Technicolor Delivery Technologies Belgium TC8706T Cable Modem User Manual

Technicolor Delivery Technologies Belgium Cable Modem

User Manual

CABLE
VOICE
DATA
VIDEO
MediaAccessTC8706T for Time Warner Cable
Smart Cable Gateway
with Battery Backup Solution
Features at a Glance
■DOCSIS®3.0 certified
■Backward compatible with DOCSIS2.0 (and older)
■8 downstream and 4 upstream channels
■Voice PacketCable™1.5 & 2.0 compliant
■Full band capture
■4 GE LAN ports
■MoCA 2.0
■Dual band high power Wi-Fi interface:
IEEE802.11n 2.4GHz (3x3) & 5GHz (3x3)
■2 FXS ports (RJ-11)
■(optional) Integrated DECT multiline base station
(CAT-iq™ 2.o ready)
■2 USB 2.0 master for hard disk, printer, 3G adapter, …
■Spectrum analyzer
■Technicolor feature set
■Dedicated applications core
■HNAP for home security services (optional)
■SNMP
■TR-069 remote management (optional)
■IPv4 and IPv6 support
Future-proof Solution for Advanced
Services over DOCSIS
As cable and wireless standards keep evolving, Technicolor presents the
TC8706T, a DOCSIS 3.0 dual band concurrent wireless embedded
Multimedia Terminal Adapter (eMTA) smart gateway with best-in-class
performance and dual band concurrent wireless support.
A dedicated applications processor and software execution environment
make it a powerful and reliable platform in the home, ready for demanding
services and applications.
The TC8706T has an extended life cycle thanks to its extensive remote
management capabilities, including the ability to smoothly upgrade itself
and add apps on the go.
Moreover, this new generation of smart high-speed data service solutions
supports up to eight bonded downstream channels and four bonded
upstream channels, and provides full connectivity to devices in the home
including set-top boxes via MoCA2.0. The optionally integrated DECT
base station oers support for up to five DECT phones.
Applications Core
As an easily updatable platform, the TC8706T is capable of providing
subscribers with advanced services and apps within the home. Its dedicated
applications processor and software service framework put services such as
the following at your fingertips:
■DLNA Digital Media Server (DMS)
■Home Security and Automation
■Troubleshooting and Diagnostics
■Customer Self Help
MediaAccessTC8706T for Time Warner Cable
Smart Cable Gateway
with Battery Backup Solution
Full Band Capture Solution
Thanks to its fully integrated 1 GHz wideband capture, the TC8706T
exceeds SCTE-40+ performance and eliminates all frequency limitations
of traditional wideband tuners. The TC8706T enables use of the full radio
frequency (RF) spectrum without the need for grouped channels. This helps
the operator migrate its entire DOCSIS 3.0 install base from one to eight
DOCSIS downstream channels without having to re-align all its broadband
channels to accommodate this new service.
The full band capture feature also facilitates spectrum analysis features and
capabilities, unleashing powerful ways to manage cable plants in a proactive
way, reducing operational expenses.
High-Speed Wireless Interface
The TC8706T has a dual band concurrent high power IEEE802.11n wireless
interface, supporting an industry leading 3x3 spatial stream configuration at
both 2.4GHz and 5GHz. Combined with internal amplifiers, the TC8706T
takes home networking to a completely new level. The TC8706T also
supports multiple SSIDs.
Voice Performance
The TC8706T is PacketCable 2.0 compliant and is equipped with basic and
extended CLASS features such as caller ID and call waiting.
Optionally, thanks to its integrated DECT base, new lines can be added by
simply pairing new cordless handsets, while legacy fax equipment can still be
connected to the FXS port.
Advanced Security
The integrated firewall provides Stateful Packet Inspection (SPI), and an
integrated intrusion detection and Prevention System (IDS) engine monitors
a wide range of attack patterns, and logs potential security breaches to a local
cache or remote server. To secure data exchange between the gateways
and the cable operators’ servers, BPi+ communications privacy is used.
