Tsuen Shing BM242A 2.4GHz Baby Monitor User Manual BM 242
Tsuen Shing Enterprises Limited 2.4GHz Baby Monitor BM 242
User Manual
WIRELESS 2.4GHz HANDHELD BABY MONITOR
BM-242 USER MANUAL
Congratulations
Giving birth to baby is the happiest experience for parents. They would offer their children
the best living quality as they can and take care of them whole-heartedly. Therefore, a baby
monitor is a necessary baby care product that helps parents pay attention to every wonderful
moment of their baby.
We have developed a 2.4G & 4 channels handheld slim size baby monitor that eliminates the
interference from crowded 900MHz band. A color LCD screen allows the parents to watch
their child. In addition, parents are able to see their baby in bright black & white view of
baby even in a darkened room.
If you want to see a bigger image of the baby on TV, a TV cable is included to help you.
First time parents may find it difficult to manage the feeding time of their baby, a digital
alarm clock is incorporated to remind the parents, “It’s time to feed the baby!”
Please read all instructions thoroughly before using your Baby Monitor.
Content and Features
AC Adaptor:
The AC Adaptors are low voltage power sources that allow you to use your household
electricity to run the Baby Monitor. Connect the Ac Adaptors to the AC Adaptor Jack in the
Parents and Baby Units. Both plug into any standard volt electrical outlet in your home. It
is recommended to turn off the units before plug in or unplug the adaptors.
CAUTION: These adaptors were made with a specific design for this product. They cannot
be used with any other appliance. Never use a different type of adaptor with this monitor.
Colour Monitor Power Indicator
Indicator’s Statues Indication
Flashing Red Light Batteries are charging
Green Light Power is good
Flashing Green Light Low power
WA R N IN G !
TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS
PRODUCT TO WATER OR MOISTURE. NEVER ATTEMPT TO OPEN THE CASE OF
EITHER THE BABY OR PARENTS UNIT. THIS IS DANGEROUS.
1. This product is not to be used as a medical monitor and its use should not replace proper
adult supervision. It is important that an adult stays within the viewing range of the
Baby Monitor at all time during use.
2. Always keep the Baby & Parents Units and AC adaptors out of child’s reach. Do not
place the Baby Unit in child’s crib or playpen.
3. It is essential to check reception regularly. Please see the Testing section for complete
instructions.
4. The Baby and Parents Units are for indoor use only.
5. NEVER use the Baby or Parents Units near water, such as bathtub, bathroom sink,
laundry tub, kitchen sink or in a wet basement etc.
6. Always unplug the AC adaptors from wall outlets and remove the batteries or the
exhausted batteries from the Parents Unit during long periods of non-use.
7. Position the Baby & Parents Units and AC adaptors to allow adequate ventilation and
prevent these components from overheating.
8. To prevent overheating, keep the Baby & Parents Units and AC adaptors away from heat
sources such as radiators, heat registers, stoves, other appliances (including amplifiers)
or direct sunlight that produce heat.
9. Use only the AC adaptors provided. Use of any other adaptors may damage the Baby
& Parents Units. Plug the AC adaptors into standard household current only! To
prevent entanglement and overheating, DO NOT use extension cord.
10. Position the AC adaptor cords so that they are not walked on or pinched by items placed
upon or against them, paying particular attention to cords at AC adaptor plugs, wall
plugs, and the point at which the cords attached to the Baby & Parents Units.
11. The AC adaptors and battery compartment of the Parents Unit may become slightly
warm to touch during operation. This is normal.
Care and Maintenance
1. The Baby Monitor is for indoor use only. Do not place the Baby Unit under direct
sunlight. Outdoor use may damage the Baby & Parents Units.
2. Clean the outer surface of Baby & Parent Units with a cloth dampened with water or
mild cleaning solution LIGHTLY. Do not immerse any part of the product in water.
3. Do not drop the product or physically damage it, otherwise electronic components may
be affected by such abuse.
