The Genie a Division of Overhead Door ACSCT1 Garage Door Opener Transmitter User Manual 2 Page 1
The Genie Company a Division of Overhead Door Corporation Garage Door Opener Transmitter 2 Page 1
User Manual
![](/img.php?id=123191&img=bg1.png)
3 4
Battery and Holder
Blue
Buttons
!
Moving Door or Gate can cause
serious injury or death
• Do Not program Remote Control unless the
Door Safety Reverse works as described in
Operator’s Manual.
• Keep people clear of opening while Door
is moving.
• Do Not allow children to play with the Remote
Control, or Door Operator.
If Safety Reverse does not work properly:
• This Remote Controller WILL NOT WORK.
• Disconnect Operator using Manual Release.
• Do Not use Remote Control, or Door Operator.
• Refer to Operator Owner’s Manual before
attempting any repairs.
Button assignments can be mixed and matched any way
you wish.
For example,
button #1 used for
INTELLICODE
2
®
,
button #2 used for INTELLICODE
®
,
button #3 (if applicable) used for
INTELLICODE
2
®.
Simply follow the steps of the appropriate section for
each individual button.
1. On your Remote Controller—Press and hold any two
buttons from 5 — 30 seconds, (the green light will come on
when the buttons are pressed and will begin blinking after 2
seconds)(repeating one blink—pause). Your random access
code is set depending on how long you hold the buttons. Fig. 1.
Release the buttons, (the green light will continue to blink).
NOTE: Programming can only be done while the green light
is blinking.
NOTE: The Green Light (LED) also indicates the strength of the
battery. It will get dimmer as the battery gets weaker. When the
Light no longer comes on, you will have several operation
cycles remaining, but be aware you will need to replace the
battery soon. The expected life of the ENERGIZER CR2032
Lithium/Manganese Dioxide Battery is at least 5 years.
2. On your Remote Controller—Press any one button, (the
green light will go out.
3. On your Door Operator—Locate the Learn Code Button.
(Refer to your Owner’s Manual.)
4. On your Door Operator—Press the Learn Code Button, (the
Learn Code Light will begin blinking twice each second).
5. On your Remote Controller—Press the button you wish to
use for controlling the first door operator, (the Learn Code
Light will stay on, no blinking).
Press the same button again, (the Learn Code Light will
go out).
Press the same button again, (the door should operate).
6. Repeat Steps 3 — 5 for any additional
INTELLICODE
2
®
equipped door operator you wish to control with this Remote.
NOTE: Once programming is complete, it cannot be changed
simply by pressing a button or combination of buttons. This
helps prevent accidental disabling of your Remote Controller.
If you need to reprogram your remote for any reason, see
“REPROGRAMMING” Section on back.
3400000000
1
2
Green
Light Screw
INTELLICODE
2
Section
Remote
Controller
w
/
WARNING
Catch
Your new
INTELLICODE
2
®
Remote Controller
is equipped to operate both the latest
INTELLICODE
2
®
Garage Door Operators and
all previous models built with INTELLICODE
®
.
Look on your Garage Door Operator for the
INTELLICODE
2
®
label.
If you have a
INTELLICODE
2
®
unit, follow the
steps in the “
INTELLICODE
2
” Section below.
If you have a previous style INTELLICODE
®
unit,
follow the steps in the “INTELLICODE” Section
on back.
![](/img.php?id=123191&img=bg2.png)
1. On your Remote Controller—Press and hold any two
buttons from 5 — 30 seconds, (the green light will come on
when the buttons are pressed and will begin blinking after 2
seconds)(repeating one blink—pause). Your random access
code is set depending on how long you hold the buttons.
Release the buttons, (the green light will continue to blink).
NOTE: Programming can only be done while the green light is
blinking.
2. On your Remote Controller—Press the same two buttons
and hold until after the Green Light begins blinking, (the
green light will come on and stay on as the buttons are
held down, and after 2 seconds will begin blinking, repeating
2 blinks—pause).
