USERS MANUAL

DRAFT

20-426

Owner’s Manual

Please read before using this equipment.

RadioShack, Adaptaplug, Hypersearch, and Hyperscan are trademarks

used by RadioShack Corporation.

Motorola, Smartnet, and Privacy Plus are registered

trademarks of Motorola Inc.

is a registered trademark of GE/Ericsson Inc.

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Front and Rear Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Icon Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

What are Highway Patrol Alerts? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

What is Scanning? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

What is Searching? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

What is Trunk Tracking? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Feature Highlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Where to Obtain More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Information on the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Included with Your Scanner Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Installing the 20-426 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

For Home Use (Desktop Installation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

For Mobile Use (In-Car Installation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Typical Mounting Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Mounting the Scanner in Your Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Applying Power for Vehicle Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

DC power Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Applying Power Using Standard AC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Connecting an External Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Listening Safely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Connecting the Clone Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Scanning Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Turn the Scanner On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

How Squelch Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Setting the Squelch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Highway Patrol Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Selecting the State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Scanning Highway Patrol Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Highway Patrol Scan Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Highway Warning Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Alert Tone Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Muting the Alert Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Alert Light Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Skip Frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Priority Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Trunked Highway Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Private Bank Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Programming Frequencies into Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Deleting a Stored Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Duplicate Frequency Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Memory Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Scanning Private Bank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Hold/Resume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Channel Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Restoring a Locked-out Channel in Hold Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Restoring All Locked-out Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Priority Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Changing the Priority Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Service Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Band Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Setting a Search Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Search Hold Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Data Skip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Frequency Skip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Storing Search Frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

iii

20-426 8/22/03 1:40 PM Page iii

Trunk Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Setting the Squelch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Programming Trunking Frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

STEP 1: Selecting Trunking System Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

STEP 2: Programming Trunking Frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Programming Talk Group ID/Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Receiving Trunked Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

ID Scan Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

ID Scan Hold Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

ID Search Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

ID Monitor Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

ID Search Hold and Direct Entry ID in Hold Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Programming Scan Lists During Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Deleting a Stored ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

ID Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Review ID Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Restoring Locked-out IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Setting the Delay Mode for Trunking Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Trunking Frequency Confirmation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Setting Priority in Trunking Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Moving between Scan List Memories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Multi-Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

EDACS® Reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

EDACS® Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Programming EDACS System Frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

An EDACS® Trunked system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Special EDACS® Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

EDACS ID Range Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

EDACS SCAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

LTR® Reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

LTR® Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Motorola Reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Motorola Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Fleet Map Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Selecting Preset Fleet Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Programming a User Fleet Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Programming a Hybrid System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Setting the Base, Spacing Frequencies and Offset Channel for Motorola VHF/UHF

Trunked Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Toggling the Status Bit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Control Channel Only Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Disconnect Tone Detect Option (End Code) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Remote Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

PC Control Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Clone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

One Year Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

20-426 8/22/03 1:40 PM Page iv

Terminology

What are Highway Patrol Alerts?

Most highway patrol vehicles on the road today are equipped with a secondary

radio system

known as a “mobile extender” or “vehicular repeater.” Whenever the dispatcher

transmits to

any vehicle in the district, “mobile extender” in every car within the district is

activated.

Using a constant PRIORITY check of specific frequencies in each state, the 20-426

recognizes and alerts you to transmissions from “mobile extender” radios as well as

from

car-to-car, aircraft-to-car and other special-purpose frequencies. You receive an

audible

(beep tone) and visual (flashing Alert light) alert whenever you are within an

approximate

three-mile radius of Highway Patrol/ State Police units using a mobile extender unit.

What is Scanning?

Unlike standard AM or FM radio stations, most two-way communications do not

transmit

continuously. The 20-426 scans the Frequencies you have programmed into the

Scanner’s

channels until it finds an active frequency.

Scanning stops on an active frequency and remains on that channel as long as the

transmission continues. When the transmission ends, the scanning cycle resumes

until

another transmission is received.

What is Searching?

The 20-426 can search each of its 13 bands to find active frequencies. This is

different from

scanning because you are searching for frequencies that have not been

programmed into

your Scanner’s channels. The scanner automatically chooses between two speeds

while

searching. During search mode the scanner will search 100 frequencies per second

for band

with 12.5 kHz steps and during Turbo SEARCH mode the scanner can achieve up

to 300

frequencies per second for bands with 5 kHz steps.

What is Trunk Tracking?

Conventional scanning is a simple concept. You enter a radio frequency in your

scanner’s

memory which is used by someone you want to monitor. For example, the police in

your

area may broadcast on 460.500 MHz, the fire department on 154.445 MHz, the

highway

department on 37.900 MHz, etc. So when your scanner stops on a frequency, you

usually

know who it is, and more importantly, you can stop on a channel and listen to an

entire

conversation. This type of scanning is easy and fun.

As the demand for public communications has increased, many public radio users

don't

have enough frequencies to meet their needs, and this has created a serious

problem.

Trunking radio systems have been implemented to solve this problem.

20-426 8/22/03 1:40 PM Page 4

In a trunked radio system the frequencies are shared among the police and fire

departments

and a computer systematically assigns available frequencies when they are needed

for

communications.

Sharing of the available public service frequencies, or trunking, allows cities,

counties, or

other agencies to accommodate hundreds of users with relatively few frequencies.

Following

a conversation on a trunked system using a scanner is difficult, if not impossible.

Because

when there's a short break during the conversation you're monitoring, it’s possible

that the

talkgroup will be assigned to a completely different frequency in the trunked system.

This

type of scanning is difficult and frustrating.

TrunkTracker Technology changes this! Not only does your new 20-426 scan

channels like

a conventional scanner, it actually follows the users of a trunked radio system. Once

you

know a talkgroups ID, you won’t miss any of the action.

If you're a new scanner enthusiast, you may want to read the first part of this

manual and

use your scanner in conventional mode before you begin trunk tracking.

Understanding

scanning fundamentals and its terminology will make trunk tracking much easier.

20-426 8/22/03 1:40 PM Page 5

Feature Highlights

• Pre-programmed frequencies specific to each state (except Hawaii).

• Pre-programmed Trunked and conventional Highway Patrol frequencies

• Highway Patrol Priority Alert

-Receive audible and visual alert when within three miles of many Highway

Patrol/State

units

• Pre-programmed frequencies for the following categories:

-Local Police and County Sheriffs

-Fire and Emergency Medical Service

-News Media

-Weather (continuous NOAA weather and Canadian Coast Guard broadcasts)

-CB Radio

-Aircraft

-Railroads

-Marine Band

-Department of Transportation

• Pager Screen - lets you set the scanner so it does not detect pager frequencies

during Close Call search.

• Trunk Tracking – Follow VHF High Band UHF 800MHz trunked public safety and

public

service systems just as if conventional two-way communications were used.

• Multi-Track – Track more than one trunking system at a time. Scan conventional

and

trunked systems at the same time.

• 1000 Channels – Program one frequency into each channel. You must have at

least one

channel programmed to use the Scan mode.

• 13 Bands – Includes 13 bands, with aircraft and 800 MHz.

• 10 Banks – 10 banks with 50 channels each are useful for storing similar

frequencies to

maintain faster scanning cycles or for storing all the frequencies of a trunked

system.

• 25 MHz-956 MHz – Indicates the range of frequencies that can be searched within

the

bands of your scanner.

Note: The frequency coverage is not continuous and excludes the cellelar

telephone

Band.

• 5 Priority Channels – You can assign one priority channel in each bank.

Assigning a

priority channel allows you to track activity on your most important channel(s) while

monitoring other channels for transmissions. You can also assign trunking priority

talkgroups.

• Data Skip – Allows your scanner to skip unwanted data transmissions and

reduces

birdies.

• Direct Channel Access – Go directly to any channel without entering

programming mode.

• Turbo Search – Increases the search speed to 300 steps per second. This

applies only to

transmission bands with 5 kHz steps.

• PC Programmable – Allows you to easily program all frequencies and Trunking

Talk

Groups into your 20-426 through Radio Shack 20-426 Scanning software running

on your PC.

– For more information on 20-426 SS Programming software visit our website at

scanner.Radio Shack.com.

20-426 8/22/03 1:40 PM Page 6

Where to Obtain More Information

Before you can scan the PRIVATE bank, you must program frequencies into the

scanner’s

channels. The Frequency Guide lists typical frequencies used around the U.S.A.

and

Canada that you may program into your new scanner. However, this is not a

complete list of

frequencies for your area.

To obtain frequency information for your area, contact one of the following:

• Scanner Master

1 (800) Scanner (722-6637) (Hours are from 10:00 a.m. to 5:00 p.m. Eastern Time

Monday through Friday.) frequencies@scannermaster.com.

To obtain another copy of the frequency guide, contact one of the following:

• Radio Shack Parts Department

(800) 554-3988 (Hours are from 8:00 a.m. to 5:00 p.m. Central Time Monday

through

Friday.)

• Local Dealer

Information on the Internet

If you have access to the internet, you may want to visit one of the following

websites for

additional information:

scanner.Radio Shack.com

www.bearcat1.com

10:36 AM Page 7

Included with Your Scanner Package

• 20-426 Scanner

• AC Adapter (AD 140U)

• DC Power Cord

• Cigarette Lighter Adapter Plug (Model CD007)

• Telescopic Antenna (Model AT129)

• Window Mount Antenna (Model AT002)

• Operating Guide

• Trunk Tracker Frequency Guide

• Other Printed Materials

• Remote Programming Software Demo CD-ROM

• Mobile Mounting Bracket (Model MB-008)

If any of these items are missing or damaged, immediately contact your place of

purchase or

Radio Shack Customer Service at: (800) 297-1023, 8:00 a.m. to 5:00 p.m., Central

Time, Monday

through Friday.

Optional Accessories

The following optional accessories for your 20-426 are available from your local

Radio Shack

Dealer or through the Radio Shack Parts Department by calling: (800) 554-3988,

8:00 AM to 5:00

PM CST, Monday through Friday. We can also be reached on the web at

www.Radio Shack.com.

DC Power Cord (Model PS-001) - For hard wiring power from your car to your

scanner.

Motorola Antenna Adapter (Model PLG-134) - Use only if your antenna has a

Motorolatype

plug.

Page 8

Installing the 20-426

For Home Use (Desktop Installation)

1. Insert the DC plug end of the AC Adapter into the DC 12V jack on the rear panel.

2. Plug the AC Adapter into a standard 120V AC wall outlet.

3. Plug the Telescoping Antenna into the ANT connector.

Extend the antenna to its full height. For frequencies higher than 406 MHz,

shortening

the antenna may improve the reception.

4. Use the desktop stand for a better viewing and operating angle.

Helpful Hints

• If strong interference or electrical noise is received, relocate the scanner or its

antenna

away from the source.

• If you are operating the scanner in a fringe area or need to improve reception, use

optional antenna designed for multi-band coverage. (You can purchase this type of

antenna at a local electronics store.)

• If the optional antenna has no cable, use 50-70 ohm coaxial cable for lead-in. A

mating

plug may be necessary for the optional antennas.

For Mobile Use (In-Car Installation)

Installation for Temporary Use:

A Cigarette Lighter Power Cord is provided for easy, temporary installation.

Warning: Do not use the cigarette lighter power cord in a positive ground vehicle.

Plug one end of the Cigarette Lighter Power Cord into the cigarette lighter jack and

the other

end into the DC 12V jack on the back of the scanner.

Connecting the Antenna Plug

Connect the mobile antenna plug into the ANT connector on the rear panel. (For

information on antenna installation, please refer to the instruction guide that came

with your

antenna.)

The 20-426 can be mounted using the supplied mounting bracket.

This bracket is available from the Radio Shack parts department (see page 8)

1. Select an ideal location in your vehicle to mount the 20-426. Avoid a location that

could

interfere with your driving. In a passenger car, the ideal location is underneath the

dashboard on the passenger side.