Caution:
1. Always remember that you are using public airwaves when you use the Baby Monitor.
Sound and video may be broadcasted other receiving devices. Conversations, even
from rooms near the Baby Unit may be broadcasted as well. To protect your privacy,
always turn the Baby Unit off when not in use.
2. It is possible for the Parents Unit to pick up sounds or display interference from other
signal producing devices including other audio or video monitors which broadcast in the
2.4GHz range. To minimize this potential problem, 4 independent channels are
available for your use.
3. If the Parents Unit experiences interference, simply switch both the Baby & Parents
Units to another channel. Selecting a channel is usually a one-time adjustment. If
interference persists on all channels, please refer to the Troubleshooting Section.
Testing
It is very important to test the transmission of Baby Unit and reception of Parents Unit before
use or whenever you change the location of either Parents / Baby Units.
1. Place Baby Unit in room where you intend to use it. Position it in the most appropriate
location for monitoring the baby (on top of a table, dresser, or on the wall). Turn on the
Baby Unit by switching the ON / OFF switch to ON.
2. Direct the camera lens towards the area you want to see on the Parents Unit screen.
While testing, it may be helpful to place an object, such as a doll or stuffed animal, in the
area you want to monitor.
3. Place the Parents Unit in different locations you intend to use inside the house. As with
any audio equipment, feedback or a high pitched sound may occur if the Parents & Baby
Units are too close to each other.
4. Set both units into the same channel.
To test video reception quality
5. Check the video reception on the Parents Unit screen. Make sure you check the
reception in all areas you intend to use both units.
6. To adjust Brightness, Contrast, or Color, please refer to the Operation Section.
7. The Baby Unit will automatically switch to night vision mode when it is placed in a
completely darkened room. In night vision mode, the picture will be black and white.
To test sound reception quality
8. Stay in the room with the Baby Unit, speak in both a whisper and a normal conversation
level from where the child is being monitored. During sound testing, keep in mind the
sound level of your child and test accordingly.
9. Keep the Baby Unit far enough away from the Parents Unit to prevent feedback noise.
Place the Baby Unit in a different room than the Parents Unit is sufficient.
Baby Unit Location & Set-up
You can position and adjust camera in different ways to provide the best view of your baby.
The Baby Unit can be easily mounted on wall, or simply placed on a stable, flat surface, such
as a dresser, table top or shelving unit.
IMPORTANT: Once you have selected a location for mounting, test the reception of the Baby
Monitor BEFORE installing any wall mount screws. If interference or other problems occur,
please refer to the Troubleshooting Section.
WARNING:
In selecting a location to mount the Baby Unit, keep the following in mind:
- To prevent entanglement, only mount the Baby Unit at where its AC adaptor cord is
OUT OF CHILD’S REACH.
- To prevent entanglement and overheating, only mount the Baby Unit at where the
AC adaptor cord can reach a standard wall outlet. Unwrap and fully extend the
AC adaptor cord. NEVER use an extension cord.
- For best viewing, position the Baby Unit approximately 3’ (1m) away from the
child.
- Mount the Baby Unit in a location where the camera lens is unobstructed. Use the
tilt and swivel adjustments to properly aim the camera.
- Allow adequate ventilation of the Baby Unit when mounted on a wall. DO NOT
mount it directly above heating vents, other heat generating sources or in direct
sunlight.
Parents Unit Battery Installation
WARNING!
- Do not mix battery types e.g. alkaline, supplied rechargeable batteries or other
rechargeable batteries.
- Do not submerge any part of the Baby Monitor in water.
- Remove and dispose empty batteries promptly.
- Do not mix old and new batteries.
- Rechargeable batteries are only to be charged under adult supervision.
- Non-rechargeable battery is not to be recharged.
- DO NOT short circuit supplied terminals
- Insert batteries as indicated inside the battery compartment
- The supplied rechargeable batteries cannot be used in other devices.
