marked with an exclamation point in front of it. The following is a list of message prioritization:
Very Urgent
Urgent
Normal
Bulk
Messages not specifying a priority shall be assumed to be normal.
1.1.1 Send Options for a message
The Outbox Details menu has several sub menus from which you can choose. These menus appear when you
press Soft
SELECT
Key. Use the scroll keys to move to the menu you want to use.
Send and Discard
Send and Save
Save
Set Urgency
Delivery Report
1.1.2 Delivery report
If you want to know your message was delivered, you can turn on the
Delivery Report
options.
Scroll to
Delivery Report
.
Press
ON
.
If you do not want to use
Delivery Report
, you can turn them off by switching to
OFF
.
1.2 Receive a text message
When you receive a text message, the phone sounds a message alert tone and the text message icon appears, along
with one of the following messages:
New Message
: Indicates that you have an unread message or page. If you have more than one message or
page, the appropriate number is listed before this message
1.2.1 Read a text message
Press
READ
.
Scroll to the message, then press
OPTIONS
.
Scroll to the Details, and press
SELECT
.
Press
OPTIONS
for a list of choices you have while reading the message.
Press
SELECT
when the option you want is highlighted.
1.2.2 Choose options for a message
When you press Options while reading a message, the following choices are available.
Details
Takes the user to the detailed view for the
message.
New Message
Allows the user to create a new SMS message.
New From Template
Allows the user to create a new SMS message
based on a predefined list of messages, such
as “Meeting cancelled” or “Call me please”.
Delete
Delete the message being viewed. The user
will be asked to confirm the deletion.
Delete All
Deletes all received SMS messages. The user
will be asked to confirm the deletion.
1.2.3 Read options for a message
The Inbox Details menu has several sub menus from which you can choose. These menus appear when you
press Soft
SELECT
Key. Use the scroll keys to move to the menu you want to use.
Reply
Provides a screen where you can write a reply.
Forward
Forwards the call to another person. That person
must have the appropriate message service.
Delete
Delete the message being viewed. The user will be
asked to confirm the deletion.
Lock
Lets you lock your received messages to phone.
Call Number
Calls the person who sent you the text message, if
their phone number is included in the message.
1.2.4 Call Number
Calls the person who sent you the text message, if their phone number is included in the message.
You can also press while the message is displayed to dial the number.
If more than one number is on the screen, the numbers appear in a list. Scroll to the phone number you want
to call and press .
1.3 When your phone’s memory is full
When your phone’s message memory is full, one or more messages of the lowest priority are automatically
deleted. These messages are usually deleted from your phone’s outbox.
If after deleting messages the memory is still full, your phone shows the message error “No space: Message
waiting” appear.
1.4 Delete a message
While reading a message, press
OPTIONS
.
Scroll
Delete
, then press
SELECT
.
Your phone asks you to confirm that you want to delete the message.
Press
OK
.
1.5 USE VOICE MAIL
Voice mail is a network services feature. Colleagues who miss you when they call
can leave a voice message, which you can retrieve later.
1.5.1 When you have a message
Your phone beeps when you receive a voice message. Also, the message
New voice message
appears on your phone’s screen, along with the
icon.
Note: To use voice mail, you need to learn the voice mail system’s various
greetings, passwords, and prompts. Your service provider can provide
instructions.
1.5.2 Set up your voice mailbox
As part of your network’s voice mail feature, your service provider gives you a
voice mailbox phone number. Save this number in your phone to make getting
your voice messages quick and convenient.
Press
MENU
3
>
6
>
2
(
Messages
>
Voice Mail
>
Voice mail Num
).
Enter your mailbox phone number.
Press
ENTER
.
Your voice mailbox number can be up to 20 digits long and is used until it’s
changed. Therefore, if your phone number changes, you may need to change
your voice mailbox number along with it.
1.5.3 Listen to your voice messages
Note: The way you listen to your voice messages may vary depending upon your service provider. Call your
service provider if you have any questions.
When your phone alerts you to new voice messages, press
LISTEN
and follow the instructions given
on the phone.
If you’d rather listen to your messages later, press
EXIT
.
To Listen to your voice messages at a later time:
Press and hold the 1 key.
OR
Press
MENU
3
>
6
>
1
(
Messages
>
Voice Mail
>
Call Voicemail
).
2. Send and receive e-mail messages
You can use your phone to send and receive e-mail messages. This means you no longer need to be at your computer to
send or receive messages.
2.1 Send an e-mail address
You can add an e-mail address to a name you’ve already saved in the phone book. Or, you can add a name and
address as a new entry.
2.1.1 Save an e-mail address for an existing name
At the Start screen, press
NAMES
or press
MENU
>
1
(
Phonebook
).
Enter the first one letters of the name or scroll to the name you want and press
OPTIONS
.
Scroll to
Details
, then press
SELECT
to view the number.
Press
OPTIONS
.
If
Edit
is not highlighted, scroll to it and press
SELECT
.
The associated name appears.
Press
SELECT
. The associated number appears.
Press
SELECT
. The E-mail address entry screen appears.
