Thomson FH58R19 5.8GHz Cordless Telephone - Base Unit User Manual 21091 DOM IB E 0

Thomson Inc. 5.8GHz Cordless Telephone - Base Unit 21091 DOM IB E 0

Users Manual

We bring good things to life.
5.8 GHz Digital Cordless Handsfree
Handset /Answering System
with Call Waiting Caller ID
User’s Guide
25825/26
2
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
EQUIPMENT APPROVAL INFORMATION
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance with parts 15 and 68, FCC
Rules and Regulations and the Technical Requirements for Telephone Terminal Equipment published by ACTA.
1Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and Ringer Equivalence Number (REN) for the
equipment. You must, upon request, provide this information to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still have all of these devices ring
when your telephone number is called. In most (but not all) areas, the sum of the RENs of all devices connected to one line should not
exceed 5. To be certain of the number of devices you may connect to your line as determined by the REN, you should contact your local
telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part
68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is
designed to be connected to a compatible modular jack that is also compliant. See installation instructions for details.
Notes
•This equipment may not be used on coin service provided by the telephone company.
•Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if you are on a party
line. Check with your local telephone company.
•Notice must be given to the telephone company upon permanent disconnection of your telephone from your line.
•If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this product does not
disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a
qualified installer.
2Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone company shall, where practicable, notify
you that temporary discontinuance of service may be required. Where prior notice is not practicable and the circumstances warrant such action,
the telephone company may temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone company must:
(1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to correct the situation; and (3) inform you of your right to
bring a complaint to the Commission pursuant to procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or procedures where such action is required in
the operation of its business and not inconsistent with FCC Rules and Regulations. If these changes are expected to affect the use or performance
of your telephone equipment, the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference; and (2) This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving” the interference).
•Reorient or relocate and increase the separation between the telecommunications equipment and receiving antenna.
•Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television technician for additional
suggestions. Also, the Federal Communications Commission has prepared a helpful booklet, “How To Identify and Resolve Radio/TV Interference
Problems.” This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify stock number 004-000-
00345-4 when ordering copies.
FCC RF RADIATION EXPOSURE STATEMENT
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with the belt clip supplied with this
product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.
HEARING AID COMPATIBILITY (HAC)
This telephone system meets FCC standards for Hearing Aid Compatibility.
3
SEE MARKING ON BOTTOM / BACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:
TABLE OF CONTENTS
EQUIPMENT APPROVAL INFORMATION ........ 2
INTERFERENCE INFORMATION ................... 2
FCC RF RADIATION EXPOSURE
STATEMENT .................................. 2
HEARING AID COMPATIBILITY (HAC) ........ 2
TABLE OF CONTENTS ............................. 3
INTRODUCTION ..................................... 5
DIGITAL SECURITY SYSTEM ................. 6
HANDSET AND BASE LAYOUT .................. 7
BEFORE Y OU BEGIN .............................. 8
PARTS CHECKLIST ............................. 8
TELEPHONE JACK REQUIREMENTS ........ 8
INSTALLATION ....................................... 9
IMPORTANT INSTALLATION GUIDELINES .. 9
INSTALLING THE PHONE .......................... 9
WALL MOUNTING THE BASE ............. 12
PROGRAMMING THE T ELEPHONE.......... 12
MEMORY ........................................... 12
STORING A NAME AND NUMBER IN
MEMORY ....................................... 12
LANGUAGE..................................... 14
HANDSET NAME ............................. 14
AREA CODE ................................... 15
RINGER VOLUME ............................. 16
RINGER MELODY ............................. 17
VIP MELODY ..................................... 18
ASSIGNING, REVIEWING, CHANGING
OR DELETING A VIP MELODY ............ 18
TO ASSIGN:............................ 18
TO REVIEW/CHANGE/DELETE:.... 20
SETTING THE SECURITY CODE............ 20
HANDSET REGISTRATION .................. 21
HANDSET DEREGISTRATION ............... 23
DEFAULT ........................................ 25
TELEPHONE BASICS ............................. 26
RINGER SETTING SHORTCUT ............. 26
HANDSET SPEAKERPHONE................. 26
CHARGE/IN USE INDICATOR................ 26
MAKING A CALL ............................. 27
MAKING A CALL WITH THE
HANDSET SPEAKERPHONE ...... 27
ANSWERING A CALL WITH THE
HANDSET....................................... 27
ANSWERING A CALL WITH THE
HANDSET SPEAKERPHONE ...... 27
CALL TIMER .................................... 27
AUTO STANDBY .............................. 28
CALL WAITING................................ 28
FLASH ........................................... 28
REDIAL .......................................... 28
EXIT ............................................. 29
PAGING ......................................... 29
HANDSET AND HANDSET PAGING ....... 29
PAGING FROM BASE/GROUP PAGING .. 29
TRANSFERRING CALLS...................... 30
MUTE ........................................... 31
4
VOLUME CONTROL ................... 31
INTERCOM ...................................... 32
MAKING AN INTERCOM CALL ............. 32
RECEIVING AN INTERCOM CALL ... 33
RECEIVING AN EXTERNAL TELEPHONE
CALL DURING AN INTERCOM CALL ..... 33
USING INTERCOM OR
CONFERENCE WITH
EXTERNAL CALLS ................. 33
STORING A REDIAL NUMBER ............. 34
INSERTING A PAUSE IN THE DIALING
SEQUENCE ..................................... 34
REVIEWING, CHANGING OR DELETING
STORED NUMBERS .......................... 35
TO REVIEW: ............................ 35
TO CHANGE:........................... 35
TO DELETE: ............................ 35
DIALING A STORED NUMBER WITH
THE HANDSET ................................. 36
CHAIN DIALING FROM MEMORY ......... 36
CALLER ID (CID) ............................... 37
RECEIVING AND STORING CID
RECORDS ....................................... 38
REVIEWING CID RECORDS ................ 38
TRANSFERRING CID RECORDS
TO MEMORY................................... 39
DIALING A CID NUMBER .................. 39
DELETING THE CID RECORD
SHOWING IN THE DISPLAY ................. 40
DELETING ALL CID RECORDS ........... 41
CID ERRORS .................................. 42
ANSWERING SYSTEM SET UP............... 42
TURNING THE ANSWERING SYSTEM
OFF AND ON.................................. 42
VOICE INSTRUCTIONS ....................... 43
RECORDING THE OUTGOING
ANNOUNCEMENT............................. 43
REVIEWING THE OUTGOING
ANNOUNCEMENT............................. 44
ERASING YOUR RECORDED
OUTGOING ANNOUNCEMENT ............. 44
RETURNING TO THE DEFAULT
OUTGOING ANNOUNCEMENT ............. 44
SETTING THE DAY AND T IME .............. 45
TO SET THE DAY ..................... 45
TO SET THE HOUR ................... 45
TO SET THE MINUTES .............. 45
SETTING THE RINGS TO ANSWER ........ 45
TOLL SAVER ................................... 45
ADJUSTING THE VOLUME .................. 46
MESSAGE COUNTER ........................ 46
MAILBOX INDICATOR ........................ 47
MESSAGE PLAYBACK ....................... 47
ERASING MESSAGES ....................... 47
MEMO .......................................... 48
SCREENING CALLS ................... 48
REMOTE ACCESS ................................ 49
ACCESSING THE ANSWERING
SYSTEM WITH THE
CORDLESS HANDSET ....................... 49
ACCESSING THE ANSWERING SYSTEM
FROM ANOTHER LOCATION ................ 49
MEMORY FULL ............................... 49
REPLACING THE BATTERY ...................... 50
BATTERY SAFETY PRECAUTIONS......... 51
HEADSET INSTALLATION ....................... 51
CONNECTING AN OPTIONAL
HEADSET TO THE HANDSET ................ 51
DISPLAY MESSAGES ............................ 52
HANDSET SOUND SIGNALS .................. 53
TROUBLESHOOTING GUIDE ................... 54
GENERAL PRODUCT CARE .................... 57
CAUSES OF POOR RECEPTION ............... 57
SERVICE ............................................ 58
INDEX ............................................... 59
ACCESSORY ORDER FORM ................... 61
LIMITED W ARRANTY ............................ 62
5
INTRODUCTION
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them for
future reference.
Congratulations on purchasing this GE cordless telephone/answering
system with Call Waiting Caller ID. This telephone has been designed to be
simple to use, however, you can reach its full potential more quickly by
taking a few minutes to read this instruction book. This telephone is a
multifunction product for use with Call Waiting and Caller ID services
available from your local telephone company.
Your Caller ID Call Waiting phone allows you to:
•view the name and telephone number of a caller while you are on the
phone (Call Waiting Caller ID).
•identify callers before you answer the phone.
•view the time and date of each incoming call.
•record up to 99 Caller ID messages sequentially in each handset and
the base.
•know who called while you are on the other line or when you
were away.
•screen unwanted calls, eliminate harassment from annoying calls, or to
get prepared before answering a call.
6
IMPORTANT: Because cordless phones operate on electricity, you should
have at least one phone in your home that isn’t cordless, in case the power in
your home goes out.
IMPORTANT: In order to use all of the features of this telephone, you must
subscribe to two separate services available from your local telephone
company: the standard Name/Number Caller ID Service to know who is
calling when the phone rings and Caller ID with Call Waiting Service to know
who is calling while you are on the phone.