2. Use the supplied mounting bracket as a template for marking the location of the

mounting screws. Note: If there are screws already holding the dashboard, you can

use

the same screw holes to mount the bracket.

Page 9

3. Drill the necessary holes and secure the mounting bracket in place using the

screws

provided.

4. Mount the radio to the bracket only after the wiring has been connected to the

rear

panel.

Connecting the Power Cord

Note: If you are not experienced in connecting accessories to the vehicle fuse box,

please

see your automotive dealer for advice on proper installation.

Installation for everyday use:

1. Check the vehicle battery connections to determine which battery terminal

(positive or

negative) is grounded to the engine block or chassis. Most of today’s vehicles use a

negative ground. If your vehicle has a negative ground, follow Steps 2 and 3.

Otherwise,

skip to the note following Step 3.

2. Connect the RED wire of the DC power cord to the accessory contact in your

vehicle’s

+12V DC fuse box.

3. Connect the BLACK wire of the DC power cord to the negative side of the vehicle

(usually the chassis).

Note: In vehicles with a positive ground, the RED wire connects to the chassis and

the

BLACK wire connects to the accessory contact in the fuse box.

4. Insert the DC plug into the DC 12V jack on the back of the scanner.

20-426 8/22/03 1:40 PM Page 10

Typical Mounting Methods

The 20-426 can be conveniently mounted on a table, bulkhead, overhead, or any

other

desired location with the supplied mounting bracket (MB008) (refer to figure below

for typical

mounting methods).

Caution: Make sure there are no hidden electrical wires or other items behind the

desired

location before proceeding. Check that free access for mounting and cabling

is available.

Mounting the Scanner in Your Vehicle

Before you mount the scanner, make sure you have all the necessary materials.

Then

confirm that the scanner fits your vehicle’s mounting area. This unit requires a

mounting

area of 2.44 inch high by 7.06 inch wide by 6.10 inch deep (50.8 x 176.5 x 152.5

mm).

Caution: Be sure to avoid obstructions behind the mounting surface.

Follow these steps to mount the scanner in your vehicle.

1. Choose a mounting location, then use the supplied

mounting bracket as a template to mark the positions for

the mounting screw holes.

2. In the marked positions, drill holes slightly smaller than

the supplied screws.

3. Attach the mounting bracket to the mounting location

using the supplied screws and lock washers.

4. Attach the scanner to the mounting bracket using the

supplied mounting knobs.

5. Connect the antenna’s cable to the ANT. connector

on the rear of the scanner.

Note: If the antenna cable’s connector does not fit in the ANT.

connector, you might also need a Motorola-to BNC

antenna plug adapter (available at a local

electronics store).

• Table top mount • Bulkhead mount • Overhead mount

SQL

VOL

ANT.

EXT.

SP.

DC 12V

REMOTE

Page 11

Applying Power for Vehicle Installation

You can power your scanner using the supplied DC cigarette lighter power cord or

an DC

power cord.

DC power Installation

To power the scanner from a vehicle’s 12V power source (such as a

cigarette-lighter

socket), you need a cigarette-lighter adapter.

To connect an DC cigarette-lighter power cable, insert its barrel plug into the

DC 12V jack on the rear of the scanner, then plug the power cable into your

vehicle’s

cigarette lighter socket.

Note : If you use a cigarette-lighter power cable and your vehicle’s engine is

running, you

might hear electrical noise from the engine while scanning. This is normal.

Caution: DC 12 V Jack can use a power source that supplies 12V DC at least 500

mA.

You must use a power source that supplies 12V DC and delivers at least

500 mA. Your standard 12V car battery should be sufficient. The cord connector’s

center tip must be set to positive and its plug must fit the scanner’s DC 12V jack.

The supplied DC power cord meets these specifications. Using a power cord that

does not meet these specifications could damage the scanner or the adapter.

• Always connect the adapter or DC power cord to the scanner before you connect it

to the

power source. When you finish, disconnect the adapter or DC power cord from the

power

source before you disconnect it from the scanner.

• For added safety and to protect your scanner,

disconnect the cable from your vehicle battery’s

negative (-) terminal before you begin.

Follow these steps to connect the DC power cord.

1. Connect the power cord’s black wire to a chassis ground, such as a metal screw

attached to a metal part of the vehicle’s frame. Be sure that the screw is not

insulated

from the frame by a plastic part.

2. Connect the power cord’s red wire (with in-line fuse) to a source

of voltage that turns on and off with the ignition switch, such as

a spare accessory terminal in your vehicle’s fuse box.

3. Insert the power cord’s barrel plug into the DC 12V jack on

the rear of the scanner.

4. Reconnect the cable to the vehicle battery’s negative (-)

terminal.

ANT.

EXT.

SP.

DC 12VREMOTE

Applying Power Using Standard AC Power

To power the scanner from an AC outlet, use the provided AC adapter with a 5.5

mm outer

diameter/2.1mm inner diameter tip.

Caution: You must use a Class 2 power source that supplies 12V DC and delivers

at least

500 mA. The cord connector’s center tip must be set to positive and its plug must

fit the scanner’s DC 12V jack. Using an adapter that does not meet these

specifications

could damage the scanner or the adapter.

• Always connect the AC adapter to the scanner before you connect it to AC power.

When

you finish, disconnect the adapter from the AC power before you disconnect it from

the scanner.

1. Insert the adapter’s barrel plug into the DC

12V jack on the rear of the scanner.

2. Plug the adapter into a standard AC outlet.

Note: Use only the AC adapter supplied with

your scanner.

Connecting an External Speaker

In a noisy area, an external speaker (available at a local electronics store)

positioned in the

right place might provide more comfortable listening.

Plug the speaker cable’s 1/8 inch (3.5 mm)

plug into your scanner’s EXT. SP. jack.

Note: Connecting an external speaker

disconnects the scanner’s

internal speaker.

Listening Safely

• Do not use the earphone. The volume is not adjustable for the Warning Alert

and

damage to your hearing could occur.

Connecting the Clone Cable

You can transfer the programmed data to and from another 20-426 scanner using a

RS232C

Straight Cable (9 pin to 9 pin) (not supplied). Connect the cable between each

scanner’s

REMOTE jacks. See "Clone Mode" on page 49. You can also upload or download

the

programmed data to or from a PC using optional programming software available

through

your local electronics store.

ANT.

EXT.

SP.

DC 12VREMOTE

12V

ANT.

EXT.

SP.

DC 12V

REMOTE

20-426 PM Page 13

Scanning Overview

You can scan in one of four ways:

1. Highway Patrol Scanning When you select a state you want to scan in Highway

Patrol

mode, you can scan pre-programmed Highway Patrol frequencies.

2. Service Scanning Press SVC to select one of the nine services to find an active

frequency.

3. Band Search Select a frequency band to search. The Search function is different

from

scanning. It searches for any active frequency step by step within the lower and

upper

limits of the band. When an active frequency is found, the scanner will stop and stay

that frequency as long as that transmission lasts. If that frequency is interesting to

you,

press HOLD/RESUME to hold the frequency on the display. Then program it into

the

private bank you want to store. If you do not want to program that frequency, press

HOLD/RESUME or just wait until the transmission ends. The search resumes

automatically 2 seconds after the last transmission and looks for more active

frequencies.

4. Private Scanning If you have programmed frequencies into this bank, press

PVT to

scan only those that you have programmed in this bank.

Note: Before you can scan the Private Bank, you must program frequencies into the

channels. To program frequencies, see “Programming Frequencies into Channels”

page 21.

When scanning stops on an active frequency, it remains on that channel as long as

the

transmission continues. When the transmission ends, the scanner will remain on

the same

channel for 2 more seconds, waiting for a responding transmission. If there is no

responding

transmission within 2 seconds, the scanning cycle resumes.

Turn the Scanner On

1. Turn the VOL knob clockwise.

The scanner is turned on: the Alert Light flashes and the Alert

Tone beeps loudly.

Note: The Alert Tone depends on the currently setting selected

(see page 17).

2. The last setting mode selected before starts.

VOL

push

ALERT

MUTE ALERT

Turn

SQL

VOL

push

ALERT

FLASH

MUTE ALERT

Alert

Light

Page 14

How Squelch Works

Think of “SQUELCH” as a gate. If the gate is too low (squelch

too low), everything (all noise as well as signals) gets through.

If the gate is set too high (squelch too high), nothing gets

through.

If the gate is set just right (squelch set properly), just the desired

signals get through.

Setting the Squelch

1. To set the squelch, press HOLD/RESUME to stop scanning.

If needed, adjust VOL until you do not hear a signal (see

page 17).

2. Turn SQL fully clockwise until hiss heard.

This lowers the “squelch gate,” allowing all signals and noise

to get through.

3. Turn SQL fully counterclockwise just until hiss stops.

This raises the “squelch gate,” allowing only strong signals to

get through.

In the city, you may want to adjust the Squelch even further

counterclockwise to decrease the range of the Highway Warning

Alert signal.

This prevents the alert from sounding unnecessarily due to

farther, less important sources.

Strong Signals

Medium Signals

Weak Signals

Noise

Strong Signals

Medium Signals

Weak Signals

Noise

Strong Signals

Medium Signals

Weak Signals

Noise

SQL push

FLASH

MUTE ALERT

Turn

SQL push

FLASH

MUTE ALERT

Turn

Page 15

Highway Patrol Scanning

Highway Patrol frequencies are pre-programmed on a state-by-state basis. When

Highway

Patrol scanning, the Highway Warning Alert is activated.

Selecting the State

1. Press STATE to select the state you are operating in.

Press and hold STATE to scroll rapidly.

Hint: For the State Code Order, please see page 56.

2. To step forward through the states (A - W), press STATE

and, within three seconds, press the ▲ key repeatedly. To

step backward through the states (W - A), press STATE and,

within three seconds, press the ▼ key repeatedly.

3. To scroll rapidly, press and hold the ▲ or ▼ key.

Scanning Highway Patrol Frequency

You can scan Highway Patrol frequencies by pressing PVT or HWY/POL.

1. Press HWY/POL to scan through only pre-programmed Highway

Patrol frequencies.

Press PVT repeatedly in Highway scanning mode until “HWY/POL”

appears on the display to scan through pre-programmed

Highway Patrol frequencies.

Hint: If you press PVT repeatedly in Highway scanning mode

until “HWY/POL” and “PVT” appears on the display, you can

mix-scan between Highway Patrol frequencies and User

Programmed channels.

2. When the scanner receives communications, scanning stops,

the state code and the frequency appear.

When the transmission ends, the scanner holds for two

seconds on that frequency for a response. For more

information on the Delay feature, please see page 28.

If there is no response, scanning resumes.

Page 16

Highway Patrol Scan Hold

1. When scanning stops on a desired frequency, press

HOLD/RESUME to hold on that frequency as long as you

like. When in the HOLD mode, press the ▲ or ▼ key to step

up or down the frequency. To step up or down rapidly, press

and hold the ▲ or ▼ key.

If you change into a frequency which is a control channel, the

scanner may display the Active ID (When TRUNK mode is

active).

2. To resume scanning, press HOLD/RESUME.

Note: Highway Warning Alert does not work while in the HOLD

mode.

Highway Warning Alert

The scanner alerts you when Highway Patrol/State Police units using mobile

extenders are

within an approximate three mile radius.

1. The ALERT Light flashes and the Alert Tone beeps twice

when a signal is received.

2. The ALERT Light glows steadily for approximately three

minutes. Then, if no other mobile extender transmissions are

received, the light goes out.

3. If more transmissions are received before three minutes have

passed, the ALERT Light flashes and the Alert Tone beeps once.

Alert Tone Volume

Push VOL to select Loud, Medium, or Soft.

The Alert Tone beeps and the ALERT Light flashes to your

choice.

