USERS MANUAL
Unpacking
Inserting the batteries
Installing the devices
Connecting a receiver
Turning on the PC
Setting ID Channel
Wireless Mouse
Wireless Keyboard
Notice
Troubleshooting
Make sure that items below are all in the box before you use.
Wireless Mouse
(2 x AA size alkaline batteries)
Wireless Mouse/USB Cable
(2 x AA size alkaline batteries)
* Depending on your model, components may vary and look different than
those pictures.
2
Type A Type B
Wireless Keyboard
(2 x AA size batteries)
Receiver
3
Place the wireless mouse/keyboard upside down and remove the cover of each
device off.
Verify +/- directions of the batteries and insert them in each wireless device.
Put on the cover of the wireless mouse and wireless keyboard.
battery cover
battery
For wireless mouse
battery cover
battery
For wireless keyboard
To use wireless keyboard and wireless mouse, you need to insert 2 AA size
alkaline batteries beforehand.
1
2
3
1
2
3
Do not use rechargeable batteries.
Only use the same type of batteries and replace them at the same time after using
them up.
USB cable only supplies the power to wireless mouse when the mouse has no batteres
in it. tharefore the receiver must be always connected to your PC to transmit its radio
frequency.
On/Off slide button
Wireless Mouse/Keyboard User’s Guide
4
USB Connector
USB cable
Wireless mouse(Type B)
Set the On/Off slide button of wireless mouse to ‘On’ after you finish inserting
batteries.
Receiver
5
Connect the receiver to USB connector.
You can use any of USB connectors.
Connecting a receiver
Turn on the computer. Check that each wireless device is properly worked with a
receiver.
Turning on the PC
You set one ID channel for one device before you use wireless keyboard and wireless
mouse. If there are more than 2 wireless mice or keyboards with same ID channel,
they might be interfered each other. Therefore you must set the different ID channels
for each wireless device.
Wireless Mouse
1
Press Connect button of the receiver for
1 or 2 seconds.
2
While the receiver indicator is on, press
the ID change hole of wireless mouse
for a couple of seconds using tool like a
pen within 15 seconds before the light
is off.
3
If ID setting is changed successfully,
the receiver indicator blinks.
6
Receiver indicator
ID change hole
Receiver indicator
Connect button
Wireless Keyboard
1
Press Connect button of the receiver for
1 or 2 seconds.
2
While the receiver indicator is on, press
the connect hole of wireless keyboard
for a couple of seconds using tool like a
pen within 15 seconds before the light
is off.
3
If ID setting is changed successfully,
the receiver indicator blinks.
Receiver indicator
Receiver indicator
Connect button
Connect hole
Wireless Mouse/Keyboard User’s Guide
7
8
When your PC is switched to power-save mode, just click any button or wheel
on your wireless mouse.
Set On/Off slide button of wireless mouse to ‘Off’ while you are not using a
mouse for a while.
Wireless optical mouse can move faster than any other mouse by 800dpi
resolution.
You can adjust the speed of its move by following the instructions.
: Click Start, choose Control panel and double-click Mouse.
Make sure that you place the optical mouse on a mouse pad or white sheet
of paper. Reflective surface, glass and other see-through surfaces inhibit
the ability of optical sensor.
Set the ID channel differently by every devices when you use more than 2
devices in one space. They can move to same directions at the same time.
Because of interference of radio frequency, each wireless device must be
placed in the distance of 2m.
Batteries are empty after 6 month for wireless keyboard and 3 month for
wireless mouse on average. Prepare for spare batteries for quick replacing.
This manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this
equipment. Such modifications could void the user’s
authority to operate the equipment.
9
The receiver is not properly connected to USB port on your computer.
Plug the receiver to another USB port and restart your computer.
Wireless Keyboard and mouse do not respond to move.
Place the mouse on a mousepad or white sheet of paper.
Mouse cursor moves too slow or functions badly.
Wireless keyboard and mouse batteries are low or empty.
Replace the two AA alkaline batteries in the wireless keyboard and mouse.
Wireless keyboard and mouse do not work properly.