INSTALLATION NOTE: Some cordless telephones operate at frequencies
that may cause interference to nearby TVs, microwave ovens, and VCRs. To
minimize or prevent such interference, the base of the cordless telephone
should not be placed near or on top of a TV, microwave ovens, or VCR. If such
interference continues, move the cordless telephone farther away from these
appliances. Certain other communications devices may also use the 5.8 GHz
frequency for communication, and, if not properly set, these devices may
interfere with each other and/or your new telephone. Typical devices that may
use the 5.8 GHz frequency for communication include wireless audio/video
senders, wireless computer networks, multi-handset cordless telephone
systems, and some long-range cordless telephone systems.
DIGITAL SECURITY SYSTEM
Your cordless phone uses a digital security system to protect against false
ringing, unauthorized access, and charges to your phone line.
There is a unique digital security code programmed in each unit. When the
base and the handset is powered up the first time, the handset
automatically registers with the base ready for normal use.
NOTE : If more than one handset is registered with the base, registration takes
approximately one minute.
7
HANDSET AND BASE LAYOUT
charge
in use
delete
ans on/off
play/stop
memo
announce
play/stop
volume
23
play/stop
1
page
+
-
skiprew
13
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select
delete
redial
int
conf
memory
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*
wxyz
0#
Back side
mailbox 2/play/
stop button
page
button
mailbox 1/
play/stop
button
mailbox 3/
play/stop
button
announce
button
minute
button
hour button
day/time check button
memo button
volume button
skip button
message counter
charge/in use
indicator
ans on/off
button
delete button
review button
delete/redial button
prog/select button
format/mute button
*/exit button
play/stop button
review button
talk/callback button
display CID/VOL button
memory button
int/conf
button
flash/answer button
erase button
#/pause button
skip button
spk button
AC power
converter
Charge indicator
charging cradle (models 25826GE
and 25826GC only)*
8
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here.
*Model 25826GE is packaged with 2 handsets, 2 battery compartment
covers, 2 battery packs, and a handset charging cradle with AC
power converter.
*Model 25826GC is packaged with 3 handsets, 3 battery compartment
covers, 3 battery packs, 2 handset charging cradles with AC power
converters, and 1 headset.
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one pictured
here, installed in your home. If you don’t have a
modular jack, call your local phone company to find
out how to get one installed.
Base Handset(s)*Mounting pedestal
AC power converter
Telephone line cord
Battery pack(s)*
Modular
telephone
line jack
Wall plate
Battery
compartment
cover(s)*
charge
in use
delete
ans on/off
play/stop
memo
announce
play/stop
volume
23
play/stop
1
page
+
-
skiprew
13
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select
delete
redial
int
conf
memory
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*wxyz
0#
charging cradle(s) (models
25826GE and 25826GC only)*
headset (model
25826GC only)*
9
INSTALLATION
•Never install telephone wiring during a lightning storm.
•Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.
•Never touch non-insulated telephone wires or terminals, unless the
telephone line has been disconnected at the network interface.
•Use caution when installing or modifying telephone lines.
•Temporarily disconnect any equipment connected to the phone such as
faxes, other phones, or modems.
IMPORTANT INSTALLATION GUIDELINES
•Install telephone near both a telephone (modular) jack and an electrical
power outlet.
•Avoid sources of noise, such as a window by a busy street, and electrical
noise, such motors, microwave ovens, and fluorescent lighting.
•Avoid heat sources, such as heating air ducts, heating appliances,
radiators, and direct sunlight.
•Avoid areas of excessive moisture or extremely low temperature.
•Avoid dusty locations.
•Avoid other cordless telephones or personal computers.
INSTALLING THE PHONE
1. Choose an area near an electrical outlet and telephone wall jack (RJ11C).
2. Plug the AC power converter into an electrical outlet and the DC
connector into the power jack on the back of the base.
CAUTION: Use only the ATLINKS USA, Inc. power supply 5-2620
(black) or 5-2627 (white) that came with this unit. Using other power
supplies may damage the unit.
3. Install the handset battery.
NOTE: You must connect the handset battery before use.
10
•Lift the battery pack and connect it's plug to the jack inside
the compartment.
NOTE: It is important to maintain the polarity (black and red wires) to the
jack inside the compartment as shown in the illustration.
•Slide the battery compartment cover back into place.
NOTE: If the handset battery is not installed or the battery pack is not
properly connected inside the battery compartment, the handset displays “NO
BATTERY” when the handset is placed in the base cradle.
4. Connect the telephone line cord by plugging one end of the telephone
line cord into the jack on the back of the base marked TEL LINE and
other end into a telephone wall jack.
NOTE: One base can support up to four handsets.
5. If you purchased model 25825, place the handset in the base cradle.
The charge indicator turns on to indicate the battery is charging.
If you purchased model 25826GE, place one handset in the base cradle,
then plug the charging cradle into an electrical outlet, and place the
other handset in the cradle. The charge indicators turn on to indicate
the battery is charging.
If you purchased model 25826GC, place one handset in the base cradle,
then plug both charging cradles into an electrical outlet, and place a
handset in each cradle. The charge indicators turn on to indicate the
battery is charging.
6. Allow the handset(s) to charge on a flat surface, such as a desk or table
top, for 16 hours prior to first use. If you don't properly charge the
phone, battery performance is compromised.
BLACK WIRE
RED WIRE
BATTERY
PRESS DOWN
FIRMLY
11
Model 25825
Model 25826GE
Model 25826GC
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select
delete
redial
int
conf
memory
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*
wxyz
0#
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select int
conf
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*
wxyz
0#
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select
delete
redial
int
conf
memory
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*
wxyz
0#
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select int
conf
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*wxyz
0#
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select
delete
redial
int
conf
memory
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*
wxyz
0#
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select int
conf
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*wxyz
0#
12
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select
delete
redial
int
conf
memory
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*wxyz
0#
WALL MOUNTING THE BASE
NOTE: For best results, leave the base on a flat surface during initial charging
before you hang it on the wall.
1. Turn the base over.
2. Remove the mounting pedestal.
3. Slip the mounting holes (on the back of the pedestal) over the wall plate
posts and slide the unit down into place. (Wall plate not included.)
PROGRAMMING THE TELEPHONE
NOTE: There are eleven programmable menus available : Add Memory,
Language, Handset Name, Local Area Code, Ringer Volume, Ringer Melody,
VIP Melody, Security Code, Registration, De-registration, and Factory Default.
NOTE: To enter the programming mode (main menu), press the prog/select
button in standby mode. To exit the main menu, press the */exit button to
return to standby mode.
MEMORY
Each handset has separate memory dialing storage areas, and can store a
maximum of fifty 15-character names and 24-digit telephone numbers.
STORING A NAME AND NUMBER IN MEMORY
1. Make sure the phone is OFF (not in talk mode).
2. Press the prog/select button.
13
3. Press the CID/VOL ( or ) button to scroll to
ADD MEMORY
.
NOTE: If you don’t want to enter the name, skip step 4.
5. Use the touch-tone pad on your handset to enter a name (up to
15 characters). More than one letter is stored in each of the number
keys. For example, to enter Bill Smith, press the 2 key twice for the
letter B. Press the 4 key 3 times for the letter I. Press the 5 key 3 times
for the letter L. Wait for 1 second. Press the 5 key 3 times for the
second letter L, and press the 1 key to insert a space between the first
and last name. Press the 7 key 4 times for the letter S; press the 6 key
once for the letter M; press the 4 key 3 times for the letter I; press the 8
key for the letter T; press the 4 key twice for the letter H.
NOTE: If you make a mistake press the delete/redial button on the base or
handset to backspace and erase the wrong character(s) or number(s).
6. Press the prog/select button to save. The display shows
ENTER TEL NUMBR
.
7. Use the touch-tone pad on your handset to enter the area code followed
by the telephone number (up to 24 digits, including pauses) and press the
prog/select button again to save. The unit beeps to confirm and returns to
the main menu.
8 . To enter another name and number in a different memory location,
repeat step 3 to 6 again.
ADD MEMORY
ENTER TEL NUMBR
ENTER NAME
ADD MEMORY
ADD MEMORY
LANGUAGE
MAIN MENU
4. Press the prog/select button.
14
LANGUAGE
1. Make sure your handset is OFF (not in talk mode).
2. Press the prog/select button while in standby mode to enter the
main menu.
3. Press the CID/VOL ( or ) button to scroll to
LANGUAGE.
4. Press the prog/select button.
5. Use touch-tone pad to select
1ENG, 2FRA , 3ESP,
or use the CID/VOL (
or ) button to scroll to
1ENG, 2FRA, or 3ESP. ENG
(English) is the
default setting.
6. Press the prog/select button to confirm. The confirmation screen
displays if any changes are made and then returns to the main menu.
HANDSET NAME
1. Make sure your phone is OFF (not in TALK mode).
2. Press prog/select button.
3. Press the CID/VOL ( or ) button to scroll to
HANDSET NAME MENU
.
LANGUAGE
HANDSET NAME
MAIN MENU
SELECT LANGUAGE
1 ENG 2FRA 3ESP
LANGUAGE
LANGUAGE
HANDSET NAME
MAIN MENU
ENGLISH
LANGUAGE
15
4. Press the prog/select button.
5. Use the touch-tone pad to enter the handset name.
More than one letter is stored in each of the number keys. For example, to
enter the name Bill Smith, press the 2 key twice for the letter B. Briefly
pause and the cursor moves to the next field. Press the 4 key 3 times for
the letter I. Briefly pause and the cursor moves to the next field. Press the
5 key 3 times for the letter L. Briefly pause and the cursor moves to the
next field. Press the 5 key 3 times for the second letter L, press 1 key to
add a space. Press the 7 key 4 times for the letter S. Briefly pause and the
cursor moves to the next field. Press the 6 key once for the letter M. Briefly
pause and the cursor moves to the next field. Press the 4 key 3 times for
the letter I. Briefly pause and the cursor moves to the next field. Press the
8 key for the letter T. Briefly pause and the cursor moves to the next field.
