Toy State 90440F27 Hyper Racer R/C Drift Rod User Manual
Toy State International Ltd. Hyper Racer R/C Drift Rod
User Manual
4
For questions, e-mail our Consumer Service Dept. at
consumerservice@toystate.com
Or Call 1-877-473-8015
www.toystate.com
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
“Modifications not authorized by the manufacturer may void users authority to operate the device.”
This toy and all accessories need to be periodically examined for potential hazards and any potentially hazardous
parts be repaired or replaced.
MANUFACTURER’S NOTE
ATTENTION PARENTS
CLEANING AND MAINTAINING
ENG
This radiocommunication device complies with all the requirements of Industry Canada Standard RSS-310.
Operation is subject to the follwing two conditions: 1). This device may not cause harmful interference. 2). This device must accept any
interference received, including interference that may cause undesired operation.
Field Strength and measurement distance: 27.195MHz - 60.49 dBµ V/m at 3 meter. 49.890MHz - 61.61 dBdB V/m at 3 meter.
This device complies with the limits of standard RSS-310 issue 1.
INDUSTRY CANADA NOTICE: CANADA ONLY
Brush areas where dirt and dust
get trapped.
Wipe body off with a soft rag or tact cloth. Do not clean vehicle with chemicals or water.
MADE IN SHENZHEN, CHINA
TOY STATE INTERNATIONAL LIMITED
66 MODY ROAD, KOWLOON, HONG KONG
IN THE INTEREST OF BETTER QUALITY AND VALUE, WE ARE CONSTANTLY IMPROVING AND UPDATING OUR PRODUCTS. CONSEQUENTLY, PICTURES IN THIS
INSTRUCTION SHEET MAY SOMETIMES DIFFER FROM THE MODEL ENCLOSED.
WARNING: Not suitable for children under 36 months
due to small parts. Choking hazard.
HOT WHEELS and associated trademarks and
trade dress are owned by, and used under license
from Mattel. ©2014 Mattel. All Rights Reserved.
90440_HWrc_IM_03212014_OP_FAR.indd 1 14/4/14 5:11 pm
www.toystate.com
90440_HWrc_IM_03212014_OP_FAR.indd 2 14/4/14 5:11 pm
CONTROLLER VEHICLE
Batteries Not Included Included
RADIO CONTROL
HYPER RACER
6+
#90440
OWNER’S MANUAL
3 x AA/LR03 6 x AA/LR6
90440_HWrc_IM_03212014_OP_FAR.indd 3 14/4/14 5:11 pm
1
NOTE: For best performance, always use alkaline batteries only.
CAUTION
Important Battery Information
• Dispose of batteries properly.
• Do not dispose of batteries in fire.
• Use only batteries of the type recommended.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Remove batteries from R/C vehicle and controller if vehicle will not be used for a long period of time.
GETTING STARTED
Remove the R/C vehicle and controller from the package. Insert batteries into the R/C vehicle and controller to begin full function play
(see “Battery Installation” section for further details).
ENG
CONTROLLER
1. To remove battery cover, loosen screw to open.
2. Insert 3 “ AA ” batteries into the controller. Be
sure the + and – are properly matched.
R/C VEHICLE
1. To remove battery cover, loosen screws to open.
2. Insert 6 “AA” batteries into the vehicle. Be sure
the + and – are properly matched.
BATTERY INSTALLATION
TO REPLACE THE BATTERIES
LOOSEN SCREW TO OPEN
LOOSEN SCREW TO OPEN
TO REPLACE THE BATTERIES
LOOSEN
SCREW
TO OPEN
1.5V
1.5V
1.5V
1.5V
1.5V
1.5V
90440_HWrc_IM_03212014_OP_FAR.indd 4 14/4/14 5:11 pm
After play, always turn vehicle to “DEMO” mode. Remove batteries from controller and R/C
vehicle when not in use or when storing. Leakage may occur and cause damage if left for a long
period of time.
Turbo Mode
Color Shifting Action
Turn
Left & Right
Drive
Forward &
Reverse
Turns In All Directions! Accelerate With Turbo Boost!
Color Shifting Action!
ENG
2
OPERATING R/C VEHICLE
ENG
Adjust Trim Switch on bottom
of R/C vehicle to ensure
precision driving
Turn PLAY/DEMO switch located
on bottom of R/C vehicle to the
PLAY position (as shown)
PLAY DEMO
90440_HWrc_IM_03212014_OP_FAR.indd 5 14/4/14 5:11 pm
TROUBLESHOOTING AND CARE FOR R/C VEHICLE
3
R/C VEHICLE
DOES NOT MOVE
• Are the + and – contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned to play?
• Are the batteries weak or out of power?
R/C VEHICLE
MOVES BY ITSELF
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
R/C VEHICLE
RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PERFORMANCE DROP,
INCONSISTENT MOVEMENT
OR FAILS TO RUN
Check batteries. If necessary, replace the batteries in the R/C vehicle and
controller with new alkaline batteries.
Radio waves control the R/C vehicle. Care for your vehicle and it will provide hours of fun! Avoid water, heat, sand and
high impact crashes!
TREAT YOUR R/C VEHICLE WELL
Store in safe place. No direct sunlight. No rain or water. No sand or dust.
No Collisions. R/C vehicle may get stuck on
carpet or grass.
Avoid running 2 vehicles with the same radio control
frequencies.
LIMITED RADIO CONTROL RANGE
While R/C vehicle may be visible at a distance, full
operational control may be lost. Hold controller high in the
air and direct vehicle back.
INTERFERENCE
Other radio signals may cause loss of control. Remove
vehicle from an area of interference.
ENG
