The Watt Stopper d b a Qmotion ZIG24DECO Zigbee 2.4 Deco Remote User Manual 15 0094 Exhibit Cover
Qmotion Incorporated Zigbee 2.4 Deco Remote 15 0094 Exhibit Cover
Manual
5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598
Certification Exhibit
FCC ID: 2ABLX-ZIG24DECO
IC: 8832A-ZIG24DECO
FCC Rule Part: 15.247
IC Radio Standards Specification: RSS-210
ACS Project Number: 15-0094
Manufacturer: Qmotion Incorporated
Model: QZR-ZIG2400
PRELIMINARY
FCC COMPLIANCE
Warning: Changes or modifications to this device
not expressly approved by Qmotion™ Incorporated
could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and the receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,
AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
RF EXPOSURE
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled
environment. This equipment is in direct contact with the body of
the user under normal operating
conditions. This transmitter must not be co-located or operating in
conjunction with any other
antenna or transmitter.
IMPORTANT
Read and understand all instructions before installing. Always wear
personal protection equipment including safety glasses and gloves.
Use a ladder per its manufacturer’s instructions. Work safely!
QADVANCED USER GUIDE
QMOTION ZIGBEE 2.4 DECO REMOTE
PARTS
The ZigBee 2.4 Deco Remote is used to control ZigBee
window coverings. In order to use the remote it must
first be joined into the ZigBee network through a ZigBee
compliant router (sold separately), in addition to the window
coverings. Window coverings or treatments may be any one
or a combination of Venetian vertical or horizontal blinds,
roller shades, roman shades, cellular or honeycomb blinds,
drapes, transitional blinds, etc.
To join your Qmotion ZigBee window coverings to the ZigBee
network follow the manufacturer’s instruction on the router
and Qmotion’s procedures for the remote and window
coverings. Once the remote and window treatments are
joined you will now be able to operate the devices.
Channel Button
Varriable
Position
Butttons
Channel/Mode Reverse Side
Mode Select Button
Up/Down
Buttons
INDUSTRY CANADA COMPLIANCE
Under Industry Canada regulations, this radio transmitter may
only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary for successful
communication. Conformément à la réglementation d’Industrie
Canada, le présent émetteur radio peut fonctionner avec une
antenne d’un type et d’un gain maximal (ou inférieur) approuvé pour
l’émetteur par Industrie Canada. Dans le but de réduire les risques
de brouillage radioélectrique à l’intention des autres utilisateurs, il
faut choisir le type d’antenne et son gain de sorte que la puissance
isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l’intensité
nécessaire à l’établissement d’une communication satisfaisante.
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may
cause undesired operation of the device. Le présent appareil
est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil
ne doit pas produire de brouillage, et (2) l’utilisateur de
l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le
fonctionnement