Press the 4 key twice for the letter H.
NOTE: If a name is already stored in the handset, you may remove it by
pressing the delete/redial button.
NOTE: If you make a mistake press the delete/redial key to backspace and
erase the wrong character.
2. Press the prog/select button to save the name The confirmation screen
shows for two seconds, then returns to the main menu. You will hear a
confirmation tone.
AREA CODE
If you entered a 3-digit area code in the area code menu, your local area
code does not display on the Caller ID (CID) list. Instead, you only see the
local seven digit number. Calls received from outside your local area code
display as the full ten-digit number.
HANDSET NAME
JOHN SMITH
HANDSET NAME
ENTER NAME
16
1. Make sure your phone is OFF (not in TALK mode).
2. Press the prog/select button.
3. Press the CID/VOL ( or ) button to scroll to
AREA CODE
.
4. Press the prog/select.
5. Use the handset touch-tone pad to enter your three digit area code.
6. Press prog/select again. The confirmation screen shows for two
seconds, and then returns to the main menu. You will hear a
confirmation tone.
RINGER VOLUME
1. Make sure your phone is OFF (not in TALK mode).
2. Press the prog/select button.
3. Press the CID/VOL ( or ) button to scroll to
RINGER VOLUME
.
4. Press the prog/select button.
HANDSET NAME
AREA CODE
MAIN MENU
SET AREA CODE
- - -
AREA CODE
AREA CODE
RINGER VOLUME
MAIN MENU
1 2 3
AREA CODE
17
5. Press the CID/VOL ( or ) button or use the handset touch-tone pad
to enter 1, 2 or 3.
6. Press prog/select again. The confirmation screen shows for two
seconds, and then returns to the main menu. You will hear a
confirmation tone.
NOTE: If RINGER is turned OFF, the handset displays RINGER OFF.
RINGER MELODY
You may choose from six different polyphonic melodies plus one ringer tone.
1. Make sure your phone is OFF (not in TALK mode).
2. Press the prog/select button.
3. Use the CID/VOL ( or ) button to scroll to
RINGER MELODY
.
4. Press prog/select again.
5. Press the CID/VOL ( or ) button, or use the touch tone pad on the
handset to select a melody. The default value is
MELODY 1
.
SET LEVEL
1HI 2LOW 3OFF
RINGER VOLUME
LEVEL LOW
RINGER VOLUME
RINGER VOLUME
RINGER MELODY
MAIN MENU
SET MELODY
1 2 3 4 5 6 7
RINGER MELODY
18
6. Press the prog/select button again to save. The confirmation screen
shows for two seconds, and then returns to the main menu. You will
hear a confirmation tone.
VIP MELODY
This features allow you to assign a specific melody to someone you want
to get your attention when the person calls. When a VIP melody is
assigned and that person calls, the VIP melody will ring instead of the
normal ring. You may choose from six different polyphonic melodies plus
one ringer tone.
NOTE: This feature only works when the following conditions are met.
1. You have subscribed to Caller ID.
2. You have your Caller ID record transferred to the memory. (Refer to
Transferring CID Records To Memory).
ASSIGNING, REVIEWING, CHANGING OR DELETING A VIP MELODY
TO ASSIGN:
1. Make sure your phone is OFF (not in TALK mode).
2. Press prog/select button to enter into
MAIN MENU
.
3. Press the CID/VOL ( or ) button to scroll to
VIP MELODY
.
4. Press prog/select button when the cursor key prompted to
VIP MELODY
.
5. Press the CID/VOL ( or ) button to your desired VIP location. If the
location is available, it will display as below.
MELODY - 4
RINGER MELODY
RINGER MELODY
VIP MELODY
MAIN MENU
19
6. A total of 10 VIP can be stored. Press prog/select button to select the
VIP memory location. The
SELECT MEMORY
screen displays for 2
seconds, and then displays the memory records.
7. Press the CID/VOL ( or ) button to scroll to your desired memory record.
8. Press prog/select button to confirm the selection.
SET MELODY
screen displays.
9. Press the CID/VOL ( or ) button or the touch tone pad to select the
desired ringer melody. The melodies ring accordingly.
10.Press prog/select select button to confirm your selection. The
confirmation screen displays for two seconds and returns to the main
menu. You will hear a confirmation tone.
JOHN SMITH
VIP MELODY
VIP1 -MELODY 7
SET MELODY
VIP MELODY
1 2 3 4 5 6 7
SELECT MEMORY
VIP MELODY
JOHN SMITH
VIP MELODY
317-123-4567
VIP 1
*EMPTY *
VIP MELODY
20
TO REVIEW/CHANGE/DELETE:
1. Repeat step 1 ~ 5 as above section.
2. If there is a VIP which has already been assigned to this location, it will
toggle to display that VIP name and number in 2 second intervals.
3. You can change, delete or return to previous menu:
a) Press prog/select button to re-assign the VIP record, or
b) Press delete/redial button to delete the VIP record, or
c) Press exit to return to previous menu.
SETTING THE SECURITY CODE
This unit provides you with the ability to access the answering system
from a tone dialing telephone in another location. The security code is
required for remote access, and it prevents unauthorized access to your
answering system. The default code is
#123
, and you may change the last 3
digits security code in any handset registered with the unit. The security
code has to start with
#
.
1. Make sure your phone is OFF (not in TALK mode).
2. Press prog/select button to enter into
MAIN MENU
.
3. Press the CID/VOL (or ) button to scroll to
SECURITY CODE
.
VIP 3
VIP MELODY
MELODY 7
JOHN SMITH
VIP MELODY
317-123-4567
VIP MELODY
SECURITY CODE
MAIN MENU
21
4. Press prog/select button.
5. Default is
#123
. Enter “
#
” and any other 3 digits.
6. Press prog/select button to confirm. The confirmation screen shows for
two seconds, and then returns to the main menu. You will hear a
confirmation tone.
HANDSET REGISTRATION
READ THIS NOTE: Your handset(s) is pre-registered and ready to use.
Registered handsets display HANDSET 1, HANDSET 2, and HANDSET 3. It is
not recommended or necessary to re-register the handset. If you purchased an
extra handset separately (model 25802), follow this procedure to register the
extra handset. One base can support up to four handsets.
During the registration process, keep your handset near the base. When
your handset shows the following:
1. Press the prog/select button.
SET CODE
# - - -
SECURITY CODE
# 258
SECURITY CODE
HANDSET NEEDS
REGISTRATION
REGISTER?
1 YES 2 NO
REGISTRATION
22
2. Use the touch-tone pad or the CID/VOL ( or ) button to select
1YES
.
NOTE: If you select 2NO, your handset cannot be registered and will not work.
3. Press the prog/select button and
HOLD BASE PAGE WAIT FOR BEEP
and
PRESS PROG KEY AFTER BASE BEEP
shows in the display.
3. Press and hold the page button on the base until you hear a long
confirmation tone.
NOTE: Registration should only take about 1 minute. If there is no
response after 1 minute, an error tone is emitted and REGISTRATION
FAIL will be displayed. Repeat step 1 to 3 to restart the registration process.
4. Press the prog/select button on the handset after you hear the base
beep.
REGISTER......
. shows in the display. If registration is successful,
HANDSET # (1, 2, 3 or 4) REGISTERED
displays for two seconds, followed
by the HANDSET NAME
entry screen.
HOLD BASE PAGE
WAIT FOR BEEP
REGISTRATION
PRESS PROG KEY
AFTER BASE BEEP
REGISTRATION
HANDSET #
HANDSET NAME
REGISTER...
REGISTRATION
HANDSET #
REGISTRATION
REGISTERED
23
5. Use the touch-tone pad to enter the name.
More than one letter is stored in each of the number keys. For
example, to enter the name Bill Smith, press the 2 key twice for the
letter B. Briefly pause and the cursor moves to the next field. Press the
4 key 3 times for the letter I. Briefly pause and the cursor moves to the
next field. Press the 5 key 3 times for the letter L. Briefly pause and the
cursor moves to the next field. Press the 5 key 3 times for the second
letter L, press 1 key to add a space. Press the 7 key 4 times for the letter
S. Briefly pause and the cursor moves to the next field. Press the 6 key
once for the letter M. Briefly pause and the cursor moves to the next
field. Press the 4 key 3 times for the letter I. Briefly pause and the
cursor moves to the next field. Press the 8 key for the letter T. Briefly
pause and the cursor moves to the next field. Press the 4 key twice for
the letter H.
NOTE: If you make a mistake press the delete/redial button to backspace and
erase the wrong character(s).
5. Press the prog/select button to save, and exit the standby mode, the
name shows in the display.
HANDSET DEREGISTRATION
Deregistration cancels a handset’s registration. During the de-registration
process, it’s important to keep the handset near the base.
WARNING: It is not recommended that a handset be de-registered unless
absolutely necessary because once a handset is deregistered, that handset’s
telephone features cannot be used until the handset is re-registered.
1. Make sure your phone is OFF (not in TALK mode).
2. Press the prog/select button.
24
3. Press the CID/VOL ( or ) button to scroll to
DE-REGISTRATION
.
4. Press prog/select and
DE-REGISTER?
1YES 2 NO
shows in the display.
5. Use the CID/VOL ( or ) button or touche tone pad to select
1YES.
