Tyco Safety Sensormatic IDX8000NA PART 15.247 SPREAD SPECTRUM TRANSMITTER, RFID READER User Manual
Tyco Safety Products/Sensormatic PART 15.247 SPREAD SPECTRUM TRANSMITTER, RFID READER
User Manual
PRELIMINARY
IDX-8000 Reader Sensor Network
Appliance
Quick Start Guide
Introduction
This guide provides overview information for the IDX-8000; which includes the
following models and part numbers:
IDX-8000-NA
IDX-8000-EU
The reader is shipped with these items:
Reader with mounting brackets
Power supply
Localized power cord
USB cable
IDX-8000 Reader Sensor Network Appliance Quick Start Guide
Document of Conformity(-EU version only)
The IDX-8000 Quick Start Guide includes LED definitions, port descriptions,
connection and mounting information, as well as regulatory and compliance
information. References to IDX-8000 apply to all versions, except where the
version is explicitly identified.
This device received all regulatory approvals under the name Sensormatic
Electronics, LLC.
8200-2697-12, Rev. 1.0b
RF Connections
Port
Description
RF Outputs 1–8
Monostatic RF output ports (Reverse Polarity-SMA)
Digital Connections
Port
Description
Power
24Vdc
Power supply port. Connect the power supply provided with the
reader.
Power consumption: 24W maximum.
Ethernet 2
PoE*
10/100 Auto MDI/MDI-X Ethernet port. The RJ-45 Ethernet jack
supports either a standard or cross over cable. The Ethernet 1 and
Ethernet 2 ports act like a network switch.
PoE (Power over Ethernet) IEEE 802.3at (802.3af with some power
limitations).
Ethernet 1*
10/100 Auto MDI/MDI-X Ethernet port. The RJ-45 Ethernet jack
supports either a standard or cross over cable. The Ethernet 1 and
Ethernet 2 ports act like a network switch.
USB A Host
USB 2.0 Standard Series A port supports standard USB
peripherals.
USB B
Device
USB 2.0 Standard Series B port supports Ethernet over USB.
Self-powered device; no host current required.
RS-485 2*
For future use (RJ-45 connector).
RS-485 1*
For future use (RJ-45 connector).
GPIO /
RS-232
General Purpose Input/Output (15 pin) port. Supports a HD-15
cable assembly for connection to external devices.
RS-232 serial port for future use.
Reset
The Reset button restores the reader with custom settings or to its
factory default settings.
* Connect Ethernet and RS-485 cables with care. The Ethernet and RS-485
connectors both use RJ-45 plugs.
LED Definitions
See the illustrations for the LED positions on the IDX-8000.
LED
State
Description
Power
Solid green
Power is on and unit is ready.
Off
No power to the unit.
Solid yellow
Unit is powering on.
Status
Off
Operational, not under LLRP management.
Solid yellow
Power LED yellow: unit is powering on.
Power LED green: unit is in power save mode.
Blinking yellow
Software is being downloaded.
Solid green
Under LLRP management. All other states take
precedence.
Solid red
Error detected / self-test failed.
Tag
Green flash
Valid tag is being read.
Yellow flash
Tag below RSSI threshold.
RF Status
Yellow
Transmitter is active.
Off
Transmitter is not active.
Three yellow
blinks
Communication has been established with a
1-Wire device.
All LEDs self-test on power cycle.
Mounting
Position the IDX-8000 on the wall or shelf, ensuring a minimum clearance of 10cm
(4in) on all sides. The mounting brackets are reversible to meet a range of
installation requirements as shown below. Mark the hole locations using the
mounting bracket as a guide.
Remove the IDX-8000 and drill four mounting holes at the marked locations.
Reposition the IDX-8000 over the mounting holes and secure using fasteners
appropriate for its 0.5kg (1.1 lb) weight, the mounting surface, and any other
conditions present, such as vibration.
CAUTION: Observe the minimum radius specified for the associated
antenna when the cable must change direction. A crushed or kinked
antenna cable may impair reader performance.
200mm (7.9in)
174.3mm (6.9in)
Power LED
Status LED
Tag LED
200mm (7.9in)
200mm (7.9in)
RF Status LEDs
RF1
RF2
RF3
RF4
RF5
RF6
RF7
RF8
Power
24Vdc
Ethernet
1
GPIO /
RS-232
Ethernet
2 PoE
1 2
RS-485
USB B
Device
USB A
Host
Reset
PRELIMINARY
Regulatory Information
Power Supply
Use only the Sensormatic Electronics power supply provided with this unit or other
power supply approved by and obtained from Sensormatic for use with this
product.
