ (e.g. 215.24.24.129)

Subnet Mask:_____. _____._____._____

Default Gateway:_____. _____._____._____

Server IP: _____. _____._____._____

DNS Servers Address 1: _____. _____._____._____

DNS Servers Address 2: _____. _____._____._____

User Name: _________

Password: ________________

TRENDnet User’s Guide

TEW-

818DRU

Hardware Installation

1. Verify that you have an Internet connection when connecting your computer directly

to your modem.

2. Turn off your modem.

3. Disconnect the Network cable from your computer to your modem.

4. Connect your modem to the router Internet port (yellow).

5. Connect your computer to one of the router LAN ports.

6. Connect the power adapter to the router and then to a power outlet.

7. Turn on your modem.

8. Verify that the status LED indicators on the front of the router are illuminated: Power,

Internet, one of the LAN ports (1,2,3,4) and Wireless Bands (2.4G,5G).

TRENDnet User’s Guide

TEW-

818DRU

Internet Setup Wizard

1. Open your web browser (e.g. Internet Explorer, Firefox, Safari, Chrome, or Opera) and

go to http://TEW-818DRU or you can access the router management using the IP

address http://192.168.10.1.

2. Your router will prompt you for a user name and password. For added security, the

router is preconfigured with a unique password. You can find the Password on a

sticker on the side of the router and on the label on the bottom of the router.

3. Enter your Username and Password, select your preferred language, then click Login.

User Name: admin

Password: (xxxxxxxx)

Note: User Name and Password are case sensitive.

4. The wizard will automatically begin when upon your initial setup. Click Next to begin.

5. Select “DHCP Connection (Dynamic IP Address)” and click Next to continue.

Note: Dynamic IP (DHCP) is typical for most Internet services. You can verify your

settings with your Internet Service Provider.

6. Confirm your Internet connection type and wireless interface settings. Click Apply to

save settings.

TRENDnet User’s Guide

TEW-

818DRU

7. Click OK when prompted.

9. Open a new tab on your web browser and enter in a website (e.g.

www.trendnet.com) to verify that you have an Internet connection.

10. For added security, the router is pre-encrypted with its own unique wireless network

security key. You can find the unique network security key and pre-assigned network

name (SSID) on a sticker on the front of the router and on a label on the bottom of the

router. If you would like to change the wireless settings, continue to the next page to

launch the wireless setup wizard.

TRENDnet User’s Guide

TEW-

818DRU

Connect additional wired devices to your network

You can connect additional computers or other network enabled devices to your

network by using Ethernet cables to connect them to one of the available LAN ports

labeled 1,2,3,4 on your router. Check the status of the LED indicators (1, 2, 3, or 4) on

the front panel of your router to ensure the physical cable connection from your

computer or device.

Note: If you encounter issues connecting to your network, there may be a problem with

your computer or device network settings. Please ensure that your computer or device

network settings (also called TCP/IP settings) are configured to obtain IP address settings

automatically (also called dynamic IP address or DHCP) and to Obtain DNS Server

address settings automatically.

Wireless Networking and Security

How to choose the type of security for your wireless network

Setting up wireless security is very important. Leaving your wireless network open and

unsecure could expose your entire network and personal files to outsiders. TRENDnet

recommends reading through this entire section and setting up wireless security on your

new router.

There are a few different wireless security types supported in wireless networking each

having its own characteristics which may be more suitable for your wireless network

taking into consideration compatibility, performance, as well as the security strength

along with using older wireless networking hardware (also called legacy hardware).

It is strongly recommended to enable wireless security to prevent unwanted users from

accessing your network and network resources (personal documents, media, etc.).

In general, it is recommended that you choose the security type with the highest

strength and performance supported by the wireless computers and devices in your

network. Please review the security types to determine which one you should use for

your network.

Wireless Encryption Types

x WEP: Legacy encryption method supported by older 802.11b/g hardware. This is

the oldest and least secure type of wireless encryption. It is generally not

recommended to use this encryption standard, however if you have old 802.11 b or

802.11g wireless adapters or computers with old embedded wireless cards(wireless

clients), you may have to set your router to WEP to allow the old adapters to

connect to the router.

Note: This encryption standard will limit connection speeds to 54Mbps.

x WPA: This encryption is significantly more robust than the WEP technology. Much

of the older 802.11g hardware was been upgraded (with firmware/driver upgrades)

to support this encryption standard. Total wireless speeds under this encryption

type however are limited to 54Mbps.

x WPA-Auto: This setting provides the router with the ability to detect wireless

devices using either WPA or WPA2 encryption. Your wireless network will

automatically change the encryption setting based on the first wireless device

connected. For example, if the first wireless client that connects to your wireless

network uses WPA encryption your wireless network will use WPA encryption. Only

when all wireless clients disconnect to the network and a wireless client with WPA2

encryption connects your wireless network will then change to WPA2 encryption.

TRENDnet User’s Guide

TEW-

818DRU

Note: WPA2 encryption supports 802.11n speeds and WPA encryption will limit

your connection speeds to 54Mbps

x WPA2: This is the most secure wireless encryption available today, similar to WPA

encryption but more robust. This encryption standard also supports the highest

connection speeds. TRENDnet recommends setting your router to this encryption

standard. If you find that one of your wireless network devices does not support

WPA2 encryption, then set your router to either WPA or WPA-Auto encryption.

Note: Check the specifications of your wireless network adapters and wireless

appliances to verify the highest level of encryption supported. Below is brief

comparison chart of the wireless security types and the recommended

configuration depending on which type you choose for your wireless network.

Security Standard

WEP

WPA

WPA2

Compatible

Wireless

Standards

IEEE 802.11a/b/g

(802.11n devices

will operate at

802.11g to connect

using this standard)

IEEE 802.11a/b/g

(802.11n d

evices

will operate at

802.11g to connect

using this

standard)

IEEE 802.11a/b/g/n

Highest

Performance

Under This

Setting

Up to 54Mbps

Up to 450Mbps (11n)

and u

p to 1.3Gbps

(11ac)*

Encryption

Strength

Low

Medium

High

Additional

Options

Open System or

Shared Key,

HEX or ASCII,

Different key sizes

TKIP or AES,

Preshared Key or

RADIUS

TKIP or AES,

Preshared Key or

RADIUS

Recommended

Configuration

Open System ASCII

13 characters

TKIP

Preshared Key

8-63 characters

AES

Preshared Key

8-63 characters

*Dependent on the maximum 802.11n

/ac data rate supported by

the device (150Mbps,

300Mbps, 450Mbps, 867Mbps, or 1.3Gbps)

Secure your wireless network

Wireless (2.4GHz or 5GHz)> Security

After you have determined which security type to use for your wireless network (see

“How to choose the security type for your wireless network” on page 12), you can set up

wireless security.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Wireless button.

3. Underneath the basic wireless band section, you will see Security Mode. Click on the

drop-down list to select your wireless security type.

Selecting WEP-OPEN, WEP-SHARED:

If selecting WEP (Wired Equivalent Privacy), please review the WEP settings to configure

and click Apply to save the changes.

Note: WEP security is only available in the Security Mode list when 802.11 n-mode is set

to Off under Wireless (2.4GHz or 5GHz) > Basic.

Note: WPS functionality is not available when using WEP.

In the Security Mode drop-down list, select WEP-OPEN or WEP-SHARED.

Note: It is recommended to use WEP-OPEN because it is known to be more secure than

Shared Key.

TRENDnet User’s Guide

TEW-

818DRU

x Current Network Key - You can define up to 4 keys however, only one key can be

active at any given time. Most users simply define one key. Click the drop-down list

to select which of the 4 keys is the active key.

x Network Key 1-4

o This is where you enter the WEP key needed for a computer to connect to the

router wirelessly

o You can define up to 4 passwords or 4 keys. Only one key can be active at a given

time. Most users simply define one key.

o Choose a key index 1, 2, 3, or 4 and enter the key.

o When connecting to the router, the client must match both the password and the

Key number. (e.g. if you have activated Key 2 with a password of 12345, then the

client must select: Key 2 (entering Key 1, 3, or 4 will block the ability to connect)

and enter password 12345)

Note: It is recommended to use 128-bit format because it is more secure to use a

key that consists of more characters.

x Click here to display - Typically, the password characters are masked for security

purposes. This link displays actual characters of the currently assigned password for

your reference.

Selecting WPA-PSK, WPA2-PSK, WPA2-PSK, or Mixed (WPA2-PSK recommended):

In the Security Mode drop-down list, select WPA-.

The following section outlines options when selecting WPA-PSK, WPA2-PSK, or WPA2-

PSK Mixed (Preshared Key Protocol),

x WPA Encryption: Select a Cipher Type to use. When selecting WPA-PSK security, it

is recommended to use TKIP + AES.

o When selecting WPA2-PSK Mixed security, it is recommended to use TKIP+AES.

o When selecting WPA2-PSK security, it is recommended to use AES.

x WPA passphrase: Enter the passphrase.

o This is the password or key that is used to connect your computer to this router

wirelessly

Note: 8-63 alphanumeric characters (a,b,C,?,*, /,1,2, etc.)

x Network Key Rotation Interval: Enter the time interval (seconds) of when the

network passphrase will rotate. Note: It is recommended to use the default interval

time. Your passphrase will not change, rotation of the key is part of the WPA

protocol and designed to increase security.

Selecting WPA, WPA2, or WPA2 Mixed:

WEP Key Format

HEX

ASCII

Character set

-9 & A-F, a-f only

Alphanumeric (a,b,C,?,*, /,1,2, etc.)

-bit key length

10 characters

5 characters

128

-bit key length

26 characters

13 characters

TRENDnet User’s Guide

TEW-

818DRU

The following section outlines options when selecting WPA. WPA2 or WPA2 Mixed

known as EAP (Extensible Authentication Protocol). Also known as called Remote

Authentication Dial-In User Service or RADIUS.

Note: This security type requires an external RADIUS server, PSK only requires you to

create a passphrase.

x RADIUS Server: Enter the IP address of the RADIUS server. (e.g. 192.168.10.250)

x RADIUS Port: Enter the port your RADIUS server is configured to use for RADIUS

authentication.

Note: It is recommended to use port 1812 which is typical default RADIUS port.

x RADIUS Key: Enter the shared secret used to authorize your router with your

RADIUS server.

Connect wireless devices to your router

A variety of wireless network devices can connect to your wireless network such as:

x Gaming Consoles

x Internet enabled TVs

x Network media players

x Smart Phones

x Wireless Laptop computers

x Wireless IP cameras

Each device may have its own software utility for searching and connecting to available

wireless networks, therefore, you must refer to the User’s Manual/Guide of your

wireless client device to determine how to search and connect to this router’s wireless

network.

See the “Appendix” on page 63 for general information on connecting to a wireless

network.

Connect wireless devices using WPS

WPS (Wi-Fi Protected Setup) is a feature that makes it easy to connect devices to your

wireless network. If your wireless devices support WPS, you can use this feature to

easily add wireless devices to your network.

Note: You will not be able to use WPS if you set the SSID Broadcast setting to Disabled or

if you are using WEP security.

There are two methods the WPS feature can easily connect your wireless devices to

your network.

x Push Button Configuration (PBC) method

o (RECOMMENDED) Hardware Push Button method–with an external button

located physically on your router and on your client device

o WPS Software/Virtual Push Button - located in router management page

x PIN (Personal Identification Number) Method - located in router management page

Note: Refer to your wireless device documentation for details on the operation of

WPS.

Recommended Hardware Push Button (PBC) Method

Note: It is recommended that a wireless key (passphrase or password) is created

before connecting clients using the PBC method. If no wireless key is defined when

connecting via PBC, the router will automatically create an encryption key that is 64

characters long. This 64 character key will then have to be used if one has to

connect computers to the router using the traditional connection method.

To add a wireless device to your network, simply push the WPS button on the wireless

device you are connecting (consult client device User’s Guide for length of time), then

push and hold the WPS button located on your router for 3 seconds and release it. A

blue LED on your router WPS button will flash indicating that the WPS setup process has

been activated on your router. (See “Product Hardware Features” on page 5)

For connecting additional WPS supported devices, repeat this process for each

additional device.

TRENDnet User’s Guide

TEW-

818DRU

PBC (Software/Virtual Push Button)

Wireless (2.4GHz or 5GHz)> WPS

In addition to the hardware push button located physically on your router, the router

management page also has push button which is a software or virtual push button you

can click to activate WPS on your router.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Select wireless band you would like to configure, Wireless 2.4GHz or Wireless 5GHz

and click on WPS.

4. To add a wireless device to your network, simply click the Add Enrollee button in the

router management page, then push the WPS button on the wireless device (consult

wireless device’s User’s Guide for length of time) you are connecting.

