The Kroger SZG4HDMI1 G4 Zooter ZigBee HDMI Display Unit User Manual G2Z CAP User Guide
The Kroger Co. G4 Zooter ZigBee HDMI Display Unit G2Z CAP User Guide
User Manual
G4HDMI1
User Guide
G4HDMI1 User Guide
Page 2
The Kroger Co.
Release 1.0
Version 1.1
Copyright © 2010, The Kroger Co. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without prior written permission from The Kroger Co.
All copyright, confidential information, patents, design rights and all other intellectual property
rights of whatsoever nature contained herein are and shall remain the sole and exclusive
property of The Kroger Co. The information furnished herein is believed to be accurate and
reliable. However, no responsibility is assumed by The Kroger Co. for its use, or for any
infringements of patents or other rights of third parties resulting from its use.
The Kroger Co. name and The Kroger Co. logo are trademarks or registered trademarks of The
Kroger Co. All other trademarks are the property of their respective owners.
G4HDMI1 User Guide
Page 3
Table of Content
1 INTRODUCTION .................................................................................................................5
2 G4HDMI1 SPECIFICATIONS................................................................................................6
PROCESSING ............................................................................................................................... 6
NETWORK CONNECTIONS .............................................................................................................. 6
POWER ...................................................................................................................................... 6
CUSTOMER APPLICATIONS ............................................................................................................. 6
FIRMWARE UPDATES .................................................................................................................... 6
OPERATING CONDITIONS ............................................................................................................... 6
DIMENSIONS ............................................................................................................................... 6
APPROVALS ................................................................................................................................ 6
INCLUDED ACCESSORIES ................................................................................................................ 7
SAFETY PRECAUTIONS .............................................................................................................. 7
ELECTROSTATIC DISCHARGE ...................................................................................................... 7
3 POWER REQUIREMENTS ...................................................................................................8
4 INTERFACE DETAILS ..........................................................................................................9
RS232 INTERFACE: ...................................................................................................................... 9
ZIGBEE INTERFACE: ...................................................................................................................... 9
5 FCC COMPLIANCE STATEMENTS .....................................................................................10
6 OPERATIONAL INSTRUCTION ..........................................................................................10
Tables
Table 1: RJ45 Connector Pin Assignment: 8
G4HDMI1 User Guide
Page 4
Revision History
Date
Change Description
Revision
26-DEC-17
Initial Revision
0.1
28-DEC-17
Sent for Kroger Review
0.2
25-JAN-18
Sent to TUV
0.3
G4HDMI1 User Guide
Page 5
1 Introduction
G4HDMI1 is a POE+ powered device ZigBee Access Point and support Display on HDMI enabled
screen.
Benefits
Supports time synchronization with a Network Time Protocol (NTP) server.
Access point for Zigbee Infrastructure.
Firmware update via LAN
Supports display over HDMI
G4HDMI1 User Guide
Page 6
2 G4HDMI1 Specifications
Processing
1Ghz Single Core SoC
Upto 512MB DDR3 RAM
256MB NAND FLASH
On-Board ZigBee Modules (4 Nos)
RS232 Interface
HDMI Interface
Linux Kernel 2.6.37
Network Connections
10/100/1000 Mbps Ethernet
Power
Input Voltage: 48-57VDC (POE+)
Input Current: 0.2A
Customer Applications
HDMI Display
Firmware Updates
Firmware updates over the LAN network
Operating Conditions
Temperature: 5 to 40º C (41 to 104 ºF)
Humidity: 20 to 80% RHG
Indoor use only (Industrial/Commercial Environment)
Dimensions
Height: 30 mm
Width: 179 mm
Depth: 179 mm
Approvals
EMI
o FCC
Safety
o UL
G4HDMI1 User Guide
Page 7
Included Accessories
Adjustable ceiling mount supporting tile mount, through ceiling mount and tear drop
installations.
Safety Precautions
Below is safety precaution that should be observed when installing device.
Electrostatic Discharge
The device will be installed over ceiling, there will not threat of ESD during normal operation.
The ESD threat will be further reduced due to plastic casing.
The installation of the device will be done through trained person. The person should take care
of ESD precautions while installing device.
G4HDMI1 User Guide
Page 8
3 Power Requirements
The G4HDMI1 can be powered through POE+ Adapter or POE+ Switch through RJ-45 Ethernet
connector. Being 802.3at compliant device, G4HDMI1 would draw 10W (< 25.5W as per POE+
standard) power from POE+ source.
The POE+ Adapter/Switch is not part standard packaging. The standard 802.3at Compliant,
FCC/CE/UL certified off-the-shelf devices should be used to avoid interference issues to
G4HDMI1.
If multiple G4HDMI1 will be powered from single multiport Ethernet switch, proper power
rating should be selected to meet individual power requirements of G4HDMI1.
Specifications for suitable POE+ Injector or Switch are as follows:
o Input Voltages: 90–264 VAC, 50-60Hz
o Output Voltage (Typ): 48-57 VDC
o Output Current: 0.6A per Port
o Power: 25.5W per Port
POE Injector/Switch
RJ45
RJ45Host Computer
90-264VAC G4ZHDMI1
RJ45
CAT5
CAT5
Standard
Source
Voltage
RJ45 Pin Number
1
2
3
4
5
6
7
8
IEEE 802.3at
using Spare
Data pairs
48-56VDC
TX+
TX-
RX+
DC+
DC+
RX-
DC-
DC-
Table 1: RJ45 Connector Pin Assignment
G4HDMI1 User Guide
Page 9
4 Interface Details
G4HDMI1 Device provides RJ45 interface for Network connectivity. It also provides HDMI
interface s output to an HDMI enabled display. The Ethernet interface and HDMI are the only
available interface to the outside world. Apart from RJ45 and HDMI, G4HDMI1 provides ZigBee
wireless connectivity through on-board ZigBee modules.
Note that The HDMI display is not part standard packaging. The standard HDMI 1.3 or above
Compliant, FCC/CE/UL certified off-the-shelf devices should be used to avoid interference issues
to G4HDMI1.
Interfaces available on-board G4HDMI1:
RS232 Interface:
On Board RS232 interface is not accessible from outside enclosure.
ZigBee Interface:
G4HDMI1 has 4 ZigBee modules for wireless connectivity.
G4HDMI1 User Guide
Page 10
5 FCC Compliance Statements
FCC ID: PBR-SZG4HDMI1
FCC compliance statements
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including Interference that may
cause undesired operation
FCC Caution!!!
Any changes or modifications not expressly approved by the party Responsible for
compliance could void the user's authority to operate this Equipment
This equipment should be installed and operated with minimum distance 20 cm
between the radiator & your body.
Part 15B compliance statements for digital devices:
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
6 Operational Instruction
For G4HDMI1 operational instruction, please contact Vendor/Manufacturer for latest updated
instruction guide.