Muting the Alert Tone

Temporary Mute

Press MUTE during the Highway Warning Alert. The Alert Tone

stops and the MUTE LED flashes until the alarm cycle (three

minutes) is finished.

Continuous Mute

Press and hold MUTE for two seconds to turn Continuous Mute on whenever you

wish. You

hear two beeps and the MUTE LED lights continuously. No Alert Tones will beep.

Canceling Mute

To cancel Mute,

VOL

push

ALERT

FLASH

MUTE ALERT

Alert

Light

Flashes

VOL

push

ALERT

MUTE ALERT

Push In

VOL

push

ALERT

FLASH

MUTE ALERT

MUTE LED

Flashes

Page 17

• Press MUTE to cancel One Moment Mute.

• Press and hold MUTE for two seconds to cancel Continuous Mute. You hear two

beeps

and the MUTE LED goes out.

• Change states. The MUTE LED goes out after scanning starts.

• Turn the scanner off and on.

Note: If MUTE is pressed for less than 2 seconds during the Continuous Mute

mode,

nothing will be changed.

Alert Light Adjustment

The ALERT Light has three settings: Bright, Dim, and Off.

Push FLASH to select Bright, Dim or Off. The ALERT Light

flashes and the Alert Tone beeps.

If you select Off, “ ” on the display reminds you the ALERT

Light is off.

WARNING: You can turn off the ALERT Light and completely

mute the Alert Tone at the same time.

This deactivates the Highway Warning Alert.

Skip Frequencies

To skip a frequency, press L/O.

You can program up to 50 skip frequencies for priority channels. And also you can

program

up to 100 skip frequencies for other frequencies (See page 27). If you skip a

preprogrammed frequency in one state and that frequency is programmed into

another state,

the frequency is skipped of both states. If you change the state code, skipped

frequencies

are cancelled as soon as scanning starts.

Priority Channels

Each state preprogrammed in the scanner contains a number of Priority channels.

The

scanner automatically checks a state’s Priority channels every two seconds for

activity. If

there is activity on one of the Priority channels, the ALERT Light will flash and the

alarm

tone will beep (see “Highway Warning Alert,” page 17).

SQL push

FLASH

MUTE ALERT

Push In

Page 18

You will experience a slight in the conversations you hear as the scanner checks

the

Priority channels. You can cancel the priority check and the interruptions in the

conversations by pressing HOLD/RESUME to hold on the frequency.

Note: The Highway Warning Alert is inoperative while the scanner is on Hold.

Remember to press HOLD/RESUME to return to normal priority-scan operation.

Priority channel cannot be changed, but you can lock-out priority channels using

L/O.

Priority channels have been pre-determined by the manufacturer as those Highway

Patrol

frequencies most commonly used for mobile extenders and for car-to-car and

aircraft-to-car

operations. Mobile extenders re-transmit every radio broadcast received on the

patrol car

radio to the officer’s walkie-talkie at low-power. Every time any officer or dispatcher

talks

(transmits), the signal is broadcast like a beacon at low-power whether or not the

officer is

out of the car.

You can select Priority Scanning mode by pressing PRI.

• Normal Priority Scan mode.

The scanner checks the Priority frequency every two seconds. “PRI” will be

displayed.

• Priority only mode.

To only monitor the priority frequencies, press and hold PRI to select Priority Only.

This

mode is especially recommended for the following states:

(Arizona) (Michigan)

(Delaware) (Oklahoma)

(Florida) (Wisconsin)

“PRI” flashes when you select Priority Only Mode.

• Priority off mode

The scanner does not check the Priority frequency. “PRI” will not displayed.

20-426 8/22/03 1:40 PM Page 19

Trunked Highway Frequency

Trunked Highway frequencies are pre-programmed for each

state. When the scanner finds the control channel data, the

scanner begins to find any active IDs. If the scanner finds any ID,

the active ID appears on the display and you will hear it.

If you press the ▲ key while monitoring an ID, the scanner will check to see if any

other IDs

are active. If none are active, scanning resumes.

When the scanner finds a control channel, it will stay on that control channel until

reception

of the control channel is lost. To force the scanner off of the trucking control channel,

press

DATA.

If you press the ▼ key while a talk group ID is active, the

frequency on which talk group is transmitting flashes on the

display.

Or press and hold the ▼ key for two seconds, and the ID and the frequency

alternately

appears on the display. To return to the normal display, press the ▼ key again.

Like conventional scanning, you can lockout reception of unwanted traffic.

You can lockout up to 30 IDs. Press L/O on the ID you want to lockout.

If you lockout 31st ID, the 1st ID already locked out is restored.

If you want to restore all the locked out IDs, pres and hold L/O for two seconds.

Or, when the state code is changed, all lockout IDs are restored as soon as

scanning starts.

If you find an interesting ID you want to continue listening to,

press HOLD/RESUME.

Press HOLD/RESUME to resume scanning.

You can set the scanner to hold on an ID for two seconds to wait for a replay before

scanning resumes. While trunking, press DELAY. “DLY” appears on the display.

Page 20

Private Bank Scanning

Programming Frequencies into Channels

Before the scanner begins Private Bank scanning, you must program a frequency

into at

least one channel. Program frequencies you purchased from your dealer, from

various free

and FCC-based sources on the internet, or from the Frequency guide included in

20-426

package. You will need to program each frequency into the

scanner’s channels in order to hear these frequencies.

1. While Private Bank scanning is activated, press

HOLD/RESUME and enter the channel number where you

want to store a frequency by using the keypad, then press

HOLD/RESUME.

✎ Change the channel by using the ▲ or ▼ key.

2. Enter the frequency you want to store by using the keypad

and (decimal key).

3. Press E to store the frequency into the channel.

4. If you want to program another frequencies into the channel,

select another channel by using the ▲ or ▼ key.

Note: • To clear a mistake while entering the frequency, press (decimal key)

repeatedly until the display is cleared.

• If you enter a invalid frequency, an error tone will sound and appears on the

display. To clear the Error message immediately, press (decimal key).

• Even if you don't enter full numbers as a frequency number, the scanner will

automatically

select the nearest valid frequency.

Deleting a Stored Frequency

To delete a stored frequency:

a. Select a channel.

b. Press 0.

c. Then press E.

Note: Channels with no frequencies are automatically locked out.

20-426 8/22/03 1:40 PM Page 21

Duplicate Frequency Alert

If you enter a frequency which has been stored in another channel, you will hear an

error

tone and the other channel displays.

Press (decimal key) to clear and start again.

––– OR –––

Press E again to store the frequency in both channels.

Note: The smallest channel appears on the display when you store same frequency

in two

or more channels.

Memory Lock

To avoid the accidental programming frequencies and talk group IDs, you can lock

the

memory with Memory Lock.

Press and hold M-LOCK for 2 seconds to activate this feature ,and “M-LOCK”

appears on

the display. If you press E to program memory, you will hear two beeps. To

deactivate

Memory Lock, press and hold M-LOCK for 2 seconds again.

Scanning Private Bank

1. After programming frequencies, simply press HOLD/RESUME

to begin scanning. Or pressing PVT repeatedly until “PVT”

appears on the display, you can start Private Bank Scanning.

The scanner scans only upward all the channels.

2. The bank indicators selected for scanning appear on the display, and the bank

being

currently monitored flashes. You can deselect banks from active scanning by

entering

their numbers on your keypad. The indicator for each deselected bank disappears,

and

the bank’s channels are not scanned.

Note: One bank must always be active. You cannot deactivate all five banks at the

same

time. If you try to deselect all the banks, the first bank is automatically selected.

To restore a bank to active scanning, enter the bank’s number on your keypad.

The bank’s indicator will display again.

3. During normal scanning the scanner skips unprogrammed or

locked out channels.

4. When a transmission is received, the scanner stops on that

channel. When the transmission ends, scanning resumes

automatically.

Note: You can set the scanner to hold for two seconds on the

frequency for a response. For more information on Delay

feature, please see page 28.

1 3 4 5 2 BANK

Frequency not entered

or Locked Out (L/O)

SCAN

Page 22

Hold/Resume

If you want to stop on a channel during scanning, press

HOLD/RESUME.

If you want to resume scanning, press HOLD/RESUME.

Direct channel access:

There are several ways to access a specific channel quickly.

1. Press HOLD/RESUME.

2. Using the keypad, enter the channel number.

3. Press HOLD/RESUME again.

Note: You can also use the PVT, ▲ or ▼ key instead of

pressing HOLD/RESUME.

Channel Lockout

You can lockout any channel so it is not checked during normal scanning. You can

also

restore the channel to scanning when you wish.

Lockout in Hold Mode

１. Press HOLD/RESUME and enter the channel number by using the keypad, then

press

HOLD/RESUME.

––– OR –––

1. Press HOLD/RESUME and enter the channel by using the ▲

or ▼ key.

2. Press L/O to lockout the channel.

“L/O” appears on the display.

Lockout in Scanning Mode

If the scanner keeps stopping on a particular channel due to noise or frequent

transmissions,

you may want to keep that channel from scanning.

1. Wait until the scanner stops on the channel.

2. Then press L/O.

3. The scanner immediately resumes scanning because the locked out channel is

no longer

in the scanning sequence.

Lockout Tips Write down your locked-out channels and put in a convenient place

case you need to restore them.

Restoring a Locked-out Channel in Hold Mode

1. Press HOLD/RESUME and select the channel number you want to restore by

using the

keypad, the ▲ or ▼ key, then press HOLD/RESUME.

2. Press L/O to unlock the channel. The “L/O” disappears.

Page 23

Restoring All Locked-out Channels

You can restore all locked-out channels in a bank only when a bank is selected for

scan. If

you have deselected a bank and you want to restore all of its locked-out channels

using the

steps below, you must press PVT until “PVT” appears and then enter the number of

the

bank on your keypad.

1. Press HOLD/RESUME.

Note: You must be in Hold mode before restoring all locked-out channels.

2. Press and hold L/O for about 2 seconds. You will hear two beeps when all the

channels

have been restored.

Priority Scan

When Priority Scan is turned ON, your scanner checks the priority channel in the

banks you

selected every two seconds for activity. If a signal is present on the priority channel,

your

scanner monitors the channel until the transmission ends, then resumes normal

scanning.

You can designate one channel in each bank as a Priority Channel. By default, the

first

channel in each bank is the Priority Channel, but you can change this.

To activate Priority Scan (in either the Hold or Scan mode):

1. Press PRI. “PRI” appears.

Note: If you have locked out the priority channel, error message

appears when you select Priority mode.

2. Press PRI again to deactivate Priority Scan. “PRI” disappears.

Changing the Priority Channel

You cannot eliminate the Priority Channel, but you can change it to any one of the

available channels in each bank.

1. Press HOLD/RESUME.

2. Select a new Priority Channel:

a. Enter the channel number using the keypad.

b. Then press HOLD/RESUME.

3. Press and hold PRI for 2 seconds to designate this channel

as your new Priority Channel.

When you hear two beeps, the Priority Channel has been

changed. “P” appears on the display.

Note: Priority in Trunking mode works just the same, except you set them for

talkgroup IDs

instead of setting priorities for channels. The scanner only checks priority talkgroups

between transmission.

Page 24

Service Scanning

The service scan feature allows you to rotate through the following nine service

banks.

q Local Police and County Sheriffs *1

w Fire and Emergency Medical Service

e News Media

r Weather (NOAA, weather and Canadian Coast Guard broadcasts)

t CB Band

y Aircraft *2

u Railroads

i Marine Band

o Department of Transportation *1

*1) Frequencies are pre-programmed on every U.S. state.

*2) Except Aeronautic Radio Navigation (108-117.9875 MHz)

1. Press SVC to select a Service.

The current service bank icon appears on the display.