PIN (Personal Identification Number)

Wireless (2.4GHz or 5GHz)> WPS

If your wireless device has WPS PIN (typically an 8-digit code printed on the wireless

device product label or located in the wireless device wireless software utility), you can

use this method.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the wireless band Wireless (2.4GHz or 5GHz) you would like to configure and

click on WPS.

3. Next to Station PIN, enter the WPS PIN of the wireless device you are connecting and

click the Add Enrollee button.

Note: You may need to initiate the WPS PIN on your wireless device first when using

this method. Refer to your wireless device documentation for details on the

operation of WPS.

TRENDnet User’s Guide

TEW-

818DRU

Basic

Access your router management page

Note: Your router management page URL/domain name http://TEW-818DRU or IP

address http://192.168.10.1 is accessed through the use of your Internet web browser

(e.g. Internet Explorer, Firefox, Chrome, Safari, Opera) and will be referenced frequently

in this User’s Guide.

1. Open your web browser (e.g. Internet Explorer, Firefox, Safari, Chrome, or Opera) and

go to URL/domain name http://TEW-818DRU or IP address http://192.168.10.1. Your

router will prompt you for a user name and password.

2. For added security, the router is preconfigured with a unique password. You can find

the Password on a sticker on the side of the router and on the label on the bottom of

the router.

3. Enter your Username and Password, select your preferred language, then click Login.

x User Name: admin

x Password: (xxxxxxxx)

Note: User Name and Password are case sensitive.

Network Status

This screen appears when you login into your router. This section provides an over view

of your.

TRENDnet User’s Guide

TEW-

818DRU

Internet: This icon turns green to indicate that your network has a valid

Internet connection. Amber color indicates a physical connection on the

Internet port of the router but with no valid Internet connection. Red color

indicates disconnected Internet port.

Guest Network: The section provides your router’s guest network SSID.

USB: This icon turns green when your router has a valid USB connection. Red

Amber color indicates no USB connection.

Wireless: This icon turns green to indicate when your router’s wireless

network is enabled. Red color indicates your router’s wireless network is

disabled.

Security: This section provides your router’s wireless network security

information.

Connected Devices: This section provides information of all connected

devices on your router.

Wireless settings

Wireless (2.4GHz or 5GHz)> Basic

This section outlines available management options under basic wireless sub tab for

both 2.4GHz and 5GHz wireless sections.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on Wireless and under the Basic tab.

3. To save changes to this section, click Apply when finished.

x Radio On/Off:

o On: Turns on wireless radio.

o Off: Turns off wireless radio.

x Wireless Name (SSID): Enter the wireless name (SSID) for your wireless network.

This acronym stands for Service Set Identifier and is the name of your wireless

network. It differentiates your wireless network from others around you. By

default, the router’s wireless name is unique to the device. If you choose to change

the SSID, change it to a name that you can easily remember.

x 802.11 n-mode

o Auto: Select this option if you have non-802.11n wireless clients (802.11a/b/g)

connecting to your wireless network.

TRENDnet User’s Guide

TEW-

818DRU

o Off: The router will operate in 802.11n mode only, non-802.11n wireless clients

will not be able to connect when this option is selected.

When applying the 802.11 n-mode setting on 2.4GHz, please keep in mind the following:

x Wireless devices that support 802.11n are backwards compatible and can connect

wirelessly at 802.11g or 802.11b.

x Connecting at 802.11b or 802.11g will limit the capability of your 802.11n

supported wireless devices from obtaining higher performance and data rates.

x Allowing 802.11b or 802.11g devices to connect to an 802.11n capable wireless

network may degrade the wireless network performance below the higher

performance and data rates of 802.11n.

x Wireless devices that only support 802.11b or 802.11g will not be able to connect

to a wireless network that is set to 802.11n only mode.

x Wireless devices that only support 802.11b will not be able to connect to a wireless

network that is set to 802.11g only mode.

x Broadcast Network Name (SSID):

o Enabled allows wireless devices to search and discover your wireless network

name (also called SSID) broadcasted by your router.

o Disabled turns off the ability for wireless devices to find your network. It is still

possible for wireless devices to be configured to connect to your wireless

network. Disabling this setting will disable WPS functionality.

x Frequency (Channel): To manually set the channel on which the router will

broadcast, click the drop-down list and select the desired Channel for wireless

communication. The goal is to select the Channel that is least used by neighboring

wireless networks.

x Channel Bandwidth: Select the appropriate channel width for your wireless

network. This setting only applies to 802.11n and 802.11ac. For greater 802.11n

performance in 2.4GHz, select 40MHz (Options: 20MHz or 40MHz). For greater

802.11ac performance in 5GHz, select 80MHz (Options: 20MHz, 40MHz, or 80MHz)

It is recommended to use the default channel bandwidth settings.

Note: Please note that this setting may provide more stability than the higher

channel bandwidth settings such as 40 MHz or 80MHz for connectivity in busy

wireless environments where there are several wireless networks in the area.

20 MHz: This mode operates using a single 20MHz channel for wireless devices

connecting at 802.11n on both 2.4GHz and 5GHz. This setting may provide more

stability than 40MHz or 80MHz for connectivity in busy wireless environments

where there are several neighboring wireless networks in the area.

40 MHz or 80MHz:When 40MHz or 80MHz is active, this mode is capable of

providing higher performance only if the wireless devices support the channel

bandwidth settings. Enabling 40MHz or 80MHz typically results in substantial

performance increases when connecting an 802.11n or 802.11ac client. Note:

Please note that 80MHz channel bandwidth is only available for 802.11ac 5GHz.

Guest Network

Wireless (2.4GHz or 5GHz) > Guest Network

Creating an isolated and separate wireless guest network (2.4GHz or 5GHz) allows

wireless clients to connect to your network for Internet access only and keep your local

LAN network safe by restricting guest access to your LAN network resources such as

shared documents and media files on your computers, network storage, and printers.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Basic tab.

3. Click on Guest Network section.

4. Review the Guest Network settings, click Apply when finished.

x Enabled: Check the option to enable the Guest Network.

TRENDnet User’s Guide

TEW-

818DRU

x Wireless Name (SSID): This acronym stands for Service Set Identifier and is the

name of your wireless network. It differentiates your wireless network from others

around you. It is recommended to use a different name from your primary wireless

network to a name that you can easily identify and differentiate from the primary.

You can reference your guests to access this network instead of the primary.

x Internet Access Only: By default, the option is checked to allow guests to only

access the Internet and restrict access to your local LAN network. Please note that

unchecking this option will open access to local LAN network to guests.

x Wireless Client Isolation: Checking this option will restrict guests from

communicating with each other over the guest network such as share files.

5. Under Security Policy, you can apply a different wireless security type and key to the

guest network. Please refer to page 15 to find out about different security types and

page 16 for wireless security configuration.

Advanced Guest Network Settings

Wireless (2.4GHz or 5GHz) > Guest Network>Advanced Guest Network Settings

At the bottom of the guest network page, you can click the “Advanced Guest Network

Settings” to configure the additional guest network options such as the guest network

interface IP address, DHCP server IP address range, and DHCP reservation.

Review the Advanced Guest Network settings, click Apply when finished.

In most cases, you do not need to change your guest network IP address settings.

Typically, the router IP address settings only needs to be changed, if you plan to use

another router in your network with the same IP address settings, if you are connecting

your router to an existing network that is already using the IP address settings your

router is using, or if you are experiencing problems establishing VPN connections to

your office network through your router.

x IP Address – Enter the new guest network IP address.

(e.g. 192.168.100.1)

x Subnet Mask – Enter the new guest network subnet mask.

(e.g. 255.255.255.0)

Note: If you are not encountering any issues or are not faced with one of the cases

described above or similar, it is recommended to keep your guest network sIP address

settings as default. The guest network IP address settings should different from your

local LAN network IP address settings (Default: 192.168.10.1 / 255.255.255.0)

Your router can be used as a DHCP (Dynamic Host Configuration Protocol) server to

automatically assign an IP address to each computer or device on your guest network.

The DHCP server is enabled by default on your router. It is recommended to leave this

setting enabled.

x DHCP Server – Enable or Disable the DHCP server.

x DHCP Start IP – Changes the starting address for the DHCP server range. (e.g.

192.168.20.20)

x DHCP End IP – Changes the last address for the DHCP server range. (e.g.

192.168.20.30)

x Lease Time – Enter the lease time in seconds.

DHCP (Dynamic Host Configuration Protocol) reservation (also called Static DHCP) allows

your router to assign a fixed IP address from the DHCP server IP address range to a

specific device on your guest network.

TRENDnet User’s Guide

TEW-

818DRU

x Hostname: Enter a name of the device you will assign the DHCP reservation rule.

x MAC Address: Enter the MAC (Media Access Control) address of the computer or

network device to assign to the reservation. (e.g. 00:11:22:AA:BB:CC)

x IP Address: Enter the IP address to assign to the reservation. (e.g.

192.168.10.101)

x Enable: Select enable to enable the setting

Steps to improve wireless connectivity

There are a number of factors that can impact the range of wireless devices. Follow

these tips to help improve your wireless connectivity:

1. Keep the number of obstructions to a minimum. Each obstruction can reduce the

range of a wireless device. Position the wireless devices in a manner that will

minimize the amount of obstructions between them.

a. For the widest coverage area, install your router near the center of your home,

and near the ceiling, if possible.

b. Avoid placing the router on or near metal objects (such as file cabinets and

metal furniture), reflective surfaces (such as glass or mirrors), and masonry

walls.

c. Any obstruction can weaken the wireless signal (even non-metallic objects), so

the fewer obstructions between the router and the wireless device, the better.

d. Place the router in a location away from other electronics, motors, and

fluorescent lighting.

e. Many environmental variables can affect the router’s performance, so if your

wireless signal is weak, place the router in several locations and test the signal

strength to determine the ideal position.

2. Building materials can have a large impact on your wireless signal. In an indoor

environment, try to position the wireless devices so that the signal passes through

less dense material such as dry wall. Dense materials like metal, solid wood, glass

or even furniture may block or degrade the signal.

3. Antenna orientation can also have a large impact on your wireless signal. Use the

wireless adapter’s site survey tool to determine the best antenna orientation for

your wireless devices.

4. Interference from devices that produce RF (radio frequency) noise can also impact

your signal. Position your wireless devices away from anything that generates RF

noise, such as microwaves, radios and baby monitors.

If possible, upgrade wireless network interfaces (such as wireless cards in computers)

from older wireless standards to 802.11n or 802.11ac. If a wirelessly networked device

uses an older standard, the performance of the entire wireless network may be slower.

If you are still experiencing low or no signal consider repositioning the wireless devices,

installing additional access points or wireless extenders.

Parental Control

This section outlines available management options under basic wireless sub tab for

both 2.4GHz and 5GHz wireless sections.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Basic tab.

3. Click on the Parental Control section.

TRENDnet User’s Guide

TEW-

818DRU

Doman/URL Filters

Basic > Parent Control

You may want to block computers or devices on your network access to specific

websites (e.g. www.trendnet.com, etc.), also called domains or URLs (Uniform Resource

Locators). You may also enter a keyword (e.g. instead of complete URL to generally

block computers or devices access to websites that may contain the keyword in the URL

or on the web page.

Review the settings under Web URL Filter Rules section. Click Apply to save settings.

Under Web URL Filter drop-down menu select Enabled to activate the feature.

x URL: Enter the Website/URL/domain (e.g.www.trendnet.com) or keyword (e.g.

trendnet) to block.

x Schedule: Click the drop-down list to select the pre-defined schedule to apply.

The filter will only be active during the time period defined in the pre-defined

schedule. (See “Create Schedule” section on page 33).

Note: Before applying scheduling, please ensure your Time settings are configured

correct and you have defined a schedule. See page 37 to configure Time Settings

and see page 38 to create a schedule.

Enabled: Checking the Enabled option activates on the URL filter rule.

IP Filters (LAN Client Filters)

Basic > Parent Control

You may want to block computers or devices on your network access to specific ports

(used or required by a specific application) to the Internet.

Review the settings under IP Filter Rules section. Click Apply to save settings. Under the

IP Filter Mode drop-down list and select Enabled to activate the feature.

x LAN IP Address Range: Enter the IP address or IP address range to apply the

protocol (e.g. 192.168.10.20-192.168.10.20 or 192.168.10.20-192.168.10.30).

Note: The filter will not be applied to IP addresses outside of the range specified.

Protocol – Select the protocol type to filter. TCP, UDP.

x Schedule: Click the drop-down list to select the pre-defined schedule to apply.

The filter will only be active during the time period defined in the pre-defined

schedule. (See “Create Schedule” section on page 33).

Note: Before applying scheduling, please ensure your Time settings are configured

correct and you have defined a schedule. See page 37 to configure Time Settings

and see page 38 to create a schedule.

x Enabled: Checking the Enabled option activates on the LAN Client Filter rule.

MAC Address Filters

Basic > Parent Control

Every network device has a unique, 12-digit MAC (Media Access Control) address. Using

MAC filters, you can allow or deny specific computers and other devices from using this

router’s wired network.

