Timi Personal Computing 161301 Intel Dual Band Wireless-AC 8265 User Manual Label

User Manual

FCC/IC Label & Location for Intel Model 8265D2W

FCC: Per KDB 784748 the marking may be placed in the user manual if the

device is unquestionably too small to be readable (smaller than 4 6 pt font).

IC: Per RSS GEN 5.2  The label text shall be legible without the use of

magnification and if too small to meet this condition the label information may

be included in the user manual.

The 8260D2W is considered to meet this criteria since the module size is 12mm

x 16mm and 4pt font is the largest that can be used for module labeling which

requires magnification for clear viewing.

16mm

12mm

FCC & IC IDs will be displayed in the User Guide as shown

Only manufacturer ID & model number will

appear on module for identification.

19mm

Model 8265D2W, FCC ID: PD98265D2

Model 8265D2W, IC: 1000M 8265D2

FCC

ID:2ALT9161301

FCC

Lable

Location

for

Model

8265D2W