2. Continue pressing SVC until your desired Service is

displayed.

3. After a three second delay scanning begins. If you want to

start scanning immediately, press HOLD/RESUME.

Notes:• Press HOLD/RESUME at any time to hold the frequency. Press the ▲ or

▼ key to

move up or down the frequency. If you find the frequency you want to store, while

in Hold mode you can store the frequency (see page 21).

• If you want to remain on a frequency until a responding transmission is received,

press DELAY to activate the delay feature (See page 28).

• To skip a frequency, press L/O. You can program up to 100 skip frequencies for

Local Police, County Sheriffs and Department of transportation. And you can

program up to 50 skip frequencies for other services (See page 27).

• If you select POLICE or DOT, press STATE to select the desired state.

Page 25

Band Search

Setting a Search Band

The 20-426 can search up to 13 separate frequency ranges to help you discover

new stations

in your area.

To set a Search Bands, enter into the Band Search mode.

1. Press SRCH. The upper and lower limits of the Bands

currently selected are on the display.

2. Use the ▲ or ▼ key to select the band you want to search.

Wait for about two seconds and the scanner will begin

searching that band. Or press HOLD/RESUME to begin

immediately.

Notes:• You must set the Search Bands prior to any searching.

• The scanner automatically increases its search speed up to 300 steps per second

for bands having 5 kHz steps. (Turbo Search)

• While searching, you can change the search direction by using the ▲ or ▼

key.

Make sure which of icon, “▲SRCH” or “SRCH▼” appears on the display.

Band

Page 26

• While Private Scanning in the trunking banks, press SRCH, then it will move to ID

Search mode.

Search Hold Feature

1. Press HOLD/RESUME at anytime to stop the search. To move up or down 1

frequency

step, use the ▲ or ▼ key.

2. Press HOLD/RESUME to resume searching.

Data Skip

A scanner will normally stop on any transmission it receives. This

means the 20-426 will occasionally stop on data signals and

unmodulated transmissions. You can automatically skip many of

these types of transmissions during search.

1. To activate the Data Skip feature, press DATA in Scan or Search mode. “ ”

appears on the display.

2. To deactivate the Data Skip feature, press DATA again. “ ” disappears.

When Data Skip is active, your scanner may pause momentarily on an unwanted

signal

but will resume searching in two or three seconds. The Data Skip feature is active

well as Scan mode and Service Search mode. Data Skip does not function during

Service Scanning band (for AIR, CB, or Weather band), Priority Scan, and Trunking

mode.

Frequency Skip

If a particular frequency continues to interrupt search scanning, it is possible to set

the

scanner to skip the frequency.

To skip over a frequency, press L/O when stopping on the frequency you want to

skip or

when in Search Hold mode.

Note: You can program up to 100 skip frequencies.

The 101st skip frequency entered causes the first skipped frequency to unlock.

To restore a Locked out/Skipped channel.

1. Select the desired frequency by using the ▲ or ▼ key in Search Hold mode.

2. Press L/O, and then press HOLD/RESUME.

To restore all skipped frequencies, press and hold L/O for 2 seconds in Search Hold

mode.

Storing Search Frequencies

You can quickly store any frequency you find during Search.

1. During Search, press HOLD/RESUME. If you want to change

the frequency, use the ▲ or ▼ key to move up or down 1

frequency step. Then press E. Or when the scanner stops on

the frequency you want to store, press E.

2. Select a bank you want to store by using the keypad. The

smallest empty channel number and the frequency alternately

appear on the display. If necessary, you can also change the

channel by using the keypad, the ▲ or ▼ key.

3. Press E.

Note: • If the frequency you want to store exists already in a bank, you will hear an

error

tone and other channel appears on the display. (See “Duplicate Frequency Alert”

on page 22.)

• After storing the frequency, it moves to the Search Hold mode.

• If there is no free channel, the frequency you want to store will automatically be

stored in the first channel in the selected bank.

4. Press SRCH to resume searching.

Delay

To help prevent missing a reply on a specific channel or frequency, you can

program a two second

delay into any channel, frequency, service band or band search. When scan or

search stops on a channel or frequency, there is a two-second pause before the

scanning

cycle resumes.

To activate the Delay feature (in either Scan mode or Search mode):

1. For Highway Scan mode or Private Scan mode, when in Hold mode, select the

desired

frequency or channel and then press DELAY. Or when the scanner stops on an

active

frequency or channel, quickly press DELAY before it continues scanning again.

––– OR –––

1. For Search mode, while searching press DELAY.

2. “DLY” will appear on the display.

20-426 8/22/03 1:40 PM Page 28

Trunk Tracking

Your 20-426 is tracks three major types of trunked radio systems. These systems

are

described here.

✎MOTOROLA - Including Type I, Type II, Hybrid, SMARTNET, and Privacy Plus.

Motorola systems are widely used by public safety and business users. Most are on

the 800 MHz band, and recent systems are appearing on other bands. (see page

43).

✎EDACS - Including "Wideband" 9600 baud and SCAT. "Wideband" systems are

mostly on

the 800 MHz band, and are used by public safety, utilities, and business users.

Some

systems are used on the VHF and UHF bands. (see page 39). SCAT systems are

single-channel EDACS systems, and are mainly used in the Midwestern United

States.

✎LTR - These systems are mostly for business users, and found on the UHF, 800

and 900

MHz bands. (See page 42).

For details on the operation and programming for all of these systems, see pages

29-47.

When tracking these types of systems, remember these important points:

• Your scanner defaults to monitor Motorola Type II 800; however, you can change

this if

the system in your area is different. (The types of systems are discussed below.)

• The frequencies for many of the trunked public safety systems are listed in the

TrunkTracker

Frequency Guide included with your 20-426 scanner. Frequencies sometimes

change, check

with www.trunktracker.com.

• If you have internet access, you can visit scanner.Radio Shack.com or

www.trunktracker.com

for additional information, for current news and frequency information, about Trunk

Tracking Scanning.

* Motorola, SMARTNET, and PRIVACY PLUS are trademarks of Motorola Inc.

EDACS is a

registered trademark of the M/A - COM Inc. LTR is a registered trademark of E.F.

Johnson

Company.

Setting the Squelch

For trunked reception, a good setting for the SQL control is in the

center of the range with the color marker pointing up. See the

illustration.

If it is set too high, it could prevent your scanner from locking to the

Control Channel reliably. If it is set too low, it will slightly delay finding

the Control Channel. The best setting is the same as for conventional

reception, and is critical for monitoring trunked systems.

SQL push

FLASH

MUTE ALERT

Page 29

Programming Trunking Frequencies

There are three steps for programming a trunked system:

1. Program the Trunk Type – What type of system will the scanner be tracking,

Motorola

Type II, Type I, EDACS, LTR, etc.

2. Program the Trunked Frequencies – Within a trunked system, the frequencies

are

shared among all the users, called “Talk Groups”.

3. Program the Talk Groups – Within the trunked system, each agency or

department is

assigned a Talk Group ID. This ID must be programmed into the scanner in order

for it to

monitor that specific agency or department.

Before you start programming your scanner to track a trunked system, consider the

following:

• You can only program one trunking system in each bank of your scanner.

• Trunked frequencies must be entered while in the Trunk Programming mode.

• If you’re in the Trunk Programming mode, you cannot select channels in other

banks.

For example, if you are programming Bank 4, you can only select channels 151-200

with

the ▲ or ▼ key.

• IMPORTANT: If you are programming an EDACS ® trunked system, you must

enter the

frequencies in a specific order. Check the frequency guide included with the radio

and the

listed web sites for details.

STEP 1: Selecting Trunking System Type

The first step in a Trunk Tracking system is storing the frequencies in one of the five

available banks in your scanner.

1. Press TRUNK for 1.5 seconds.

You will hear two beeps, and “BANK” and “TRUNK” will begin to flash on the

display.

2. Select the bank you want to store the frequency by using the

keypad.

3. Select the system you want to track by using the ▲ or ▼ key,

then press E.

List of trunking systems as follows:

E2-800 (Motorola Type II 800 MHz)

E2-Hi (Motorola Type II VHF 136-174 MHz) *

E2-UHF (Motorola Type II UHF 406-512 MHz) *

E1 (Motorola Type I and Hybrid) **

Ed (EDACS® Wide Band: 9600 band)***

Ed SCt (EDACS Scat)

Lt (LTR)

* Requires programming of a Base and Spacing frequency Offset channel (See

page 45).

** Requires programming of a Fleet map (See page 44).

Page 30

*** Requires programming of frequencies in exact order and location.

STEP 2: Programming Trunking Frequencies

1. Select and press E. Use the keypad and (decimal key) to enter a frequency

for the trunked system.

For example, enter .

Note: To clear a mistake while entering a frequency, press

(decimal key) twice, and start over.

2. Then press E.

The “E” (EDACS), “M” (Motorola) or “L” (LTR) appears depending on the trunked

system selected.

If the frequency is out of the range of the system chosen in this step, you will hear

error tone, the channel number flashes and an error message appears on the

display.

3. Use the ▲ or ▼ key to select the next channel in the bank and press E.

4. Repeat steps 2 and 3 until all frequencies have been entered.

5. Press SRCH to begin searching the bank you‘ve

programmed.

Then select the programmed bank by using the keypad.

✎ Remember! To lockout the keypad to prevent re-programming of talkgroups,

you can

use Memory Lock (Refer to “Memory Lock” on page 22).

Hint: If you want to return to the previous menu screen, press HOLD/RESUME in

the

Trunk Programming mode.

Programming Talk Group ID/Scan Lists

Scan Lists

Each bank of your 20-426 can be a trunk tracking bank and it can be a conventional

scanning

bank. When you designate a bank as a trunking bank, your scanner sets up 5 Scan

Lists,

which are simply lists used to store your favorite Talk Group IDs. Each list can

contain up to

10 IDs, so you can store a total of 50 IDs for each trunk tracking bank. (250 IDs if

you use

all the banks as trunking banks!)

Scan Lists help you organize the trunking system users into categories. For

example, you

might use List#1 for police IDs, List#2 for fire department IDs, List#3 for emergency

medical

service IDs, etc. Once IDs are stored in lists, you can scan them as you scan

conventional

frequencies and you can lockout any one (up to 4) of the 5 Scan Lists by pressing

the

corresponding numeric key. When an ID is active, the Scan List number will appear

on the

display. You can program your Scan Lists either manually or during Trunking

Search mode.

Check the web site www.trunktracker.com for a complete list of talkgroups for

your area

that you can program into your Scan Lists.

Page 31

In order to program Talk Group ID’s, you must first complete Step1–“Selecting

Trunking

System Type”, page 30 and Step 2 – “Programming Trunking Frequencies”, page

31.

1. After programming a frequency, press HOLD/RESUME to return to the main

screen of

system type selected and select . Then press E.

2. Select the Scan List location by using the ▲ or ▼ key.

3. Enter the Talk Group IDs for each trunk system as follows.

To enter a Type 2 Talk Group ID:

1. Enter the ID you want to store by using the keypad.

2. Press E.

To enter a Type 1 ID:

For a Type I ID, the Block number, Fleet number and Subfleet number make up the

Talk

Group ID number. For detail please see page 59.

1. Enter the ID you want to store by using the keypad (ID = Block number + Fleet

number +

(decimal key) + Subfleet number).

2. Press E.

To enter a Full EDACS ID®:

1. Enter the Agency number.

2. Press (decimal key) for the “dash”.

3. Enter the Fleet number and Subfleet number.

4. Press E.

To enter a Partial EDACS® ID:

1. Enter the Agency number you want to store.

Use the (decimal key) for the "dash".

2. Press E.

Or you can program all the Talk Group numbers within one fleet of an Agency.

