UNITEIC STEALTH Stealth-6 REMOTE CONTROL ACTIVE SPEAKER User Manual
UNITEIC COMPANY LIMITED Stealth-6 REMOTE CONTROL ACTIVE SPEAKER
UNITEIC >
User Manual
User Manual
Model:STEALTH 6 ULTRA HD
Manufacture: UNITEIC COMPANY LIMITED
Product Name: Stealth-6 REMOTE
CONTROL ACTIVE SPEAKER
STEALTH 6
ALL-IN ONE AMPLIFIED SOUNDBAR WITH REMOTE
USER MANUAL
wetsounds.com
ULTRA HD
1.
1. Reset
• If needed, press to reset sound bar
for bluetooth pairing
2. Source Indicator Light
• Blinking Blue – Pairing Mode
• Blue – Bluetooth
• No Light – Aux
3. Power – Play/Pause – Mute
• Press and Hold For 3-5 Seconds to
turn the unit on or off
• When Source Is Selected On
Bluetooth, Press For Pause/Play
Function
• When Source Is Selected On
Auxiliary Input, Press To Mute Audio/
Un-Mute Audio
4. Volume Up
• Turns the volume up
5. Source Select
• Toggle between Bluetooth and
Auxiliary input (3.5mm)
6. Track Back
• Skip to previous track
7. Track Forward
• Skip to next track
8. Volume Down
• Turns the volume down
PASSION. PERFORMANCE. RUGGED FOR THE GREAT OUTDOORS!
Thank you for choosing Wet Sounds for your high performance Audio system! We
build every product with Unsurpassed PASSION so we can deliver the HIGHEST
PERFORMING Products to you! We live and breathe high performance audio. So
you can enjoy the very best system options available for your vehicle.
The STEALTH ULTRA HD Series Sound bars are designed to give every owner of
a Boat, UTV, Golf Cart and virtually any vehicle the ability to add high performance
Audio in a SIMPLE to use design. Made for the great outdoors the STEALTH
ULTRA HD Series Sound Bars are designed to be simple & easy audio options
for your vehicle. The STEALTH ULTRA HD Sound Bars are the true High
Performance 2-wire 12 Volt stealth audio system!
We appreciate your passion for great audio! Thank you for choosing Wet Sounds
for your high performance audio needs.
For further questions, please call 1-877-938-7757 or visit www.wetsounds.com
2.
INSTRUCTIONS FOR USING THE UNIT
Press and hold the power button for 3-5 Seconds to turn the unit on.
Next, select what source you want to listen to, either Bluetooth or Auxiliary input.
Stealth, then select it. That’s it! You are now paired with the unit.
NOTICE: You can only pair one device to the unit at a time. If the unit is not blinking
(indicating that it’s in pairing mode) make sure that it’s not connected to another device. If
Bluetooth device and turn it off allowing the Stealth Ultra HD Soundbar to automatically
search for new devices.
Once the Stealth Ultra HD Soundbar is powered up, it can be controlled using either the control
pad on the unit, or the included RF wireless remote control. Please note – power On and Off must
be completed on the control pad, but all other functions of the control pad are duplicated on the
wireless remote.
The range for the wireless remote is approximately 12 feet, and is affected by factors such as
limit the usable range of the remote.
Included is a bracket to easily attach the wireless remote to a steering wheel or any other round
bar. Stretch the rubber cords around the steering wheel tightly to attach the bracket, then simply
slide the remote control onto the bracket.
If the remote stops working the most likely cause is a dead battery. The remote is powered by one
CR2032 3V lithium battery that is available wherever batteries are sold and is easily accessible
by removing the 4 screws on the back of the remote housing. Before removing the screws, the
rubber screw covers need to be removed. The battery slides into the battery compartment with
the positive (+) side facing up. It is important to replace the rubber screw covers after reassembly
to make sure the remote control is watertight.
Some unique features on the STEALTH ULTRA HD Soundbar when playing your Bluetooth
device, you can use the buttons on the sound bar to control your device by advancing tracks
or replaying music on your device as well as volume. Also, by pressing the power button on
the unit it will pause your music on your device and by pressing it again it will allow the de-
vice to continue playing. When the unit is selected in Auxiliary mode and the power button is
pressed, the unit will mute the audio and un-mute the audio when pressed again.
seconds and the unit will turn off. If the unit does not sense a signal from either the blue tooth
or auxiliary input for 10 minutes, it will automatically turn itself off.
3.
Wet Sounds STEALTH ULTRA HD
Sound Bars are an operating voltage of 12 volts
Weight - 13 lbs
4.
INSTALLATION
A. Mounting
1. Fit the appropriate tube clamp around the front strut in the desired location. *Note: you
may need to remove bolts connecting the top to the front strut to complete this
step.
2. If a sliding adapter was supplied in your kit, you will need to loosely fasten it to the
soundbar, and then to the round tube clamps installed in step 1.
3. Ensure that the sound bar is in the desired location, then tighten all hardware.
B. Wiring
1. If installing on an electric vehicle, switch it into TOW mode. Carefully remove the
Positive (+) then Negative (-) battery wires.
2. A. If installing on a gas vehicle, wire the Negative (Black) wire to the Negative (-)
battery terminal and the Positive (Red) wire to the Positive (+) battery terminal.