Enter the address, and then press
ENTER
to save the new e-mail address.
2.1.2 Add a new e-mail address
At the Start screen, press
NAMES
, press
OPTIONS
, scroll to
New
and press
SELECT
.
Enter the name and press
ENTER
.
The Number entry screen appears.
Enter the phone number and press
ENTER
.
The E-mail address entry screen appears.
Enter the address, using the special characters screen to insert the “dot(.)” and @ signs.
Press
ENTER
.
The message
Entry written
appears briefly, confirming your action.
2.1.3 Add a new e-mail address
Follow steps through in “Save an e-mail address for an existing name” (earlier in this section) to find
the name whose e-mail address you want to edit.
Enter any changes, using the scroll keys to move the insertion point backward and forward in the address.
When the address is the way you want it, press
ENTER
.
The message
Entry written
appears briefly, confirming your action.
2.2 Send an e-mail message
At the Start screen, press
MENU
and then, at
Messages
, press
SELECT
.
Scroll to
Write E-mail
, and press
SELECT
.
Enter the e-mail address.
If you press
SEARCH
, enter the first few letters of the name you want and press
ENTER
when you
find the name. The address appears in the Recipient address box. Press
ENTER
.
The phone finds only names with e-mail address and lets you know if it doesn’t find any. If no names with
e-mail address are found, you are returned to the Recipient address box.
If you enter the e-mail address, press
ENTER
when you’ve finished.
The
Subject:
opens.
Enter a subject and press
ENTER
.
When the message contents screen appears, enter your message.
When you’ve finished the message, press
ENTER
, select
Send and Discard
or
Send and
Save
, and press
ENTER
.
A status message tells you the mail is being sent.
2.2.1 Other options for a completed message:
Save
Save the message in the saved folder until you send it.
Quit
Erase the message and returns you to the Recipient address box.
3. USE ADVANCED CALLING FEATURE
3.1 Set in-call options
Your phone allows you to use a number of features during a
call. These features are known as in-call options.
Note: Many in-call options are network services features.
To use these options, you must contact your service
provider.
You cannot use all these options at all times. This section tells you when you can
use a certain option.
To access an option during a call, press
OPTIONS
.
Choose from some or all of the following options:
Drop
Allows you to end the call.
Voice Privacy
Allows you to access the Voice Privacy.
Main Menu
Allows you to access the
MENU
.
3.2 Use call waiting
If you have call waiting, your phone beeps during a call to let you know that someone else is calling you.
Depending on your caller ID setup, the phone can also display the number of the
incoming call.
Note: Call waiting may not be available in all wireless systems. Contact your service provider for details and
availability.
Before you can use call waiting, you must first store its feature code. Then you must activate the call waiting
feature.
3.2.1 Store the call waiting feature code
Press
MENU
4
>
4
>
5
(
Settings
>
Network services
>
Feature Code Set
).
The
Feature code
field appears.
Enter the feature code your service provider gave to you and press
ENTER
.
Scroll to
Call waiting
and press
SELECT
.
Make sure that
Activate
is highlighted and press
SELECT
.
3.2.2 Activate call waiting
Press
MENU
4
>
4
>
3
(
Settings
>
Network services
>
Call waiting
).
Use or to scroll to
Activate
and press
SELECT
.
Your phone calls the network to confirm the feature code you entered. After the network confirms the feature
code, call waiting is activated.
3.2.3 Manage calls
Call waiting works with both local and long distance calls.
To answer an incoming call, press .
To switch from one call to another, press .
To end both calls, press .
3.3 Use call forwarding
While call forwarding, you can forward incoming calls to another number. This
way, if you are unable to receive calls on your phone, all calls going to that phone
can be forwarded to another phone. You never have to miss an important call.
Note: The call forwarding feature might not be available in all wireless systems.
3.3.1 Store the call forwarding feature code
Press
MENU
4
>
4
>
5
(
Settings
>
Network services
>
Feature Code Set
).
The Feature code field appears.
Enter the feature code your service provider gave you and press
ENTER
.
Use or to scroll to
Call forwarding
and press
SELECT
.
3.3.2 Activate call forwarding
Press
MENU
4
>
4
>
2
(
Settings
>
Network services
>
Call forwarding
).
Scroll to the desired call forwarding option, as described in the following table, and press
SELECT
.
All Calls
Forwards all incoming calls.
If Busy
Forwards calls only when you’re one your phone and do not have
voice mail.
If Not Answered
Forwards calls if you don’t answer. This option is handy if you want
to give your phone to someone for a short period of time, but you
don’t want this person to answer the phone.
If Out Of Reach
Forwards calls if you are out of the home wireless network, or if your
phone is turned off.
Cancel All Fwd
Cancels all forwarding options that are currently active.
Highlight
Activate
and press
SELECT
.
Scroll to
Other Number
and press
SELECT
, and then enter the number to which you want your
calls forwarded.
Press
ENTER
.
Your phone calls the network to confirm the feature code that you entered in
MENU
4
>
4
>
5
. After the
network confirms the feature code, call forwarding is activated.