1. Enter the Agency number.

2. Press (decimal key) for the “dash”.

3. Enter the Fleet number.

4. Press E.

Hint: Remember that Radio Shack's AFS format allows you to enter full or partial

EDACS IDs for

powerful flexibility in all modes. Be sure to read the section "EDACS Reception" on

page 39 to learn how this works.

Note: The 20-426 default to "AFS" talkgroup displays for EDACS® only.

To enter a LTR ID:

For a LTR ID, the Area Code, Home Repeater number and ID make up the Talk

Group ID.

Page 32

Please see page 42 for more information.

1. Enter the Area Code.

2. Enter the Home Repeater number.

3. Enter the ID you want to store

4. Press E.

Note: To clear a stored ID while entering an ID, press 0 and E successively, and

start over.

Receiving Trunked Systems

When you have properly programmed all the frequencies for a trunked system, you

can

monitor the system in several different ways. You will find that Search, Hold,

Lockout, Scan

and Delay are all similar to conventional scanning.

✎ ID SCAN lets you receive those talkgroups that you store in Scan Lists.

✎ ID SCAN HOLD lets you selectively listen to a talkgroup in your Scan Lists.

✎ ID SEARCH lets you hear all system talkgroup activity. This is the best way to

get

started.

✎ ID SEARCH HOLD works with Search mode to let you quickly freeze reception

on an

interesting transmission. Or you can manually specify a talkgroup with DIRECT

ENTRY in ID HOLD.

✎ ID LOCKOUT works with Search and Scan to exclude talkgroups that you don't

want

to hear.

✎ ID DELAY works with each talkgroup to be delayed when the communication

ends.

When receiving EDACS systems, remember that Radio Shack's AFS talkgroups

give you powerful

flexibility. In a few key presses, you can specify a single talkgroup, a fleet, or an

entire

agency in all the above modes. Read the section "EDACS Reception" to

understand how

this works.

Hint: If the scanner is not in the Trunking mode, you can enter the Trunk mode by

pressing

TRUNK. Pressing TRUNK in the Trunking mode will move to the Private Scan Hold

mode.

ID Scan Mode

1. When in the Trunking mode, press PVT to begin scanning the lists you have

programmed.

If you haven't programmed any IDs, the scanner cannot stop

on an active conversation.

2. To remove a Scan List from active scanning, press the

number of the Scan List on your keypad.

The Scan List indicator turns Off, and the IDs in that list are not scanned.

20-426 8/22/03 1:40 PM Page 33

Note: One Scan List must always be active. If you try and deactivate all the Scan

Lists,

Scan List 1 will automatically be active.

3. To restore a Scan List to active scanning, press its number again.

✎ Remember! When you press TRUNK in the Trunking mode, you can be out of

the

Trunking mode and enter into Private Scan Hold mode.

Note: • appears on the display during Trunk Scan instead of simply .

ID Scan Hold Feature

If you want to stop on a ID during ID scanning, press

HOLD/RESUME.

To directly access a specific ID location:

There are several ways to access a specific ID quickly.

1. Press HOLD/RESUME to enter into Hold mode.

2. Using the keypad, ▲ or ▼ key, enter the ID location number

(See page 31).

3. Press HOLD/RESUME.

If you want to resume scanning, press HOLD/RESUME.

ID Search Mode

Once you have programmed all the frequencies for a trunked system, Search will let

you

immediately start hearing transmissions.

When in the Trunking mode, press SRCH and the scanner begins to find any active

IDs.

When the scanner finds any ID, you will hear it.

Talkgroups display differently in Motorola, EDACS and LTR systems. You should

read the

appropriate parts of this guide to understand the formats.

The display indicates the bank and the type of trunked system you are monitoring.

While

monitoring on ID, press the ▲ key, and the scanner will check if any other IDs are

active.

Regardless of the system, you won't know exactly who you are receiving until you

listen for

a while, or refer to frequency guides or internet sites such as

www.trunktracker.com.

Of course, figuring out who each ID represents is half the fun of Trunk Tracking.

Later, when you learn more about a system, you will want to store lists of talkgroups.

Then

you can scan specific agencies and users, and use the many other features your

radio

provides.

Page 34

ID Monitor Mode

By using ID Monitor mode, you can determine which talk groups are the most active

without

hearing conversations.

1. Press and hold SRCH for 2 seconds until you hear two beeps. Then begins

flashing and all active talk group IDs appear on the display every 0.5 seconds.

2. To activate ID search mode, press SRCH

Note: Lockout ID also appears on the display.

ID Search Hold and Direct Entry ID in Hold Mode

Just like in Conventional Search, Hold lets you pause ID Search on an interesting

transmission without storing the talkgroup into memory.

If you hear an interesting ID during Search mode,

and want to continue listening to it --

• Press HOLD/RESUME to stop the search.

If you want to listen to a specific ID, while in Hold mode --

• Use the keypad to enter the ID you want and press

the ▼ key.

If you want to resume searching --

• Press HOLD/RESUME to return to Search mode.

Note: ID Hold feature is also applied to ID Scan mode.

Programming Scan Lists During Search

To select a Scan List location and store an ID during Search

mode, follow these steps:

1. When your scanner stops on an ID you want to store, press

HOLD/RESUME.

2. You can change the Scan List memory location by using the

▲ or ▼ key. And then press E.

3. Press SRCH to return to Trunk Tracking Search mode.

Deleting a Stored ID

To delete a stored ID:

1. Press HOLD/RESUME in the ID Scan mode.

2. Select the Scan List location you want to delete by using the ▲ or ▼ key.

3. Press 0.

4. Then press E.

Page 35

ID Lockout

Like conventional scanning, it’s possible to lockout unwanted traffic. This is

particularly

important in trunked systems because in many areas, water meters, door alarms,

traffic

signals, and other mechanical devices are assigned IDs just like other users. Also

some

departments scramble or encrust their communications, and you may want to lock

out these

unintelligible broadcasts.

To Lockout an ID, press L/O on the ID you want to lockout.

The ID is locked out. You can Lockout up to 100 IDs. The 101st skip frequency

entered

causes the first skipped freqnency to unlock.

Note: If you Lockout an ID in Search mode, it is also locked out in Scan List mode.

Conversely, if you Lockout an ID while in Scan List mode, it is locked out in Search

mode. For information about Scan Lists see page 31.

EDACS BLOCKOUT is a powerful form of ID Lockout that can be used only with

AFS and

EDACS systems. This feature lets you lockout entire Agencies or Fleets, not just

individual

talkgroups. Using EDACS Blockout you can, for example, prevent Search from

stopping on

any of hundreds of talkgroups in the Utilities agency. You can do this with just a few

key

presses. To use this mode just enter the Agency-part, or the Agency-Fleet part, of

the

talkgroup code and press L/O. For example, to Blockout Agency 4 in Trunk Search,

press

HOLD/RESUME, 0, 4, (decimal key), and then L/O. For other ways to use partial

AFS

entry, be sure to read the section "EDACS Reception".

Review ID Lockout

You can check all IDs already locked out.

1. Press and hold TRUNK for 1.5 seconds in the Trunking mode.

2. Select the bank you want to review by using the keypad, and then the trunked

system

selected appears on the display. Then press E.

3. Select by using the ▲ or ▼ key ,and then press E.

4. You can see the locked out IDs by using the ▲ or ▼ key.

Hint: Press and hold L/O for 2 seconds to check all locked out IDs when in the

Trunking

mode.

Restoring Locked-out IDs

To restore a single ID, follow these steps:

• While in locked out review mode, select the locked out ID you want to restore and

press

L/O.

The ID is restored and “L/O” disappears.

To restore all locked out IDs in a bank once:

• While in locked out review mode, press and hold L/O for 3 seconds. All locked out

IDs in a

bank are restored.

Page 36

Setting the Delay Mode for Trunking Mode

A default delay of 2 seconds is automatically set for each talkgroup for ID Scan

mode and ID

Search mode. To set the delay feature on or off, press DELAY while trunking,

“DLY” will

appear or disappear depending on your setting.

Trunking Frequency Confirmation

You can check the frequency while a talkgroup ID is active.

Press the ▼ key ,and the active frequency on which the talk group is transmitting

will flash on

the display. Or press and hold the ▼ key for 2 seconds, the ID and the frequency

alternately

appears on the display. To cancel this mode, press the ▼ key again.

Hint: This feature is applied to ID Scan mode and ID Search mode.

Setting Priority in Trunking Mode

You can set priority in your Scan lists, just as you do in your conventional ones.

Default

setting for the Priority ID is the first location in each Scan List. You can set the

priority by

pressing and holding PRI for 2 seconds in ID Scan Hold mode. After you’ve set up

your

Scan List, press PRI to activate it.

It’s very similar to conventional priority although there is no "interrupt" during the

transmissions. Priorities are checked in between transmissions.

With Priority ON, you can hold on an ID in your Scan List, such as Scan List 3,

memory

location 7, and the scanner will check all the priorities in all the active Scan Lists in

between

any transmissions on the ID on which you’re holding. The lowest numbered priority

will be

checked first. For example, the Priority ID in List 1 will be checked before the

Priority in List

2, etc.

Note: • This function does not work in LTR tracking.

• Priority Scan does not operate when Priority IDs are locked out.

Moving between Scan List Memories

There are a number of ways to step and move through your Scan List memories:

1. Press HOLD/RESUME in the ID Scan mode and use the ▲ or ▼ key to

move to up or

down.

2. Or, press HOLD/RESUME in the ID Scan mode, next press 0-9 (scan list

number), then

press 0-9 (memory position). For example to move to Scan List 4, memory position

10,

press: HOLD/RESUME, 4, 0, HOLD/RESUME

Page 37

Multi-Track

The 20-426 allows you to track more than one system at a time. Here are some

highlights of

this feature:

✎ You can actually track up to 5 trunking systems at one time.

✎ You can trunk scan, or search and scan conventional frequencies at the same

time.

✎ You can program conventional frequencies in the same bank as trunking

systems.

After the scanner finishes checking a trunked system for activity, it will

conventionally

scan the other frequencies in the bank (remember, only trunking frequencies are

programmed in Trunk mode).

To scan a mix of trunking and conventional banks, select the banks you wish to be

active,

and then press TRUNK. The scanner will instantly begin scanning. You can switch

to Search

mode and the scanner will search for any active ID’s on the system.

Note: To switch ID Scan or ID Search, press PVT or SRCH in the trunked system.

Multi-Track Operational Details

When more than one trunk system is active (for example two or more trunked

systems or a

trunked system and one or more conventional frequencies), the radio jumps

between

systems/frequencies as follows:

TRUNK SCAN: The scanner moves to a trunked system and looks for IDs in your

Scan

List(s) for up to 1 second. If it finds no activity on your programmed talkgroups, it

moves

on to conventional channels in the same bank or to the next active bank.

If the scanner finds a talkgroup in one of your active Scan Lists, you will begin to

hear that

communication and the scanner will of course display the proper talkgroup number.

When

the communication ends, the scanner will wait for 2 seconds for any further replies

and, if

none, the scanner will move to the conventional channels in the same bank or to the

bank.

The scanner will not look for any other IDs within the same trunked system (as this

would slow the scan process). If you press the ▲ key while you are listening to

one ID,

the scanner will check to see if another ID in your Scan List is active. It will disregard

the

ID to which you were just monitoring.

TRUNK SEARCH: This mode works similarly to Trunk Scan. If the scanner finds

any (nonlocked-

out) ID when it checks the control channel, you will hear it. You will then hear any

replies that follow within 2 seconds. After that the scanner will move on and not

continuously search the system for additional IDs (on busy systems you would

never leave

the system if this were the case). If you press the ▲ key while monitoring one ID,

the radio

will check if any other IDs are active (it will disregard the ID you just left), and if none

are

active, it will move on.