Review the settings under MAC Filter section. Click Apply to save settings.

TRENDnet User’s Guide

TEW-

818DRU

x MAC Filter Mode: Select the option you would like to apply to the listed MAC

address.

o Disabled: Select this option to disable MAC filter rule.

o Deny: Select this option to deny listed MAC addresses.

o Allow: Select this option to only allow listed MAC addresses.

x MAC Filters: Enter the MAC address of the devices you would like to filter. (e.g.

00:11:22:AA:BB:CC)

Note: Enter the Add the MAC addresses to the MAC Table first before applying the

MAC filter function.

x Interface: Select the interface of the MAC address filter

o LAN: Local Access Network, wired clients

o WLAN: Wireless Local Access Network, wireless clients

o Both: Select this option if you uncertain which interface to use.

Note: MAC filter can be configured to allow access to the listed MAC address and

deny all others unlisted or vice versa. The recommended function is to choose to

only allow access to the MAC addresses listed and deny all others unlisted because it

is easier to determine the MAC addresses of devices in your network then to

determine which MAC addresses you do not want to allow access. You can check the

DHCP Client List for the MAC addresses of the devices on your network, see page 56

or refer to your computer or device documentation to find the MAC address.

ADVANCED

Change your router IP address

Advanced > Setup > LAN Setting

In most cases, you do not need to change your router IP address settings. Typically, the

router IP address settings only needs to be changed, if you plan to use another router in

your network with the same IP address settings, if you are connecting your router to an

existing network that is already using the IP address settings your router is using, or if

you are experiencing problems establishing VPN connections to your office network

through your router.

Note: If you are not encountering any issues or are not faced with one of the cases

described above or similar, it is recommended to keep your router IP address

settings as default.

Default Router IP Address: 192.168.10.1

Default Router Network: 192.168.10.0 / 255.255.255.0

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Setup section and click on LAN Setting.

4. In LAN Interface Setting section, Enter the router IP address settings. Click Apply to

save settings.

TRENDnet User’s Guide

TEW-

818DRU

Note: The DHCP address range will change automatically to your new router IP

address settings so you do not have to change the DHCP address range manually to

match your new router IP address settings.

x IP Address: Enter the new router IP address. (e.g. 192.168.200.1)

x Subnet Mask: Enter the new router subnet mask. (e.g. 255.255.255.0)

Note: You will need to access your router management page using your new

router IP address. (e.g. Instead of using the default http://192.168.10.1 your new

router IP address will use the following format using your new IP address

http://(new.ipaddress.here) to access your router management page. You can

also use the default login URL http://TEW-818DRU

Set up the DHCP server on your router

N Advanced > Setup > LAN Setting

Your router can be used as a DHCP (Dynamic Host Configuration Protocol) server to

automatically assign an IP address to each computer or device on your network. The

DHCP server is enabled by default on your router. If you already have a DHCP server on

your network, or if you do not want to use your router as a DHCP server, you can disable

this setting. It is recommended to leave this setting enabled.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Setup section and click on LAN Setting.

3. Review the DHCP Server settings. Click Apply to save settings.

x DHCP Server: Enable or Disable the DHCP server.

x DHCP Start IP: Changes the starting address for the DHCP server range.

(e.g.192.168.10.20)

x DHCP End IP: Changes the last address for the DHCP server range. (e.g.

192.168.10.30)

Note: The Start IP and End IP specify the range of IP addresses to automatically

assign to computers or devices on your network.

x DHCP Lease Time: Click the drop-down list to select the lease time.

Note: The DHCP lease time is the amount of time a computer or device can keep an

IP address assigned by the DHCP server. When the lease time expires, the computer

or device will renew the IP address lease with the DHCP server, otherwise, if there is

no attempt to renew the lease, the DHCP server will reallocate the IP address to be

assigned to another computer or device.

Set up DHCP reservation

Network > LAN Setting

DHCP (Dynamic Host Configuration Protocol) reservation (also called Static DHCP) allows

your router to assign a fixed IP address from the DHCP server IP address range to a

TRENDnet User’s Guide

TEW-

818DRU

specific device on your network. Assigning a fixed IP address can allow you to easily

keep track of the IP addresses used on your network by your computers or devices for

future reference or configuration such as virtual server (also called port forwarding, see

“Virtual Server” on page 35) or special applications (also called port triggering, see

“Special Applications” on page 36).

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Setup section and click on LAN Setting.

3. Review the DHCP reservation settings. Click Apply to save settings.

x Hostname: Enter a name of the device you will assign the DHCP reservation rule.

x MAC Address: Enter the MAC (Media Access Control) address of the computer or

network device to assign to the reservation. (e.g. 00:11:22:AA:BB:CC)

x IP Address: Enter the IP address to assign to the reservation. (e.g. 192.168.10.101)

x Enable: Check the Enabled option to enable the reservation.

Manually configure your Internet connection

Advanced > Setup > WAN Setting

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Setup section and click on WAN Setting.

4. In the WAN Connection Type drop-down list, click the type of Internet connection

provided by your Internet Service Provider (ISP).

5. Complete the fields required by your ISP.

6. Complete the optional settings only if required by your ISP.

7. To save changes, click Apply.

Note: If you are unsure which Internet connection type you are using, please contact

your ISP.

Clone a MAC address

Advanced > Setup > WAN Setting

TRENDnet User’s Guide

TEW-

818DRU

On any home network, each network device has a unique MAC (Media Access Control)

address. Some ISPs register the MAC address of the device (usually a router or a

computer) connected directly to the modem. If your computer MAC address is already

registered with your ISP and to prevent the re-provisioning and registration process of a

new MAC address with your ISP, then you can clone the address (assign the registered

MAC address of your previous device to your new router). If you want to use the MAC

address from the previous device (computer or old router that directly connected to the

modem, you should first determine the MAC address of the device or computer and

manually enter it into your router using the clone MAC address feature.

Note: For many ISPs that provide dynamic IP addresses automatically, typically, the

stored MAC address in the modem is reset each time you restart the modem. If you

are installing this router for the first time, turn your modem before connecting the

router to your modem. To clear your modem stored MAC address, typically the

procedure is to disconnect power from the modem for approximately one minute,

then reconnect the power. For more details on this procedure, refer to your

modem’s User Guide/Manual or contact your ISP.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Setup section and click on WAN Setting.

4. Next to MAC Address field, enter the MAC address of your computer. Click Apply to

save settings

Note: You can check the DHCP Client List for the MAC addresses of the devices on

your network, see page 36 or refer to your computer or device documentation to

find the MAC address.

Add static routes to your router

Advanced > Setup > Routing

You may want set up your router to route computers or devices on your network to

other local networks through other routers. Generally, different networks can be

determined by the IP addressing assigned to those networks. Generally speaking and for

the case of an example, your network may have 192.168.10.x IP addressing and another

network may have 192.168.20.x IP addressing and because the IP addressing of these

two networks are different, they are separate networks. In order to communicate

between the two separate networks, static routing needs to be configured. Below is an

example diagram where routing is needed for devices and computers on your network

to access the other network.

Note: Configuring this feature assumes that you have some general networking

knowledge.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Setup section and click on Routing.

TRENDnet User’s Guide

TEW-

818DRU

4. Review the LAN/WAN Static Routes section. Click Apply to save settings.

x IP Address: Enter the IP network address of the destination network for the route.

(e.g. 192.168.20.0)

x Subnet Mask: Enter the subnet mask of the destination network for the route.

(e.g. 255.255.255.0)

x Gateway: Enter the gateway to the destination network for the route.

(e.g. 192.168.10.2)

x Metric: Enter the metric or priority of the route. The metric range is 1-15, the

lowest number 1 being the highest priority. (e.g. 1 )

IPv6 Internet Connection Settings

Advanced > Setup > IPv6 Setting

IPv6 (Internet Protocol Version 6) is a new protocol that significantly increases the

number of available Internet public IP addresses due to the 128-bit IP address structure

versus IPv4 32-bit address structure. In addition, there are several integrated

enhancements compared to the most commonly used and well known IPv4 (Internet

Protocol Version 4) such as:

x Integrated IPsec – Better Security

x Integrated Quality of Service (QoS) – Lower latency for real-time applications

x Higher Efficiency of Routing – Less transmission overhead and smaller routing tables

x Easier configuration of addressing

Note: In order to use IPv6 Internet connection settings, it is required that your ISP

provide you with the IPv6 service. Please contact your ISP for availability and more

information about the IPv6 service.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Setup section and click on IPv6 Setting.

4. Review the IPv6 Internet Connection settings and enter information settings specified

by your ISP.

In WAN IPv6 Setting section, enter your IPv6 settings provided by your ISP (Internet

Service Provider) to configure your router’s IPv6 WAN settings. Click Apply to save

settings.

In LAN IPv6 Setting section, enter your IPv6 settings you would like to apply to your

LAN (Local Area Network). Click Apply to save settings.

TRENDnet User’s Guide

TEW-

818DRU

x Mode

o Disabled: IPv6 will be disabled when this option is selected

o 6to4 Only: 6to4 is provided as a transitional mechanism for migrating from IPv4

to IPv6. It allows IPv6 packets to be transmitted over an IPv4 network through

the automatic tunneling technology and routes traffic between 6to4 and IPv6

networks.

o Native IPv6 only: Native IPv6 refers to a network where IPv6 is the only transport

protocol.

o 6to4 + Native IPv6: Supports 6to4 and Native IPv6 simultaneously.

x LAN Network Prefix: Enter the LAN Network Prefix here. This can be based on ULA

(Unique Local Address).

x DNS server: IPv6 DNS address will be provided by your local ISP.

x 6to4 subnet ID: Specifies, in hexadecimal notation, a subnet ID other than 0

Prioritize traffic using QoS (Quality of Service)

Advanced > Setup > QoS

You may want to prioritize traffic for specific computers or devices on your network to

have higher priority. QoS involves prioritization of network traffic. QoS can be targeted

at a network interface, toward a given server or router's performance, or in terms of

specific applications.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Setup section and click on IPv6 Setting.

4. Review the QoS settings.

x Enable QoS: Enable or Disable the Quality of service through the router.

x Prioritize ACK: Enable or disable ACK prioritization.

x Prioritize ICMP: Enable or disable ICMP prioritization.

5. Select the traffic class you would like to configure for your QoS rule.

6. Review the Inbound/Outbound Class Setting section.

TRENDnet User’s Guide

TEW-

818DRU

x BW Max Inbound: Enter the maximum download speed of your ISP (Internet

Service Provider).

x Highest/High/Medium/Low/Lowest: Enter the download speeds you would like to

apply on each state of download speeds. This setting is similar to setting the priority

speeds of each class

7. Review the QoS Rule settings. Click Add Rule to add and save the rule to the QoS Rule

List

x IP/MAC Address Filter: Select from the pull down menu the IP address or MAC you

would like to apply and enter the IP address of MAC address.

x Protocol Filter: Select the protocol you would like to apply on the QoS Rule.

x Port Filter: Select the port from the pull down menu you would like to assign on the

QoS rule and enter the port.

x Class Assigned: Select from the pull down menu the class you applied on the

previous section you would like to assign the QoS rule.

x Description: Enter the QoS description that best describes the rule.

Advanced wireless settings

The advanced wireless features provide can provide you with additional options for

setting up your wireless network such as multiple SSID and WDS (Wireless Distribution

System) or wireless bridging.

Multiple SSID

Advanced > Wireless (2.4GHz or 5GHz) > Multiple SSID

The multiple SSID feature allows you to broadcast up to 2 additional SSIDs (or wireless

network names). When wireless devices are searching for available wireless networks to

connect to, the SSIDs (or wireless network names) will appear as separate and different

wireless networks. Since they appear as separate wireless networks, they are also

referred to as virtual APs (Access Points) since they appear as separate wireless access

points but are actually all being broadcasting and managed by a single wireless access

point. Each virtual AP can be configured each with a different SSID (or wireless network

name), security type and additional settings for wireless devices to connect. You can use

TRENDnet User’s Guide

TEW-

818DRU

the multiple SSID feature to setup guest wireless accounts with a different security type

to keep your primary wireless network security information private. The diagram shows

an example of a client connecting to SSID 1 and another client connecting to SSID 2.

By default, your router functions in Access Point mode to allow wireless client devices to

connect and access your network resources and access the Internet using a single SSID.

The diagram shows an example of a client connecting to SSID 1 and another client

connecting to SSID 2.

To configure multiple SSID on your router:

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Select the wireless band you would like to configure Wireless 2.4GHz or Wireless

5GHz and click on Multiple SSID.

4. Review the Multiple SSID settings, click Apply when finished.

x Enabled: Check the option to enable the Guest Network.

x Wireless Name (SSID): This acronym stands for Service Set Identifier and is the

name of your wireless network. It differentiates your wireless network from others

around you. It is recommended to use a different name from your primary wireless

network to a name that you can easily identify and differentiate from the primary.

