Users Manual

KING WINS TECHNOLOGY CO.,LTD.

UserManual





Name：RF2.4GRemoteController

ModelNo.：TMRCD200TX

&

Name：RF2.4GUSBDongle

ModelNo.：TMRCD200RX



TradeMark：TOSHIBA



Version：1.0

KING WINS TECHNOLOGY CO.,LTD.

ProductProfile

1. RF2.4GRemoteController.

2. RF2.4GUSBDongle.



KING WINS TECHNOLOGY CO.,LTD.

◎ElectricalCharacteristic



USBDongle

Transmitrate250KHzbps

Frequency2404.0MHz–2480.0MHz

Powerout‐18dBm‐0dBm

FunctionHID‐compliantdevice,

ModulationGFSK



Controller

Transmitrate250KHzbps

Frequency2404.0MHz–2480.0MHz

Powerout‐18dBm‐0dBm

Function2.4GWirelessTransmission

ModulationGFSK

KING WINS TECHNOLOGY CO.,LTD.

◎Thekeyvalueisdefaultasbelow:

ButtonFunction

RFCode

Usage

Page(Hex)

Usage

ID(Hex)

Home(F7)073C

Back(F2)073B

Menu(F3)073C

Up0752

Left0750

Right074F

Down0751

Ok(F6)073F

VolumeDec(F4)073D

VolumeInc(F5)073E

KING WINS TECHNOLOGY CO.,LTD.

◎FUNCTIONDESCRIPTION

1.TheremotecontrollertransmitsRFsignaltoUSBreceiverdongle.

2.USBDongle

ThedongleisdefinedasstandardHIDdevice.WhenitplugintoPCUSBport,the

USBDonglewillreceiveRFsignalfromremotecontrollertransmitter.

3. Pair

■PowerontheController,press“ ”continuouslythenpress

“”buttons,pairmodeison.

■PlugUSBdongleintoandwaitabout3seconds,thenpressanykeyfunction,

thenpairingissuccessful.

◎POWERCONSUMPTION

1.Normalmode

WhenUseroperatesthecontroller,it’sinnormalmode;powerconsumption

islessthan20mW.

2.Sleepingmode

Ifuserhasn’tusedthecontrollerfor1SECS,itwillentersleepingmode,

powerconsumptionislessthan0.1mW.Usercanpressanybuttontowakeit

up.



KING WINS TECHNOLOGY CO.,LTD.

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB

digitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedto

providereasonableprotectionagainstharmfulinterferenceinaresidential

installation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergy

and,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmful

interferencetoradiocommunications.However,thereisnoguaranteethat

interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescause

harmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby

turningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe

interferencebyoneormoreofthefollowingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe

receiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



Caution:Anychangesormodifytothisdevicenotexplicitlyapprovedby

manufacturercouldvoidyourauthoritytooperatethisequipment.



Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe

followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)

thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay

causeundesiredoperation.



KWSdeclaresthatthisRadio‐Frequencyperipheralisincompliancewiththeessential

requirementsandotherrelevantprovisionsofDirective1999/5/EC.