Page 38

Multi-Track

The 20-426 allows you to track more than one system at a time. Here are some

highlights of

this feature:

✎ You can actually track up to 5 trunking systems at one time.

✎ You can trunk scan, or search and scan conventional frequencies at the same

time.

✎ You can program conventional frequencies in the same bank as trunking

systems.

After the scanner finishes checking a trunked system for activity, it will

conventionally

scan the other frequencies in the bank (remember, only trunking frequencies are

programmed in Trunk mode).

To scan a mix of trunking and conventional banks, select the banks you wish to be

active,

and then press TRUNK. The scanner will instantly begin scanning. You can switch

to Search

mode and the scanner will search for any active ID’s on the system.

Note: To switch ID Scan or ID Search, press PVT or SRCH in the trunked system.

Multi-Track Operational Details

When more than one trunk system is active (for example two or more trunked

systems or a

trunked system and one or more conventional frequencies), the radio jumps

between

systems/frequencies as follows:

TRUNK SCAN: The scanner moves to a trunked system and looks for IDs in your

Scan

List(s) for up to 1 second. If it finds no activity on your programmed talkgroups, it

moves

on to conventional channels in the same bank or to the next active bank.

If the scanner finds a talkgroup in one of your active Scan Lists, you will begin to

hear that

communication and the scanner will of course display the proper talkgroup number.

When

the communication ends, the scanner will wait for 2 seconds for any further replies

and, if

none, the scanner will move to the conventional channels in the same bank or to the

bank.

The scanner will not look for any other IDs within the same trunked system (as this

would slow the scan process). If you press the ▲ key while you are listening to

one ID,

the scanner will check to see if another ID in your Scan List is active. It will disregard

the

ID to which you were just monitoring.

TRUNK SEARCH: This mode works similarly to Trunk Scan. If the scanner finds

any (nonlocked-

out) ID when it checks the control channel, you will hear it. You will then hear any

replies that follow within 2 seconds. After that the scanner will move on and not

continuously search the system for additional IDs (on busy systems you would

never leave

the system if this were the case). If you press the ▲ key while monitoring one ID,

the radio

will check if any other IDs are active (it will disregard the ID you just left), and if none

are

active, it will move on.

Page 38

EDACS® Reception

EDACS® Tracking

TrunkTracker III now allows tracking of EDACS® trunked systems. Until now

these widely

used systems have been almost impossible to monitor with a conventional

scanner. With

your TrunkTracker III listening to EDACS(s) is remarkably easy, and perhaps

even easier

than conventional scanning.

EDACS systems use 'Transmission Trunking', which means that each

transmission is

assigned a new frequency. As the conversation moves through the system's

frequencies,

your TrunkTracker III automatically follows it.

This chart shows a 30 second sample of EDACS transmissions. Eight different

talkgroups

are using the system as their transmissions switch between the thirteen system

frequencies.

Notice how the dotted line shows talkgroup 02-023 moving from channel to

channel. Your

20-426 can clearly and automatically follow this talkgroup, or any other, as you

select.

EDACS systems are organized in a logical way that keeps related talkgroups

together. Your

scanner is designed to take maximum advantage of this organization to make

your scanning

easy. It lets you zero in on just the part of the system you want to hear, whether

it is an

individual channel, an entire department or city.

Programming EDACS System Frequencies

When you program EDACS frequencies, it is critical that you store each one in

the

CORRECT LOCATION. By the nature of EDACS systems this is necessary for

tracking. This

often is not the frequency order, so you must be sure you have the right

sequence. Sources

for this information can be found at scanner.Radio Shack.com.

An EDACSR Trunked system

This chart shows how talkgroups are organized within an

EDACS system at the Agency level. The individual

talkgroups cannot be shown at this scale because there

are over 2000. However the chart can show the 16

Agencies in this example. The system is logical and easy

to understand. EDACS systems are typically arranged in

an outline structure.

The system users are given blocks of talkgroups. Sizes

vary but most large cities and other agencies have blocks

of 128 channels. Smaller cities have only 64 or 32

channels.

In this example, the County Sheriff is agency 01. The city

of Sullivan is Agency 03. Adams Hill and Matthew Junction

share Agency 08.

Your scanner shows EDACS talkgroups in AFS (Agency-

Fleet-Subfleet) format. This helps you see, at a glance,

who you are monitoring. And with the partial-entry feature

you can easily include nearby, related channels in the

same Fleet or Agency. You can just as easily exclude

entire unwanted Fleets and Agencies.

When in Search mode, with the system frequencies

programmed, and your scanner locked to the control

channel, you can select a desired city by keying in the

Agency part of the AFS talkgroup. For example, in Hold

mode you can select the entire city of Sullivan with 4 key

presses 0, 3,

(decimal key), SRCH key.

When you hear an interesting talkgroup, in Hold mode

capture it to your Scan List by pressing E during the

transmission.

Or hold on it by pressing HOLD/RESUME.

If you want to monitor the Sullivan Police Dispatch channel (which is talk

group 03-062), press 0, 3, (decimal key), 0, 6, 2, the ▼ key. Your scanner

can also work in decimal format.

Talkgroup 03-62 in decimal format is 402. But decimal format does not give you

any information

about the system hierarchy.

For example Sullivan, in decimal, uses channels from 384 to 511. This is not as

easy to

remember as Agency 03. But decimal is useful if you need to work from decimal

talkgroup lists.

Special EDACSR Features

AFS Partial Entry Feature

AFS is Radio Shack's method of encoding EDACS talkgroups.

AFS stands for 'Agency-Fleet-Subfleet'.

AFS talkgroups are used in all EDACS reception -- in ID Search, ID Lockout

and ID Scan. The

powerful AFS Partial Entry feature designed into the 20-426 lets you use either

a complete

talkgroup code, or just the most significant part.

This feature lets you expand or narrow searching and

scanning to one of 4 levels. By entering only the desired part

of an AFS talkgroup, you can select 128 talkgroups, 8

talkgroups, or a single talkgroup.

For example, you could program every talkgroup in a police

department with just 4 key presses. You can use the AFS

Partial Entry feature anywhere you need to specify EDACS

talkgroup.

Your 20-426 can also enter or display EDACS talkgroups in decimal format

(0-2047).

1. Press and hold TRUNK for 1.5 seconds and select the bank you want to

change.

2. Use the ▲ or ▼ key to select , then press E.

3. Use the ▲ or ▼ key to select , then press E.

4. Use the ▲ or ▼ key to select or , then press

You can use this feature to translate decimal talkgroups lists to the much more

powerful

AFS format.

Examples of how you might use AFS are shown above in the description of an

EDACS

trunked system, and elsewhere in this manual. It is very easy to use. Be sure to

become

familiar with AFS Partial Entry, and your scanning will become far more

flexible and efficient.

EDACS ID Range Search

When the scanner searches EDACS talk group IDs, the scanner can search

within a range

you set for Agency or Fleet listings. For example if you want to search within

the 01 agency,

while in Hold mode press 0, 1, (decimal key) then SRCH. Or if you want to

search within

the 01 agency and 01 fleet, while trunking press 0, 1, (decimal key), 0, 1, then

SRCH.

To stop the ID range search, press SRCH.

EDACS SCAT

With the EDACS SCAT feature, the data stream transmissions will be

eliminated allowing

you to clearly monitor the voice communications on EDACS SCAT systems.

To monitor EDACS SCAT systems you only need to program the frequency in

the Trunk

Tracking Programming mode. You do not need to enter group ID’s.

Note: As EDACS SCAT is different from the other tracking feature, and it is not

a feature

which the scanner tracks any ID, you do not need to program Talk Group ID’s.

LTRR Reception

LTRR Tracking

LTRR (Logic Trunked Radio) systems are trunking systems used primarily by

business or

private communications service providers, such as taxicabs, delivery trucks,

and repair

services. These systems encode all trunking information as digital subaudible

data that

accompanies each transmission. Users on an LTR system are assigned to

specific

talkgroups, which are identified by the radio as six digit numbers.

These numbers are in the form AHHUUU, where:

A= Area code (0 or 1)

H= Home repeater (01 through 20)

U= User ID (000 through 254)

When the scanner receives a transmission on a channel set to the LTR mode, it

first

decodes the LTR data included with the transmission. In the ID Search mode,

the scanner

stops on the transmission and displays the talkgroup ID on the display. In the

ID Scan mode,

the scanner only stops on the transmission if the LTR data matches a talkgroup

ID that you

have stored in the bank’s talkgroup ID list and have not locked out.

LTR systems are frequently programmed so that each radio has a unique ID

code.

Motorola Reception

Motorola Tracking

There are really two types of Motorola trunking systems. These are usually

referred to as

Type I and Type II systems. Type I only occurs on some 800 MHz systems. All

VHF and

UHF trunking systems use Type II.

One important distinction between these two systems is the amount of data

transmitted by

each radio when its push-to-talk button (PTT) is pressed. Every radio in a

trunked system is

assigned a unique ID so the central site computer can identify it when it’s used.

Both Type I

and Type II systems place radios (or radio users) into groups, called talkgroups,

and these

talkgroups are also assigned unique IDs. Some radios have access to only one

talkgroup,

while others have access to many talkgroups. The talkgroup(s) each radio can

access is

called the radio’s affiliation(s).

In a Type II system, when someone uses their radio, only the radio ID is

transmitted when

PTT is pressed, whereas in a Type I system the radio ID and its current

affiliation are both

transmitted when PTT is pressed.

Why the difference? Type II systems are slightly more advanced because the

central

computer maintains a database which is used to determine each radio’s

affiliation(s).

Changes to a Type II system are easier than Type I because the system manager

only

needs to update the database instead of reprogramming individual radios.

Another difference between the systems is that Type I systems are arranged in

a Fleet-

Subfleet hierarchy. For example, its possible for a city using a Type I system to

designate 4

Fleets, each with 8 Subfleets. Their fleets might be the Police Department, the

Fire

Department, Utilities, and Administration. The Police may decide to further

divide their fleet

into subfleets such as Dispatch, Tactical Operations, Detectives, North, South,

East and

West Side Patrols, and Supervisors. All the available police radios would then

be assigned

to one of the police subfleets. Determining the exact Fleet-Subfleet hierarchy for

a particular

area is referred to as Fleet Map Programming, which is discussed further in this

manual.

The disadvantage of a Type I system is that when PTT is pressed, the brief

burst of data

must contain the radio’s ID and its Fleet and Subfleet. This is three times the

amount of data

a Type II system radio sends, and as a result Type I systems usually

accommodate fewer

users than Type II systems.

Even though there are many Type II systems, Type I systems are still in use.

There are also

Hybrid systems which are a combination of both Type I and Type II. Your

scanner defaults

to monitor Type II systems, but its possible to select a Preprogrammed Fleet

Map or create

a Custom Fleet Map for your area.

For VHF and UHF Type II trunking systems, you will need to know the base,

spacing

frequencies and offset channels. See page 45 for details.

Fleet Map Programming

If you have programmed a trunk tracking bank for Motorola, press TRUNK to

start Multi-

Track, and you will see user IDs on the display. Since the 20-426 defaults to

Type II systems,

all the IDs will appear as numbers. However, if you notice a mix of odd and even

user IDs,

for example 6477, 2560, 6481, 6144, 1167, etc., then you are probably

monitoring either a

Type I or Hybrid systems.

You may also notice that you are missing responses when you hold on an active

ID. Unlike

Type II, Type I/Hybrid systems require a Fleet Map that sets specific

Fleet-Subfleet

parameters. It is easy to select a Fleet Map for your scanner; what is not always

easy is

selecting or programming a map that matches your particular area.

There are 16 preset Fleet Maps listed in the Appendix that you can choose, and

these are

usually a good place to start when setting up a Type I/Hybrid trunk tracking

bank. If you

choose a preset map and still have difficulty following complete conversations,

then you'll

have to program your own Fleet Map.