NOTE: If you select 2NO, your handset is not deregistered.
6. Press prog/select again,
MOVE NEAR TO BASE
displays until you move
the handset closer to the base. Then
CONFIRM? 1YES 2 NO
shows in
the display.
7. Use the CID/VOL ( or ) button to scroll to
1YES
. The default setting
is
1YES
.
NOTE: If you select 2NO, your handset is not deregistered.
8. Press the prog/select button to confirm the deregistration.
HANDSET #
DEREGISTERED
followed by
HANDSET NEEDS REGISTRATION
shows
in the display.
REGISTRATION
DEREGISTRATION
MAIN MENU
DEREGISTER?
1 YES 2 NO
DEREGISTRATION
CONFIRM?
1YES 2NO
DEREGISTRATION
MOVE NEAR TO
BASE
DEREGISTRATION
25
NOTE: If one or more handsets becomes lost, you should de-register all
handsets (globally) to ensure proper system operation.
1. Press and hold the base page button on the base until the charge/in use
indicator flashes.
2.Press and hold the base page button again until the charge/in use
flashes rapidly.
3. Press and release the page button on the base. The charge/in use indicator
stops blinking, and confirms all handsets are de-registered. Then the base
initializes again and each handset displays HANDSET NEEDS
REGISTRATION. You should also set the date/time on the base answerer.
DEFAULT
As you become familiar with this system, you may prefer to use the
system’s original settings. Follow the steps to return to the factory settings.
1. Make sure your handset is in menu mode and it is OFF (not in
TALK mode).
2. Use the CID/VOL ( or ) button to scroll to
DEFAULT SETTING
.
3. Press the prog/select button.
4. Use the touch-tone pad to select
1YES
or
2NO
, or press the CID/VOL (
or ) button to scroll to
1YES
or
2NO
. The default setting is
NO
.
•If you select
YES
, all settings in the programmable menu on the
handset return to the factory default settings except Memory and
VIP Melody.
HANDSET
#
DEREGISTERED
DEREGISTRATION
HANDSET NEEDS
REGISTRATION
26
•If you select
NO
, your programmed setting are retained.
5. Press the prog/select button to save. The confirmation screen displays
then returns to the main menu. You will hear a confirmation tone.
TELEPHONE BASICS
RINGER SETTING SHORTCUT
NOTE : In addition to setting the ringer level through the programmable
menu, you may also set it with the shortcut key.
1. Make sure the phone is OFF (not in TALK mode).
2. Press the #PAUSE button, and
SET RINGER 1ON 2OFF
shows on
the display.
3. Press 1 to turn the ringer ON and 2 to turn it OFF. You will hear a
confirmation tone, and the display returns to standby.
HANDSET SPEAKERPHONE
For hands-free operation and convenience, your multi-handset system is
equipped with a handset speakerphone.
For best handset speakerphone performance, avoid the following:
•Areas with high background noise. (The microphone might pick up
these sounds.)
•Surfaces affected by vibration.
•Recessed areas such as in a corner, under a cupboard, or next to a
cabinet, which can generate an echo effect.
Note the following guidelines when using the speakerphone:
•Stay reasonably close to the phone so that you can be clearly heard by
the person to whom you are talking.
CHARGE/IN USE INDICATOR
When the charge/in use indicator on the base is lit, the handset is correctly
seated in the cradle and is charging. The indicator flashes, when the base
pages the handset, or when you receive an incoming call.
27
MAKING A CALL
1. Pick up the handset and press the talk/callback button. Listen for a
dial tone.
2. Dial the desired number, or pre-dial the number first then press the
talk/callback button.
3. When finished, press the talk/callback button again to hang up.
MAKING A CALL WITH THE HANDSET SPEAKERPHONE
1. Press the spk button on the handset. You will hear a dial tone.
2. Dial a number. Or, pre-dial the number and then press the spk button.
3. When finished, press the talk/callback button to hang up.
NOTE: You can enter up to 32 pre-dial digits. If you want to delete the
pre-dial number you entered, press the delete/redial button until all of
the digits are erased.
NOTE: The unit only supports tone dialing mode.
ANSWERING A CALL WITH THE HANDSET
1. When the phone rings, press the talk/callback button on the handset.
2. When finished, press the talk/callback button again to hang up.
ANSWERING A CALL WITH THE HANDSET SPEAKERPHONE
1. When the phone rings, press the spk button to answer a call.
2. When finished press talk/callback to hang up.
NOTE: If you are using the handset and want to switch to the handset
speakerphone, press spk button once. Pressing the spk button a second time
will turn the handset speaker phone off and back to the earpiece. At any time
during a conversion, if talk/callback button is pressed, the line will be
dropped and end the call.
CALL TIMER
After you press talk/callback or spk button on the handset, the built-in call
timer shows in the display and counts the length of time of the call in
minutes and seconds.
28
AUTO STANDBY
Placing the handset in the base cradle while the handset is off hook
(during a call) automatically hangs up the handset.
CALL WAITING
If you subscribe to the combined Call Waiting Caller ID service from your local
telephone company, you will receive Caller ID information (if available) on Call
Waiting calls. During a phone call you will hear a beep, which indicates
another call is waiting on the line, and Caller ID information shows in the
handset display. To connect to the waiting call, press the flash button on the
handset, and your original call is put on hold. You may switch back
and forth between the two calls by pressing the flash button.
FLASH
Use the flash/answerer button on the handset to activate custom calling
services, such as call waiting, which are available through your local
phone company.
TIP: Don’t press the talk/callback or spk button on the handset to activate a
custom calling service, such as call waiting, or you’ll hang up the phone.
REDIAL
You may redial the last 4 numbers, each up to 32 digits long. If the
number is longer than 32 digits, it won’t be stored in the redial list. To
quickly redial the last number you dialed:
1. Press the talk/callback or spk button on the handset.
2. Press the redial button to redial the last number called.
-OR-
1. Press the redial button.
NOTE: If you get a busy signal and want to keep dialing the number, press the
redial button to quickly redial the number.
29
EXIT
Press the exit button on the handset to end an operation, such as
TRANSFER or exit the programmable menu.
PAGING
This feature helps you locate a misplaced handset. All handsets must be
registered to use the page function. If your handsets are not registered,
follow the instructions in the Handset Registration section of this manual.
HANDSET AND HANDSET PAGING
NOTE: For model 25825, you must register an additional handset (model
25802) in order to use this feature.
Make sure the phone is OFF (not in talk mode).
1. Press the int/conf button on the handset.
2. Use the touch-tone pad on your handset to enter the handset number you
want to page when
PAGING EXTENSION?
shows in the display. The
paged handset beeps for 2 minutes.
3. To cancel the page, press the *exit button, or press the int/conf button.
PAGING FROM BASE/GROUP PAGING
1. Press the page button on the base. All registered handsets (or the
single handset on model 25825) beep for 2 minutes and “
PAGING
FROM BASE
” shows on each handset’s display.
2. To cancel the page, press the page button on the base again, or press
the talk/callback button on each handset.
NOTE: Handsets are numbered from 1 to 4.
PAGING
EXTENSION ?
30
TRANSFERRING CALLS
NOTE : For model 25825, you must register an additional handset (model
25802) in order to use this feature.
This feature lets you transfer calls between handsets in talk mode.
1. During talk mode, press the int/conf button to put the call on hold.
2. Enter the handset number you want to transfer the call to, and the
receiving handset is paged. During the page, a page tone is emitted on
the receiving handset. For example, HANDSET 2 pages Steve’s handset
and the following information shows in the displays:
RECEIVING HANDSET
SENDING HANDSET
NOTE: If the page isn’t answered, press the exit button on handset or the int/
conf button to cancel the transfer.
When the int/conf or talk/callback button is pressed on the receiving
handset, the unit goes into intercom mode. When the talk/callback button
on the sending handset is pressed, the call is transferred.
EXTENSION ?
PAGING
TALK 00:30 VOL4
HANDSET 2
PAGING FROM
STEVE PAGING
HOLD
31
NOTE: 1) If talk/callback button on the sending handset is pressed before int/
conf or talk/callback button is pressed on the receiving handset, the receiving
handset emits the ringer tone (not the page tone), and
TRANSFER FROM
and the handset number or name shows in the display.
2) If the other extension does not take the call within 30 seconds, the call is
transferred back to your handset, and
CALLBACK
is displayed.
MUTE
To have a private, off-line conversation use the mute feature. The party on
the other end of the line cannot hear you, but you can still hear them.
1. During a phone conversation press the format/mute button on the
handset.
MUTE
shows in the display.
2. Press the format/mute button again to cancel mute and return to your
phone conversation.
VOLUME CONTROL
When the phone is ON (in talk mode) adjust the receiver volume by
pressing the CID/VOL ( or ) button on the cordless handset. There are
four volume levels, and each press of the CID/VOL ( or ) button adjusts
the receiver volume by one level.
NOTE: You may also adjust the volume during intercom mode, conference
mode, and handset remote access.
MUTE 00:50 VOL 3
TALK 00:59 VOL 3
32
INTERCOM
The intercom feature allows you to have an unlimited-duration, two-way
conversation between two handsets.
NOTE : For model 25825, you must register an additional handset (model
25802) in order to use this feature.
MAKING AN INTERCOM CALL
1. Make sure the phone is OFF (not in talk mode).
2. Press the int/conf button on the handset.
PAGING EXTENSION
shows in the display.
3. Enter the handset number you want to intercom with. The receiving
party is paged.
NOTE: To cancel the page, press the int/conf button again or press the
*exit button on the sending handset.
