USER MANUAL
FCC NOTICE
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
- Owner's Manual -
MP-2000 Portable Music Pla
y
er
Be Sure to Check
www.audiovox.com
for FREE
Software Upgrades!
ENABLED
Warning
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
! NOTE: You are cautioned that any change or modifications to the equipment not
expressly approved by the party responsible for compliance could void your authority
to operate such equipment.
! NOTE: This unit was tested with shielded cables on the peripheral devices. Shielded
cables must be used with the unit to insure compliance.
TAB LE O F C O N TEN TS
INTRODUCTION TO MP3 AND THE MP-2000
MPDJ KIT CONTENTS
BEFORE USING THE MP-2000
MP-2000 CONTROL BUTTONS
MP-2000 LCD DISPLAY
OPTIONAL MULTIMEDIA CARD (MMC)
CONNECTING THE MP-2000 TO YOUR PC
SOFTWARE INS TALLATION
OBTAININ G AND MA NAG ING M P3 FILE S
REAL JUKEBOX SOFTWARE
THE DOWNLOADER PROGRAM
HOW TO USE THE MP-2000
TROUBLESHOOTING
CAUTION IN USING AND STORING THE MP-2000
MP-2000 TECHNICAL SPECIFICATIONS
1
2
3
4
5
6
7
8
9
10
17
19
36
37
38
WHAT IS M P3?
THE MP-2000
1
Warning
It is ille
g
al to encode MP3 files for trade or sale, unless
y
ou
have the expressed and explicit permission of the Copyright
holder(s).
MP3, short for MPEG-1, AUDIO LAYER 3 (an
t is an efficient way to store music or other audio content on your
compu
audio subset of an industry standard
referred to as the Moving Picture Experts Group), digital audio compression
algorithm that achieves a compression factor of about 12:1 while preserving sound
quality. MP3 is an open format for making large music files smaller without radically
degrading their audio quality. It is widely recognized as the most popular format for
storing music on the World Wide Web and other components of the Internet.
is a
In addition, i
ter. MP3 files can be anywhere from 1/4 to 1/20 the size of a commercial CD
audio file, while retaining a high sound quality. These files have the extension of
*.mp3 and can be downloaded from the Internet. They can also be converted for
personal use from your library of favorite CD's.
The MP-2000 player stores your favorite MP3 files in its flash memory so that they
can be played anywhere you please, even on-the-go. The MP-2000's solid-state
design makes it impervious to the skipping and jitter experienced with portable CD
players. Since the MP-2000 is extremely light-weight and about the size of a pager,
it is perfect for use during jogging, walking, hiking, and just about any activity you
like to do.
MPDJ KIT CONTENTS
MANUAL
MP-2000 PLAYER OWNER'S MANUAL PARALLEL PORT PC
CONNECTING CABLE
EARPHONES BATT ERIE S (2 x AAA ) LEATHER CASE
INSTALLATION CD HAND STRAP
2
D
I
G
I
T
A
L
S
T
E
R
E
O
C
YB
E
R
M
U
S
IC
Take a moment to examine the components provided with your
MP DJ kit.
BEFORE USING M P-2000
3
System R equire m e n ts
M P3 Internet Site s
You can obtain MP3 files and the latest information on MP3
technology from a growing number of Internet sites.
The following are some sites you might want to explore:
http://www.audiovox.com
http://realguide.real.com
http://www.altavista.com
http://www.emusic.com
http://www.mp3now.com
http://www.goodnoise.com
http://www.listen.com
http://www.mp3site.com
http://mp3.lycos.com
http://www.mp3.com
Microsoft Windows 95 or 98
16MB RAM or greater (64MB recommended)
30MB available HD space (more if MP3 file storage is desired)
1 External Parallel Port
10X or faster CDROM Drive (32X recommended)
Installed sound card and speakers
Installed Mouse
Internet access for the download of MP3 files and CD Database support
(Recommended modem speed is 56K)
Windows
90MHz Intel Pentium or faster compatible processor
4
MP-2000 CONTROL BUTTONS
MODE
VOLUME LEVEL ADJUSTMENT(+)
EARPHONE JACK
VOLUME LEVEL ADJUSTMENT(-)
HOLD
PC CONNECTION
SOCKET
PROGRAM SELECTION FORWARD
PROGRAM SELECTION REVERSE
POWER ON/
PLAY/PAUSE
STOP/
POWER OFF BATTERY CASE
EJECT
MULTIMEDIA CARD SLOT
M P-2000 LC D D ISPLAY
5
HOLD
128kb
256kb
VOL
1 ALL
M P3
HOLD
128kb
256kb
VOL
1 AL L
M P3
Displays the track number
Indicates repe at fu nction is activated
Indicates volume level
Indicates that an MP3 file is playing or is paused
1
2
3
4
5
6
Indicates that the HOLD switch has been set to the on
position. Prevents accidental or unintended operation of
any button.
Indicates the bit rate at which the MP3 file was created.
The higher number equals higher quality audio output. The
bit rate is measured in Kilobits-per-second (Kbps).
Indicates current battery status. Three bars indicates a fully
charged battery. This icon is always on while the unit is
operating.
7
6
OPTIONAL FLASH M EM ORY
MULTIMEDIA CARD [M M C]
1
2
3
Inserting The Flash Memory Card
Ejecting The Flash M em ory Card
Turn off the power by pressing and holding the
Stop Button for 2 seconds. Insert the
MultiMedia card into the MMC slot .
(figure 1)
()
■
S
T
E
R
E
O
Eject
button
The MP-2000 player can store and play additional MP3 files by inserting
an optional flash memory card into the MMC slot.
If you have a MultiMedia Card inserted into the
MP-2000 player, remove it by pressing the Eject
Button .
(figures 2 & 3)
Caution: Do not remove the MultiMedia Card
while unit is on, or damage to the unit
and/or MMC could result.
7
1
2
CONNECTING THE M P-2000 TO YOUR PC
Connect the supplied PC connecting
cable to your computer's parallel
printer port.
Connect the PC cable to the MP-2000
by pressing in the lock/release tabs
on each side and inserting the
connector into the MP-2000 plug.
Release the side tabs.
Turn on the MP-2000 by pressing the
Play button ( ).
To transfer MP3 files between your PC (personal computer) and the MP-2000, you
must connect the two as shown below. Do this prior to using the MPDJ Downloader.
Note: The MP-2000 connector is
keyed and will accept the PC
Connector Cable only if
properly oriented (metal side
up).
Lock/Release
Ta b( s)
M P-2000 TECHNICAL SPECIFICATIO NS
38
M P-2000 Player
A ccessories
Processor
Memory
Voltage Input
Battery
LCD Display
Dimensions (W*H*D)
Weight
Case
File Transfer
(from PC to MP-2000)
Speed
Memory Socket
S/N Ratio
Output of Earphone
Frequency Range
20MHz, 8bit MCU
64MB Built-in (expandable to 128MB)
3VDC
95dB
20Hz~20KHz( 1dB)
2 x 'AAA' size alkaline batteries
Alphanumeric 3 line with 12 characters
63.4 83 18.3
Aluminum, Poly Carbonate
Multimedia Card (MMC)
Earphones
Parallel PC Connecting Cable
32MB Flash Memory Card (MMC) - Optional
Leather Carrying Case
56g (without batteries)
~10sec/MB
Hand Strap
14mW (Max)
You may purchase any of the above accessories by calling the
Audiovox Customer Service Center at (800) 290-6650.
150 Marcus Boulevard
Hauppauge, NY 11788
USA
http://www.audiovox.com
(800) 290-6650
Printed in Korea
FORM No. 128-5827