3.4 Redial automatically
Automatic redial enables your phone to continue trying to call a number that was
busy due to wireless network problems.
When you call a number and get a busy signal because of network problems, your
phone redials this number up to 3 times. If you want to stop this process prior to
the last attempt, press . This stops the automatic redialing.
Before you can use the Automatic Redial feature, you must activate it.
Press
MENU
4
>
1
>
4
> (
Settings
>
Call Settings
>
Auto Redial
).
Press
ON
.
3.5 Use a calling card
You can use a calling card when you dial long distance calls. First you must store
your calling card information in the phone. Your phone can store information about
a maximum of four calling cards.
3.5.1 Save calling card information
Press
MENU
4
>
1
>
2
(
Settings
>
Call Settings
>
Calling card
).
Scroll to the
Card A
,
Card B
,
Card C
, or
None
calling card and press
Options.
Scroll to
Edit
and press
OK
.
Enter your
Security code
and press
OK
.
Press
SELECT
.
Use or to scroll through the list of dialing sequences, as described
in the following table.
Dialing sequence Use for cards that require you to Associated
cards
Access no.
+ phone no.
+ card no
Dial 1-800 access number, then
phone number, then card number (+
PIN if required).
MCI,
Sprit Canada,
Unitel
Access no.
+ card no.
+ phone no.
Dial 1-800 access number, then card
number (+ PIN if required), then
phone number
Network MCI,
WorldPhone MCI,
AT&T
Prefix
+ phone no.
+ card no.
Dial the prefix (any numbers that
must precede the phone number) and
phone number you want to dial, then
card number )+ PIN, if required).
GTE, PacBell,
AT&T, Stentor
Calling cards shown here are frequently used with the dialing sequences
listed in the first column. However, this information could vary and it is
subject to change by the phone companies’.
Press
SELECT
.
3.5.2 Choose a calling card to use
If you have more than one calling card, you’ll need to choose one before
making a call.
Press
MENU
4
>
1
>
2
(
Settings
>
Call Settings
>
Calling card
).
Scroll to the desired card and press
OPTIONS
.
Press or to highlight
SELECT
and press
OK
.
The
Security code
field appears.
Enter your security code and press
OK
.
The message
Card ready for use
appears.
3.5.3 Make a calling card call
To make a calling card call:
Enter the phone number, including any prefix (such as 0 or 1) your calling
card might require when you make a calling card call. See your calling card
for instructions.
Press and hold until your phone displays the message
Card call
, then
Wait for tone and press OK
, and then
Wait for tone and press OK
again.
When you hear the tone from your calling card service, press
OK
.
Note: This procedure might not apply to all the calling card options that
are programmed into your phone. Check the back of your calling card
for more information, or contact your long distance company.
3.6 Send your own number in caller ID
You can determine, for each call you make, whether your telephone number
appears on another phone’s caller ID.
In most service areas, when you call others, your name is presented to their caller
ID (if they subscribe). With Send Own Number, you can block (or not) the display
of your number to others’ caller ID when you call them.
Note: Send Own Number might not be available in all wireless systems. Contact
your service provider for details and availability. Also note that this feature
is effective only when you call a number that is equipped with caller ID.
Before you can use Send Own Number, you must first store its feature code.
Otherwise, this feature will not appear on your phone’s menu.
3.6.1 Store the Send Own Number feature code
Press
MENU
4
>
4
>
5
(
Settings
>
Network services
>
Feature Code
Set
).
Then
Feature Code
field appears
Enter the feature code your service provider gave you and press
ENTER
.
Use or to scroll to
Send Own Number
and press
SELECT
.
Scroll to
YES
or
NO
.
Press
SELECT
.
Your phone calls the network to confirm the feature code that you entered in
MENU
4
>
4
>
5
. After the network confirms the feature code, Send Own
Number is activated.
3.6.2 Set whether or not your number will appear
Press
MENU
4
>
4
>
4
(
Settings
>
Network services
>
Send Own
Number
).
Scroll to
YES
or
NO
.
Press
SELECT
.
Enter the number you wish to call, and press
ENTER
.
4. Customize your phone
4.1 What is a profile?
A profile is a “set of settings” you can use to customize the way your phone works.
You can set your own preferences for these items:
Volume
Ring Tone
Message Tone
Ring Style
Vibration
Warning & Game-Tone
Keypad Volume
Your phone comes with seven profiles:
General
Meeting
Outdoor
Silent
Custom
Car
You can customize any of the profiles. If at any time you want to return to the original settings, you can do so.
4.2 Customize a profile
Press
MENU
5
(
Profiles
).
Scroll to the desired profile in the list.
Press
OPTIONS
to view the options for the selected profile.
Select one of the following options, and then press
OK
.
Select
Activates the currently highlighted profile.
Customize
Enables you to customize a profile by changing the current
settings.
Press
SELECT
to choose from several lists.
Rename
Enables you to rename the profile.
4.2.1 Set the ringer volume
You can set the default ringing volume for incoming voice calls and message
alert tones.
Press
MENU
5
(
Profiles
).