You can reference your guests to access this network instead of the primary.

x Broadcast Network Name (SSID):

o Enabled allows wireless devices to search and discover your wireless network

name (also called SSID) broadcasted by your router.

o Disabled turns off the ability for wireless devices to find your network. It is still

possible for wireless devices to be configured to connect to your wireless

network. Disabling this setting will disable WPS functionality.

5. Under Security Policy, you can apply a different wireless security type and key to the

guest network. Please refer to page 15 to find out about different security types and

page 16 for wireless security configuration.

Note: You can repeat the steps to enable and configure additional SSIDs. You can

configure your wireless security settings for the additional SSIDs under Wireless

(2.4GHz or 5GHz)>Security. Under the Security Policy section, click the Wireless

Name (SSID) drop-down list to select the additional SSIDs to configure. Please refer

to page 15 to find out about different security types and page 16 for wireless

security configuration.

TRENDnet User’s Guide

TEW-

818DRU

Wireless bridging using WDS (Wireless Distribution System)

Advanced > Wireless (2.4GHz or 5GHz) > WDS

Wireless bridging using WDS allows the device to create a wireless bridge with other

WDS supported wireless routers and access points configured in WDS mode to bridge

groups of network devices together wirelessly. Simultaneously, the router will also

function in access point mode allowing wireless client devices such as computers, game

consoles, mobile phones, etc. to connect in order to access network resources from

multiple groups of network devices as well as the Internet.

Note: You can create up to four WDS bridge connections on each wireless band

(2.4GHz and 5GHz). WDS (Wireless Distribution System) is not currently

standardized and may not connect to different model wireless routers or access

points, therefore, when using WDS, it is recommended to use the same model and

version for wireless bridging.

By default, your router functions in Access Point mode to allow wireless client devices to

connect and access your network resources and access the Internet.

In the diagram below, the blue color represents the WDS wireless bridged connections

between the routers. The green color represents access point mode connections

between wireless client devices and the routers.

Note: Before configuring WDS, please ensure the following first:

1. Make sure different IP addresses are assigned to each WDS supported wireless

device used for bridging. (ex. 192.168.10.1,192.168.10.2, 192.168.10.3) to avoid

IP address conflict. See page 34 for changing the LAN IP address.

2. If you are using more than one WDS supported router, please make sure the LAN

DHCP server is enabled on only one and disabled on all others to avoid IP address

conflict. See page 35 for DHCP server options.

3. Configure the same wireless channel and use the same on all WDS supported

wireless devices. See page 20 for configuring basic wireless settings.

4. Configure the same wireless security and key on all WDS supported devices. See

page 15 for configuring wireless security settings.

To configure WDS bridging between TEW-818DRU routers:

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Select wireless band you would like to configure, Wireless 2.4GHz or Wireless 5GHz

and click on WDS.

4. Next to Wireless Distribution System (WDS), in an empty field, enter the MAC

address of the other WDS supported wireless device you are bridging. (e.g.

00:11:22:AA:BB:CC). To save settings, click Apply.

TRENDnet User’s Guide

TEW-

818DRU

For additional routers, make sure to disable the DHCP server first on all additional

routers and configure the LAN IP address to be different on each router. You will

connect devices to the LAN ports 1-4 only on all additional routers and the WAN port is

not used. Then, repeat the steps for additional routers you are bridging.

Additional wireless settings

Advanced > Wireless (2.4GHz or 5GHz) > Advanced

These settings are advanced options that can be configured to change advanced

wireless broadcast specifications. It is recommended that these settings remain set to

their default values unless you are knowledgeable about the effects of changing these

values. Changing these settings incorrectly can degrade performance.

To configure multiple SSID on your router:

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Select wireless band you would like to configure, Wireless 2.4GHz or Wireless 5GHz

and click on Multiple SSID.

4. Review the Multiple SSID settings, click Apply when finished.

x Beacon Interval: A beacon is a management frame used in wireless networks that

transmitted periodically to announce the presence and provide information about

the router’s wireless network. The interval is the amount time between each

beacon transmission.

Default Value: 100 milliseconds (range: 25-1000)

x DTIM: A DTIM is a countdown informing clients of the next window for listening to

broadcast and multicast messages. When the wireless router has buffered

broadcast or multicast messages for associated clients, it sends the next DTIM with

a DTIM Interval value. Wireless clients detect the beacons and awaken to receive

the broadcast and multicast messages. The default value is 1. Valid settings are

between 1 and 255.

x Fragment Threshold: Wireless frames can be divided into smaller units (fragments)

to improve performance in the presence of RF interference and at the limits of RF

coverage. Fragmentation will occur when frame size in bytes is greater than the

Fragmentation Threshold. This setting should remain at its default value of 2346

bytes. Setting the Fragmentation value too low may result in poor performance.

TRENDnet User’s Guide

TEW-

818DRU

x RTS Threshold: The Request To Send (RTS) function is part of the networking

protocol. A wireless device that needs to send data will send a RTS before sending

the data in question. The destination wireless device will send a response called

Clear to Send (CTS). The RTS Threshold defines the smallest data packet size

allowed to initiate the RTS/CTS function.

Default Value: 2347 (range: 1-2347)

x Short Preamble: Using a short (400ns) guard interval can increase throughput.

However, it can also increase error rate in some installations, due to increased

sensitivity to radio-frequency reflections. Select the option that works best for your

installation.

x Xpress™ Technology: A frame bursting technology used to improve wireless

performance. The feature will only work with other Xpress™ supported devices. It is

recommended to leave this feature On.

x MCS: Select the speed you would like your wireless network to operate.

Note: It is recommended to keep the default setting – Auto.

Set your router date and time

Advance > Administrator > Time

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on Administrator section and click Time.

4. Review the Time settings. Click Apply to save settings.

x Time Configuration: Displays the current device time and date information.

x Enable Daylight Saving: Check the option to configure the DST settings. Set the

annual range when daylight saving is activated.

x NTP Settings: Check the Enable NTP Server option to set your router date and time

to synchronize with an NTP (Network Time Protocol) server address (e.g.

pool.ntp.org). Enter the NTP server address next to Default NTP server, (e.g.

pool.ntp.org). Click the Time Zone drop-down list to select the appropriate zone

and you can optionally change your NTP Sync period.

Note: NTP servers are used for computers and other network devices to synchronize

time across an entire network.

x Manually set time – Set your router date and time manually in the Date and Time

Settings section.

Note: Time is specified in 24-hour format.

Create schedules

Advance > Administrator > Schedule

For additional security control, your router allows you to create schedules to specify a

time period when a feature on your router should be activated and deactivated. Before

you use the scheduling feature on your router, ensure that your router system time is

configured correctly.

TRENDnet User’s Guide

TEW-

818DRU

Note: You can apply a predefined schedule to the following features:

x Virtual Server

x Access Control (Domain/URL Filters & IP/Protocol LAN Client Filters)

x Special Applications

x Gaming

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on Administrator section and click Schedule.

3. Review the Schedule settings. Click Apply to save settings.

x Rule Name: Enter a name for the schedule you would like to apply.

x Days: Check the days you would like the rule to be applied or select All Week to

enable the rule all week.

x Start/End Time: Select the start and end time you would like the schedule to follow.

Note: The schedule defined will define the time/day the feature will be activated.

Access Control

Advanced > Security > Access Control

You may want to block computers or devices on your network access to specific ports

(used or required by a specific application) to the Internet.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Security section and click on Access Control.

3. Under Access Control, click the LAN Client Filter Function drop-down list and select

Enabled to activate the feature.

4. Review the settings under LAN Client Filter Rules section. Click Apply to save settings.

x LAN IP Address Range: Enter the IP address or IP address range to apply the

protocol (e.g. 192.168.10.20-192.168.10.20 or 192.168.10.20-192.168.10.30).

TRENDnet User’s Guide

TEW-

818DRU

Note: The filter will not be applied to IP addresses outside of the range specified.

x Protocol: Select the protocol type to filter. TCP, UDP.

x Destination Port Range: Enter the port number or range of port numbers to apply

in the firewall rule. (e.g. 80-80 or 20-21). For all ports, use the port range 1 - 65534.

x Schedule: Click the drop-down list to select the pre-defined schedule to apply. The

filter will only be active during the time period defined in the pre-defined schedule.

(See “Create Schedule” section on page 33).

Note: Before applying scheduling, please ensure your Time settings are configured

correct and you have defined a schedule. See page 32 to configure Time Settings

and see page 33 to create a schedule.

x Enabled: Checking the Enabled option activates on the LAN Client Filter rule.

Open a device on your network to the Internet

This router can provide access to devices on your local area network to the Internet

using the Virtual Server, Special Application, method (DMZ NOT recommended).

DMZ

Advanced > Firewall > DMZ

You may want to expose a specific computer or device on your network to the Internet

to allow anyone to access it. Your router includes the DMZ (Demilitarized Zone) feature

that makes all the ports and services available on the WAN/Internet side of the router

and forwards them to a single IP address (computer or network device) on your

network. The DMZ feature is an easy way of allowing access from the Internet however,

it is a very insecure technology and will open local area network to greater threats from

Internet attacks.

It is strongly recommended to use Virtual Server (also called port forwarding, see

“Virtual Server” on page 35) to allow access to your computers or network devices from

the Internet.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Firewall section and click on DMZ.

4. Select Enable in the DMZ Settings section.

5. Enter the IP address you assigned to the computer or network device to expose to the

Internet. Click Apply to save settings.

Virtual Server

Advanced > Firewall > Virtual Server Rules

Virtual Server (also called port forwarding) allows you to define specific ports (used or

required by a specific application) and forward them to a single IP address (a computer

or device) on your network. Using this feature is more secure compared to using DMZ

(see “DMZ” on page 35) in which DMZ forwards all ports instead of only specific ports

used by an application. An example would be forwarding a port to an IP camera

(TRENDnet IP cameras default to HTTP TCP port 80 for remote access web requests) on

your network to be able to view it over the Internet. To open several ports please refer

to “Gaming” section on page 37.

Since most ISPs constantly change your home IP address, to be able to access the Virtual

Server port(s) from the Internet it is recommended to setup Dynamic DNS service

(outlined in Identify Your Network section page 50).

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

TRENDnet User’s Guide

TEW-

818DRU

3. Click on the Firewall section and click on Virtual Server Rules.

4. Select Enable in the Virtual Server Function section.

5. Review the virtual server settings. Click Apply to save settings.

x Protocol: Select the protocol required for your device. TCP or UDP.

Note: Please refer to the device documentation to determine which ports and

protocols are required. You should assign a static IP address to the device or use

DHCP reservation to ensure the IP address of the device does not change.

x Public Port: Enter the port number used to access the device from the Internet.

x LAN IP Address: Enter the IP address of the device to forward the port (e.g.

192.168.10.101).

x Schedule: Select the defined schedule you would like to have the rule to be applied

(see “Create Schedule” section on page 33).

Note: The Public Port can be assigned a different port number than the Private Port

(also known as port redirection), however it is recommended to use the same port

number for both settings. Please refer to the device documentation to determine

which ports and protocols are required.

x Enabled: Selecting Enabled turns on the virtual server and unchecking disabled the

rule.

Example: To forward TCP port 80 to your IP camera

1. Setup DynDNS service (see Identify Your Network section page 50).

2. Access TRENDnet IP Camera management page and forward Port 80 (see product

documentation)

3. Make sure to configure your network/IP camera to use a static IP address.

Note: You may need to reference your camera documentation on configuring a

static IP address.

4. Log into your router management page (see “Access your router management page”

on page 17).

5. Click on Advanced, and click on Virtual Server.

6. Click Enabled to turn on this virtual server.

7. Next to Name, you can enter another name for the virtual server, otherwise, leave

the default name.

8. Next to LAN Server, enter the IP address assigned to the camera. (e.g.

192.168.10.101)

9. Next to Protocol, make sure TCP is selected in the drop-down list.

10. The Private Port and Public Port, make sure port number 80 is configured for both

settings.

11. To save the changes, click Add.

Special Applications

Advanced > Firewall > Special Applications

Special applications (also called port triggering) is typically used for online gaming

applications or communication applications that require a range of ports or several

ports to be dynamically opened on request to a device on your network. The router will

wait for a request on a specific port or range of ports (or trigger port/port range) from a

device on your network and once a request is detected by your router, the router will

forward a single port or multiple ports (or incoming port/port range) to the device on

your network. This feature is not typically used as most devices and routers currently

TRENDnet User’s Guide

TEW-

818DRU

use UPnP (Universal Plug and Play) to automatically configure your router to allow

access for applications. See “Enable/disable UPnP on your router” on page 39.

Note: Please refer to the device documentation to determine if your device supports

UPnP first, before configuring this feature.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Firewall section and click on Special Applications.