Approved Antennas
This device has been designed to operate only with the approved antennas
described in the table below. Approved antennas must be connected using the
cables supplied with them. Use of antennas not on this approved list will not be
supported by Sensormatic and may damage the device as well as violate local
regulations.
This device has been designed to operate with the antennas listed below, and
having a maximum gain of 6dB. Antennas not included in this list or having a gain
greater than 6dB are strictly prohibited for use with this device. The required
antenna impedance is 50 ohms.
This radio transmitter IC: 3506A-IDX8000NA has been approved by Industry
Canada to operate with the antenna types listed below with the maximum
permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for use with this device.
Manufacturer
Model Number
Polarization
Composite
Gain
Sensormatic
IDA-1000-US / IDA-1000-EU
RHCP
3.3dBiL
Sensormatic
IDA-2100-US
RHCP
6.0dBiL
Sensormatic
IDA-2100-EU
RHCP
5.15dBiL
Sensormatic
IDKM-1000 / IDKM-1010
near field
–8.5dBiL
Motorola (Symbol)
AN480-CL66100WR
LHCP
6.0dBiL
Motorola (Symbol)
AN480-CR66100WR
RHCP
6.0dBiL
Remote and Standalone Antenna Configurations
The antennas used with this transmitter must be installed to provide a minimum
separation distance of 20cm (7.9in) from all persons and must not be co-located or
operated in conjunction with any other antenna or transmitter.
Frequency of Operation
Model
Frequency band
Max Power
IDX-8000-NA
902 – 928 MHz
4W EIRP
IDX-8000-EU
865.7 – 867.5 MHz
2W ERP
Wireless Devices
If frequency is selectable for your model, select only the country in which you are
using the device. Any other selection will make the operation of this device illegal.
Declarations
All Sensormatic devices are compliant with rules and regulations in locations in
which they are sold and are labeled, as required. Any changes or modifications to
Sensormatic equipment, not expressly approved, in writing, by Sensormatic could
void the authority to operate the equipment.
EMC 47 CFR, Part 15 IDX-8000-NA
ICES-003 IDX-8000-NA
RSS-210 IDX-8000-NA
EN 302 208 IDX-8000-EU
EN 301 489 IDX-8000-EU
Safety UL 60950-1 IDX-8000-NA
CSA-C22.2.60950-1 IDX-8000-NA
EN 60950-1 IDX-8000-EU
Federal Communications Commission (FCC): IDX-8000-NA
FCC ID: BVCIDX8000NA
This equipment complies with Part 15 of the FCC rules for intentional radiators and
Class A digital devices when installed and used in accordance with the instruction
manual. Following these rules provides reasonable protection against harmful
interference from equipment operated in a commercial area. This equipment should
not be installed in a residential area as it can radiate radio frequency energy that
could interfere with radio communications, a situation the user would have to fix at
their own expense.
Equipment changes or modifications not expressly approved by Sensormatic
Electronics, LLC, the party responsible for FCC compliance, could void the user’s
authority to operate the equipment and could create a hazardous condition.
Industry Canada (IC): IDX-8000-NA
IC: 3506A-IDX8000NA
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de
l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
This Class B digital device complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
Restriction of Hazardous Substances Directive (RoHS)
All parts and components are manufactured in accordance to and be compliant
with the “DIRECTIVE 2002/95/EC OF THE EUROPEAN PARLIAMENT AND OF
THE COUNCIL of 27 January 2003 on the restriction of the use of certain
hazardous substances in electrical and electronic equipment.”
Service
If a problem using the equipment occurs, contact the facility Technical or Systems
Support. If there is a problem with the equipment, contact Sensormatic Technical
Support at http://www.sensormatic.com/support/techsupport/default.aspx.
© 2012 Sensormatic Electronics, LLC. All rights reserved.
Sensormatic Electronics, LLC makes no representation or warranty with respect to the contents
hereof and specifically disclaims any implied warranties of merchantability or fitness for any
particular purpose. Further, Sensormatic Electronics, LLC reserves the right to revise this
publication and make changes from time to time in the content hereof without obligation of
Sensormatic Electronics, LLC to notify any person of such revision or changes.
Sensormatic and the Sensormatic logo are registered trademarks of Sensormatic Electronics,
LLC. All other product names or company names mentioned in this document may be
trademarks or registered trademarks of their respective companies and are hereby
acknowledged.
Sensormatic Electronics, LLC
6600 Congress Ave.
Boca Raton, FL 33487
http://www.sensormatic.com
Part Number: 8200-2697-12, Rev. 1.0b
