Toplink Technology Development TOP-MS04 Wireless module User Manual
Shenzhen Toplink Technology Development CO.,LTD Wireless module
user manual
Shenzhen Toplink Technology.,Ltd
1 / 6
| ADD:2F,BldgB,JindingshengIndustrial Park, DaHe Road, Longhua,Shenzhen
Call：0755-85225016/89345781 Fax：0755-28471983
User Manual
Product Name： Wireless module
Model Number: TOP-MS04
Shenzhen Toplink Technology.,Ltd
2 / 6
| ADD:2F,BldgB,JindingshengIndustrial Park, DaHe Road, Longhua,Shenzhen
Call：0755-85225016/89345781 Fax：0755-28471983
1.Introduction
TOP-MS04 is a WLAN module supporting IEEE 802.11b/g/n standards with 4-pin
connector supporting USB2.0 interface. This is a low cost compact WLAN module
designed in the product with embedded system for the wireless connectivity.
Scope:
TOP-MS04 WLAN module is designed to operate in 2.4GHz ISM frequency band it
applies a highly integrated MAC/BBP and RF single chip RT5070 with 150Mbps
PHY rate supporting it fully complies with 802.11b/g/n draft 3.0 and
802.11b/g/n feature
z 802.11b:1,2,5.5,11Mbps;
z 802.11g:6,9,12,18,24,36,48,54Mbps
z 802.11n:(20MHz)MCS0-7,Support up to 72Mbps
z 40MHz) MCS0-7,Support up to 150Mbp
z OFDM,Peak rate 150Mbps,Peak throughput 90Mbps.
z Security support for 64/128 WEP,WPA,WPA2,TKIP,AES
z Operates in 2.4GHz frequency bands. Power Management
z Antenna configuration:I-PEX receptacle for external antenna/
Built-in On Board
2.Product
Information
Standards
IEEE802.11b/g&802.11n(1T1R mode)
Operating
Frequency
USA(FCC):2.412GHz～2.462GHz(channel 1–11)ISM band
Europe (CE):2.412GHz～2.472GHz(channel 1–13)ISM band
Protocols
802.11b: CCK, QPSK, BPSK, 802.11g/n:OFDM
Antenna
External Antenna via an I-PEX receptacle/Built-in On Board
Security
WPA/WP2,64/128/152-bit WEP, WPS
Shenzhen Toplink Technology.,Ltd
3 / 6
| ADD:2F,BldgB,JindingshengIndustrial Park, DaHe Road, Longhua,Shenzhen
Call：0755-85225016/89345781 Fax：0755-28471983
Specification Overview
Software
and
syste Information
3.Temperature
Operating
Temperature
Continuous reliable operation in ambient temperature:-20ºC to+45ºC
Storage
Temperature
The product is not damaged or degraded when keeping in -20ºC to +85ºC
ReceiveSensitivit
y
11b:-86dBm@11Mbps;11g:-72dBm@54Mpbs.
802.11n:(HT20),-68dBm@MSC7,(HT40),-64dBm@MSC7
Operating
Voltag
e
5.0VDC±5%(or3.3VDV±5%upon special requirement)
Operating
Curren
t
<110mA at 5.0V DC input.
Bus
Interface
USB 2.0/USB1.1
USB
Interface
USB2.0
Antenna
Impedanc
e
I-PEX receptacle for external antenna/Built-in onBoard
Operation
System
CPU
Supplier
Driver
Linux
2.4/2.6
ARM,
MIPSII
Available
Windows
2000/XP/Vista
X86
Platform
Available
Windows
CE
5.0/6.0
ARM,
MIPSII
Available
Mac
OS
X
10.3/10.4/10.5/10.6
N/A
Available
Shenzhen Toplink Technology.,Ltd
4 / 6
| ADD:2F,BldgB,JindingshengIndustrial Park, DaHe Road, Longhua,Shenzhen
Call：0755-85225016/89345781 Fax：0755-28471983
4.Humidity
Operating
Humidity
Conditions
The product is capable of continuous reliable operation when subjected
to relative humidity in the range of 20% to 80% (non-condensing)
Non-Operating
Humidity
Conditions
(including
warehouse)
The product is not damaged or degraded when kept in the relative humidity
range from 20% to 80%
5.Disclaimer
These MaterIals And Information Are Provided“AS IS” Without.Warranty of Any Ki
nd, Either Express or Implied, Including But Not. Limited To, The Implled Warranties
Of Merchantability, Fitness For A. particular Purpose or Non-infringement.
We uses reasonable efforts to include accurate and up-to-date information on th
is document.it does not, however, make any representations as to its accuracy or co
mpleteness of the.information, text, graphics, links or other items contained within
these materials. Your use ofthis Document is at your own risk. TOPLINK, its suppliers
, and other parties involved in.creating and delivering this Document’s contents shall
not be liable for any special, indirect,incidental, or consequential damages, includin
g without limitation, lost revenues or lost profits.
Shenzhen Toplink Technology.,Ltd
5 / 6
| ADD:2F,BldgB,JindingshengIndustrial Park, DaHe Road, Longhua,Shenzhen
Call：0755-85225016/89345781 Fax：0755-28471983
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two condi
tions: (1) this device may not cause harmful interference, and (2) this device must accept any inte
rference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could v
oid the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital de
vice, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec
tion against harmful interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructio
ns, may cause harmful interference to radio communications. However, there is no guarantee tha
t interference will not occur in a particular installation. If this equipment does cause harmful inter
ference to radio or television reception, which can be determined by turning the equipment off a
nd on, the user is encouraged to try to correct the interference by one or more of the following m
easures:
‐ Reorient or relocate the receiving antenna.
‐ Reorient or relocate the receiving antenna.
‐ Reorient or relocate the receiving antenna.
‐Consult the dealer or an experienced radio/TV technician for help important announcement
Important Note:
Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
This device is intended only for OEM integrators under the following conditions:
1. The transmitter module may not be co-located with any other transmitter or antenna,
As long as the three conditions above are met, further transmitter testing will not be required.
However, the OEM integrator is still responsible for testing their end-product for any additional
compliance requirements required with this module installed.
Important Note:
In the event that these conditions cannot be met (for example co-location with another
transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be
used on the final product. In these circumstances, the OEM integrator will be responsible for
re-evaluating the end product (including the transmitter) and obtaining a separate FCC
authorization.
End Product Labeling
The final end product must be labeled in a visible area with the following" Contains FCC ID:
2AATNTOP-MS04 ".
Shenzhen Toplink Technology.,Ltd
6 / 6
| ADD:2F,BldgB,JindingshengIndustrial Park, DaHe Road, Longhua,Shenzhen
Call：0755-85225016/89345781 Fax：0755-28471983
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user’s manual of the end product which integrates this
module.
The end user manual shall include all required regulatory information/warning as show in this
manual.