THE SENDING PARTY THE RECEIVING PARTY
4. When the receiving party answers the page (by pressing the int/
conf, or talk/callback button), the intercom is activated. When the
intercom is setup the following information shows in the display:
THE SENDING PARTY THE RECEIVING PARTY
EXTENSION ?
PAGING
HANDSET 2
PAGING FROM
HANDSET 1
PAGING
HANDSET 1
INTERCOM
HANDSET 2
INTERCOM
33
5. When finished, press the exit button or the int/conf button or talk/
callback on either handset to deactivate the intercom.
RECEIVING AN INTERCOM CALL
When an intercom call is received, the handset beeps. To answer the
intercom call, press the int/conf, talk/callback or spk button on the handset.
RECEIVING AN EXTERNAL TELEPHONE CALL DURING AN INTERCOM CALL
If you receive a telephone call during an intercom call you will hear a beep in
the earpiece to alert you of the incoming call. Press the talk/callback or *exit
button on the handset to end the intercom first, and then press the talk/
callback button or spk button to answer the external telephone call.
USING INTERCOM OR CONFERENCE WITH EXTERNAL CALLS
During an external telephone call, you may page other handsets and have
off-line, private intercom conversations between an external caller and the
handsets, or you may have a 3-way conference with external line and
another handset or the base.
1. During an external call, press the int/conf key on your handset to place
the external call on hold.
2. Enter the handset number you want to intercom/conference. The
receiving handset is paged.
SENDING PARTY RECEIVING PARTY
HANDSET 2
PAGING
HOLD 01:39 VOL1
HANDSET 1
PAGING FROM
EXTENSION ?
PAGING
HOLD 01:30 VOL1
34
3. The receiving handset must press the int/conf or talk/callback or spk
button to answer the intercom, then both intercom users may speak
privately. The external caller cannot hear the intercom conversation.
SENDING PARTY RECEIVING PARTY
4. Press the int/conf button on the sending handset to initiate a
conference between handset 1 and handset 2.
NOTE: Press the exit button on the handset to cancel the intercom call, and
the sending party may continue to talk to the external party. Or the calling
party may press the talk/callback button to transfer the call to the receiving
party who may speak to the external caller independently.
NOTE: A handset can enter conference directly by pressing talk/callback
while the other handset is on an external call.
STORING A REDIAL NUMBER
1. Make sure your phone is OFF (not in TALK mode).
2. Press the delete/redial button on the handset.
3. Press CID/VOL ( or ) button to scroll to the desired redial number.
4. Press the memory button, and the display shows
ENTER NAME
.
5. Repeat steps 4 through 7 in Add Memory.
NOTE: If the redial number has more than an 24 digits, it cannot be
stored in memory. “UNABLE TO STORE” is displayed.
INSERTING A PAUSE IN THE DIALING SEQUENCE
If a pause is needed to wait for a dial tone press the # pause button on
the touch-tone pad to insert a delay in dialing sequence of a stored
telephone number (for example, after you dial 9 for an outside line, or
wait for a computer access tone.) Each pause counts as one digit and
shows as
“P”
in the dialing sequence.
HANDSET 2
INTERCOM
HOLD 01:40 VOL1
HANDSET 1
INTERCOM
35
REVIEWING, CHANGING OR DELETING STORED NUMBERS
TO REVIEW:
1. Make sure the phone is OFF (not in talk mode).
2. Press the memory button, and the display either shows
EMPTY
or the
number of stored records.
3. Press the CID/VOL ( or ) button to review the memories.
TO CHANGE:
1. Repeat the steps from 1 to 3 in Reviewing Stored Memory.
2. Press the memory button, the display shows
ENTER NAME
.
3. Use the touch tone pad to enter a name.
NOTE: The first press of the new character entirely removes the previous
name so you may enter a new name.
4. Press the memory button, the display shows
ENTER TEL NUMBR
.
5. Use the touch tone pad to enter a number.
NOTE: The first press of the new number entirely removes the previous
number so you may enter a new telephone number.
6. Press the memory button again. You will hear a confirmation tone.
TO DELETE:
1. Make sure the phone is OFF (not in talk mode).
STORED 50
MEMORY
PETER CHAN
317 - 123 - 4567
MEMORY
36
2. Press the memory button, and the display either shows
EMPTY
or the
number of stored records.
3. Press the CID/VOL ( or ) button to scroll to a desired record.
4. When the record shows in the display, press the delete/redial
button. The display shows
DELETE?
5. Press the delete/redial button again to delete the record.
DELETED
shows in the display.
NOTE: If you don’t want to change or delete a number, press the exit button
or wait for one minute to exit the review mode automatically.
DIALING A STORED NUMBER WITH THE HANDSET
1. Make sure the phone is OFF (not in talk mode).
2. Press the memory button.
3. Press the CID/VOL ( or ) button to scroll through memory until the
desired number displays, or, after the first name displays, press the
first character of the stored name to find the memory you want to dial.
4. Press the talk/callback button. The number dials automatically.
CHAIN DIALING FROM MEMORY
Use this feature to make calls that require a sequence of numbers, such as
a calling card number used for a frequently called long distance number.
The following example shows how you can store each part of the long
dialing sequence and use chain dialing to make a call through a long
distance service:
**DELETED**
MEMORY
DELETE ?
MEMORY
37
1. Make sure the phone is ON.
For example:
The Number Memory Name
Long Distance Access Number LONG D-1
Authorization Code LONG D-A
Long distance number DON SMITH
2. Press memory button on the handset, and then press CID/VOL ( or
) to scroll to
LONG D-1
. Press the talk/call back button to dial the
long distance access number.
3. When you hear the access tone, press the memory button, and then press
CID/VOL ( or ) to scroll to
LONG D-A
. Press the memory button again
to dial the authorization code.
4. At the next access tone, press memory button, then press CID/VOL (
or ) to scroll to the call that you want to make. Press the memory
button again to dial the long distance number.
CALLER ID (CID)
Caller ID (CID) is a service available from your local telephone company.
For Caller ID to work on this system, you must subscribe to Caller ID
service. To receive Caller ID information for a Call Waiting call, you must
subscribe to the combined Caller ID Call Waiting service.
When your telephone rings, and you are subscribed to Caller ID Call
Waiting service, you will receive information (if available) transmitted by
your local telephone company. You will also receive Caller ID information
from Call Waiting calls. If you receive an incoming call and you are already
on the phone, a beep indicates the presence of a Call Waiting Call on the
line, and Caller ID information for the Call Waiting call shows on the
display. This information may include the phone number, date and time; or
the name, phone number, and date and time.
38
RECEIVING AND STORING CID RECORDS
When you receive a call, Caller ID information is transmitted by the phone
company to your Caller ID telephone between the first and second ring.
The Caller ID information appears on the display while the phone rings,
giving you a chance to monitor the information and decide whether or not
to answer the call.
If you are not at home or cannot answer, your telephone’s Caller ID
memory automatically stores the call number, date, time, phone number,
and name for the 99 most recent calls so you can see who called while you
were unavailable. CID records are stored sequentially, in the order they are
received. When the 100th call is received, the oldest CID record is
automatically deleted.
You may review the stored information for the most recent 99 calls at any
time. Calls received since your last review show as
NEW
in the display.
REVIEWING CID RECORDS
As CID records are received and stored, the display is updated to let you
know how many calls you have received.
1. Press the CID/VOL () to review the oldest call and scroll toward the
most recent calls (higher numbers). When you reach the newest call,
the display shows
END OF LIST
.
2. Press the CID/VOL () button on the handset to review the newest call
and scroll to older calls (lower numbers). When you reach the oldest call,
the display shows
END OF LIST
.
As you review calls, the display shows you the following information for
each call:
•The telephone number of the caller.
•The number of the call, with regard to the order received.
•The name of the caller, if this service is available in your area.
NOTE: If a name is received which exceeds 15 characters, the extra characters
are removed.
39
•Time and date the call was received.
•
NEW
appears at the bottom right corner of the display for all calls that
have not been reviewed.
NOTE: Check with your local phone company regarding name
service availability.
•
NEW
and
REPT
appears at the bottom right corner of the display for
all calls received more than once which have not been reviewed.
TRANSFERRING CID RECORDS TO MEMORY
You may transfer a Caller ID record to your phone ’s memory.
NOTE: It is important that you format CID records correctly before storing in
memory. It is not possible to reformat CID records stored in memory. For
details, please see Dialing a Caller ID Number.
1. Use the CID/VOL ( or ) button on the handset to scroll to the desired
CID record.
2. Press the memory button. The display shows
STORED
for two
seconds, and you will hear a confirmation tone. The handset returns to
standby mode.
DIALING A CID NUMBER
While reviewing CID records, you may dial the phone number showing in
the display.
1. Make sure the phone is OFF (not in talk mode).
2. Press the CID/VOL ( or ) button until the desired CID record shows
in the display.
PETER CHAN
317 - 123 - 4567
CALL
#
9:58
AM
11/24
NEW
CALLER LIST
40
NOTE: Depending on (a) how the incoming phone number is formatted
when the CID record is received, and (b) whether or not you pre-programmed
your local area code in the set up menu, you may need to adjust the format of
the telephone number in the CID record before dialing it back. The mute/
format button lets you change the format of a displayed number.
Available formats include:
Number of digits Explanation Example
Eleven digits long distance code “1 ” 1-317-888-8888
+3- digit area code +7-digit
telephone number.
Ten digits 3-digit area code +7-digit 317-888-8888
telephone number.
