Product Summary
The RF 2-Way Siren is a supervised device that transmits
supervisory signals for the panel to receive. When the bat-
tery is low, the module transmits a low battery signal.
Note
The RF 2-Way Siren does not have a backup power sup-
ply. Therefore, the battery must be replaced immediately
when a low battery condition occurs. If the battery is
allowed to completely drain, the panel identifies the RF 2-
Way Siren as being in a supervisory (non-working) state,
which prevents system events from being reported.
Installation Guidelines
Use the following guidelines when installing the RF 2-Way
Siren:
↕Before permanently mounting to a wall, test the RF 2-
Way Siren from the desired location to ensure commu-
nication to and from the panel. This means you must
first add (learn) the RF 2-Way Siren into panel mem-
ory. Then perform a sensor test.
↕Mount the module within 100 feet of the panel, but not
closer than 10 feet to another RF 2-Way Siren or the
panel.
↕Always mount the RF 2-Way Siren in the upright verti-
cal position.
Tools and Supplies
↕Phillips screwdriver
↕Two #6 phillips-head screws (included)
↕Two wall anchors (included)
↕Pencil
Installation
This section describes programming, testing, mounting, and
phone line connections.
Programming
This section describes the steps for adding (learning) the RF
2-Way Siren into panel memory.
1. With the system disarmed, enter program mode by
pressing +.
2. Press twice and twice. The display shows ZONE
01 - TRIP.
3. Press Test button. The siren will beep three times, indi-
cating it is learned into the panel.
4. Exit Program mode.
Testing
This section describes the basic steps for testing transmit-
ting reange from the RF 2-Way Siren to the panel. For com-
plete testing instructions, see the panel installation
instructions.
Note
Be sure to attach the cover to the RF 2-Way Siren before
testing communications.
1. Straighten the antenna to a vertical position.
2. Place the RF 2-Way Siren in the desired location.
3. Enter sensor test mode on the panel
4. Press Test button on siren.
5. Listen for the panel piezo to sound 7 - 8 beeps. This
indicates good reception from the siren to the panel.
6. If you hear fewer than 7 beeps, test the siren in different
locations. Mounting locations should be limited to
areas where the panel responds with 7 - 8 beeps.
7. To re-test transmitting range after relocating the siren,
press the Test button again and listen for 7 - 8 beeps.
8. Exit from the test mode after determining acceptable
locations.
Mounting and Antenna Positioning
After finding an acceptable mounting location (based on
testing), mount the RF 2-Way Siren and position the
antenna as described below. The antenna can be inserted
into a wall or positioned upright inside the antenna housing.
Note
For best range, it is recommended that the antenna be
inserted into the wall.
Mounting with Antenna in Wall
1. Remove the circuit board from the plastic housing by
pushing up on the tab and pulling the board outward
(see Figure x). Place the board in the cover.
2. Mark the mounting holes and the antenna insertion hole
(see Figure x).
WARNING: Youmustbefreeofallstatic
electricity when handling electronic compo-
nents. Touch a bare metal surface or wear a
grounding strap before touching the circuit.
Preliminary 2/8/02
2
3. Make a hole in the wall at the antenna insertion hole
and mounting hole marks.
4. Insert wall anchors where necessary, then use two #6
screws to secure the plastic housing to the wall.
5. Insert the antenna into the antenna insertion hole and
re-install the board onto the plastic base. Insert the bot-
tom first, then push in at the top until it snaps in under
the tab.
6. Install the protective dust cap (included in accessory
packet) in the hole located on the top-right of the RF 2-
Way Siren’s plastic housing.
Mounting with Antenna Housing
1. Hold the RF 2-Way Siren against the wall and mark the
mounting holes (see Figure x). Be sure to leave at least
4 inches above the siren for the antenna housing.
2. Make a hole in the wall at the mounting hole marks.
3. Slide the antenna housing over the antenna and snap
the housing into the upper-right hole (see Figure x).
4. Insert wall anchors where necessary, then use two #6
screws to secure the siren module to the wall through
the mounting holes.
5. Re-install the board onto the plastic base. Insert the
bottom first, then push in at the top until it snaps in
under the tab.
Troubleshooting
No System Response
If the system does not respond in sensor test (as described in
the panel installation instructions), try the following:
↕Change the antenna position. Best range is achieved by
inserting the antenna into the wall.
↕Check that the RF 2-Way Siren batteries is installed.
↕Check the RF 2-Way Siren batteries for low voltage.
replace the batteries if necessary.
↕Use an RF Sniffer (60-401) to verify that the RF 2-Way
Siren is transmitting.
↕Verify that the RF 2-Way Siren was added (learned)
into panel memory correctly.
Trouble Condition
↕The tamper switch may have been tripped. Check that
the cover is securely in place.
↕The RF 2-Way Siren batteries may be low. Check the
batteries and replace if necessary.
Module Supervisory
↕If the panel indicates a RF 2-Way Siren supervisory
condition, use an RF Sniffer (60-401) to verify that the
siren transmits when the tamper switch is pressed. If it
does not transmit, check the batteries and replace them
if necessary.
↕If the sniffer indicates that the RF 2-Way Siren is trans-
mitting, it may be out of panel receiving range. Use the
sensor test to verify that the siren is within panel range.
If necessary, test the siren from other locations until an
acceptable location is found.
Specifications
Compatibility: ............ Allegro™,Simon3
Power Requirements: 3 AAA Alkaline batteries
Storage Temperature: -30° to 140°F (-34° to 60°C)
Operating Temperature: 32° to 120°F (0° to 49° C)
Maximum Humidity: . 90% relative humidity, noncon-
densing
Dimensions: ................ 4.6” (11.7 cm) x 1.2” (3 cm) x 6.6”
(16.8 cm) (W x D x H). Plus 3.5”
(8.9 cm) for antenna housing.
Installation: ................ Wall mounting
UL Listings:
UL 864 - Control Units for Fire-Protective Signaling
UL 985 - Household Fire Warning System Units (pending)
ULC - Canada Commercial Fire/Burglary Warning System
(pending)
CSFM - California State Fire Marshall (pending)
DOD - Sensitive Compartment Information Fac. (pending)
FM - Factory Mutual (pending)
MEA - New York City Material Equipment Acceptance
(pending)
Compiles with NFPA 72 for Fire Alarm Code