MoCA
The TC8706 also includes an integrated MoCA2.0 interface which enables
the gateway to provide connectivity to set-top boxes and client devices
connected within the home. MoCA 2.0 provides a future proof, high
bandwidth and high node count wired backbone within the subscriber’s
home.
Hardware robustness and immunity
The TC8706T has industry leading EMC robustness for maximum reliability.
Best in class radiated immunity specification provides protection against
wireless and LTE interference. Industry leading immunity to conducted
interference gives protection against in-home conducted disturbances. Best
in class surge immunity provides protection against electrical surge events.
Power supply thermal stability is fully characterized to protect against any
safety or reliability concerns such as brown-out situations.
Easy to Use
Like all Technicolor modems and gateways, the TC8706T is an easy to use,
easy to install gateway.
For instance, the easy-to-access LEDs provide a clear indication of start-up
sequence, connectivity status and channel bonding status (number of used
downstream and upstream channels). Additionally, multiple integrated web
pages allow direct access to the status and settings, including privacy and
security information.
With Wi-Fi Protected Setup (WPS) users can easily connect with the
TC8706T wireless network by simply pushing a button or entering a PIN
code. It allows home users to easily connect to a secure network without any
complex configuration and eliminates the need to remember or store their
security information in an unsafe way.
ECO
Technicolor oers its customers environmentally friendly products. In addition
to carefully selected plastics and packaging to minimize the ecological
footprint, the TC8706T benefits from a unique combination of hardware
and software features that reduce power consumption substantially.
Professional Services
To reinforce our extensive portfolio of digital home solutions, Technicolor has
a dedicated Professional Services team to make sure that every deployment
is a success, from initial provisioning and integration to operations, upgrades,
ongoing support and beyond.
Our wide array of services spans the entire customer project lifecycle,
encompassing:
■Expert consulting
■Seamless system integration
■Warranty on all our products
■Qualified technical support and maintenance
■Ecient repair, refurbishment and recycling
MediaAccessTC8706T for Time Warner Cable
Smart Cable Gateway
with Battery Backup Solution
Technical Specifications
Cable Certifications
■Data DOCSIS®3.0 certified
■Voice PacketCable™2.0 compliant
■CMTS interoperability Any qualified DOCSIS® CMTS
Hardware Specifications
■Interfaces WAN 1 RF connector F-Type
■Interfaces LAN 4-port auto-MDI/MDI-X 10/100/1000 Base-T port
Ethernet LAN switch (RJ-45)
MoCA 2.0 for LAN through WAN RF connector F-Type
2 FXS POTS ports (RJ-11)
Integrated DECT base station (optional)
2 USB 2.0 master ports
Wi-Fi IEEE 802.11b/g/n high power 2.4GHz 3x3
Wi-Fi IEEE802.11b/g/n high power 5GHz 3x3
■Interfaces other WPS button
Reset button
■Dimensions 242 x 52 x 218mm (9.5 x 2.0 x 8.6in.)
■Power supply 90-135VAC, 50-60Hz
Lifeline battery backup
■Radiated immunity More than 10V/m
■Conducted interference immunity
Up to 10V e.m.f.