Seven digits 7-digit telephone number. 888-8888
3. If the number does not dial as shown, press the format/mute button.
Repeat if necessary, until the correct number of digits show in the display.
4. Press the talk/callback or spk button. The number dials automatically.
NOTE: If the incoming number is a Direct Dial Number, it is supplied by your
local phone company, and you may not adjust its format. When you press the
mute/format button on handset PRESS TALK KEY displays. Press the talk/
callback button on handset to dial the number.
NOTE: If the number is corrupted, such as a number in a name or an
alphabetical character in a number, an error tone returns and the number
cannot be dialed.
DELETING THE CID RECORD SHOWING IN THE DISPLAY
1. Make sure the phone is OFF (not in talk mode).
HANDSET 1
NAME
11:03 AM
41
2. Use the CID/VOL ( or ) button to display the desired CID record.
3. Press the delete/redial button. The display shows
DELETE ?
4. Press the delete/redial button to erase the record. The display briefly
shows
DELETED
, and then confirms the deletion with a tone.
NOTE: Press exit button to return to standby mode.
DELETING ALL CID RECORDS
1. Make sure the phone is OFF (not in talk mode).
2. Use the CID/VOL ( or ) button to display any CID record.
**DELETED**
CALLER LIST
STEVE
12 34567890 1 2 34 5
CALL
#
9:58
AM
11/24
NEW
CALLER LIST
DELETE CALL ID ?
CALLER LIST
HANDSET 1
NAME
11:03 AM
NAME
12 34567890 1 2 34 5
CALL
#
9:58
AM
11/24
NEW
CALLER LIST
42
3. Press and hold the delete/redial button until the display shows
DELETE ALL?
4. Press the delete/redial button to erase all CID records from memory.
The display shows
NO CALLS
. You will hear a confirmation tone. The
handset returns to standby mode.
NOTE: Press exit button to return to standby mode.
CID ERRORS
If there is an error in the transmission of information to your phone,
ERROR
or
INCOMPLETE DATA
shows in the display. If you are not
subscribed to CID service, or it is not working properly,
NO DATA
shows in
the display.
ANSWERING SYSTEM SET UP
This section shows you how to set up your answering machine to receive
incoming calls. Answering system setup may only be done at the base.
TURNING THE ANSWERING SYSTEM OFF AND ON
1. Make sure the unit is not in TALK mode.
2. Press the ans on/off button, you will hear “
ANSWER ON
” or
“
ANSWER OFF
”.
3. The MESSAGES indicator lights when the answering system is on. The
indicator and the corresponding mailbox blink when you have new
messages in that mailbox.
DELETE ALL ?
CALLER LIST
NO CALLS
CALLER LIST
43
NOTE : The answering system displays “- -” when it is off.
VOICE INSTRUCTIONS
If you need additional assistance, press the review (rew) button in standby
mode and follow the voice instructions.
RECORDING THE OUTGOING ANNOUNCEMENT
Before using your answering system, you should record an outgoing
announcement (the announcement caller hear when your answering
system answers a call). A customized outgoing announcements can be
recorded. If you don’t record an outgoing announcement, callers hear
a default outgoing announcement, which says, “
PLEASE LEAVE YOUR
MESSAGE AFTER THE TONE
.”
You can record two types of outgoing announcements, one to use for
global mailbox 1, or one to direct callers to leave messages in specific
mailboxes. This is especially useful for active families or small businesses.
When recording the outgoing announcement, you should be about 6
inches from the unit. This ensures the best recording quality. Eliminate as
much background noise as possible.
Both types of outgoing announcements are recorded by the following:
1. Prepare your outgoing announcement.
For example:
Sample Single Mailbox Outgoing announcement: Hi, this is (use your
name here), I can’t answer the phone right now, so please leave your name, number
and a brief message after the tone, and I’ll get back to you. Thanks.
Sample Multi-Mailbox Outgoing announcement: Hi, this is (use your name
here), We can’t answer the phone right now, so please press 1 to direct your message to
(name 1), press 2 to direct your message to (name 2), press 3 to direct your message to
(name 3). Leave your name, number and a brief message after the tone, and we’ll get
back to you. Thanks.
44
2. Press and hold the announce button. You will hear “
RECORD
ANNOUNCEMENT AFTER TONE
”. After the tone, say your
outgoing announcement.
3. Release the announce button when you finish. The new recorded
outgoing announcement plays.
NOTE: You can direct callers to leave messages in a specific mailbox by having
them press the desired mailbox (1-3) after the outgoing announcement plays. If
no mailbox is selected, the incoming messages automatically go into mailbox 1.
NOTE: The outgoing announcement must be 2 seconds or longer to be valid
and should not be longer than 2 minutes. Otherwise, the system uses the
default announcement.
DEFAULT MAILBOX for incoming messages: mailbox 1.
REVIEWING THE OUTGOING ANNOUNCEMENT
To review the outgoing announcement, press and release the
announce button.
ERASING YOUR RECORDED OUTGOING ANNOUNCEMENT
1. To erase your outgoing announcement while listening to it, press and
release the delete button. You will hear
ANNOUNCEMENT ERASED
.
2. To re-record your outgoing announcement from any point, press and
hold the announce button. After the tone, say your new outgoing
announcement. Release the announce button when you finish.
3. The new outgoing announcement will be announced indicating that
the default one is being replaced.
RETURNING TO THE DEFAULT OUTGOING ANNOUNCEMENT
To return to the answerer’s default outgoing announcement after you’ve
recorded one:
1. Press and release the announce button to play your
outgoing announcement.
2. Press and release the delete button while your outgoing
announcement is playing.
45
3. Your outgoing announcement will stop and be erased, a confirmation
tone is emitted.
4. You will hear
ANNOUNCEMENT ERASED
, and the default
announcement is restored.
SETTING THE DAY AND TIME
For each message received, a day/time stamp is added to the message.
Press the day/check button, the unit will announce current time and day
(Day/ Hour/ Minute/ (AM/PM)).
TO SET THE DAY
1. Press and hold the day/check button until the unit announces the
correct day.
2. After the day is set, the new day and time will be announced.
TO SET THE HOUR
1. Press and hold the hour button until the unit announces the correct hour.
2. After the hour is set, the new day and time will be announced.
TO SET THE MINUTES
1. Press and hold the minute button until the unit announces the
correct minute.
2. After the minute is set, the new day and time will be announced.
SETTING THE RINGS TO ANSWER
This feature is used to set the unit to answer a call after a specific number
of rings. The Ring Select Switch is located at the back of the unit.
1. When it is set at “3”, the unit will answer the incoming call after 3 rings.
2. When it is set at “5”, the unit will answer the incoming call after 5 rings.
TOLL SAVER
The toll saver is the final setting in the rings to answer menu. This feature
allows you to know if you have new messages when calling the machine from
a remote phone. If you have new messages, the unit will ring twice before
46
answering. If you don’t, it will ring four times. This allows you to hang up
before the machine answers so that you don’t have to pay toll charges.
ADJUSTING THE VOLUME
Use the Volume + and – buttons to increase the volume up and down. The
unit beeps when the maximum or minimum volume is reached. L8 is the
maximum level and L1 is the minimum level.
Call screening level from the base will be low when the unit is set to its minimum
volume, that is you will not hear what caller says while caller is recording.
MESSAGE COUNTER
The MESSAGES counter gives you a numeric display of how many
messages you have.
•MESSAGES COUNTER has a number displayed (not flashing) – No new
messages. Shows total of old messages.
•MESSAGES COUNTER has a flashing number displayed – There are
new messages. Shows total of new and old messages.
•MESSAGES COUNTER has bars (- -) – Answerer is off.
•MESSAGES COUNTER has an “
F
” flashing on the display – Memory
is full.
•MESSAGES COUNTER has a “
CL
” flashing on the display – Clock is not
set since power up.
• MESSAGES COUNTER has a “
- -
- -
--
” flashing on the display – OGM
playing / recording or MEMO recording.
•MESSAGES COUNTER has a “
An
” flashing on the display – Answering
incoming calls and recording an incoming call.
•MESSAGES COUNTER has “
LA
” – The answering machine is being
accessed remotely.
NOTE: While the messages are playing, the MESSAGES COUNTER will
display the messages in the order they were received.
47
MAILBOX INDICATOR
The mailbox indicators tell you if you have any messages in each
individual mailbox and if they are new or old.
Mailbox indicator is on – There are no new messages, but there are old ones.
Mailbox indicator is off – There are either no messages or the answerer is
turned off.
Mailbox indicator is flashing – There are new messages.
MESSAGE PLAYBACK
The base mailboxes play/stop 1, play/stop 2 and play/stop 3 buttons let
you know when you have new messages. To play messages, press the
corresponding play/stop 1 or 2 or 3 button. While a message is playing,
you may do the following:
1. Press the corresponding play/stop 1 or 2 or 3 button to stop
message playback.
2. Press rew button once to re-play the current message.
3. Press rew button twice to review previous messages.
4. Press skip button to skip to the next message.
5. Press the delete button to erase the current message.
ERASING MESSAGES
You may erase messages in the following three ways:
To Erase a Message While it is Playing
1. Press and release the respective mailbox button (play/stop 1 or play/
stop 2 or play/stop 3).
2. Press rew or skip button to select and play the message you want
to erase.
3. Press the delete button, the current message is erased, and the next
message plays.
48
To Erase All Previously Played Messages in a Mailbox
1. Make sure the phone is OFF (not in talk mode).
2. Press and hold the delete button, the answerer will announce “
TO
ERASE MESSAGES, PRESS MAILBOX
”.