Selecting Preset Fleet Map

1. Press and hold TRUNK for 1.5 seconds and select the bank you want to

change.

2. Use the ▲ or ▼ key to select (Type 1 system), then press E.

3. Use the ▲ or ▼ key to select , then press E.

4. Use the ▲ or ▼ key to select the map you want, then press

E. The scanner returns to FLEET Map list item.

Note: You will now begin to see Type I Fleet-Subfleet IDs. For

example, 100-12, 100-9, 000-12, 400-8, etc.

See "User Defined Fleet Maps in the Appendix" for

more information about Type I IDs.

How do you know if the preset map is correct? You will have to listen to see if

you're

following complete conversations. If not, you should try another preset map.

Programming a User Fleet Map

You may want to read "User Defined Fleet Maps" in the Appendix before

programming a

Fleet Map. It contains a detailed explanation of Scanner Fleet Map

Programming, as well as

a table listing the Fleet Map Size Codes.

1. Press and hold TRUNK for 1.5 seconds and select the bank you want to

change.

2. Use the ▲ or ▼ key to select (Type 1 system), then press

3. Use the ▲ or ▼ key to select , then press E.

4. Use the ▲ or ▼ key to select , then press E.

5. Use the ▲ or ▼ key to select the size code for the first block,

then press E.

The next available block appears on the display.

6. Repeat step 5 until you have selected a size code for each

block.

For details about each size code, see "Fleet Map Size Codes"

in the Appendix.

Programming a Hybrid System

A Hybrid system is simply a Type I system with some blocks designated as Type

II blocks.

To program a Hybrid system, follow the steps listed in "Programming a User

Fleet Map" in

the previous section. However, if you want a block to be Type II, select Size

Code .

When you begin searching a trunking bank with a Hybrid Fleet Map, you will

see both types

of system IDs. That is, Type II IDs usually appear as an even number without a

dash; Type I

IDs appear as a three or four digit number, followed by a hyphen, followed by a

one or two

digit number.

Setting the Base, Spacing Frequencies and Offset Channel for Motorola

VHF/UHF Trunked Systems

To properly track Motorola VHF and UHF trunked systems, you must enter

what is known as

the Base, Spacing Frequencies and Offset Channels for each system.

To find these out, check the scanner.Radio Shack.com or www.trunktracker.com

and other

web sites and frequency resources.

To enter the Base, Spacing Frequencies and Offset Channel: (You can set up to

three sets

of these, but almost all systems only use one set)

1. Press and hold TRUNK for 1.5 seconds and select the bank you want to

change.

2. Use the ▲ or ▼ key to select (Motorola Type2 VHF) or (Motorola Type2

UHF), then press E.

3. Use the ▲ or ▼ key to select , then press E.

4. Use the keypad to enter Configuration Block Number(1-3).

5. Use the keypad to enter a new Base Frequency, then press

6. Press the ▲ key and select for entering the Spacing

Frequency.

7. Use the keypad to enter a new Spacing Frequency, then

press E.

Note: You can only enter within a range of 5-100 kHz, and 5 or

12.5 kHz multiples.

8. Press the ▲ key and select for entering the Offset

Channel.

9. Use the keypad to enter a new Offset Channel, then press E.

Note: . You can only input within a range of 380-759.

. If the system is not tracking properly, you may need to

try a new Base Frequency or Offset Channel, or you

may be missing frequencies from the system.

. You can set up to three Base, Spacing and Offsets for Motorola VHF/UHF

trunked

systems.

Toggling the Status Bit

On Type II trunking systems there is a method by which specialized types of

communications

utilize unique talkgroup numbers. An emergency call will occur on a unique

talkgroup from its

primary assignment, for example. Because the 20-426 defaults to Status-Bit ON

mode, you

never need to worry about missing these transmissions. If you have

programmed talkgroup

33264 into Scan List memory, for example, and there is an emergency call

within the group,

you will hear it on 33264.

The only time you may wish to turn Status Bits OFF is if you're trying to figure

out the proper

Fleet Map of a Type I trunking system.

1. Press and hold TRUNK for 1.5 seconds and select the bank you want to

change.

2. Use the ▲ or ▼ key to select (Motorola TYPE2 800MHz), (Motorola Type2

VHF) or (Motorola Type2 UHF), then press E.

3. Use the ▲ or ▼ key to select , then press E.

4. Use the ▲ or ▼ key to select or , then press E. The scanner returns to

Status Bit list item.

Control Channel Only Mode

When this function is activated, trunking is performed using Control Channel

data only.

Voice channel (also known as "DATA channel") frequencies do not have to be

programmed

into memory. This feature only applies to Motorola 800 MHz systems.

1. Press and hold TRUNK for 1.5 seconds and select the bank you want to

change.

2. Use the ▲ or ▼ key to select (Motorola Type2 800MHz) or (Motorola Type1

800 MHz), then press E.

3. Use the ▲ or ▼ key to select , then press E.

4. Use the ▲ or ▼ key to select a plan from 4 frequency plans,

then press E. The scanner returns to Control Channel Only

list item.

Note: You must choose a plan before you begin to Control Channel Trunk (Only

when 800

MHz system is selected).

When you deselect Control Channel only mode, appears on the display.

Read the descriptions of the Plan 1~4 for details on which may apply for you.

PL1 (plan 1): This plan is the most common. Use Plan 1 if the last three digits of

ALL the

frequencies in use end in one of the following three digits: 125, 375, 625, or 875

(example:

856.1125, 860.7375, 859.6625, 855.8875).

PL2 (plan 2): If the last three digits of frequencies are less than 860.000 and end

in one of

the following three digits (125, 375, 625, or 875) and if ANY other frequencies

end in (000,

250, 500, or 750) use Plan 2.

PL3 (plan 3): If the last three digits of ALL the frequencies in use end in one of

the

following three digits (000, 250, 500, or 750) use Plan 3.

PL4 (plan 4): If the last three digits of frequencies are less than 866.0000 and

end in one

of the following three digits (000, 250, 500, or 750) and if ANY other frequencies

end in

(125, 375, 625, or 875) use Plan 4.

Of course you will know the Control Channel frequency itself so that will help

you determine

the proper plan. If you try one plan and you receive errors (such as the scanner

jumping to

channels that are obviously not part of the system), you should try an alternate

Plan.

Note: . You can assign a Fleet Map to TYPE 1 or Hybrid systems scanned in

Control

Channel Only mode by going into the Trunk Programming mode. You can also

program

IDs, set a delay, and all the other parameters for systems scanned in this

mode. You can then either search the system to find new IDs or you can

program

IDs into memory and then scan them.

. The Control Channel Only feature is an extremely powerful tool. You can use it

determine if systems you are familiar with may have added new frequencies or

you

can use it to discover new systems by simply finding active control channels

(using

Search) and then programming them for Control Channel operation only.

Remember that this feature only applies to Motorola 800 systems, that you do

have

to set the proper system type (800 MHz of Type 1 or Type 2) and you do have to

program the Control Channel frequency into memory and identify the frequency

trunked in the Trunk Programming mode.

Disconnect Tone Detect Option (End Code)

When this function is disabled, the radio looks for squelch before returning to

the Control

Channel instead of waiting for the Disconnect Tone. Only in rare instances will

you need to

adjust the default settings. The condition to return to Control Channels

depends on whether

the signal is present or not.

1. Press and hold TRUNK for 1.5 seconds and select the bank you want to

change.

2. Use the ▲ or ▼ key to select (Motorola TYPE2 800MHz), (Motorola Type2

VHF) or (Motorola Type2 UHF), then press E.

3. Use the ▲ or ▼ key to select , then press E.

4. Use the ▲ or ▼ key to select or , then press E.

Note: Set the SQL control so that you hear a hissing, and the scanner will

remain on the

voice channel (even when a disconnect tone is transmitted or there is no signal

all).

Remote Interface

You can communicate and program your 20-426 in numerous ways with

peripheral devices

using a Remote Interface Cable port. This radio offers the following modes:

. PC Control mode

Program and control your scanner from a PC using Radio Shack’s 20-426

Scanner Software.

. Clone mode

Clone all the frequencies, trunking talkgroups, and fleet maps programmed into

your

scanner to another 20-426 scanner or another 20-426.

PC Control Mode

To connect Scanner to PC:

Plug the scanner end of the RS232C straight cable into the remote port which is

on the rear

of the scanner. Plug the other end of the cable (DB-9 serial connector) into a

personal

computer’s serial port. A few PC’s may require an adapter, most will not. Of

course, make

sure your PC is turned ON.

To program your scanner:

You can program and control your scanner remotely from a PC using Radio

Shack’s 20-426

Scanner software.

After connecting the scanner to a PC, turn the scanner ON.

To use the Remote (PC Control) mode, you must install Radio Shack’s 20-426

Scanner software

and use as directed. Make sure that your scanner is connected to the serial port

of the PC

using the RS232C straight cable.

Start Remote Mode and Change Transfer Speed:

1. Press and hold RMT for 2 seconds to activate the Remote

mode.

2. Select the transfer speed except for , then press E and

the scanner will start Remote mode.

A unique feature of the 20-426 is that all the front panel keys on the radio

remain operational

in Remote mode.

For information on purchasing 20-426 Scanner software to program and control

your 20-426,

you can contact the following:

Radio Shack Parts Department (800) 554-3988

(Hours are from 8:00 a.m. to 5:00 p.m. Central Time

Monday through Friday)

scanner.Radio Shack.com

PC Control Parameter

For your information:

Transfer speed : 9600/19200/38400/57600 bps (adjustable)

Start/Stop bit : 1 bit, 1 bit

Data Length : 8 bit

Parity Check : None

Code : ASCII code

Flow Control : None

Return Code : Carriage Return only

Clone Mode

You will need to purchase a RS232C straight cable a null modem adapter.

RS232C straight

cables are available as male to male or male to female. Even if the RS232C

straight cable

you buy already has the male to male connectors, you will still have to have the

null modem

adapter. On the next page you will see the pin connections that are internal to a

standard

device. (These items are available at your local electronics stores.)

Start Remote Mode and Change Transfer Speed:

1. Press and hold RMT for 2 seconds to activate the Remote

mode.

2. Select the transfer speed except for , then press E and

the scanner will start Remote mode.

A unique feature of the 20-426 is that all the front panel keys on the radio

remain operational

in Remote mode.

For information on purchasing 20-426 Scanner software to program and control

your 20-426,

you can contact the following:

Radio Shack Parts Department (800) 554-3988

(Hours are from 8:00 a.m. to 5:00 p.m. Central Time

Monday through Friday)

scanner.Radio Shack.com

PC Control Parameter

For your information:

Transfer speed : 9600/19200/38400/57600 bps (adjustable)

Start/Stop bit : 1 bit, 1 bit

Data Length : 8 bit

Parity Check : None

Code : ASCII code

Flow Control : None

Return Code : Carriage Return only

Clone Mode

You will need to purchase a RS232C straight cable a null modem adapter.

RS232C straight

cables are available as male to male or male to female. Even if the RS232C

straight cable

you buy already has the male to male connectors, you will still have to have the

null modem

adapter. On the next page you will see the pin connections that are internal to a

standard

device. (These items are available at your local electronics stores.)

Start Remote Mode and Change Transfer Speed:

1. Press and hold RMT for 2 seconds to activate the Remote

mode.

2. Select the transfer speed except for , then press E and

the scanner will start Remote mode.

A unique feature of the 20-426 is that all the front panel keys on the radio

remain operational

in Remote mode.