4. Select Enable under Port Triggering Function.

5. Review the special application settings. Click Apply to save settings.

x Match Protocol: Select the protocol to be forwarded to the device. TCP or UDP.

x Match Port: Enter the ports or port range to be forwarded to the device. (e.g. 2000-

2038 ,2200-2210).

x Trigger Protocol: Select the protocol requested by the device. TCP or UDP.

x Trigger Port: Enter the ports or port range requested by the device. (e.g. 554-554 or

6112-6112).

Note: Please refer to the device documentation to determine which ports and

protocols are required.

x Schedule: Select the defined schedule you would like to have the rule to be applied

(see “Create Schedule” section on page 33).

x Enabled: Selecting Enabled turns on the virtual server and selecting unchecking

disables the rule.

Gaming

Advanced > Firewall > Gaming

Gaming allows you to define multiple ports (used or required by a specific application or

game) and forward them to a single IP address (a computer or device) on your network.

Using this feature is more secure compared to using DMZ (see “DMZ” on page 35) in

which DMZ forwards all ports instead of only specific ports used by an application. Since

most ISPs constantly change your home IP address, to be able to access the Virtual

Server port(s) from the Internet it is recommended to setup Dynamic DNS service (see

“Identify your network over the Internet” section on page 50).

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Firewall section and click on Special Applications.

TRENDnet User’s Guide

TEW-

818DRU

4. Click on Enabled under Gaming Function section.

5. Review the virtual server settings. Click Apply to save settings.

x LAN IP Address: Enter the IP address of the device to forward the port (e.g.

192.168.10.101).

x TCP Ports to Open: Enter the TCP port you would like to set.

x UDP Ports to Open: Enter the UDP port you would like to set.

Note: Please refer to the device documentation to determine which ports and

protocols are required. You should assign a static IP address to the device or use

DHCP reservation to ensure the IP address of the device does not change.

x Schedule: Select the defined schedule you would like to have the rule to be applied

(see “Create Schedule” section on page 33).

x Enabled: Selecting Enabled turns on the virtual server and selecting unchecking

disables the rule.

Enable/disable Application Layer Gateways (ALG)

Advanced > Firewall > ALG

You may want to configure your router to allow computers the use of specific high layer

applications or service sessions to pass through. Application Layer Gateways (ALG)

allows you to easily enable or disable these applications to pass through your router.

Note: It is recommended to leave these settings enabled.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Firewall section and click on Special Applications.

4. Review the applications to enable or disable. Click Apply to save the changes.

x Email Receiving (POP3): Allows POP3 protocol through your router.

TRENDnet User’s Guide

TEW-

818DRU

x Email Receiving (SMTP): Allows SMTP protocol through your router.

x Streaming Video (RTP): Allows RTP video protocol through your router.

x Streaming Media (RTSP): Allows STMP video protocol through your router.

x Streaming Media (WMP/MMS): Allows WMP/MMS protocol through your router.

x Streaming Media-VoIP (SIP): Allows SIP protocol through your router.

x Streaming Media-VoIP (H.323): Allows H.323 protocol through your router.

x File Transfer (FTP): Allows FTP protocol through your router.

x File Transfer (TFTP): Allows TFTP protocol through your router.

x Remote control (Telnet): Allows Telnet protocol through your router.

x Instant messaging (MSN): Allows MSN instant messaging protocols through your

router.

x VPN Pass-Through: Allows VPN connections through your router.

Enable/disable UPnP on your router

Advanced > Advanced Network

UPnP (Universal Plug and Play) allows devices connected to a network to discover each

other and automatically open the connections or services for specific applications (e.g.

instant messenger, online gaming applications, etc.) UPnP is enabled on your router by

default to allow specific applications required by your computers or devices to allow

connections through your router as they are needed.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Advanced Network.

4. Click the UPnP drop-down list and select Enabled to enable UPnP or Disabled to

disable UPnP. Click Apply to save settings.

Note: It is recommended to leave this setting enabled, otherwise, you may

encounter issues with applications that utilize UPnP in order allow the required

communication between your computers or devices and the Internet.

Using External USB Storage

Your router’s USB port can be used to share files through the network when a USB

storage device is connected on the back USB port. The router supports both FTP and

SAMBA (SMB) filing sharing protocols.

Samba Network File Server

Advanced > USB > SAMBA

Samba is a network protocol that allows you to access shared files through your

network. In order to share files, you will need to plug in a USB storage device on the USB

port on the back of the router. You can access these files under your network map or by

typing \\routerIPaddress on your browser’s address bar. Please follow the below steps

to configure the router’s Samba settings

TRENDnet User’s Guide

TEW-

818DRU

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the USB section and click on Samba Server.

4. Review the setting on Samba Server Information section. Click Apply to save settings

x Server Status: Select enable or disable for the feature.

x Server Name: Enter the name of your server.

x Workgroup: Enter the work group of your server.

x Description: Enter a description of the server.

5. Review the administrator settings required for your Samba server. Click Apply to save

settings. Administrator will have read and write access to files. To define user

accounts continue to the next step.

x User Name: Enter the user name to be used to access your files.

x Password: Enter the password for the user name.

6. Review the User Account List section. Click Apply to save settings

x User Name: Enter the user name to be used to access your files.

x Password: Enter the password for the user name.

x Permission: Select the permission you will grant to the user

x Enabled: Click to activate user account.

FTP (File Transfer Protocol) Server

Advanced > USB > FTP

FTP (File Transfer Protocol) is used to access shared files through the Internet. In order

to share files, you will need to plug in a USB storage device on the USB port on the back

of the router. Signing up for a Dynamic DNS service (outlined in Identify Your Network

section pg.49) will provide identification of the router’s network from the Internet. You

can access your shared files by typing ex.ftp://router’sWANIPaddress or

ftp://myDDNSservice. Please follow the steps below to configure the router’s FTP

settings

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

TRENDnet User’s Guide

TEW-

818DRU

3. Click on the USB section and click on FTP Server.

4. Review the setting on Samba Server Information section. Click Apply to save settings

x Server Status: Select enable or disable for the feature.

x Language: Select your language.

5. Review the administrator settings required for your FTP server. Click Apply to save

settings

x User Name: Enter the user name to be used to access your files.

x Password: Enter the password for the user name.

5. Review the User Account List section. Click Apply to save settings

x User Name: Enter the user name to be used to access your files.

x Password: Enter the password for the user name.

x Permission: Select the permission you will grant to the user

x Enabled: Click to activate user account.

Properly Eject USB device

Advanced > USB > Eject Device

It is recommended to properly eject your USB device to prevent any file corruption.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the USB section and click on Eject Device.

4. Review the settings.

TRENDnet User’s Guide

TEW-

818DRU

x Safely remove device: Click this button to eject your USB shared device

x Refresh: Click to refresh the connected USB device list.

Print Share Utility Installation

Windows Installation

1. For each computer that requires access to USB printer, insert the Utility CD-ROM into

your computer's CD-ROM Drive.

2. Click Install Utility

3. Follow the installation instructions and click Finish when prompted. Make sure to click

Launch TRENDnet USB Control Center Utility to run the utility.

TRENDnet User’s Guide

TEW-

818DRU

4. Double click on the TRENDnet USB Control Center Utility icon

5. The utility will automatically detect your router and USB printer.

MAC OS X Installation

1. Insert the included CD-ROM into your computer’s CD-ROM drive.

2. Open the CD contents and locate the “TRENDnet USB Control Center Utility Installer”

(.dmg) file. Double-click the file.

3. Double-click the file in the window.

4. You will be prompted to install the utility. Click Install to start the installation.

5. You will be prompted for your password to allow the installation. Enter your

password and click OK.

TRENDnet User’s Guide

TEW-

818DRU

6. Once the installation is completed. Click Restart to restart your computer.

7. Run the TRENDnet USB Control Center Utility. The utility will automatically find your

router and USB printer.

Launching the Utility

Windows OS

Upon completing the software installation, a desktop shortcut is automatically created.

You double click the icon to start the utility or open the utility if it is already running.

If the utility is already running and you attempt to close the window, it will continue to

run in the background and you will find the icon in your notification area if the utility is

still running. To close and exit the utility and exit the application, you can right-click the

notification icon and select Exit or click System > Exit in the utility main window,

however, it is recommended to keep this utility running in the background.

MAC OS X

Upon completing the software installation, a desktop shortcut is automatically created.

Double-click the icon to start the utility. Closing the utility will exit the application.

Utility Main Window

In the utility window, you will see the model name and IP address of your print server

listed. When USB devices are connected, they will be listed under the model name and

IP address of the print server.

Windows OS

MAC OS X Utility

Menu Items (Windows Only)

x System:- Clicking Exit will close the utility and exit the application.

x Tools

TRENDnet User’s Guide

TEW-

818DRU

o Configuration – Checking the option Automatically execute when logging on

Windows will automatically start the utility when you log on. Unchecking the

option will disable the utility from automatically starting when logging on.

o Auto-Connect Printer List – Provides a list of printers installed on your

computer. Select the printer you would like to assign to the Auto-Connect

printer list. If you would like to delete printers from this listing, select the

printer in the list and click Delete. Click Close to close the window.

x About

o About – Displays the software/driver version and support contact information.

Configure Server

Select the print server you would like to configure in the utility window.

Windows OS

MAC OS X

1. Clicking the Configure Server button will open the router’s management page in your

web browser.

Windows OS MAC OS X

Connect

To connect your computer to a USB device, select the USB device in the list, then click

the Connect button to connect your computer to the USB device.

Note: The utility will only allow one computer to connect to one USB device at any given

time, therefore, a computer must disconnect from the USB device first before another

computer can connect to it.

Windows OS MAC OS X

To verify if you are connected to the USB device, a message will appear next to the USB

device displaying a message that the USB device is “Manually connected by <your

computer name>”.

Windows OS

MAC OS X

Disconnect

To disconnect your computer from a USB device, select the USB device in the list, then

click the Disconnect button to disconnect your computer to the USB storage device or

printer.

Note: The utility will only allow one computer to connect to one USB device at any given

time, therefore, a computer must disconnect from the USB device first before another

computer can connect to it.

TRENDnet User’s Guide

TEW-

818DRU

Windows OS MAC OS X

To verify if you disconnected from the USB device, the status message next to the

message will not show any status message.

Windows OS

MAC OS X

If another computer is currently connected to the USB device you are trying to connect

your computer to, you will not be able to connect to it. To verify if another computer is

connected to the device, a message will appear next to the USB device displaying a

message that the USB device is “Manually connected by <another computer name>”.

Windows OS

MAC OS X

If a USB device is currently being used by another computer, click the Request to

Connect button to send a request to the computer that is currently connected to the

USB device. The computer that is currently connected to USB device will be prompted to

“Accept” or “Reject” the your connection request.

Windows OS MAC OS X

Sending a Request to Connect

You can send a request to connect to the computer that is currently connected to the

USB device you would like to establish connection too.

Windows OS

To send t a request to connect to a USB device, click the Request to Connect button.

The remote computer will receive the request message below.

x Accept: Clicking this option will disconnect your computer from the device and

allow the requesting computer to connect to the USB device.

x Reject: Clicking this option will disregard the request and your computer will not

be able to connect to the USB

MAC OS X

To send t a request to connect to a USB device, click the Request to Connect button.

The local computer sending the request will show the status message below.

TRENDnet User’s Guide

TEW-

818DRU

The remote computer will receive the request message below.

x Accept: Clicking this option will disconnect your computer from the device and

allow the requesting computer to connect to the device.

If the remote computer accepts the request, the local computer will display the message

below. Click Close to close the message.

x Reject: Clicking this option will disregard the request.

If the remote computer rejects the request, the local computer will display the message

below. Click OK to close the message.

Connect to a Printer

Note: This function applies to stand-alone USB printers or USB multi-function

printers. It is required that the printer drivers are installed before your

computer is able to print. Please ensure the printer drivers are installed. If the

printer drivers are not installed, please refer to your printer manufacturer

website or documentation on where to download and how to install the printer

drivers. Before installing the printer drivers, connect your computer to the

printer using the USB utility first. Some printers may require that the printer is

directly connected to the computer in order to complete the driver installation.

Once the printer drivers are installed properly on your computer,

1. Select the printer listed in the utility.

2. Click Connect to connect your computer to the printer.

3. Once your computer is connected, you can send print jobs to the printer.

4. After you have finished printing, click Disconnect, to make the printer available to

other computers on your network that use the printer, or, you can use the Auto-

Connect Printer Feature.

TRENDnet User’s Guide

TEW-

818DRU

Auto-Connect Printer

When a USB printer is connected and selected in the main window, clicking this option

allows you to enable/disable the auto connect feature to a selected printer in the Auto-

Connect printer list. When your computer attempts to print, the Auto-Connect feature

will automatically connect your computer to the set Auto-Connect printer assigned in

the utility. Once the print job from your computer is completed, it will automatically

disconnect to make the printer available to other computers on your network.