Use or to scroll to the profile for which you want to set the
Volume
, and press
OPTIONS
.
Highlight
Customize
and press
OK
.
Scroll to
Volume
and press
SELECT
.
4.2.2 Set the ring tone
You can set your phone’s ring tone to a specific sound-or tune- for incoming
voice calls.
Note: If you have already chosen a ringing option of either Silent or Beep
once, the ring tones are already turned off.
Press
MENU
5
(
Profiles
).
Use or to scroll to the profile for which you want to set the ringing tones.
Press
OPTIONS
.
Highlight
Customize
and press
OK
.
Scroll to
Ring Tone
and press
SELECT
.
Scroll through the options, and, when you hear the tone you want to use, press
SELECT
.
4.2.3 Set the message alert tone
You can set your phone to use a certain tone to indicate an incoming text
message.
Press
MENU
5
(
Profiles
).
Use or to scroll to the profile for which you want to set the message alert tone, and press
OPTIONS
.
Highlight
Customize
and press
SELECT
.
Scroll to
Message Tone
, then press
SELECT
.
Use or to scroll through your choices.
The phone plays samples of each choice as you scroll to it.
When you find the tone you want, press
SELECT
.
4.2.4 Set ring style
You can choose the tone that your phone uses to notify you of an incoming call. This setting does not affect
any incoming text message alert tones.
Press
MENU
5
(
Profiles
).
Your phone lists each profile.
Use or to scroll to the desired profile in the list for which you want to set the
Ring
Style
, and press
OPTIONS
.
Highlight
Customize
and press
OK
.
Scroll to
Ring Style
and press
SELECT
.
Scroll to one of the
Ring Style
, as described below, and press
SELECT
.
Ring
The phone rings until it is answered.
Ring Ascending
Ringing volume increases (gets louder) if the phone is not answered.
One Ring
The phone rings once to indicate an incoming call.
One Beep
The phone beeps once to indicate an incoming call.
Silent
The phone makes no sound.
4.2.5 Set a vibration
Instead of choosing to have your phone ring, you can have it vibrate to indicate an incoming call.
Press
MENU
5
(
Profiles
).
Use or to scroll to the profile for which you want to set the vibration, and press
OPTIONS
.
Highlight
Customize
and press
SELECT
.
Scroll to
Vibration
and press
SELECT
again.
Press the
SELECT
key to switch the
ON
or
OFF
.
The phone does not vibrate when it is connected to or placed in any changing device.
4.2.6 Set warning and game tones
You can set warning tones and the tones used for the games in your phone.
Warning tones include the sounds your phone makes during error conditions, during confirmations, when a
battery is low, and when you need to recharge the battery.
Press
MENU
5
(
Profiles
).
Use or to scroll to the profile for which you want to set the warning tone, and press
OPTIONS
.
Highlight
Customize
and press
SELECT
.
Scroll to
Warn&GameTon
, then press
SELECT
.
Press the
SELECT
key to switch the
ON
or
OFF
.
If you do not want to use warning or game tones, you can turn them off by switching to
OFF
.
4.2.7 Set keypad volume
Keypad volume set the volume of the tone you hear when you press your phone’s keys.
Press
MENU
5
(
Profiles
).
Use or to scroll to the profile for which you want to set the keypad volume, and press
OPTIONS
.
Highlight
Customize
and press
SELECT
.
Scroll to
Keypad Volume
and press
SELECT
.
Use or to scroll to one of the levels and press
SELECT
.
If you chose the
Silent
profile in step , the keypad volume is turned off.
4.3 Rename profiles
Press
MENU
5
(
Profiles
).
Use or to scroll to the desired profile and press
OPTIONS
.
Scroll to
Rename
and press
SELECT
.
Enter the new name and press
OK
again.
4.4 Restore defaults settings
You can change the default settings for your phone. Later, you can return them to the original settings when
needed.
Note: The memory, timers, language selection, security code, and lock code are not reset. However, any profiles
you have modified are reset when you restore the default settings.
Press
MENU
4
>
2
>
7
(
Settings
>
Phone Settings
>
Restore Defaults
).
Press
OK
.
4.5 Set the display language
You can set your phone to display a certain language.
Press
MENU
4
>
2
>
4
(
Settings
>
Phone Settings
>
Languages
).
Use or to scroll to the language you want to use and press
OK
.
You can choose from
English
,
Mexico Spanish
,
Canada French
and
Brazil Portuguese
.
4.6 Set and display the clock
Your phone has an internal clock that you can set to appear on the phone’s screen.
The clock is connected to an alarm clock.
4.6.1 Set the clock
To set the clock to the appropriate time:
Press
MENU
4
>
2
>
1
(
Settings
>
Phone Settings
>
Date and Time
).
Use or to scroll to
Set Time
and press
SELECT
.
The Time field appears.
Enter the time using a
xx:xx
format and press
OK
.
For example, to set your clock to 9:30, enter 09:30.
Use or to scroll to
AM
or
PM
and press
SELECT
.
