TYT ELECTRONICS MDUV380 DMR Digital Transceiver User Manual MD UV380 180321

TYT ELECTRONICS CO., LTD DMR Digital Transceiver MD UV380 180321

Contents

user manual II

otherwise, it may damage your DMR Digital Transceiver. It can be operating under 2000m.
Hereby, (TYT Electronics Co.,Ltd) declare that the radio equipment type (DMR Digital Transceiver)
Operation Frequency:
Max. Output Power: 5W/1W
AC ADAPTER: , Input: 100-240V~ 50/60Hz, 0.6A; output: 12V 0.5A
136-174 & 400-480MHz
is compliance with Directive 2014/53/EU.
MD-UV380 /MD-UV390
Antenna Gain:1.5dBi
Use the DMR Digital Transceiver in the environment with the temperature between-10 and 40 ,
℃ ℃
Test position and configuration Head SAR was performed with the device configured in the positions
according to EN 62209-2:2010, and face up SAR was performed with the device 25mm from the
phantom. Body SAR was also performed with the headset and belt clip attached and without 0mm from the phantom.
Caution:
For Adapter: Shall be installed near the equipment and shall be easily accessible.
For Battery: Risk of explosion battery is replaced by an incorrect type, dispose of
used batteries according to the instructions.
EU Declaration of Conformity
We, hereby declare that the essential requirements set out in the RED Directive 2014/53/EU, have
been fully fulfilled on our product with indication as below:
Product Name DMR Digital Transceiver
Brand Name / Model TYT/ MD-UV380, MD-UV380G, MD-UV390
The following standards have been applied for the investigation of compliance:
Safety EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Health EN 62209-2:2010; EN50566:2017
EMC EN 301 489-1 V2.2.0 (draft)
EN 301 489-5 V 2.2.0 (draft)
Radio
ETSI EN 300 086 V 2.1.2
ETSI EN 300 219 V 2.1.1
EN 300 113 V2.2.1
Notified Body number 0700 PHOENIX TESTLAB GmbH
Furthermore, the ISO requirement for the in-process quality control procedure as well as the
manufacturing process has been reached. The technical document as well as the test reports will be
kept for a period at least 10 years after the last product has been manufactured at the disposal of the
relevant national authorities of any Member State for inspection.
Detail contact information for this declaration has been listed below as the window of any issues
relevant for this declaration.
Hardware Version: UV-V2.1-171109
Software Version: V1.06
Battery: (MD-UV390) TYT Electronics Co., Ltd, MD-390, 7.4V, 2200mAh
(MD-UV380& MD-UV380G)TYT Electronics Co., Ltd, MD-380, 7.4V, 2000mAh
Antena: Detachable , Gain 1.5dBi
Charger: (MD-UV390)TYT Electronics Co.,Ltd, Model name: CH390 , INPUT: DC 12V 0.5A,
OUTPUT: DC 8.4V, 0.5A;
(MD-UV380& MD-UV380G)TYT Electronics Co.,Ltd, Model name: CH380 , INPUT: DC 12V 0.5A,
OUTPUT: DC 8.4V, 0.5A
AC ADAPTER: (MD-UV390) TYT Electronics Co., Ltd, MD-UV390, Input: 100-240V~ 50/60Hz, 0.6A,
output: 12V 0.5A
(MD-UV380& MD-UV380G)TYT Electronics Co., Ltd, MD-UV380, Input: 100-240V~ 50/60Hz,
0.6A; output: 12V0.5A
Manufacturer Information：
Company TYT Electronics Co.,Ltd
Address Block 39-1,Optoelectronics-information industry base, Nan'an, Quanzhou,
Fujian, China
Name/Title Sophia Wong E-mail tyt@tyt888.com
Tel. No. +86-15259596756 Fax No.
Signature / stamp Date:
SAFETY TRAINING INFORMATION
our TYT Electronics Co., Ltd. radio generators RF electromagnetic
during transmit mode.This radio is designed for and classified as"Occupational Use Only",
meaning it must be used only during the course of employment by individuals aware of the
hazards,and the ways To Minimize Such hazards. This radio is NOT intended for use by the"General Population"
in an uncontrolled environment. This radio has been tested and complies with the FCC RF exposure limits for
"Occupational Use Only".Inaddition, our TYT Electronics Co., Ltd radio complies with the.
following Standards and Guidelines with regard to RF energy and electromagnetic energy levels and evaluation
of such levels for exposure to humans:
--IEEE Std. 1528:2013 and KDB447498, Evaluating Compliance with FCC Guidelines for Human
Exposure to Radio Frequency Electromagnetic Fields.
--American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to
Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz.
--American National Standards Institute (C95.3-1992), IEEE Recommended Practice for the Measurement
of Potentially Hazardous Electromagnetic Fields- RF and Microwave.
The information listed above provides the user with the information needed to make him or
her aware of RF exposure, and what to do to asÿsure that this radio operates with the FCC RF
exposure limits of this radio.
Electromagnetic Interference/Compatibility
During transmissions, TYT Electronics Co., Ltd. radio generates RF energy that can
possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in
areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to
electromagnetic radiation such as hospitals, aircraft, and blasting sites.
Occupational/Controlled Use
The radio transmitter is used in situations in which persons are exposed as consequence of their employment
provided those persons are fully aware of the potential for exposure and can exercise control over their exposure.
Attention:
This radio complieswith IEEE and ICNIRP exposure limits for occupational/controlled RF exposure
emvironment at operating duty factors of up to 50% and is authorized by the FCC for occupational use only. An
appropriate warning lable is affixed to all units. In order to comply with RF exposure requirements, a minimum
distance of 2.5cm must be maintained when held-to-face, and body-worn operations are restricted to the approved
original acessories (belt clip). Do not use this device when antenna shows obvious damages
This product is compliance to FCC RF Exposure requirements and refers to FCC website
information include SAR Values.
(Model:MD-UV390 FCC ID: POD-MDUV390) to gain further
https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm search for(Model:MD-UV380 &MD-UV380G FCC ID:
POD-MDUV380 )