Note: It is recommended to enable this feature on all computers that will need to

connect to the USB printer. Enabling the Auto-Connect Printer feature will avoid the

complexity of having to manually connect and disconnect from the printer for each

computer when multiple computers are sending print jobs to the USB printer.

1. Click Auto-Connect Printer.

2. Select the assigned printer to use as the auto connect printer by checking the box.

3. When you are finished, click Apply.

Connect to a Scanner

Note: This function applies to stand-alone USB scanners or USB scanners

included with multi-function printers. It is required that the scanner drivers are

installed before your computer is able to scan. Please ensure the scanner

drivers are installed. If the scanner drivers are not installed, please refer to your

printer manufacturer website or documentation on where to download and

how to install the scanner drivers. Before installing the scanner drivers, connect

your computer to the printer using the USB utility first. Some scanners may

require that the scanner is directly connected to the computer in order to

complete the driver installation.

1. Select the scanner or multi-function printer with scanning capability listed in the

utility.

2. Click Connect to connect your computer to the scanner.

3. Once your computer is connected, you can receive scanned files from the scanner.

4. After you have finished printing, click Disconnect, to make the scanner available to

other computers on your network that use the scanner.

TRENDnet User’s Guide

TEW-

818DRU

Router Maintenance & Monitoring

Change your router login password

Advanced > Administrator > Management

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Management.

4. Under the Administrator Settings section, in the Password field, enter the new

password. Click Apply to save settings.

x Idle Timeout: Enter the idle timeout in seconds before automatically logging you

out of the router management page.

Note: If you change the router login password, you will need to access the router

management page using the User Name “admin” and the new password instead of

the default password “admin”. If you reset the device to defaults, you will need to

access the router management page use the predefined settings on the side or

bottom labels.

Change your device name

Advanced > Administrator > Management

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Management.

4. Under the Device Name Settings section, in the Device Name field, enter the new

device name to display on your network to identify the router. Click Apply to save

settings.

TRENDnet User’s Guide

TEW-

818DRU

Change your device URL

Advanced > Administrator > Management

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Management.

3. Under the Device URL Settings section, in the Device URL field, enter the new device

URL used to log into the router management page.

Note: Even if the LAN IP address of the router is changed, the device URL will still

allow to use the name as reference to log into the router management page.

4. To save changes, click Apply.

Identify your network on the Internet

Advanced > Administrator > Management

Since most ISPs constantly change your home IP address, providing access to devices on

your home or small office Local Area Network (such as IP Cameras) from the Internet

requires setting up a Dynamic DNS service and entering the parameters into this

management area. Dynamic DNS services allow your router to confirm its location to the

given Dynamic DNS service, thereby providing the Dynamic DNS service with the ability

to provide a virtual fixed IP address for your network. This means that even though your

ISP is always changing your IP address, the Dynamic DNS service will be able to identify

your network using a fixed address—one that can be used to view home IP Camera and

other devices on your local area network.

Note: First, you will need to sign up for one of the DDNS service providers listed in

the Server Address drop-down list.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Management.

4. Review the DDNS Settings section. Click Apply to save settings.

x Dynamic DNS Provider: Click the drop-down list Select your DDNS service.

TRENDnet User’s Guide

TEW-

818DRU

x Host Name: Personal URL provided to you by your Dynamic DNS service provider

(e.g. www.trendnet.dyndns.biz)

x User Name: The user name needed to log in to your Dynamic DNS service account

x Password: This is the password to gain access to Dynamic DNS service (NOT your

router or wireless network password) for which you have signed up to.

Note: If you would like to discard the changes, click Cancel before you click Save.

Allow remote access to your router management page

Advanced > Administrator > Management

You may want to make changes to your router from a remote location such at your

office or another location while away from your home.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Management.

4. Review the setting on the Remote Management section. Click Apply to save settings

x Remote Control: Select enable or disable for the feature.

x Port: Enter the port to assign remote access to the router. It is recommended to

leave this setting as 8080.

Note: If you have configured port 8080 for another configuration section such as

virtual server or special application, please change the port to use.

(Recommended port range 1024-65534)

Reset your router to factory defaults

Advance > Administrator > Settings Management

You may want to reset your router to factory defaults if you are encountering difficulties

with your router and have attempted all other troubleshooting. Before you reset your

router to defaults, if possible, you should backup your router configuration first, see

“Backup and restore your router configuration settings” on page 52.

There are two methods that can be used to reset your router to factory defaults.

x Reset Button – Located on the side panel of your router, see “Product Hardware

Features” on page 5. Use this method if you are encountering difficulties with

accessing your router management page.

x Router Management Page

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Settings Management.

TRENDnet User’s Guide

TEW-

818DRU

4. Under Load Factory Default, click Load Default. When prompted to confirm this

action, click OK.

Router Default Settings

Administrator User Name

admin

Administrator Password

Please refer sticker or device label

Router IP Address

192.168.10.1

Router Subnet Mask

255.255.255.0

DHCP Server IP Range

192.168.10.10

1-192.168.199

ireless 2.4GHz

Enabled

Wireless 2.4GHz Encryption

Please refer sticker or device label

Wireless 5Ghz

Enabled

Wireless 5GHz Encryption

Please refer sticker or device label

Backup and restore your router configuration settings

Advanced > Administrator > Settings Management

You may have added many customized settings to your router and in the case that you

need to reset your router to default, all your customized settings would be lost and

would require you to manually reconfigure all of your router settings instead of simply

restoring from a backed up router configuration file.

To backup your router configuration:

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Settings Management.

4. Under Export Settings section, click Export.

5. Depending on your web browser settings, you may be prompted to save a file (specify

the location) or the file may be downloaded automatically to the web browser

settings default download folder. (Default Filename: .cfg)

TRENDnet User’s Guide

TEW-

818DRU

To restore your router configuration:

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Settings Management.

4. Under Import Settings, next to Settings file location, depending on your web

browser, click on Browse or Choose File.

5. A separate file navigation window should open.

6. Select the router configuration file to restore and click Import. (Default Filename:

.cfg). If prompted, click Yes or OK. Wait for the router to restore settings.

Upgrade your router firmware

Advanced > Administrator > Upload Firmware

TRENDnet may periodically release firmware upgrades that may add features or fix

problems associated with your TRENDnet router model and version. To check if there is

a firmware upgrade available for your device, please check your TRENDnet model and

version using the link. http://www.trendnet.com/downloads/

In addition, it is also important to verify if the latest firmware version is newer than the

one your router is currently running. To identify the firmware that is currently loaded on

your router, log in to the router, click on the Administrator section and then on the

Status. The firmware used by the router is listed at the top of this page. If there is a

newer version available, also review the release notes to check if there were any new

features you may want or if any problems were fixed that you may have been

experiencing.

1. If a firmware upgrade is available, download the firmware to your computer.

2. Unzip the file to a folder on your computer.

Please note the following:

x Do not interrupt the firmware upgrade process. Do not turn off the device or press

the Reset button during the upgrade.

x If you are upgrade the firmware using a laptop computer, ensure that the laptop is

connected to a power source or ensure that the battery is fully charged.

x Disable sleep mode on your computer as this may interrupt the firmware upgrade

process.

x Do not upgrade the firmware using a wireless connection, only using a wired

network connection.

x Any interruptions during the firmware upgrade process may permanently damage

your router.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

TRENDnet User’s Guide

TEW-

818DRU

3. Click on the Administrator section and click on Upload Firmware.

3. Depending on your web browser, in the Upload Firmware section, click Browse or

Choose File.

4. Navigate to the folder on your computer where the unzipped firmware file (.bin) is

located and select it.

5. Click Apply. If prompted, click Yes or OK.

Reboot your router

Administrator > Settings Management

You may want to restart your router if you are encountering difficulties with your router

and have attempted all other troubleshooting.

There are two methods that can be used to restart your router.

x Turn the router off for 10 seconds using the router On/Off switch (EU version

only) located on the rear panel of your router or disconnecting the power port,

sees “Product Hardware Features” on page 5.

Use this method if you are encountering difficulties with accessing your router

management page. This is also known as a hard reboot or power cycle.

x Router Management Page – This is also known as a soft reboot or restart.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Settings Management.

3. Under System Reboot section, click Reboot.

Allow/deny ping requests to your router from the Internet

Advanced > Advanced Network

To provide additional security, you may want to disable your router from responding to

ping or ICMP (Internet Control Message Protocol) requests from the Internet. A ping is

network communication test to check if a device with IP address is alive or exists on the

network. By disabling this feature, you can conceal your router’s IP address and

existence on the Internet by denying responses to ping requests from the Internet. You

can additionally use this feature as a tool for troubleshooting purposes.

TRENDnet User’s Guide

TEW-

818DRU

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Settings Management.

4. Click the WAN Ping Respond drop-down list and select Enabled to allow ping requests

from your router to the Internet. Click Apply to save settings.

5. To save changes, click Apply.

Note: If you would like to discard the changes, click Cancel before you click Save.

Check the router system information

Advanced > Administrator > Router Status

You may want to check the system information of your router such as WAN (Internet)

connectivity, wireless and wired network settings, router MAC address, and firmware

version.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on Router Status.

System Info

x Firmware Version: The current firmware version your router is running.

x System Time: The current time set on your router.

x Router Up Time: The duration your router has been running continuously

without a restart/power cycle (hard or soft reboot) or reset.

TRENDnet User’s Guide

TEW-

818DRU

Internet Configurations

x Connected Type: The WAN connection type applied on your router.

x IP Address: The current IP address assigned to your router WAN port or interface

configuration.

x Subnet Mask: The current subnet mask assigned to your router WAN port or

interface configuration.

x Default Gateway: The current gateway assigned to your router WAN port or

interface configuration.

x DNS (Domain Name System): The current DNS address(es) assigned to your router

port or interface configuration.

x Renew (DHCP WAN Type): Click this option to renew your WAN IP address.

x Release (DHCP WAN Type): Click this option to release the WAN IP address of your

router.

x Connect (PPPoE WAN Type): Click this option to connect to your DSL ISP

x Disconnect (PPPoE WAN Type): Click this option to disconnect from your DSL ISP.

LAN Information

x MAC Address: The current MAC address of your router’s wireless or interface

configuration.

x IP Address: Displays your router’s current IP address.

x Subnet Mask: Displays your router’s current subnet mask.

2.4GHz Wireless LAN

x MAC Address: The MAC address of your router’s wireless LAN or interface

configuration.

x Channel: Displays the current wireless channel your router is operating.

x Network Name (SSID)/ Security Mode: Displays the current wireless network name

assigned to your router and the wireless security applied to the SSID

5GHz Wireless LAN

TRENDnet User’s Guide

TEW-

818DRU

x MAC Address: The MAC address of your router’s wireless LAN or interface

configuration.

x Channel: Displays the current wireless channel your router is operating.

x Network Name (SSID)/ Security Mode: Displays the current wireless network name

assigned to your router and the wireless security applied to the SSID

IPv6 Status

Advanced > Administrator > IPv6 Status

You can view the current IPv6 status on your router.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on IPv6 Status.

x Connected Type: The type of IPv6 being used on your router.

x Network Type: Your IPv6 network type.

x Network Prefix: IPv6 prefix used

x IPv6 Default Gateway: IPv6 default gateway

x IPv6 DNS Server: IPv6 DNS server

View your router log

Administrator > System Log

Your router log can be used to obtain activity information on the functionality of your

router or for troubleshooting purposes.

1. Log into your router management page (see “Access your router management page”

on page 17).

2. Click on the Advanced tab.

3. Click on the Administrator section and click on System Log.

TRENDnet User’s Guide

TEW-

818DRU

4. Select Enable System Log and click Apply to save settings.

x Refresh: Click to refresh screen.

x Clear: Click to clear the screen.