3. On your Remote Controller—Press the button you wish to
use to control the door operator. (The green light will
continue blinking as you hold down the button). Release the
button, (the green light will go out).
Repeat Step 3 for each button that will be assigned to a
previous style INTELLICODE®Operator.
4. On your Door Operator—Locate the Learn Code Button.
(Refer to your Owner’s Manual.)
5. On your Door Operator—Press the Learn Code Button, (the
Learn Code Light will begin blinking twice each second).
6. On your Remote Controller—Press the button you wish to
use for controlling the first door operator, (the Learn Code
Light will stay on, no blinking).
Press the same button again, (the Learn Code Light will
go out).
Press the same button again, (the door should operate).
7. Repeat Steps 4 —6 for any additional INTELLICODE®
equipped door operator you wish to control with this
Remote.
NOTE: Once programming is complete, it cannot be changed
simply by pressing a button or combination of buttons. This
helps prevent accidental disabling of your Remote Controller.
If you need to reprogram your remote for any reason, see
“REPROGRAMMING” Section.
If, during the first few weeks of operation, you wish to
reprogram your Remote for any reason, simply follow the
initial programming procedure again.
If you attempt reprogramming at some point long after initial
programming (usually beyond 3 weeks), when you press the
two buttons in Step 1 you may see an immediate rapid
flashing of the Green Light. Your Remote has considered the
initial program as permanent and is protecting against
unauthorized attempts to change your code. You Must then:
1. Remove the Battery, and with the battery removed,
2. Press and hold one of the blue buttons on the circuit board
for 1 or 2 seconds. (This insures all power is drained from
the circuit.)
Fig. 5.
3. Replace the battery.
4. Begin programming as before.
1. Slide the visor Clip off the back of the Remote and remove
the small screw.
2. With a thin flat object (the visor clip works well) push in on
the catch located in the small notch at the base of the
Remote. This releases the hinged section of the case.
Fig. 2.
3. Holding the Top half of the case in one hand, and the hinged
section in the other, gently pull the two halves apart.
Fig. 3.
4. Flip the hinged section out of the way and slide the battery
out of its holder.
Fig. 4.
5. Using a new ENERGIZER CR2032 Long Life
Lithium/Manganese Dioxide Battery, reverse the process.
WARNING
Always keep batteries out of the reach of children. They
pose an extreme internal health hazard. If swallowed
contact a physician immediately.
CAUTION
Be sure to comply with Local and Federal Regulations
Concerning the disposal of Lithium/Manganese
Dioxide Batteries.
FCC Certified
This device complies with FCC Part 15 of the FCC Rules. Operation
is subject to the following conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.
Certificado por la FCC
Este dispositivo cumple con las normas de la FCC (Comisión Federal
de Comunicaciones), Parte 15 de Dominio de FCC. La operación esté
sujeta a las dos condiciones siguientes: (1) Este dispositivo puede no
causar interferencia dañina, y (2) este dispositivo debe aceptar
cualquier interferencia, incluyendo la interferencia que pueda causar la
operación indeseable.
Los cambios o modificaciones no aprobados expresamente por el
fabricante pueden invalidar la autoridad del usuario de operar el equipo
Certifié conforme à la réglementation FCC
Ce dispositif est conforme aux normes FCC section 15 de Ordonnance
de FCC. Son fonctionnement est soumis aux deux conditions suivantes
: (1) Il ne doit pas causer une interférence dangereuse et (2) ce
dispositif doit accepter toute interférence y compris l’interférence qui
peut causer le fonctionnement non désiré.
Les changements ou les modifications non approuvés expressément
par le fabricant peuvent annuler l’autorisation del’utilisateur à actionner
l’équipement.
BATTERY REPLACEMENT
INTELLICODE Section
REPROGRAMMING
BATTERY STORAGE & HANDLING