4.6.2 Set the clock to be updated by the network
You can set your phone’s clock to be updated by the network, if available.
Turn on the network date and time update
Press
MENU
4
>
2
>
3
(
Settings
>
Phone Settings
>
AutoDate & Time
), and then
press
SELECT
.
Scroll to
ON
or
Confirm
, and then press
SELECT
.
If you choose
Confirm
, you will receive the message
Really Update date and time?
Before
the phone’s clock is updated. Select
OK
to accept the update or
CANCEL
to reject it.
Turn off the network date and time update
Press
MENU
4
>
2
>
3
(
Settings
>
Phone Settings
>
AutoDate & Time
), and then
press
SELECT
.
Scroll to
OFF
, and then press
SELECT
.
4.7 Add a welcome note
You can set your phone to display a welcome note each time you switch on your
phone. This note could say, for example: Hello. It could include your name, a
reminder, or more. The maximum lengths of this note 20 characters.
Press
MENU
4
>
2
>
5
(
Settings
>
Phone Settings
>
Welcome
).
Enter the text of the welcome note.
As you enter characters, they appear to the left of the cursor. Press
CLEAR
to delete characters to the left
of the cursor. Press or to move the cursor right or left.
Press
ENTER
.
4.8 Set the answer
4.8.1 Set your phone to answer automatically
You can set your phone to answer incoming voice calls after one ring. This feature can be used only when
your phone is connected to a headset or to an approved handsfree car kit that is equipped with the ignition
sense option, with the ignition on.
Press
MENU
4
>
3
>
1
(
Settings
>
Answer Settings
>
Auto Answer
).
Scroll to
Auto Answer
and press
SELECT
.
Use or to scroll to the phone setting for which you want to set your phone to answer
automatically, and press
SELECT
.
4.8.2 Set your phone to answer by pressing any key
This feature allows you to answer an incoming call by pressing any key except the END key. The default
setting for this feature is OFF.
To enable Any Key answer:
Press
MENU
4
>
3
>
2
(
Settings
>
Answer Settings
>
Any Key Answer
).
Press
ON
.
Repeat the steps above except, in step , press
OFF
.
4.9 Emergency calls
Before attempting any emergency calls, see “18.1 Emergency Calls” for important
safety information.
If the phone is not on, switch it on
Press the key to ready the phone for calls.
(Press it twice if there are still digits on the display.)
Key in the emergency number for your present location (e.g. 911 or other
official emergency number). Emergency numbers vary by location.
Press .
IMPORTANT!
This phone, like any cellular phone, operates using radio signals, cellular and
landline networks, as well as user-programmed functions which can not guarantee
connection in all conditions. Therefore, you should never rely solely upon any
cellular phone for essential communications (e.g., medical emergencies).
Remember, to make or receive any calls, the phone must be switched on and in a
service area with adequate cellular signal strength.
Emergency calls may not be possible on all cellular phone networks or when
certain network services and/or phone features are in use. Check with local
cellular service providers.
If certain features are in use (keyguard, restrict calls, etc.), you may first need to
turn those features off before you can make an emergency call. Consult this
document and your local cellular service provider.
When making an emergency call, remember to give all the necessary information
as accurately as possible. Remember that your cellular phone may be the only
means of communication at the scene of an accident - do not cut off the call until
given permission to do so.
4.10 Use emergency key 9
When the emergency key feature is turned on, the phone attempts to make an
emergency call when you press 9 and . The phone dials the emergency
number preprogrammed into your phone.
Note: If you have activated the emergency key 9 feature, you can also dial an
emergency call by pressing and holding 9 until the phone indicates it is
attempting to make an emergency call. This method does not work,
however, when Keyguard is active.
4.10.1 Activate the emergency key 9
Before you can use the emergency key feature, you must first activate it.
Press
MENU
4
>
1
>
1
(
Settings
>
Call Settings
>
Emergency Key 9
).
Press
ON
.
Repeat the steps above except, in step , press
OFF
.
Warning: Official emergency numbers vary by location. Only one emergency
number is programmed into your phone, and this is the number
that is dialed when you press key 9. However, this might not be the
proper number in all circumstances.
4.10.2 Make an emergency call
Press
9
and .
5. Security
Your phone is equipped with a versatile security system that prevents the
unauthorized use of the phone.
You cannot activate or use certain phone features without having first successfully entered your phone’s security code.
When entering the security code, a * appears on the screen each time you press a number key. This prevents others from
seeing your code.
If you incorrectly enter a security code five times in a row, your phone won’t accept any entries for the next 5 minutes.
However, if you realize that you’ve entered the code incorrectly before pressing
OK
, you can use
CLEAR
to erase
the code, digit by digit, beginning with the last digit.
When this guide describes an action that requires the entry of your security code, each step necessary to this action is
provided.
5.1 Change your security code
Press
MENU
4
>
5
>
2
>
4
(
Settings
>
Security Settings
>
Access Codes
>
Change
Sec Code
).
The Security code field appears.
Enter the default security code and press
ENTER
.
At the message
New Secu Code
, enter your new security code and press
ENTER
.