TRENDnet User’s Guide

TEW-811

DRU

Router Management Page Structure

BASIC

Network Status

x Internet Connection Setup Wizard

x Wireless Security Setup Wizard

Wireless

x 2.4 GHz Wireless Network

x Security

x 5GHz Wireless Network

x Security

Guest Network

x 2.4 GHz Guest Network

x Security

x 5GHz Guest Network

x Security

Parental Control

x Web URL Filter

x IP Filter

x MAC Filter

ADVANCE

Administrator

x Management

o Password

o Device Name

o Device URL

o DDNS Settings

o Remote Management

x Upload Firmware

x Settings Management

o Export Settings

o Import Settings

o Load Factory Default

o Reboot

x Time

x Schedule

x Router Status

x IPv6 Status

x System Log

x Advance Network

o UPnP

o WAN Ping

Setup

x LAN Setting

o DHCP Server

o DHCP Reservations

x WAN Setting

o Clone MAC

x Routing

x IPv6 Setting

x QoS

x Wizard

Wireless 2.4GHz

x Multiple SSID

x WDS

x Advanced

x WPS

Wireless 5GHz

x Multiple SSID

x WDS

x Advanced

x WPS

Security

x Access Control

Firewall

x DMZ

x Virtual Server Rules

x Special Applications

x Gaming

x ALG

x Access Control

USB

x Samba Server

x FTP Server

x Eject Device

TRENDnet User’s Guide

Limited Warranty

Technical Specifications

Hardware

Standards

Wired: IEEE 802.3 (10Base

-T), IEEE 802.3u (100Base-

TX),

IEEE 802.3ab (1000Base

-T)

Wireless: I

EEE 802.11ac (draft 2.0), IEEE 802.11n, IEEE

802.11g, IEEE 802.11b, 802.11a

Internet Protocol

IPv4 and IPv6

LAN

4 x 10/100/1000 Mbps Auto

-MDIX

WAN

1 x 10/100/1000 Mbps Auto

-MDIX

USB

x USB 3.0 Type-A (Storage / Printing)

x USB 2.0 Type-A (Storage / Printing)

WPS Button

-Fi Protected Setup (WPS) connects with other WPS

compliant devices

Reset Button

Reset unit back to factory default (press and hold for 10

seconds)

Network

Prot

ocols / Features

IGMP v1/2/3 proxy and snooping , Static and dynamic

outing, UPnP, DHCP, server, Dynamic DNS (No-IP.com

and DynDNS.com), NTP, IPsec / PPTP / L2TP VPN pass

through, IPv6

Quality of Service

WMM and WAN (Configurable Upload / Download)

Control Center Utility

OS Support

Windows: 8 (32/64

-bit), 7 (32/64-bit),

Vista (32/64

bit),

XP (32/64

-bit)

Mac OS X: 10.4 / 10.5/ 10.6/ 10.7

/ 10.8

Internet

Connection Type

IPv6,

Dynamic IP, Static (fixed) IP, PPPoE, PPTP, L2TP

Firewall

NAT, SPI, DMZ host, virtual servers, MAC / IP filters and

URL filter

Management

/ Monito

ring

Local / remote configuration, upgrade firmware, backup

/ restore configuration via web browser, internal system

log, ping test tool

Supported

Web Browser

Internet Explorer 6.0 or above, Firefox 2.0 or above,

Chrome, Opera, Safari

LED Indicator

Power

/WPS, LAN 1-4, WAN, 2.4 GHz Wireless, 5 GHz

Wireless,

USB

Power Adapter

Input: 100 ~ 240 V, 50~60 Hz, 0.8 A

Output: 12 V DC, 2 A

external power adapter

Power Consum

ption

22 watts (max.)

Dimension (L x W x H)

48 x 155 x 180 mm (1.8 x 6.1 x 7.1 in)

Wei

ght

395 g (14 oz)

Temperature

Operation: 0

q~ 40qC (32qF~ 104qF)

Storage:

-20q~ 60qC (-4qF~140 qF)

Humidity

Max

90% (non-condensing)

Certifications

CE, FCC

Wireless

Frequency

2.4 GHz: 2.412~2.462 (FCC) and 2.412~2.472 (ETSI)

5 GHz: 5.1

8 ~ 5.24 / 5.745~5.825 GHz (FCC) and 5.1

5.2

40 (ETSI)

Antenna

2.4 GHz:

6.0dBi Max Peak Gain(Front Top), 5.5dBi Max

Peak Gain (Front Bottom), 2.5dBi Max Peak Gain (Top)

GHz: 6.0dBi Max Peak Gain (Front Top), 6.0dBi Max

Peak Gain (Front Bottom), 4.8dBi Max Peak Gain

(Top)

Modulation

CCK, DQPSK, DBPSK, OFDM, BPSK, QPSK, 16/64/256

QAM

Data Rate

802.11a: up to 54 Mbps

802.11b: up to 11 Mbps

802.11g: up to 54 Mbps

802.11n: up to

600 Mbps 2.4GHz (TurboQAM), up to

450

Mbps

5GHz

TRENDnet User’s Guide

Limited Warranty

802.11ac: up to 1.3 Gbps

Security

WPA/WPA2

-PSK, WPA/WPA2-RADIUS

Guest network

per wireless band

Access Control

MAC Address

Filter (Up to 24 entries)

Output Power

802.11a:

22 dBm (max.) FCC, 18 dBm (max.) CE

@ HT40

802.11b: 1

9 dBm (max.) @ CCK

802.11g: 1

dBm (max.) @ HT40

802.11n (2.4GHz):

18 dBm (max.) @ HT40

802.11n (5GHz): 2

2 dBm (max.) FCC, 18 dBm (max.)

CE @

HT40

802.11ac: 2

3 dBm (max.) FCC, 19 dBm (max.)

CE @ HT80

Receiving Sensitivity

802.11a:

-68 dBm (typical) @ 54 Mbps

802.11b:

84 dBm (typical) @ 11 Mpbs

802.11g:

-72 dBm (typical) @ 54 Mbps

802.11n:

-68 dBm (typical) @ 600 Mbps for 2.4 GHz,

@450

Mbps for 5 GHz

802.11ac:

-55 dBm (typical) @ 1.3 Gbps

Channels

2.4 GHz: 1~11 (FCC), 1~13 (ETSI)

5 GHz: 36, 40, 44, 48, 149, 153, 157, 161, 165 (FCC) 36,

40, 44, 48 (ETSI)

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical

specifications. Actual data throughput and coverage will vary depending on

interference, network traffic, building materials and other conditions. TurboQAM

speeds requires clients with TurboQAM support.

** Printer Control Center utility installation required for each computer in order to

access the printer

TRENDnet User’s Guide

Limited Warranty

Troubleshooting

Q: I typed http://192.168.10.1 in my Internet Browser Address Bar, but an error

message says “The page cannot be displayed.” How can I access the router

management page?

Answer:

1. Check your hardware settings again. See “Router Installation” on page 8.

2. Make sure the LAN and WLAN lights are lit.

3. Make sure your network adapter TCP/IP settings are set to Obtain an IP address

automatically or DHCP (see the steps below).

4. Make sure your computer is connected to one of the router’s LAN ports

5. Press on the factory reset button for 15 seconds, the release.

Windows 7

a. Go into the Control Panel, click Network and Sharing Center.

b. Click Change Adapter Settings, right-click the Local Area Connection icon.

c. Then click Properties and click Internet Protocol Version 4 (TCP/IPv4).

d. Then click Obtain an IP address automatically and click OK.

Windows Vista

a. Go into the Control Panel, click Network and Internet.

b. Click Manage Network Connections, right-click the Local Area Connection

icon and click Properties.

c. Click Internet Protocol Version (TCP/IPv4) and then click Properties.

d. Then click Obtain an IP address automatically and click OK.

Windows XP/2000

a. Go into the Control Panel, double-click the Network Connections icon

b. Right-click the Local Area Connection icon and the click Properties.

c. Click Internet Protocol (TCP/IP) and click Properties.

d. Then click Obtain an IP address automatically and click OK.

Note: If you are experiencing difficulties, please contact your computer or operating

system manufacturer for assistance.

Q: I am not sure what type of Internet Account Type I have for my Cable/DSL

connection. How do I find out?

Answer:

Contact your Internet Service Provider (ISP) for the correct information.

Q: The Wizard does not appear when I access the router. What should I do?

Answer:

1. Click on Wizard on the left hand side.

2. Near the top of the browser, “Pop-up blocked” message may appear. Right click on

the message and select Always Allow Pop-ups from This Site.

3. Disable your browser's pop up blocker.

Q: I went through the Wizard, but I cannot get onto the Internet. What should I do?

Answer:

1. Verify that you can get onto the Internet with a direct connection into your modem

(meaning plug your computer directly to the modem and verify that your single

computer (without the help of the router) can access the Internet).

2. Power cycle your modem and router. Unplug the power to the modem and router.

Wait 30 seconds, and then reconnect the power to the modem. Wait for the modem to

fully boot up, and then reconnect the power to the router.

3. Contact your ISP and verify all the information that you have in regards to your

Internet connection settings is correct.

Q: I cannot connect wirelessly to the router. What should I do?

Answer:

1. Double check that the WLAN light on the router is lit.

2. Power cycle the router. Unplug the power to the router. Wait 15 seconds, then plug

the power back in to the router.

3. Contact the manufacturer of your wireless network adapter and make sure the

wireless network adapter is configured with the proper SSID. The preset SSID is

TRENDnet(model_number).

4. To verify whether or not wireless is enabled, login to the router management page,

click on Wireless.

5. Please see “Steps to improve wireless connectivity” on page 21 if you continue to

have wireless connectivity problems.

TRENDnet User’s Guide

Limited Warranty

Appendix

How to find your IP address?

Note: Please note that although the following procedures provided to follow for your

operating system on configuring your network settings can be used as general

guidelines, however, it is strongly recommended that you consult your computer or

operating system manufacturer directly for assistance on the proper procedure for

configuring network settings.

Command Prompt Method

Windows 2000/XP/Vista/7

1. On your keyboard, press Windows Logo+R keys simultaneously to bring up the Run

dialog box.

2. In the dialog box, type cmd to bring up the command prompt.

3. In the command prompt, type ipconfig /all to display your IP address settings.

MAC OS X

1. Navigate to your Applications folder and open Utilities.

2. Double-click on Terminal to launch the command prompt.

3. In the command prompt, type ipconfig getifaddr <en0 or en1> to display the wired

or wireless IP address settings.

Note: en0 is typically the wired Ethernet and en1 is typically the wireless Airport

interface.

Graphical Method

MAC OS 10.6/10.5

1. From the Apple menu, select System Preferences.

2. In System Preferences, from the View menu, select Network.

3. In the Network preference window, click a network port (e.g., Ethernet, AirPort,

modem). If you are connected, you'll see your IP address settings under "Status:"

MAC OS 10.4

1. From the Apple menu, select Location, and then Network Preferences.

2. In the Network Preference window, next to "Show:", select Network Status. You'll see

your network status and your IP address settings displayed.

Note: If you are experiencing difficulties, please contact your computer or operating

system manufacturer for assistance.

How to configure your network settings to obtain an IP address automatically or use

DHCP?

Note: Please note that although the following procedures provided to follow for your

operating system on configuring your network settings can be used as general

guidelines, however, it is strongly recommended that you consult your computer or

operating system manufacturer directly for assistance on the proper procedure for

configuring network settings.

Windows 7

a. Go into the Control Panel, click Network and Sharing Center.

b. Click Change Adapter Settings, right-click the Local Area Connection icon.

c. Then click Properties and click Internet Protocol Version 4 (TCP/IPv4).

d. Then click Obtain an IP address automatically and click OK.

Windows Vista

a. Go into the Control Panel, click Network and Internet.

b. Click Manage Network Connections, right-click the Local Area Connection

icon and click Properties.

c. Click Internet Protocol Version (TCP/IPv4) and then click Properties.

d. Then click Obtain an IP address automatically and click OK.

Windows XP/2000

a. Go into the Control Panel, double-click the Network Connections icon

b. Right-click the Local Area Connection icon and the click Properties.

c. Click Internet Protocol (TCP/IP) and click Properties.

d. Then click Obtain an IP address automatically and click OK.

MAC OS 10.4/10.5/10.6

a. From the Apple, drop-down list, select System Preferences.

b. Click the Network icon.

c. From the Location drop-down list, select Automatic.

d. Select and view your Ethernet connection.

In MAC OS 10.4, from the Show drop-down list, select Built-in Ethernet and

select the TCP/IP tab.

In MAC OS 10.5/10.6, in the left column, select Ethernet.

e. Configure TCP/IP to use DHCP.

TRENDnet User’s Guide

Limited Warranty

In MAC 10.4, from the Configure IPv4, drop-down list, select Using DHCP and

click the Apply Now button.

In MAC 10.5, from the Configure drop-down list, select Using DHCP and click

the Apply button.

In MAC 10.6, from the Configure drop-down list, select Using DHCP and click

the Apply button.

f. Restart your computer.

Note: If you are experiencing difficulties, please contact your computer or operating

system manufacturer for assistance.

How to find your MAC address?

In Windows 2000/XP/Vista/7,

Your computer MAC addresses are also displayed in this window, however, you can type

getmac –v to display the MAC addresses only.

In MAC OS 10.4,

1. Apple Menu > System Preferences > Network

2. From the Show menu, select Built-in Ethernet.

3. On the Ethernet tab, the Ethernet ID is your MAC Address.

In MAC OS 10.5/10.6,

1. Apple Menu > System Preferences > Network

2. Select Ethernet from the list on the left.

3. Click the Advanced button.

3. On the Ethernet tab, the Ethernet ID is your MAC Address.

How to connect to a wireless network using the built-in Windows utility?

Note: Please note that although the following procedures provided to follow for your

operating system on configuring your network settings can be used as general

guidelines, however, it is strongly recommended that you consult your computer or

operating system manufacturer directly for assistance on the proper procedure for

connecting to a wireless network using the built-in utility.