B. If installing on an electric vehicle, wire the Negative (Black) wire to the Ground on
the DC-DC Converter and the Positive (Red) wire to the Positive (+) post on the DC-DC
Converter.
3. Route the thick Blue Aux In & Aux Out wires to your desired location. The Aux In is for a
music source that does not have Bluetooth capability. The Aux Out is to connect to an
4. The Blue Remote Out wire provides +12V when the soundbar is powered on. This
subwoofer, such as the STEALTH AS-10 or AS-6.
5. Tie up all excess wires and reinstall the Positive (+) then Negative (-) battery wires. If
installing on an electric vehicle, switch it back into RUN mode.
Note: DC-DC Converter is required on electric vehicles to avoid damage to the
accessory and the vehicle.
5.
What This Warranty Covers
This is a “Limited” warranty. This warranty
covers any defects in materials and
workmanship and warranty only applies to
the original purchaser and is not transferable.
This warranty is also only valid if the original
purchase was made from an authorized Wet
Sounds™ dealer.
How Long Coverage Lasts
This warranty runs for 2 years from the
date of the purchase. It is recommended to
REGISTER your warranty online within 45
days of your purchase at www.wetsounds.com
– click on “warranty registration”.
What Is Not Covered
This warranty does not cover fading or
discoloration caused by exposure to sunlight
or chemicals such as ammonia, household
bleach, or any cleaning material that contains
abrasive substances. (For information on how
to prevent fading or discoloration, consult
for recommendations on cleaning products)
Wet Sounds, Inc. does not cover the cost
for removal and reinstallation of any kind.
Additionally, shipping TO Wet Sounds, Inc.
is covered by the purchaser This warranty is
void and inapplicable if Wet Sounds™ deems
that the product was abused or misused;
including but not limited to Speaker product
that has been improperly-powered (under or
over powered), causing thermal (burnt voice
coil) and/or mechanical failure (torn surrounds
or spiders), damage caused by accident,
mishandling, improper installation, negligence,
normal wear and tear, excessive water or
heat damage, freight damage or products that
have been altered in any way. Product owned
by anyone other than the original purchaser
from an authorized Wet Sounds dealer. (The
warranty is not transferable and will not apply
to products purchased from unauthorized
dealers.) Wet Sounds is not responsible for
any damages to a consumer’s boat or person
from a product failure. The warranty is void if
Wet Sounds deems the product was installed
or used improperly. Wet Sounds shall not be
responsible for any incidental or consequential
damages, except to the extent provided (or
prohibited) by applicable law. This warranty
also have other rights which vary from state.
What Wet Sounds™, Inc. Will Do
Wet Sounds, Inc will repair any part of your
product that proves to be defective in materials
or workmanship. In the event repair is not
possible, Wet Sounds, Inc will replace the
product in question. If it is deemed necessary
Wet Sounds, Inc. will either replace the entire
product with a refurbished unit or it will be
replaced with a model that is similar in price
if that model is no longer available. Labor
cost and materials needed to complete this
service will be at no charge to the purchaser.
Additionally, the cost of shipping TO the
consumer is also covered under this warranty.
How to Obtain Warranty Service
Contact Wet Sounds, Inc. either by phone
at 877-938-7757 or by email at warranty@
wetsounds.com. A service representative will
assist you in the necessary actions to verify
that the problem that you are experiencing is
covered under warranty. If it is in fact a warranty
issue, Wet Sounds will issue an RA number
for tracking purposes and give instructions
on sending the product in for evaluation. Wet
Sounds™, Inc.
How State Law Applies
and you may also have other rights which vary
from state to state.
Internet Warning
Wet Sounds, Inc. products sold on any non
authorized web site or internet auction site are
void of any and all manufacturer’s warranty.
Please contact Wet Sounds™ at 877-938-
7757 or visit our web site at www.wetsounds.
com to search for an authorized site and/or an
authorized retailer near you.
Caution & Respect
Wet Sounds™ speakers can achieve very
high sound pressure levels. Please use this
product responsibly. Be aware that sound
travels great distances so please respect
others. Wet Sounds, Inc. is not responsible for
any violations of the law that may be a direct
result of excessive volume. Please abide by
the rules but have fun doing it.
Optional Accessories
Please visit www.wetsounds.com for more information
Stealth Clamp Square 1.25” (ST-ADP-SQ 1.25)
Stealth Clamp Square 1.0” (ST-ADP-SQ 1.0)
Stealth Clamp Square .75” (ST-ADP-SQ .75)
Stealth Adapter Side Bracket (ST-ADP-SIDE BRACKET)
Stealth Clamp Round 1.75” (ST-ADP-SQ 1.75)
Stealth Clamp Round 1.5” (ST-ADP-SQ 1.5)
WET SOUNDS INC.
www.wetsounds.com • 877-938-7757
10621 S Sam Houston PKWY W • Suite 100
Houston, Texas 77071 • USA
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC Warning
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada . Son fonctionnement
est soumis aux deux conditions suivantes :
( 1 ) Ce dispositif ne peut causer d'interférences ; et
( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent
causer un mauvais fonctionnement de l'appareil.
A separation distance of at least 20 cm is maintained between the transmitter's radiating
structure(s) and the body of the user or nearby persons.
Une distance de séparation d'au moins 20 cm est maintenue entre la (les) structure (s)
rayonnante (s) de l'émetteur et le corps de l'utilisateur ou des personnes proches