At the message
Verify Secu Code
, enter your new security code again and press
ENTER
.
The message
Security Code has been changed
appears.
If you have changed your security code and don’t remember the new code, contact your service provider. Once you
have changed your security code, the default setting is no longer valid.
5.2 Protect your phone with the lock code
The lock code enables you to activate and deactivate your phone. When the lock code is on, you cannot access most
of your phone’s memory or menu features. Also, you cannot make phone calls without first entering the lock code.
Note: If you save the unlocked phone number, you can make calls without entering the lock code. Refer to “Store
an unlocked phone number”.
With the lock code on, your phone locks when you switch it off. The next time you switch your phone on, it asks
you for a lock code when you press either
NAMES
or
MENU
.
Note: If you enter an incorrect lock code five times in a row, your phone prompts you for the security code.
The default lock code is 12345.
MTD-3500 recommends that you change this code immediately.
5.2.1 Turn on the phone lock
Press
MENU
4
>
5
>
2
>
1
(
Settings
>
Security Settings
>
Access Code
>
Phone
Lock
).
Enter the lock code and press
ENTER
.
When your phone is locked, it will be possible to place a call to the emergency number programmed into
your phone, such as 911 or any other official emergency number. You can either dial this emergency number
or press the emergency key 9 (if you have activated the 9 key to act as an emergency key).
You can also store a number in the Unlocked phone number location. This allows you to call the number
even though your phone is locked.
5.2.2 Store an unlocked phone number
Press
MENU
4
>
5
>
2
>
2
(
Settings
>
Security Settings
>
Access Code
>
Unlock
Phone No.
).
Enter the lock code and press
ENTER
.
The
Enter Unlock Num
field appears.
Enter the unlock code and press
ENTER
.
Press
OK
.
5.2.3 Change your lock code
Press
MENU
4
>
5
>
2
>
3
(
Settings
>
Security Settings
>
Access Code
>
Change
Lock Code
).
Enter the lock code and press
ENTER
.
Only numeric characters are accepted.
Enter the new lock code and press
ENTER
.
Verify the new lock code, and press
ENTER
.
When you change your lock code, make sure you store it in a safe place, away form your phone. Avoid
entering access codes similar to emergency number to prevent accidental emergency calls.
5.2.4 Turn off the lock code
Press
MENU
4
>
5
>
2
>
1
(
Settings
>
Security Settings
>
Access Code
>
Phone
Lock
).
Enter the lock code and press
ENTER
.
With the lock code feature turned off, you can use your phone without having to enter the lock code each
time you turn your phone on.
5.3 Lock the keypad
When you lock the keypad, you prevent accidental key pressesfor example, when
your phone is in a pocket or purse. This feature is called keyguard.
5.3.1 Active keyguard
There are three different ways to activate the keyguard:
At the Start screen:
Press
MENU
0
(
Keyguard
).
5.3.2 Deactivate keyguard
Press
UNLOCK
.
Press .
5.3.3 Answer a call while keyguard is active
During an incoming call, the keypad automatically unlocks.
Press any key to answer the call.
After you end the call, keyguard automatically becomes active again.
5.4 Restrict calls
You can restrict incoming and outgoing calls. To restrict outgoing calls, you create a list of restrictions and apply
the appropriate restriction.
Before you define restrictions for outgoing calls, only one restriction option is
available:
Add restriction
, which enables you to create your own list of outgoing call restrictions. The maximum
number of call restrictions you can define is ten.
Delete
Delete any existing outgoing call restriction.
Delete All
Delete all existing outgoing call restriction.
Edit
Allows you to edit an existing outgoing call restriction.
Restrict All
Allows you to activate all outgoing call restrictions.
When calls are restricted, you will be able to make calls to the emergency number that is programmed into your
phone. For example, you could dial 911 and press . However, emergency key 9 might not work, depending
on the type of restriction you choose.
5.4.1 Restrict incoming calls
To restrict incoming calls:
Press
MENU
4
>
5
>
1
(
Settings
>
Security Settings
>
Call Restriction
).
Use or to scroll to
Incoming
and press
SELECT
.
Enter your security code and press
ENTER
.
Scroll to
Restrict All
and press
ON
.
Press
OFF
to remove an already-set restriction.
5.4.2 Restrict outgoing calls
Press
MENU
4
>
5
>
1
(
Settings
>
Security Settings
>
Call Restriction
).
Use or to scroll to
Outgoing
and press
SELECT
.
Enter your security code and press
SELECT
.
Press
OPTIONS
.
Scroll to
Add Restriction
and press
SELECT
.
Enter the number you want to restrict and press
ENTER
.
6. Set network services features
The following network services can be obtained from your service provider:
Voice Privacy
Call Forwarding
Call Waiting
Send Own Number
When you subscribe to any of these services, your service provider gives you a
feature code that activates each service. Deactivation codes are used to deactivate
each service.
After you store the appropriate code in your phone, the code is sent to the network to verify that you’re using the correct
feature code. The voice privacy feature does not require you to store a feature code before using it.