1. Expose the battery compartment door on the back of the Parents Unit by pulling the belt
clip downward and lift it up. It is not necessary to remove the belt clip to install the
batteries (Figure A)
2. Install the supplied rechargeable batteries into the battery compartment (Figure B).
Close the battery compartment door and realign the belt clip.
3. For the initial use, we recommend the charging time is 10 hours. After that, the
recommended charging time is 10 hours. Use only the supplied 6V AC adaptor for
charging the supplied rechargeable batteries. Plug into any nearby standard electrical
outlet at home. When the batteries are charging, the power indicator lights up with
flashing red colour. When the batteries are fully charged, the power indicator is in
green colour.
4. User can also install 3 alkaline AA batteries instead of the supplied rechargeable
batteries or directly operated by the supplied 6V AC adaptor.
Note:
- The Baby Monitor will not work if the batteries are not inserted properly.
- A green-flashing power indicator and a low power alarm (2 beep tone) indicate the
battery level is low. You are recommended to recharge the rechargeable batteries
or insert new batteries. If not, the monitor will automatically shutdown after 2
minutes.
Operational Procedure
Parents Unit
1. Once batteries are inserted properly, the clock display turns on and you could see 12:00.
2. Switch the ON/OFF switch to On position. The power indicator lights up in green.
At the same time, you should see the picture in the color display and hear sound from
the speaker, if Parents and Baby Units set on same channel.
3. Adjust the volume level by rotating the volume dial up and down.
Baby Unit
1. Connect the Baby Unit with the supplied 9V AC adaptor. Plug it into the nearest
standard electrical outlet at home.
2. Turn on the unit by switching the ON/OFF switch to ON position. The power indicator
lights up in green.
3. Switch Channel Switch to set both units to the same channel until you receive the
correct picture and clear voice on the Parents Unit.
4. Adjust the focus by turning the camera lens clockwise or anti-clockwise until you see a
clear picture on the monitor.
SUMMARY OF CONTROL PANEL
Symbols shown on the clock
display window Mode/Functions
CH Channel Selection
CO Colour Setting
br Brightness Setting
Ct Contrast Setting
CL Clock Setting
AL Alarm Setting
A. Video Setting
i) Color Setting
1. Press ▲ /▼ until you see “CO”
2. Press “FUN” to enter the color adjustment mode.
3. Press ▲ or ▼ to adjust the picture’s color from 1 to 8 levels. Level 8 is the highest
level.
4. To confirm the setting, press “FUN” or leave the unit alone for 5 seconds to return to its
normal operation.
ii) Brightness Setting
1. Press ▲ /▼ until you see “br”
2. Press “FUN” to enter the brightness adjustment mode
3. Press ▲ or ▼ to adjust the picture’s brightness from 1 to 8 levels. Level 8 is the
brightest.
4. To confirm the setting, press “FUN” or leave the unit alone for 5 seconds to return to its
normal operation.
ii) Contrast Setting
1. Press ▲ /▼ until you see “Ct”
2. Press “FUN” to enter the contrast adjustment mode
3. Press ▲ or ▼ to adjust the picture’s contrast from 1 to 8 levels. Level 8 is the highest
level.
4. To confirm the setting, press “FUN” or leave the unit alone for 5 seconds to return to its
normal operation.
B. Channel Setting
1. Press ▲ /▼ until you see “CH”
2. Press “FUN” to enter the channel selection mode.
3. Press ▲ or ▼ to select a channel.
4. Repeat step 3 until you hear a clear sound and receive a clear image on the Parents Unit,
then press “FUN” to confirm the setting. Make sure the Baby Unit is in the same
channel as the Parents Unit.
