Specifications
This appendix provides technical specifications for the SkyPilot
SkyGateway/SkyExtender
Radios, Antennas, and Security
5 GHz mesh backhaul 802.11b/g AP
Frequency band 4.960-4.980 GHz (center
freq) 2.400-2.483 GHz
Antennas 8-antenna array (360°
coverage), Each antenna:
45° horizontal x 6°
vertical, 17 dBi
1 external 7.4 dBi
omnidirectional antenna
EIRP 6.5W / 38.35 dBm peak
EIRP 400 mW / 26 dBm radio Æ
2.2 W / 33.4 dBm EIRP
Media access Time Division Duplex
(TDD) IEEE 802.11b/g CSMA/CA
Wireless
Connectivity SkyGateways,
SkyExtenders, and
SkyConnectors
IEEE 802.11b/g Wi-Fi clients
Modulation
technique OFDM OFDM (802.11g)
DSSS (802.11b)
Modulation rates 6 to 54 Mbps 802.11b: 1 to 11 Mbps
802.11g: 6 to 54 Mbps
C
SkyPilot SkyAccess DualBand Installation 3
Throughput Up to 20 Mbps UDP / up to 12 Mbps TCP
Latency 10-12 ms roundtrip per hop
Channel width 20 MHz 20 MHz
Channel
resolution 5 MHz frequency
control 5 MHz frequency control
Receive
sensitivity -90 dBm at 6 Mbps
modulation -98 dBm at 1 Mbps modulation
Authentication MD5-based
certificates RADIUS support for multiple
servers
802.1x
Encryption 128-bit AES
encryption on all
wireless links
WEP, Dynamic WEP, & WPA (EAP-
TTLS, EAP-PEAP/MSCHAPv2 with
TKIP)
Physical Specifications
Connectors RJ-45: power & Ethernet (Power over Ethernet)
RJ-45: RS-232 serial for local management
Mounting Tower, utility pole, lampposts, building, or other
infrastructure
LEDs Wireless activity, wireless link
Dimensions 33.0” (83.8 cm) H x 12.2” (31.0 cm) diameter
Weight 15.0 pounds (6.75 kg)
Operating
temperature -40° to 131° F (-40° to 55° C)
Wind loading Up to 100 mph (160 km/h)
SkyPilot SkyAccess DualBand Installation 4
Enclosure/humidity NEMA-4X
Power 110VAC, 50-60 Hz input; 11 Watts typical - 35 W
Peak
Certifications FCC Part 15/90, FCC 47 CFR Part 15, Class A USA;
compliance with UL safety standards
EMI and susceptibility FCC Part 15.107 and 15.109
