Ubiquiti B5 High Performance 802.11b/g outdoor point to point device User Manual b5 guide graffle
Ubiquiti Networks, Inc. High Performance 802.11b/g outdoor point to point device b5 guide graffle
Ubiquiti >
Guide
B5 USER GUIDE
DataRate Power Tolerance DataRate Sensitivity Tolerance
6Mbps 24 dBm +/-1.5dB 6Mbps -94 dBm +/-1.5dB
9Mbps 24 dBm +/-1.5dB 9Mbps -93 dBm +/-1.5dB
12Mbps 24 dBm +/-1.5dB 12Mbps -91 dBm +/-1.5dB
18Mbps 24 dBm +/-1.5dB 18Mbps -90 dBm +/-1.5dB
24Mbps 26 dBm +/-1.5dB 24Mbps -86 dBm +/-1.5dB
36Mbps 22 dBm +/-1.5dB 36Mbps -83 dBm +/-1.5dB
48Mbps 21 dBm +/-1.5dB 48Mbps -77 dBm +/-1.5dB
54Mbps 19 dBm +/-1.5dB 54Mbps -74 dBm +/-1.5dB
802.11a OFDM
802.11a OFDM
RANGE PERFORMANCE
TX SPECIFICATIONS
RX SPECIFICATIONS
Outdoor (BaseStation Antenna Dependent):
Over 10km
Wireless Approvals
FCC Part 15.247, IC RS210, CE
RADIO OPERATING FREQUENCY 5.745-5.825GHz
SYSTEM INFORMATION
Processor Specs
Atheros AR2313 SOC, MIPS 4KC, 180MHz
Memory Information
16MB SDRAM, 4MB Flash
Networking Interface
10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interface
RoHS Compliance
YES
REGULATORY / COMPLIANCE INFORMATION
SOFTWARE
12V, 1A (12 Watts).
Operating Temperature
-20C to +70C
Operating Humidity
5 to 95% Condensing
Shock and Vibration
Power Supply
PHYSICAL / ELECTRICAL / ENVIRONMENTAL
Enclosure Size
26.4 cm x 8 cm x 3cm
Weight
0.4kg
ETSI300-019-1.4
visit www.ubnt.com/airos
Enclosure Characteristics
Outdoor UV Stabalized Plastic
Mounting Kit
Pole Mounting Kit included
Power Method
Passive Power over Ethernet (pairs 4,5+; 7,8 return)
Max Power Consumption
5 Watts
COMPLIANCE INFORMATION
FCC
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to pro-vide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
!
The antennas used for this transmitter must be installed to provide a separation
operating in conjunction with any other antenna or transmitter.
!
INDUSTRY CANADA
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à! la norme NMB-003 du
Canada.
!
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
!!
To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.)
is not more than that permitted for successful communication.!
distance of at least 193cm from all persons and must not be located or