C. Clock Function
i) Clock Setting
1. Press ▲ /▼ until you see “CL”
2. Press “FUN” to enter the Clock Setting mode.
3. Press ▲ to select the HOUR or MINUTE digit to be adjusted
4. Press ▼ to select the desired number for the selected digit.
5. Press “FUN” to confirm the clock setting.
ii) Alarm Setting
1. Press ▲ /▼ until you see “AL”
2. Press “FUN” to enter the alarm setting mode
3. [picture of bell] symbol would appear at the top right hand corner
4. Press “FUN” to enter the alarm setting mode; or press ▲ /▼ to cancel alarm setting, the
symbol [picture of bell] will disappear
5. To set alarm, press ▲ to select the digit to be adjusted.
6. Press ▼ to select the desired number for that digit.
7. Press “FUN” to confirm the setting. The symbol [pic of bell] will appear
iii) Stop Clock Alarm
1. Press “FUN” /▲ or▼ to stop the clock alarm
C. Connect Parents Unit with TV Set
By connecting the Parents Unit with TV set, the video will be displayed on the TV set.
1. Connect the Parents Unit with the TV set with the supplied TV cable (For NTSC
System).
2. Turn on the TV, set it to the video viewing channel; user could see the image captured by
Baby Unit on TV screen now.
Troubleshooting
Problem Possible Cause Solution
Baby Unit is not turned
ON
- Slide the ON/OFF switch to the ON
position.
- Make sure house fuses and circuit breakers
are on.
- Make sure that any switch that controls the
power flow to the wall outlet is on
Baby Unit power
indicator does not
light
AC adaptor not properly
connected
- Check AC adaptor jack-to-socket and
plug-to-outlet connections.
Power is turned off.
Batteries may be dead
- Turn on both Parents and Baby Units.
- Replace batteries, or recharge the supplied
rechargeable batteries.
- Operate the monitor by using the adaptor
only to see if the Parents Unit is still
functioning.
- Make sure house fuses and circuit breakers
are on.
Parents Unit does not
show video image or
deliver sound
AC adaptor not properly
connected
- Make sure that any switch that control the
power flow to the wall outlet is on. Check
the AC adaptor jack-to-socket and
plug-to-outlet connections.
- Be certain it is plugged into the AC jack.
Object is too close to the
Baby Unit
- Remove objects that are too close to the
Baby Unit or move the Baby Unit further
apart.
Baby or Parents Units
are near metal
concentration
- Test reception by moving the Baby or
Parents Unit to different locations
throughout the house.
Picture flickers in low
light
Signal interference due
to other monitors,
cordless or cellular
telephones, etc.
- Change the channel setting on the Baby
and Parent Units.
- Identify and eliminate the source of
interference
Parents Unit is too close
to the Baby Unit
- Move the Parents Unit further away from
the Baby Unit
Audio feedback
(squealing)
Volume is set too high - Lower the volume on the Monitor
Power is turned off - Check the Baby and/or Parents Units’
power indicator.
- Check the connection of the adaptors and
the Parents and/or Baby Units.
Dark picture at night
Batteries may be dead - Replace batteries or recharge the supplied
rechargeable batteries
Technical Specification
I. Handheld Parents Unit
1. Handheld operation voltage: DC6V or 3 x “AA” Supplied Rechargeable / Alkaline
Battery
2. Low-voltage indication: ≤3.4V
3. Temperature range: 0˚ C ~ 50˚ C
4. Power consumption: 3.0W
5. Operation frequency: 2.414GHz-2.468GHz
6. Max range (clear line of sight): up to 150ft (in open area)
7. Video system: NTSC
8. Number of effective Pixels: 312(H) x 230(V)
9. Display usage: 1.6”DTFD Panel
10. Size of handheld:120 x 77 x 35mm
11. Battery life: supplied rechargeable batteries: 2 Hours (100% continuous use)
II. Baby unit
1. Operation voltage: AC/DC 9.0V 300mA
2. Temperature Range: 0˚ C ~ 50˚ C
3. Power consumption: 2.7W
4. Operation Frequency: 2.414GHz-2.468GHz
5. Sub-carrier Frequency: 6.5MHz
6. Mic Sensitivity: 1 to 2 meter
FCC Statement
Warning: changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