3. Press the mailbox button (play/stop 1 or play/stop 2 or play/stop 3).
4. The answerer will announce “
ALL MESSAGES ERASED MAILBOX X
”,
followed by a confirmation tone.
To Erase a message from the handset:
1. Press the flash/answerer button on the handset.
2. Press the play/stop (key 2) followed by the mailbox number on the
handset (eg. Press key 2 and then key 3).
3. Press the erase (key 0) on the handset to erase a message
during playback.
NOTE : Erased messages cannot be restored.
MEMO
Use the memo feature to leave a message for yourself.
1. Press the memo button, the answerer will announce “
TO RECORD,
PRESS AND HOLD MAILBOX
”.
2. Press and hold the mailbox button (play/stop 1 or play/stop 2 or
play/stop 3).
3. Begin speaking after you hear “
RECORD MESSAGE
” and the beep.
4. Release the mailbox button when you are finished recording the memo.
SCREENING CALLS
This feature allows you to screen incomings calls by using the handset to
listen as the caller leaves a message.
1. Press the flash/answer button on any handset after the answerer
answers to the external call.
2. Press the answer button again to exit.
49
3. During call screening, you can press talk/callback button or pick up the
extension phone to connect to the external caller and start the
conversation. The answerer stops recording once you answer the call.
REMOTE ACCESS
This section explains how to use the cordless handset, or any touch-tone
phone, to access the answering system with your 4-digit security code.
TIPS: If you access the answering system with any other touch-tone phone, a
voice menu guides you through the steps.
ACCESSING THE ANSWERING SYSTEM WITH THE CORDLESS HANDSET
1. Make sure your handset is in standby mode.
2. Press the ans flash/answer button to access the answering system. The
display shows “
ANSWERER REMOTE ACCESS
”.
3. Follow the voice menu to use the answering system’s remote functions.
4. Press vol + or vol – button during message playback to adjust the
volume of earpiece or speaker.
5. At any time, you can press the exit button or the flash/answer button to
abort the current operations and return to the standby mode.
ACCESSING THE ANSWERING SYSTEM FROM ANOTHER LOCATION
You can access your answering system from any touch-tone
phone by entering your 4-digit security code after you hear the
outgoing announcement.
1. Dial the phone number to which the answering system is connected.
2. When the answering system answers enter the security code after you
hear the tone.
3. Follow the voice menu to use the answering system’s remote functions.
MEMORY FULL
When you access your answering system remotely, and the answering
system’s memory is full, the system answers after 10 rings, beeps, and
awaits for you to enter the 4-digit security code. You have 10 seconds to
50
enter the security code before the pone disconnects. You should erase
some of the old messages so the system can record new messages.
NOTE: The unit also answers after the 10th ring if it is turned off. To access the
answering machine, enter your 4-digit security code after you hear the beep.
The remote feature enables you to perform the following function:
To Press this Button
Replay the current message press 1 once
Review the previous message press 1 twice
Play back messages 2 + mailbox number
Stop message playback 2
Erase messages 0
(during message playback)
Skip message 3
Turn answering system off/on 4
Review voice menu options 7
REPLACING THE BATTERY
CAUTION: To reduce the risk of fire or personal
injury, use only the battery listed on the accessory
order form, which is compatible with this unit.
1. Make sure the telephone is OFF before you
replace battery.
2. Remove the battery compartment door.
3. Disconnect the cord attached to the battery pack
from the jack inside the battery compartment and
remove the battery pack from the handset.
51
4. Insert the new battery pack and reconnect the battery plug.
5. Put the battery compartment door back on.
6. Place handset in the base to charge. If you don’t charge the handset
battery properly (for 16 hours) when you first set up the phone and/or
when you install a new battery pack, the battery’s long-term
performance will be compromised.
NOTE : If the battery is not installed in the handset or the battery pack is not
properly connected inside the compartment, the handset displays “NO
BATTERY” when it is placed on the cradle.
BATTERY SAFETY PRECAUTIONS
•Do not burn, disassemble, mutilate, or puncture. Like other batteries of
this type, toxic materials could be released which can cause injury.
•Keep batteries out of the reach of children.
•Remove batteries if storing over 30 days.
HEADSET INSTALLATION
CONNECTING AN OPTIONAL HEADSET TO THE HANDSET
For hands free conversation, remove the rubber
cap, insert the headset plug into the headset jack.
Adjust the headset to rest comfortably on the ear.
Move the microphone to approximately 2 to 3
inches from your mouth.
•Press the talk/callback button to answer or
place a call while using the headset.
NOTE : The headset is packaged with model
25826GC only.
Headset jack
Headset plug
CID/VOL
call
back
talk spk
skiprew
play
stop
exit pause
erase
format answer
flash
mute
prog
select
delete
redial
int
conf
memory
wxyz
9
mno
6
def
3
abc
2
jkl
5
tuv
8
pqrs
7
ghi
4
1
*
wxyz
0#
52
DISPLAY MESSAGES
The following indicators show the status of a message or of the unit.
INCOMPLETE DATA Caller information has been interrupted during
transmission or the phone line is excessively noisy.
ENTER NAME Prompt telling you to enter the name in one of the
50 memory locations. (NOTE: The memory records
in the cordless handsets do not overlap and cannot
be shared. Each handset has 50 individual
memory locations.)
DELETE ALL? Prompt asking if you want to erase all
Caller ID records.
DELETE CALL ID? Prompt asking if you want to erase the current
Caller ID record that is shown on the display.
DELETE? Prompt asking if you want to erase one of the 50
numbers stored in the phone’s outgoing memory.
END OF LIST Indicates that there is no additional information in
Caller ID memory.
UNKNOWN NAME/ The incoming call is from an area not serviced by
CALLER/NUMBER Caller ID or the information was not sent.
PAGING/PAGING Someone has pressed the page/intercom button on
FROM the base or handset.
BLOCKED NUMBER The caller’s number is blocked from transmission.
REPT Repeat call message. Indicates that a new call from
the same number was received more than once.
53
PRESS TALK KEY Prompt telling you that a CID number cannot be
formatted and you may only use the talk button to
dial back the CID number.
NO DATA No Caller ID information was received.
NO BATTERY Indicates the battery is not installed in the handset or
the battery pack is not properly connected in
the compartment.
LOW BATTERY Indicates the battery needs to be charged.
LINE IN USE Displays on handset when the telephone line is in use.
LONG DISTANCE Indicates CID record is from a long distance call.
NO CALLS Indicates there are no CID records in memory.
NEW CALLS XX XX represents the number of new CID records
not reviewed.
ENTER TEL NUMBR Prompt telling you to enter a telephone number in
one of the 50 memory locations.
BLOCKED CALL Indicates CID information is blocked
from transmission.
BLOCKED NAME The caller’s name is blocked from transmission.
HANDSET SOUND SIGNALS
Signal Meaning
A long warbling tone (with ringer on) Signals an incoming call
Three short beeps Page signal
One short beep (every 7 seconds) Low battery warning
54
TROUBLESHOOTING GUIDE
TELEPHONE SOLUTIONS
No dial tone
•Check or repeat installation steps.
•Make sure base power cord is connected to a working electrical outlet.
Make sure the telephone line cord is connected to the base and the
modular phone jack.
•Connect another phone to the same jack; if there is still no dial tone,
the problem might be your wiring or local service.
•The cordless handset may be out of range of the base. Move closer to
the base.
•Make sure the battery is properly charged (16 hours).
•Make sure the battery pack is installed correctly.
•Did the handset beep when you pressed the talk/callback button? Did
the charge/in use indicator on the base turn on? The battery may need
to be charged.
Handset does not ring
•Make sure the handset ringer setting is on and is programmed to HI.
•The cordless handset may be out of range of the base. Move closer to
the base.
•You may have too many extension phones on your line. Try unplugging
some phones.
•Check for dial tone.
You experience static, noise, or fading in and out
•The cordless handset may be out of range of the base. Move closer to
the base.
55
•Relocate the base. Make sure base is not plugged into an outlet with
another household appliance.
•Charge the battery.
Unit beeps
•Place the handset in the cradle for 20 seconds. If it still beeps, charge
battery for 16 hours.
•Clean charging contacts on cordless handset and base/charge cradle
with a soft cloth or an eraser.
•See solutions for “No dial tone.”
•Replace the battery.
Memory Dialing doesn't work
•Did you program the memory correctly?
•Did you follow proper dialing sequence?
Unit shows
SEARCHING
or
OUT OF RANGE
•Unplug the handset battery and plug it in again after 1 minute.
•Unplug the base power converter and plug it in again after 1 minute.
Unit locks up and no communication between the base and cordless handset
•Unplug the power converter from the electrical outlet and the back of
the base/charge cradle. Remove the handset battery. Wait for 30
seconds and plug the power converter back into the base/charge cradle
and electrical outlet. Reconnect the battery and charge for 16 hours.
Re-register the handset.
Cannot register extra handset
. During registration, press and hold the page/int button on the base of Model 25895 or 
the page button on the base of Model 25825 or 25826 until you hear a long beep. 
Then follow the steps listed in session HANDSET REGISTRATION.
. If no long beep tone is emitted but in use/charging LED is blinking indicates that the 
base can no longer be in the registration mode. It has fully occupied with the 
maximum number of handsets (i.e., 4). To register a new handset, you need to do a 
Global De-registration. Please follow the steps listed at the end of the 
session HANDSET DE-REGISTRATION.
56
CALLER ID SOLUTIONS
No Display
•Charge or replace the battery.