■Surge immunity 6kV on AC input
6kV shield to ground
4kV center conductor to shield
■Operating temperature 0° to 50°C (32° - 122°F)
■Operating humidity 20% to 90% non-condensing
■Storage temperature -20° to 70°C (-4° - 158°F)
Receiver Specifications
■Downstream modulation
QAM 64/256
■Downstream frequency range
54 - 1002MHz
■Maximum downstream data range
340Mbps (theoretical)
(42.88Mbps x 8channels)
■Capture windows Full Band Capture: possibility to have any of the 8
downstream channels over the full DOCSIS®spectrum
■Up to 8 downstream channels
■Input signal level range -15dBmV / + 15dBmV
■Input impedance 75Ohm
Transmitter Specifications
■Upstream modulation QPSK and 8, 16, 32, 64 and 128 QAM
■Upstream frequency range
5 - 42MHz
■Maximum upstream data range
131Mbps (theoretical)
(32.78Mbps x 4 channels)
■4 upstream channels
■Channel bandwidth 200, 400 and 800kHz, 1.6, 3.2 and 6.4MHz
■Output impedance 75Ohm
MoCA Specifications
■MoCA2.0
■Full backward compatibility to MoCA1.1
■Support for up to 16 MoCA network nodes
■Throughput up to 400Mbps
■Expanded range of operating frequencies – 1150MHz to 1650MHz
■Supports both Parameterized and Prioritized QoS
Management
■User-friendly GUI via HTTP
■Web-based user interface management and administration
■Logging and alert
Wireless Specifications
■Dual band concurrent Wi-Fi access points, Wi-Fi certified®
IEEE802.11b/g/n high power 2.4GHz 3x3
IEEE802.11b/g/n high-power 5GHz 3x3
■WPA(2)™-Personal support of Temporal Key integrity Protocol (TKIP)
IEEE802.1x port-based authentication with RADIUS client
■Wi-Fi Protected Setup (WPS™)
■Up to 8 BSSIDs (virtual AP) support
■Security and service segregation per SSID
■6 internal antennas
Security
■Stateful Packet Inspection Firewall (SPIF)
■Customizable firewall security levels
■Intrusion detection and prevention (DoS, SYN Flood, Ping of Death)
■URL- and content-based website filtering
Networking
■Network protocol IP, TCP, UDP, ARP, ICMP, DHCP, TFTP, SNMP, HTTP
■Protocol filtering Ethernet and IP
■SNMP management SNMPv2, SNMPv3
Software Specifications
■Downloadable software
■Multiple client support 254
■Class of Services 16 DSID
■Security BPI+
■HTTP server
TECHNICOLOR WORLDWIDE HEADQUARTERS
1, rue Jeanne d’Arc
92443 Issy-les-Moulineaux France
Tel: +33 (0)1 41 86 50 00 - Fax: +33 (0)1 41 86 58 59
www.technicolor.com
SALES CONTACT
For more information please get in touch with your
usual sales representative or use the following email:
EMEASalescontact@technicolor.com
APACSalescontact@technicolor.com
NAMSalescontact@technicolor.com
LATAMSalescontact@technicolor.com
© Copyright 2013 Technicolor. All rights reserved.
Photos and specifications are subject to change without
notice. All trade names referenced are service marks,
trademarks, or registered trademarks of their respective
companies.
DMS-DAT-20121017-0000 vA.1
MediaAccessTC8706T for Time Warner Cable
Smart Cable Gateway
with Battery Backup Solution
Technical Specifications
DECT Specifications
■CAT-iq™ 2.0 mulit-line (enhancement to DECT6.0 for use in IP based devices)
■Far reaching
■Improved voice quality
■Wideband voice support
Telephony Specifications
■Audio codecs PCM A-law, PCM μ-law, G.728, G.729, G.729a, G.729e,
iLBC and BV16
Wideband (G.722, G.722.2)
■Multi-line phone support 2 phone lines
3-party conference calls
Supports two complex voice codecs simultaneously
■Fax relay T.38
■DTMF tone relay RFC2833
■Caller ID Type I and Type II
■CLASS features Basic and extended CLASS features
■Voice Activity Detection (VAD)
■Comfort Noise Generation (CNG)
■Echo cancellation G.65 / G.168 up to 16ms
■Packet tone DTMF generation /
Call progress generation /
Custom tone generation
■Call discrimination Fax and modem detection
■Telephony interface capabilities
Loopback and on-demand diagnostics
■Modems Up to V.90 (38.5kbps)
■RFC2833 DMTF tone relay
Enabled / disabled via SNMP
■REN 5 REN
■Pulse dialing DTMF/pulse tones and pulse/DTMF tones conversion
■RTP layer RFC1889 / RFC1890
■RTCP statistics collection
■PacketCable protocols PacketCable™ NCS
Network-based call signalling protocol
(PKT-SP-EC-MGCP)
SIP protocol by software upgrade
■SIP based protocols
Content of the Box
■Smart Cable Gateway with Battery Backup Solution
■Power supply cable

Navigation menu