After you store a feature code, the respective service appears as a menu option on your phone’s screen. You can use
these menus to activate and deactivate the network services.
6.1 Set up how your phone selects a system
Your phone is capable of working in residential, private, and public systems (such
as your home system). You can choose how your phone selects a network to use.
Press
MENU
6
.
You see the following three options:
Automatic
: Your phone automatically searches for available networks and
chooses the appropriate one. Every time you turn on your phone, it resets to
Automatic
.
Manual
: The phone searches for networks and then displays a listing of all of
the possible networks on your phone’s screen. Next to each network, one of
the following appears:
Available
or
Not available
. If a network is
designated as
Not available
, you cannot use it.
New Search
: Your phone begins a new search for both private and residential
systems. When it finds the best system available, your phone displays it on its
screen. You can then select this system or start another search by pressing
NEXT
.
Use or to scroll through the choices, and press
SELECT
when you
see the one you want.
6.2 Roaming
The term roaming is used to indicate when your phone is not in its home area. Calls made or received while you
are roaming are usually more expensive than calls made in your home area.
While roaming in some systems outside your home area, your phone may not be recognized by the host system,
which is the system in which you’re traveling. You may not be able to place a call.
Contact your service provider for more specific information on how roaming works with your phone and for
information about coverage limitations.
6.3 NAM selection
The service provider programs your phone with the phone number and system information into your phone’s
memory when your phone is first activated. This is called a Number Assignment Module (NAM).
For example, your phone can be activated in up to 2 different service areas (e.g. one in Chicago or New York, and
maybe one more in New York), each giving your phone a different phone number or account.
Only one number can be active at a time. When you select a phone number, you’re also selecting which system
you’re using as your home system. The first phone number displayed with this menu is the currently selected
number.
Note: It may not be necessary to have three NAMs for your phone if your service provider has service or roaming
agreements for each area in which you wish to use your phone. Contact your service provider for details.
6.3.1 Selecting the NAM for your phone
Press
MENU
4
>
4
>
6
(
Settings
>
Network Services
>
NAM Selection
)
Highlight the phone number you want to use and press
OK
.
Note: You need at least one active number to make calls. You cannot change from one NAM to another
during a call.
7. USE YOUR PERSONAL ASSISTANT
Your phone can be your personal assistant. It can wake you up in the morning and
remind you of meetings, birthdays, and tasks. You can check the current time,
calculate a tip at dinner, and convert currencies.
With a calendar, clock, alarm clock, and phone book, you have everything you need to
keep track of your life.
7.1 Use the calendar
The calendar application allows you to enter appointments
and reminders into the phone.
Your phone must be switched on for the calendar to work. Do
not switch on the phone, however, where wireless phone use
is prohibited or where the use of the phone could cause interference or danger.
7.1.1 View the calendar
Press
MENU
>
7
(
Calendar
).
Press
SELECT
.
Today’s day and date appear.
Press
SELECT
.
You can select the Current day’s notes or all notes list.
If you select the
Current Day Select
, you can view the notes of the day currently on display.
If you select the
All List View
, you can view the all notes of the entire calendar.
7.1.2 Move from day to day
After you set the date, whenever you press Menu 7, your phone displays the current date and day.
To move forward or backward through the calendar, use or .
When you reach the date you want, press
SELECT
and scroll to highlight the select you want.
7.1.3 Add a calendar note
This option enables you to add a note. You can also set an alarm for any calendar note.
Go to the day you want, then press
SELECT
.
The list of note appears.
Press
ADD
.
The
NOTE:
field appears.
Enter the information and press
ENTER
.
The current date appears.
If you do not want to change the date, just press
OK
.
The
Time:
field appears.
If you want to change the date for this note, do so and press
OK
.
Enter the time when you need to make this call using the hh:mm format and press
OK
. Select
AM
or
PM
and press
SELECT
.
Select either
No Alarm
or
Set Alarm
and press
SELECT
.
If you don’t want to set an alarm, select
No Alarm
.
If you select
Set Alarm
, the alarm date field appears.
Enter the date on which you want the alarm to sound and press
OK
.
The alarm time field appears.
Enter the time at which you want the alarm to sound using the hh:mm format and press
OK
.
Select either
AM
or
PM
and press
SELECT
.
7.1.4 View the day’s notes
You can review notes you’ve written for certain days.
To review notes for a certain day, open the calendar and scroll to the day you want.
Press
SELECT
, scroll to note list and press
SELECT
.
The following options are available:
Details
Add Entry
Edit Entry
Delete Entry
Delete All For Day
Delete All Entries
7.2 Alarm clock
You can set the alarm clock to ring at any time. The alarm clock’s volume is
determined by the current ringing volume and tone settings.
If you have selected the
Silent
or
One Beep
ringing tone, then your alarm
clock quietly beeps once.
7.2.1 Set the alarm clock
Press
MENU
4
>
2
>
2
(
Settings
>
Phone settings
>
Set Alarm Clock
).
The Set alarm clock message appears.
Enter the time for which you want to set the alarm using the hh:mm format and press
OK
.