•Make sure that the unit is connected to a non-switched electrical outlet.
Disconnect the power supply cord from the base/charge cradle and
reconnect it.
Caller ID Error Message
•The unit displays this message if it detects anything other than valid
Caller ID information during the silent period after the first ring. This
message indicates the presence of noise on the line.
No Caller ID
•You must be subscribed to Caller ID service from your local telephone
company to receive Caller ID records.
BATTERY SOLUTIONS
If you experience any of the following problems, even after fully
recharging the battery, you may need to replace the battery pack:
•Short talk time
•Poor sound quality
•Limited range
• Charge indicator fails to light when the handset is placed in the base or
charge cradle.
57
GENERAL PRODUCT CARE
To k eep your unit working and looking good, follow these guidelines:
•Avoid putting the phone near heating appliances and devices that
generate electrical noise (for example, motors or fluorescent lamps).
•DO NOT expose to direct sunlight or moisture.
•Avoid dropping the handset, as well as other rough treatment to
the phone.
•Clean the phone with a soft cloth.
•Never use a strong cleaning agent or abrasive powder because this
will damage the finish.
•Retain the original packaging in case you need to ship the phone at a
later date.
•Periodically clean the charge contacts on the handset and base with a
soft, clean cloth.
CAUSES OF POOR RECEPTION
•Aluminum siding.
•Foil backing on insulation.
•Heating ducts and other metal construction that can shield radio signals.
•You’re too close to appliances such as microwaves, stoves,
computers, etc.
•Atmospheric conditions, such as strong storms.
•Base is installed in the basement or lower floor of the house.
•Base is plugged into AC outlet with other electronic devices.
•Baby monitor is using the same frequency.
•Handset battery is low.
•You’re out of range of the base.
58
SERVICE
If trouble is experienced with this equipment, for repair or warranty
information, please contact customer service at 1-800-448-0329. If the
equipment is causing harm to the telephone network, the telephone
company may request that you disconnect the equipment until the
problem is resolved.
This product may be serviced only by the manufacturer or its authorized
service agents. Changes or modifications not expressly approved by
ATLINKS USA, Inc. could void the user’s authority to operate this product.
For instructions on how to obtain service, refer to the warranty included in
this guide or call customer service at 1-800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the
date this product was purchased or received as a gift. This information will
be valuable if service should be required during the warranty period.
Purchase date ________________________________________________
Name of store ________________________________________________
59
INDEX
A
Accessing the Answering System from
Another Location 49
Accessing the Answering System with the
Cordless Handset 49
Accessory Order Form 61
Adjusting the Volume 46
Answering a Call with the Handset 27
Answering a Call with the Handset
Speakerphone 27
Answering System Set Up 42
Area Code 15
Assigning, Reviewing, Changing or Deleting a
VIP Melody 18
Auto Standby 28
B
Battery Safety Precautions 51
Battery Solutions 56
Before You Begin 8
C
Call Timer 27
Call Waiting 28
Caller ID (CID) 37
Caller ID Solutions 56
Causes of Poor Reception 57
Chain Dialing from Memory 36
Charge/in use Indicator 26
CID Errors 42
Connecting an Optional Headset to the
Handset 51
D
Default 25
Deleting All CID Records 41
Deleting the CID Record Showing in the
Display 40
Dialing a CID Number 39
Dialing a Stored Number with the Handset 36
Digital Security System 6
Display Messages 52
E
Equipment Approval Information 2
Erasing Messages 47
Erasing Your Recorded Outgoing
Announcement 44
Exit 29
F
FCC RF Radiation Exposure Statement 2
Flash 28
G
General Product Care 57
H
Handset and Base Layout 7
Handset and Handset Paging 29
Handset Deregistration 23
Handset Name 14
Handset Registration 21
Handset Sound Signals 53
Handset Speakerphone 26
Headset Installation 51
Hearing Aid Compatibility (HAC) 2
I
Important Installation Guidelines 9
Inserting a Pause in the Dialing Sequence 34
Installation 9
Installing the Phone 9
Intercom 32
Interference Information 2
Introduction 5
L
Language 14
Limited Warranty 62
60
M
Mailbox Indicator 47
Making a Call 27
Making a Call with the Handset
Speakerphone 27
Making an Intercom Call 32
Memo 48
Memory 12
Memory Full 49
Message Counter 46
Message Playback 47
Mute 31
P
Paging 29
Paging from Base/Group Paging 29
Parts Checklist 8
Programming the Telephone 12
R
Receiving an External Telephone Call During an
Intercom Call 33
Receiving an Intercom Call 33
Receiving and Storing CID Records 38
Recording the Outgoing Announcement 43
Redial 28
Remote Access 49
Replacing the Battery 50
Returning to the Default Outgoing
Announcement 44
Reviewing, Changing or Deleting Stored
NumbersTo Review 35
Reviewing CID Records 38
Reviewing the Outgoing Announcement 44
Ringer Melody 17
Ringer Setting Shortcut 26
Ringer Volume 16
S
Screening Calls 48
Service 58
Setting the Day and Time 45
Setting the Rings to Answer 45
Setting the Security Code 20
Storing a Name and Number in Memory 12
Storing a Redial Number 34
T
Telephone Basics 26
Telephone Jack Requirements 8
Telephone Solutions 54
The remote feature enables you to perform the
following function 50
To Change 35
To Delete 35
To Erase a message from the handset 48
To Erase a Message While it is Playing 47
To Erase All Previously Played Messages in a
Mailbox 48
To Review/Change/Delete 20
To Set the Day 45
To Set the Hour 45
To Set the Minutes 45
Toll Saver 45
Transferring Calls 30
Transferring CID Records to Memory 39
Troubleshooting Guide 54
Turning the Answering System Off and On 42
U
Using Intercom or Conference with
External Calls 33
V
VIP Melody 18
Voice Instructions 43
Volume Control 31
W
Wall Mounting the Base 12
61
Please make sure that this form has been filled out completely.
A
CCESSORY
O
RDER
F
ORM
CUSTOMER: CUT ALONG DOTTED LINE. ✂
*Prices are subject to change without notice.
Total Merchandise.........................................$_______________
Sales Tax........................................................$_______________
We are required by law to collect the appropriate sales tax for each
individual state, county, and locality to which the merchandise is being
sent. Duties will apply for shipments to Canada.
Use VISA or Master Card or Discover preferably. Money order or check must
be in U.S. currency only. No COD or Cash. All accessories are subject to
availability. Where applicable, we will ship a superseding model.
Shipping/Handling....................................... $_______________
Total Amount Enclosed.................................$_______________
Mail order form and money order or check (in U.S. currency)
made payable to Thomson to:
Thomson
Mail Order Department
P.O. Box 910139
Dallas, TX 75391-0139
Name_______________________________________________________
Address_____________________________________ Apt.____________
City ________________________State________ ZIP_________________
Daytime Phone Number ( )________________________________
$5.00
____________________________________________________________________
Authorized Signature
My card expires:
Copy the number above your
name on the Master Card
For credit card purchases
Your complete charge card number, its expiration date and your
signature are necessary to process all charge card orders.
Copy your complete account number from your VISA card.
My card expires:
Copy your complete account number from your
Master Card or Discover.
To order, call 1-800-338-0376 (for accessories only) or complete this order form.
DESCRIPTION
AC power adapter
MODEL NUMBER TOTAL
PRICE*
Replacement Handset Battery
Headset
5-2620
5-2628
5-2601
QTY.
White
Black
5-2627
5-2638
Model 25825
55903980 (Rev. 0 E/S)
04-09
Printed in China
ATLINKS USA, Inc.
101 West 103rd Street
Indianapolis, IN 46290
© 2004 ATLINKS USA, Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
LIMITED WARRANTY
What your warranty covers:
•Defects in materials or workmanship.
For how long after your purchase:
•One year, from date of purchase. (The warranty period for rental units begins with the first rental or 45 days from date
of shipment to the rental firm, whichever comes first.)
What we will do:
•Provide you with a new or, at our option, a refurbished unit. The exchange unit is under warranty for the remainder of
the original product’s warranty period.
How you get service:
•Properly pack your unit. Include any cables, etc., which were originally provided with the product. We recommend
using the original carton and packing materials.
•”Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the product is within the
warranty period, must be presented to obtain warranty service.” For rental firms, proof of first rental is also required.
Also print your name and address and a description of the defect. Send via standard UPS or its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
•Pay any charges billed to you by the Exchange Center for service not covered by the warranty.
•Insure your shipment for loss or damage. ATLINKS accepts no liability in case of damage or loss.
•A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
•Customer instruction. (Your Owner’s Manual provides information regarding operating instructions and user controls.
Any additional information, should be obtained from your dealer.)
•Installation and setup service adjustments.
•Batteries.
•Damage from misuse or neglect.
•Products which have been modified or incorporated into other products.
•Products purchased or serviced outside the USA.
•Acts of nature, such as but not limited to lightning damage.
Product Registration:
•Please complete and mail the Product Registration Card packed with your unit. It will make it easier to contact you
should it ever be necessary. The return of the card is not required for warranty coverage.
Limitation of Warranty:
•THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY ATLINKS
USA, INC., ITS AGENTS, OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF
THIS WARRANTY.
•REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
ATLINKS USA, INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE
STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE
WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
•Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations on how
long an implied warranty lasts so the above limitations or exclusions may not apply to you.
•This warranty gives you specific legal rights, and you also may have other rights that vary from state to state.
If you purchased your product outside the USA:
•This warranty does not apply. Contact your dealer for warranty information.

Navigation menu
