TFM-138 - Technisonic
Home Airborne FM TFM-138
TFM-
138
The Technisonic TFM-138 is a frequency agile airborne VHF/FM High Band transceiver operates from
138.000 MHz to 174.000 MHz in 2.5 KHz steps, providing for either 12.5 KHz (Narrow Band) or 25.0
KHz (Wide Band) channel spacing.
The TFM-138 offers a two channel synthesized Guard Receiver (no crystals), 100 channels of preset
memory, scan and priority scan, all available CTCSS tones, and can operate without restriction on
any split frequency pair available within the band. Function control is via a panel mounted 12 button
key pad. Operating frequency, alpha numeric identifier and other related data are presented on a 48
character, two line LED matrix display. This transceiver weighs just 3.1 lbs, is Dzus panel mounted
and is completely self contained (no heavy remote transceiver), eliminating problematic,
complicated, heavy and costly R/T to control head interconnect wiring. The TFM-138 is compliant
with current US Forest service contract requirements.
Download TFM-138 Series Brochure (63 KB)
Download TFM-138 Series Installation Diagram (109 KB)
Download TFM-138 Installation/Operators Manual (749 KB)
