UTT TECHNOLOGIES REG10-UTT Wireless Router User Manual 10
SHANGHAI UTT TECHNOLOGIES CO., LTD. Wireless Router 10
10 user manual
![](/img.php?id=3078041&img=bg1.png)
SOHO Wireless Router
SN: 0904-0003-014
WAN
LAN
USB
TF
DC
ON/OFF
Reset
The LED indicator blinks twice per second when the system is operating
properly, and it will blink slower if the system is under heavy load.
Insert a TF card for data sharing.
The DC interface is where you connect the provided power adapter.
Press this button to turn the Device on and off.
The LED indicator is yellow when the USB interface is connected
properly, and it is red when the TF port is connected properly.
The WAN interface is connected to your Internet device, such as a cable
or modem.
These interfaces provide a LAN connection to network devices, such as
PCs or switches.
Plug-in a USB storage for data sharing.
The LAN LED indicator is on when Ethernet cable connection is normal,
and it blinks when the LAN port is sending or receiving data.
The WAN LED indicator is on when Ethernet cable connection is normal,
and it blinks when the WAN port is sending or receiving data.
The 5G LED indicator is on when 5GHz Wireless is enabled, and it
blinks when transmitting/receiving 5G wireless data.
The 2.4G LED indicator is on when 2.4GHz Wireless is enabled, and it
blinks when transmitting/receiving 2.4G wireless data.
The Power LED indicator is on when the Device is powered on.
Note: 3. Please install the equipment in a place away from the High
Power Radio or Radar Station.
4. Please KEEP THIS DEVICE AWAY FROM WATER!
5. Please use the provided power adapter.
1. The picture is only for reference. Please make the object as the standard.
2. Please power off the Device and disconnect all cables from the Device
during thunderstorms to avoid possible damage from a lightning strike.
DSL Modem
Reset current settings to Factory Default Settings. While the Device is
powered on, use a pin or paperclip to press and hold the Reset button
for more than 5 seconds, and then release the button. After that, the
Device will restart with factory defalut settings.
![](/img.php?id=3078041&img=bg2.png)
www.uttlogin.com
www.uttlogin.com www.uttlogin.com
http://www.uttlogin.com/-Microsoft Internet...
www.uttlogin.com
http://www.uttlogin.com/-Microsoft Internet...
PPPoE Connection: Enter your PPPoE
username and password offered by your
ISP.
Dynamic IP: ISP does not provide any
data, you can access Internet without any
username or IP address settings.
Static IP: Enter your IP Address, Subnet
Mask, Gateway IP Address and DNS Address
offered by your ISP.
Configure your Internet settings and click “Save”.
Enter wireless password that has been set
in the pop-up screen and click “Connect”.
Enter wireless password that has been
set in the pop-up screen and click “OK”.
Click icon in the task bar. Please
choose the wireless network you are
going to connect in the pop-up list and
click “Connect”.
Click “Start Control Panel Network
and Connection Wireless Network
Connection”, make sure wireless
network connection is enabled.
Click “Start Control Panel Network
and Connection Network and sharing
centre Change Adapter Settings”,
make sure wireless network connection
is enabled.
Click icon in the task bar. Please
choose the wireless network you are
going to connect in the pop-up list and
click “Connect”.
Please click the wireless
network you are going to
connect.
Click “Connect to the network”.Open the WLAN, and click network
list.
Click “System setup”.
Please click the wireless
network you are going to
connect.
Open the WLAN.Click “ WLAN”.
Click “setup”.
If you need to configure 5G wireless network,
you can click “Save” and continue to configure
5G Wireless network (only for dual-band
wireless router.
Congigure wireless settings (2.4G)
and click “Save”.
Configuration completed.
address field of your browser. Click “Yes to configure
the router now”.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body.
