Transact Campus DR4100X007 Contactless Card Readers User Manual DR4110 Brochure

Blackboard Inc. Contactless Card Readers DR4110 Brochure

DR4110 Brochure

The Blackboard DR4110 Hybrid Door Reader with
Key Pad provides the ultimate in versatility for
access control, incorporating both contactless
and magnetic stripe reader capabilities, ideal for
campuses transitioning to a contactless campus.
Additionally, the DR4110 reader adds another
layer of security with a key pad for two-factor
authentication.
Why contactless?
The payment industry is rapidly migrating to contactless
card technology for its increased benefits over magnetic
stripe cards. Because of these benefits, the contactless
smart card market is expected to grow 33% over the
next three years.
Contactless card technology offers multiple advantages
over magnetic stripe:
• Encryptedkeysprovideahigherlevelofdata
security
• Cardsarenotaseasilyduplicatedasmagnetic
stripe cards
• Useofcontactlesscardsvirtuallyeliminates
reader wear and tear, as the card does not need
to physically touch the reader
SPECIFICATIONS
Model Number:
DR4110
Physical Size:
2 1/2” W x 4 1/2” H x 1 1/8” D
Weight:
.30 pounds
Input Power:
12 VDC 100mA Maximum
OPERATING
• Temperature
-35 to +66 degrees Celsius
• RelativeHumidity
0 to 85%, non-condensing
• Altitude
0 to 20,000 feet
blackboard.com/contactless
Blackboard
DR4110 Hybrid
Door Reader with
Key Pad
Copyright © 2009-2010. Blackboard Inc., Blackboard, the Blackboard logo, Bb, and Blackboard Transact are all trademarks or registered trademarks of Blackboard Inc. in the United
States and/or other countries. All rights reserved. All other trademarks/trade names are the property of the respective owners and are used with permission. All rights reserved.
Worldwide Headquarters Phoenix Office
650 Massachusetts Avenue NW 22601 North 19th Avenue
6th Floor Suite 130
Washington, DC 20001-3796 Phoenix, AZ 85027
+800.424.9299, ext. 4 +800.528.0465
+202.463.4860, ext. 4 +800.476.1400
Contactless Technology from Blackboard
Contactless technology from Blackboard enables consumers to wave their card over a smart
reader at the point of acceptance.
• Highsecuritysmartcardcredential
• Transmissionsecurityandencryption
• Nearzerovulnerabilitypointsforidentitytheftandfraud
• Fastdatatransferrate,212Kbps
COMPONENTS
SonyFeliCa™contactless,ISO18092compliant(NFCstandard)
3-Track HiCo mag stripe read head
12buttonkeypad
DEVICECONFIGURATION
Device comes pre-configured. A smart card based configuration tool is used to change the
Wiegand output.
FormoreinformationontheDR4110BlackboardHybridDoorReaderwithKeyPad,
contactyourBlackboardsalesrepresentativeorcall800.424.9299,ext.4.