Any existing numbers are replaced with the newly entered numbers.
Select either
AM
or
PM
and press
SELECT
.
7.2.2 Turn off the alarm clock when it rings
When the alarm clock rings:
Press
OK
to turn it off.
Press
SNOOZE
to set the alarm to go off again in 5 minutes.
If you let the alarm ring for 1 minute or more without pressing a key, it
stops ringing, waits 5 minutes, and then rings again. This continues until
you press Stop.
7.2.3 Turn off the alarm clock altogether
If you decide that you don’t want the alarm to ever go off, you can turn it completely off.
Press
MENU
4
>
2
>
2
(
Settings
>
Phone settings
>
Set Alarm Clock
).
Press
OFF
.
If you have selected the
Silent
or
Meeting
profile, your alarm beeps only once. The best profile to use
when using the alarm clock is
General
or
Outdoor
, unless these profiles have been modified from their
original settings.
7.3 Calculator
Your phone’s calculator adds, subtracts, multiplies, divides, and converts
currencies.
7.3.1 Use the calculator
Press
MENU
8
(
Calculator
).
Enter the first number in the calculation.
If you need to enter a number with a decimal point, press to indicate it.
Then, based on the type of calculation that you need to perform, use one of the following actions:
If you want to… Then…
Add
Press * (for + symbol)
Subtract
Press ** twice (for – symbol)
Multiply
Press *** (for * symbol)
Divide
Press **** (for / symbol)
Or, you can press Options, then use or to scroll to:
Equals
,
Add
,
Subtract
,
Multiply
,
Divide
, or
Exit
. Then press
SELECT
.
Enter the second number in the calculation and press
Options
.
Use or to scroll to
Equals
and press
SELECT
.
Note: Repeat steps and as many times as necessary.
Press
Clear
to erase any mistakes.
8. GAMES
You phone includes for exciting games that you can play whenever the phone is
turned on:
Breakout
Snake
Press
MENU
9
(
Games
) to display the listing of these games.
Use or to scroll to the game you want to play and press
SELECT
.
8.1 Snake
This game places an object, which represents a piece of food, in the middle of the
screen. At the bottom of the screen is a line that represents the snake.
Use the following keys as cursors: 2 (up), 4 (left), 6 (right), and 8 (down).
Move the snake toward the food and watch the snake grow.
The longer the snake’s tail grows, the higher the score. If the snake hits its own
tail or the surrounding wall, the game is over.
8.2 Breakout
This game places an object, which represents a ball, in the middle of the screen.
At the right of the screen are the blocks. At the left of the screen is a bar.
Use the following keys as cursors to move the bar: (down), (up)
Bounce the ball using bar, and break the block.
The more blocks are broken, the higher the score. If the ball hits the left wall
instead of the bar, the game is over.
9. REFERENCE INFORMATION
9.1 Emergency Calls
IMPORTANT!
This phone, like any wireless phone, operates using radio signals, wireless and
landline networks, and user-programmed functions. Because of this, connections
in all conditions cannot be guaranteed. Therefore, you should never rely solely on
any wireless phone for essential communications (e.g. medical emergencies).
Remember, to make or receive any calls, the phone must be switched on and be
used in a service area that has adequate signal strength. Emergency calls might
not be possible on all wireless phone networks or when certain network services
and/or phone features are in use. Check with local service providers.
Always ensure that your phone is properly charged before attempting any
emergency calls. If you allow your battery to become empty, you will be unable to
receive or make calls, including emergency calls. You must then wait a few
minutes after the charging begins to place any emergency calls.
9.1.1 Make an emergency call
If the phone is not on, switch it on.
Enter the emergency number for your present location (for example, 911 or
any other official emergency number—emergency numbers vary by
location).
Press .
If certain features are in use (Keyguard, fixed dialing, restrict calls, and so
on), you might first need to turn those features off before you can make an
emergency call. Consult this guide and your local cellular service provider.
When making an emergency call, remember to give all of the necessary
information as accurately as possible. Remember that your wireless phone
might be the only means of communication at the scene of an accident—do
not terminate the call until given permission to do so.
9.2 Troubleshooting
9.2.1 No service
If you’re outside the wireless service area, No service will display on your
phone. No calls can be made or received, however, emergency 911 calls may
still be possible.
9.2.2 What if the call doesn’t go through?
Your phone can make and receive calls only when it’s switched on and in the
wireless network’s service area.
No service
means that you’re probably outside the wireless service area. No
calls can be made or received.
This number is restricted.
means calls to the phone number you tried to
call are restricted (see “Restrict calls”).
10. TECHNICAL INFORMATION
Weight 84.0g with 790 mAh
Li–ion Battery
Size (H x W x D) 112.0 x 45.6 x 21.4 mm
Wireless Networks TDMA800
AMPS
Frequency Range 824.04-848.97 MHz (TX)
869.04-893.97 MHz (RX)
Battery Voltage 3.7V nominal
Number of
Channels 832
Number of NAMs 2
Memory Locations 100
Memory Capacity Alpha: 15 digits per location
Numeric: 32 digits per location