Windows 7

1. Open Connect to a Network by clicking the network icon ( or ) in the notification

area.

2. In the list of available wireless networks, click the wireless network you would like to

connect to, then click Connect.

4. You may be prompted to enter a security key in order to connect to the network.

5. Enter in the security key corresponding to the wireless network, and click OK.

Windows Vista

1. Open Connect to a Network by clicking the Start Button. and then click Connect

To.

2. In the Show list, click Wireless.

3. In the list of available wireless networks, click the wireless network you would like to

connect to, then click Connect.

4. You may be prompted to enter a security key in order to connect to the network.

5. Enter in the security key corresponding to the wireless network, and click OK.

Windows XP

1. Right-click the network icon in the notification area, then click View Available

Wireless Networks.

2. In Connect to a Network, under Available Networks, click the wireless network you

would like to connect to.

3. You may be prompted to enter a security key in order to connect to the network.

4. Enter in the security key corresponding to the wireless network, and click Connect.

TRENDnet User’s Guide

Limited Warranty

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one of the following measures:

x Reorient or relocate the receiving antenna.

x Increase the separation between the equipment and receiver.

x Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

x Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible

for compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired

operation.

IMPORTANT NOTE:

Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance

20cm between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other antenna

or transmitter.

Country Code selection feature to be disabled for products marketed to the US/CANADA

Europe – EU Declaration of Conformity

TRENDnet hereby declare that the product is in compliance with the essential requirements

and other relevant provisions under our sole responsibility.

Safety

EN60950-1 : 2006 + A11 : 2009 + A1: 2010 + A12: 2011

EMC

EN 55022: 2010 + AC: 2011 Class B

EN 55024: 2010

EN 301 489-1 V1.9.2: 09-2011

EN 301 489-17 V2.2.1: 09-2012

Radio Spectrum & Health

EN 300 328 V1.8.1 : (2012-06)

EN 301 893 V1.7.1 : (2012-06)

EN 62311 : 2008

Energy Efficiency

Regulation (EC) No. 1275/2008, Regulation, No. 278/2009, No. 801/2013

This product is herewith confirmed to comply with the Directives.

Directives

Low Voltage Directive 2006/95/EC

EMC Directive 2004/108/EC

R&TTE Directive 1999/5/EC

Ecodesign Directive 2009/125/EC

RoHS Directive 2011/65/EU

REACH Regulation (EC) No. 1907/2006

Operations in the 5.15-5.25GHz / 5.470 ~ 5.725GHz band are restricted to indoor usage only.

The band from 5600-5650MHz will be disabled by the software during the manufacturing

and cannot be changed by the end user. This device meets all the other requirements

specified in Part 15E, Section 15.407 of the FCC Rules.

20c

TRENDnet User’s Guide

Limited Warranty

Česky [Czech]

TRENDnet tímto prohlašuje, že tento TEW-818DRU je ve shodě se

základními požadavky a dalšími příslušnými ustanoveními směrnice

1999/5/ES.

Dansk [Danish]

Undertegnede TRENDnet erklærer herved, at følgende udstyr TEW-

818DRU

overholder de væsentlige krav og øvrige relevante krav i

direktiv 1999/5/EF.

Deutsch

[German]

Hiermit erklärt TRENDnet, dass sich das Gerät TEW-818DRU in

Übereinstimmung mit d

en grundlegenden Anforderungen und den

übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG

befindet.

Eesti [Estonian]

Käesolevaga kinnitab TRENDnet seadme TEW-818DRU vastavust

direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist

tulenevate

le teistele asjakohastele sätetele.

English

Hereby, TRENDnet, declares that this TEW-818DRU is in compliance

with the essential requirements and other relevant provisions of

Directive 1999/5/EC.

Español

[Spanish]

Por medio de la presente TRENDnet declara que el TEW-818DRU

cumple con los requisitos esenciales y cualesquiera otras

disposiciones aplicables o exigibles de la Directiva 1999/5/CE.

Ελληνική

[Greek]

ΜΕ ΤΗΝ ΠΑΡΟΥΣΑTRENDnet ΔΗΛΩΝΕΙ ΟΤΙTEW-818DRU

ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ

ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.

Français

[French]

Par la présente TRENDnet déclare que l'appareil TEW-818DRU est

conforme a

ux exigences essentielles et aux autres dispositions

pertinentes de la directive 1999/5/CE.

Italiano[Italian]

Con la presente TRENDnet dichiara che questo TEW-818DRU è

conforme ai requisiti essenziali ed alle altre disposizioni pertinenti

stabilite dalla

direttiva 1999/5/CE.

Latviski [Latvian]

AršoTRENDnetdeklarē, ka TEW-818DRU deklarē, ka [type of

equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām

prasībām un citiem ar to saistītajiem noteikumiem.

Lietuvių

[Lithuanian]

Šiuo TRENDnet deklaruoja, kad šis TEW-818DRU atitinka esminius

reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.

Nederlands

Hierbij verklaart TRENDnet dat het toestel TEW-818DRU in

[Dutch]

overeenstemming is met de essentiële eisen en de andere relevante

bepalingen van richtlijn 1999/5/EG.

Malti [Maltese

]

Hawnhekk, TRENDnet, jiddikjara li dan TEW-818DRU jikkonforma

mal

ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm

fid

-Dirrettiva 1999/5/EC.

Magyar

[Hungarian]

Alulírott, TRENDnet nyilatkozom, hogy a TEW-818DRU megfelel a

vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv

egyéb

elõírásainak.

Polski [Polish]

Niniejszym TRENDnet oświadcza, że TEW-818DRU ] jest zgodny z

zasadniczymi wymogami oraz pozostałymi stosownymi

postanowieniami Dyrektywy 1999/5/EC.

Português

[Portuguese]

TRENDnet declara que este TEW-818DRU está conforme com os

requisitos essenciais e outras disposições da Directiva 1999/5/CE.

Slovensko

[Slovenian]

TRENDnet izjavlja, da je ta TEW-818DRU v skladu z bistvenimi

zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.

Slovensky

[Slovak]

TRENDnettýmtovyhlasuje, že TEW-818DRU spĺňa základné

požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES.

Suomi [Finnish]

TRENDnet vakuuttaa täten että TEW-818DRU tyyppinen laite on

direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien

direktiiv

in muiden ehtojen mukainen.

Svenska

[Swedish]

Härmed intygar TRENDnet att denna TEW-818DRU står I

överensstämmelse med de väsentliga egenskapskrav och övriga

relevanta bestämmelser som framgår av direktiv 1999/5/EG.

TRENDnet User’s Guide

Limited Warranty

ErP Statement

English

This network device is an Energy Related Product (ErP) that

automatically switches to a power saving standby mode within 10

minutes of no data transmission. When the device is not in use it can

be powered down using its power button, or simply disconnect the

power adapter for additional energy savings.

Networked standby mode:

0.5 watts

Off mode:

0.15 watts

Deutsch [German]

Dieses Netzwerkgerät ist ein Energy Related Product (ErP), das

innerhalb von 10 Minuten ohne Datenübertragung automatisch in

einen Stromsparmodus umschaltet. Wenn das Gerät nicht verwendet

wird, kann es über die Ein

/Austaste heruntergefahren werden, oder

ziehen Sie für zusätzliche Stromersparnis das Netzgerät aus der

Steckdose.

Vernetzt und in

Bereitschaft: 0.5 Watt

Ausgeschaltet:

0.15 watts

Français [French]

Ce périphérique réseau est un Energy Related Product (ErP) qui passe

automatiquement en mode veille, économisant l’énergie, après 10

minutes sans transfert de données. Lorsque le périphérique n’est pas

utilisé, il peut être éteint

en utilisant le bouton d’alimentation, ou

simplement déconnecté en débranchant l’adaptateur secteur pour

obtenir davantage d’économies d’énergie.

Mode veille en réseau

: 0.5 Watt

Mode éteint :

0.15 watts

Español [Spanish]

Este dispositivo de red es un producto relacionado con la energía

(ErP) que pasa automáticamente a un modo en espera, de ahorro de

energía, tras 10 minutos de ausencia de transmisión de datos.

Cuando el dispositivo no está en uso, se puede apagar utilizando el

botón de alimentación, o simplemente desconectar el adaptador de

corriente para optimizar el ahorro de energía.

Modo de espera en red:

0.5 vatios

Modo apagado:

0.15 vatios

Italiano[Italian]

Questo apparato di rete è un Energy Related Product (ErP) il quale

commuta automaticamente

in una modalità standby entro 10 minuti

dall’interruzione della trasmissione di dati. Quando l’apparato non

viene utilizzato, può essere spento tramite il tasto di accensione, o si

può scollegare l’alimentatore, per ottenere un maggior risparmio di

energia.

Modalità standby in rete:

0.5 watt

Modalità spento:

0.15 watts

Português

[Portuguese]

Este dispositivo de rede é um Produto de Consumo de Energia (ErP)

que alterna automaticamente para modo de espera com economia

de energia após 10 minutos sem transmi

ssão de dados. Quando o

dispositivo não está sendo usado pode ser desligado no botão de

energia, ou simplesmente desligando o adaptador de corrente para

economia de energia adicional.

Modo de espera em rede:

0.5 watts

Modo off:

0.15 watts

Русский [Russian]

Данное сетевое устройство - это продукт, относящийся к

категории потребителей электрической энергии (ErP), которые

переходят в экономный режим ожидания, если в течение 10

минут не осуществляется передача данных. Когда устройство не

используется, его можно отключить от источника питания путем

нажатия кнопки включения или путем физического отключения

адаптера питания.

В режиме ожидания:

0.5

Ватт

В выключенном состоянии:

0,15 Ватт

TRENDnet User’s Guide

Limited Warranty

Industry Canada Statement

This device complies with Industry Canada license-exempt RSS standard(s). Operation is

subject to the following two conditions: (1) this device may not cause interference, and (2)

this device must accept any interference, including interference that may cause undesired

operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio

exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil

ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout

brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le

fonctionnement.

Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance

20cm between the radiator & your body.

Déclaration d'exposition aux radiations:

Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un

environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum

de 20 cm de distance entre la source de rayonnement et votre corps.

TRENDnet User’s Guide

Limited Warranty

TRENDnet warrants its products against defects in material and workmanship, under

normal use and service, for the following lengths of time from the date of purchase.

TEW-818DRU – 3 Years Warranty

AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1 year warranty.

If a product does not operate as warranted during the applicable warranty period,

TRENDnet shall reserve the right, at its expense, to repair or replace the defective

product or part and deliver an equivalent product or part to the customer. The

repair/replacement unit’s warranty continues from the original date of purchase. All

products that are replaced become the property of TRENDnet. Replacement products

may be new or reconditioned. TRENDnet does not issue refunds or credit. Please

contact the point-of-purchase for their return policies.

TRENDnet shall not be responsible for any software, firmware, information, or memory

data of customer contained in, stored on, or integrated with any products returned to

TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to

service the product by any unauthorized service center. This warranty is voided if (i) the

product has been modified or repaired by any unauthorized service center, (ii) the

product was subject to accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet within the applicable

warranty period and providing a copy of the dated proof of the purchase. Upon proper

submission of required documentation a Return Material Authorization (RMA) number

will be issued. An RMA number is required in order to initiate warranty service support

for all TRENDnet products. Products that are sent to TRENDnet for RMA service must

have the RMA number marked on the outside of return packages and sent to TRENDnet

prepaid, insured and packaged appropriately for safe shipment. Customers shipping

from outside of the USA and Canada are responsible for return shipping fees. Customers

shipping from outside of the USA are responsible for custom charges, including but not

limited to, duty, tax, and other fees.

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS

WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT TRENDNET’S

OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES AND REMEDIES ARE

EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,

EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

TRENDNET NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR

IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE

OR USE OF TRENDNET’S PRODUCTS.

TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND

EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST

OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT,

IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR

MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY

ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO

EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN

CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL,

INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE OR

PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER FINANCIAL

LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY

OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND

OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF LIABILITY

FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL

OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of the state of

California.

Some TRENDnet products include software code written by third party developers.

These codes are subject to the GNU General Public License ("GPL") or GNU Lesser

General Public License ("LGPL").

Go to http://www.trendnet.com/gpl or http://www.trendnet.com Download section

and look for the desired TRENDnet product to access to the GPL Code or LGPL Code.

These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of

the developers. TRENDnet does not provide technical support for these codes. Please go

to http://www.gnu.org/licenses/gpl.txt or http://www.gnu.org/licenses/lgpl.txt for

specific terms of each license.

PWP05202009v2 2014/12/23

TRENDNET TEW818DRU AC1900 Dual Band Wireless Router User Manual test 3

TRENDNET, Inc. AC1900 Dual Band Wireless Router test 3

Contents

Users Manual

Navigation menu

Namespaces

Views

Navigation