For information on purchasing 20-426 Scanner software to program and control

your 20-426,

you can contact the following:

Radio Shack Parts Department (800) 554-3988

(Hours are from 8:00 a.m. to 5:00 p.m. Central Time

Monday through Friday)

scanner.Radio Shack.com

PC Control Parameter

For your information:

Transfer speed : 9600/19200/38400/57600 bps (adjustable)

Start/Stop bit : 1 bit, 1 bit

Data Length : 8 bit

Parity Check : None

Code : ASCII code

Flow Control : None

Return Code : Carriage Return only

Clone Mode

You will need to purchase a RS232C straight cable a null modem adapter.

RS232C straight

cables are available as male to male or male to female. Even if the RS232C

straight cable

you buy already has the male to male connectors, you will still have to have the

null modem

adapter. On the next page you will see the pin connections that are internal to a

standard

device. (These items are available at your local electronics stores.)

To connect the Scanner to Scanner:

Plug the male end of the RS232C straight interface cable into the

remote port on the rear of one of the two scanners. Then connect the

DB-9 to DB-9 null modem adapter to the cable. Plug the other end of

the null modem adapter into the other scanner (DB9 Gender Changers

are also available at your local electronics store.).

You can clone all of the programming of one 20-426 into another, including

frequencies,

talkgroup IDs, delay settings, etc. After connecting the two scanners, turn the

radios ON.

Prepare each scanner for clone mode as follows.

After connecting the two scanners, make sure the scanners are turned off.

1. While you press and hold E, turn the radio on for each scanner.

2. Determine the scanner which has the frequency data that you want to

transfer. This one

must be set up as the "First Unit", and the other must be set as the "Clone

Unit".

3. On the scanner that is the "Clone Unit", use the ▲ or ▼ key

to select , then press HOLD/RESUME.

4. On the scanner that is the "First Unit", use the ▲ or ▼ key to

select , then press HOLD/RESUME.

Care and Maintenance

General Use

. Turn the scanner OFF before disconnecting the power.

. Always write down the programmed frequencies in the event of memory loss.

. If memory is lost, simply reprogram each channel.

The display shows 000.0000 in all channels when there has been a memory loss.

Location

. Do not use the scanner in high-moisture environments such as the kitchen or

bathroom.

. Avoid placing the unit in direct sunlight or near heating elements or vents.

. If the scanner receives strong interference or electrical noise, move it or its

antenna away

from the source of the noise. If possible, a higher elevation may provide better

reception.

Cleaning

. Disconnect the power to the unit before cleaning.

. Clean the outside of the scanner with a mild detergent.

To prevent scratches, do not use abrasive cleaners or solvents. Be careful not to

rub the

LCD window.

. Do not use excessive amounts of water.

Repairs

. Do not attempt any repair. The scanner contains no user serviceable parts.

Contact the

Radio Shack Customer Service Center or take it to a qualified repair technician.

Birdies

. All radios can receive birdies (undesired signals). If your scanner stops during

Scan mode

and no sound is heard, it may be receiving a birdie. Birdies are internally

generated

signals inherent in the electronics of the receiver.

Press L/O to lockout the channel, and then press HOLD/RESUME to resume

scanning.

Troubleshooting

If your 20-426 is not performing properly, try the following steps.

Problem Suggestion

1. Make sure you are scanning in Highway Mode.

2. Check antenna connections.

3. Conditions to activate the alarm are variable and depend upon the timing of

the dispatcher transmissions and proximity of patrol car to your vehicle. Also,

terrain and other factors may be involved.

4. Officer has the ability to turn off the mobile extender when off-duty, or when

going to court, etc., but will normally leave extender operating when on traffic

duty.

5. If you’re monitoring user-programmed frequencies, switch to one of the

preprogrammed frequency banks.

6. Check to see if MUTE and FLASH are both turned off.

7. Some priority frequencies may be locked out.

1. Check the connections at both ends of the AC Adapter.

2. Turn ON the wall switch of your room. You could be using an outlet

controlled by the wall switch.

3. Move the AC Adapter to another wall outlet.

1. Check the antenna connection.

2. Move the scanner.

3. You may be in a remote area which could require an optional multi-band

antenna. Check with your dealer or local electronics store.

1. Adjust squelch threshold - refer to page 15, "Setting the Squelch".

2. Check the antenna connection.

3. Check to see if many of the channels are Locked Out.

If so, the scanner has less chance of finding an active channel.

4. Review each channel's frequency to see if it is still stored in Memory and is

correct.

5. It's possible that none of the programmed frequencies are currently active.

1. Press PVT key again.

2. Adjust the SQL control.

3. Check to see if all channels are Locked Out.

1. Adjust squelch threshold - refer to page 15, "Setting the Squelch".

2. Check the antenna.

1. The priority system is checking for alarms. Use HOLD/RESUME to hold on

a frequency without checking priority channels every two seconds.

2. Select Priority off mode or Priority only mode.

Going by patrol cars and

not receiving alarms.

Scanner won't work.

Improper reception.

Scan won't stop.

Scan won't start.

Weather Scan won't

work.

Radio transmissions

(conversations) are

cutting in and out in

Highway mode.

If you experience difficulty while in TrunkTracker mode, try the following steps.

If you still cannot get satisfactory results while using your scanner or if you

want additional

information, please call or write the Radio Shack Parts and Service Division.

The address and

phone number is listed in the warranty at the end of this manual. If you would

like immediate

assistance, please call Customer Service at (800)297-1023.

If you have internet access, you can visit scanner.Radio Shack.com for

additional information.

Problem Suggestion

1. Missing the Data Frequency.

2. Change to a Type 1 Scanner setup.

Review Fleet Map Programming on page 45.

1. No IDs have been programmed.

2. The IDs you have stored are not active.

1. Adjust the squelch for Trunking mode - refer to page 29.

2. Missing the frequency used for the data channel.

Check your frequency list.

1. Change a Type 1 scanner setup.

Review Fleet Map Programming on page 44.

2. Try another Preset Fleet Map or Program your own Fleet Map.

3. Check to see that all of the system's frequencies have been entered.

1. May be a telephone interconnect call, which are intentionally blocked by

your scanner.

2. The ID on your display is not active.

1. Logical channel numbers (frequencies) for the system are not programmed

in the correct order. Check frequency resources and reprogram.

2. Not all frequencies for the system are programmed.

Check frequency resources.

Scanner won't track.

Scanner won't stop

during Scan List mode.

Scanner will not acquire

data channel.

Missing replies to

conversations.

Channel Activity

Indicators are flashing

but no sound is heard.

Scanner not tracking an

EDACS system properly.

Specifications

Certified in accordance with FCC Rules and Regulations Part 15, Subpart C, as

of date

of manufacture.

Channel: 1000

Banks: 10 (50 channels each)

Service Bands: 9 preprogrammed search bands

(including the NOAA and Canada Weather Service band)

Frequency Range: 25.0-28.0 MHz Petroleum Prod., CB Class D channels,

Business and Forest Products

28.0-30.0 MHz 10 Meter Amateur Band

30.0-50.0 MHz VHF Low Band

50.0-54.0 MHz 6 Meter Amateur Band

108-137 MHz Aircraft Band

137-144 MHz Military Land Mobile

144-148 MHz 2 Meter Amateur Band

148-174 MHz VHF High Band

400-420 MHz Federal Government

420-450 MHz 70 cm Amateur Band

450-470 MHz UHF Standard Band

470-512 MHz UHF T Band

806-956 MHz 800 Band

Operating Temperature: E0 °C to +60 °C (-4 °F to +140 °F)

Scan Rate: 100 channels per second (conventional mode)

Search Rate: 100 steps per second (Normal Search)

300 steps per second (Turbo Search)

Audio Output: Maximum 2.6W (2.2W normal @ 10% THD)

Internal Speaker: 8 ohms (57 mm outer diameter)

Power Requirements: AD140U AC Adapter (12V DC, 500mA)

Antenna: Telescopic Antenna (included)

Window Mount Antenna (included)

Antenna Jack: BNC type

External Jacks: External Speaker (EXT.SP.) (3.5 mm)

DC 12 V Power Jack, (center is positive)

Remote Control (REMOTE) Jack (DB-9)

Size: 7.06 in. (W) x 6.10 in. (D) x 2.44 in. (H)

176.5mm (W) x 152.5mm (D) x 50.8mm (H)

Weight: 1.1 kg (2 lbs 7 oz.)

Features and specifications are all subject to change without notice.

Limited Warranty

RadioShack Corporation

Fort Worth, Texas 76102

Cat. No. 20-426

09A04

Printed in China

UBZZ01331ZZ

NWR SAME

During weather scanning, press [HOLD] to go to hold mode.

Press F+[WX ALT] to enable NWR SAME alert.

When WX alert is on, “ALERT” LED is displayed ON. And the audio mute is

set on.

Press F+[WX ALT] to turn off NWR SAME alert.

If the scanner receives a SAME event code from the local weather service, it

sounds an alert and displays the description for any alert received.

And then audio mute is off. And “ALERT” LED is blinking.

The scanner display in channel area the following message;

Warning : “L1”

Watch : “L2”

Advisory : “L3”

Test : “TST”

WX alert (1050 Hz) : WXA

During an alert, press any key, then an alert stops. If you do not press any key,

then the scanner continues sounding the alert beep.

Although alert beep (warning beep, watch beep ,advisory beep) is sounded at

short intervals for 5 minutes, after that, the emergency beep will be sounded

beep at intervals of 10 sec.

Programming FIPS code

To specify a county, SAME uses a standard established by the US Census

bureau, called FIPS. The format of a FIPS code is:

DSSCCC

Where

D = area subdivision (0=entire area)

SS = State code (00=all states)

CCC = County code (000=all counties)

For example, the FIPS code for Tarrant County, Texas is:

048439 (48=Texas; 439=Tarrant County).

Some counties are further subdivided, in which cases, the first digit will be 0 for

all subdivisions in the county and each subdivision will be labeled 1-9.

To program your scanner to alert you when the weather service issues an alert,

you must set the scanner to the alert mode, and then leave the scanner

monitoring the weather service. You cannot scan and monitor for weather

alerts at the same time.

To limit alerts to a specific area, you must also program in the FIPS code(s) for

the area(s) you want to receive alerts for. The scanner can be set to either alert

for all areas, or only the areas you have programmed.

Programming FIPS

To program weather alert operation:

During weather scan hold mode, press F+[E], go to FIPS programming mode.

If the scanner is set to alert for all FIPS. “ALLFＩPS” is displayed.

If the scanner is set to alert only the area you have programmed, “F1” is

displayed.

Press [▲] or [▼] to move FIPS code “F1” to “F15”.

If FIPS code is no programmed, “------“ is displayed.

Input FIPS code by numeric key.

Press [./CLR] to cancel inputted FIPS code.

Press [E] to store FIPS code.

Press [0], [E] to clear FIPS code. “------“ is displayed.

If an invalid value has been inputted, FIPS code will be cleared.

To set to alert all FIPS, press [▲] or [▼] to move “ALLFＩPS”.

And press [E]. Then go to WX hold mode.

To set to alert only the area you have programmed, press [▲] or [▼] to move

“F1” to “F15”. And press [E]. Then go to WX hold with WX alert.

Press [HOLD] to exit this mode.

SIGNAL STALKER

Signal Stalker

Your scanner's Signal Stalker feature lets you set the

scanner so it detects then displays the frequency of

a nearby strong radio transmission. You can set the

scanner so Signal Stalker works "in the background"

while you are scanning other frequencies, turn off

normal scanning while Signal Stalker is working, or

turn off Signal Stalker and use the scanner normally.

You can set the scanner so it alerts you when Signal

Stalker finds a frequency. You can also set the

frequency band where you want the scanner to look

for transmissions.

Notes:

. Signal Stalker works well for locating the source

of strong local transmissions such as mobile

and handheld two-way radios in areas with no

other strong transmission sources. However, if

you are in an area with many transmission

sources (such as pager radio transmitters, multiuse

radio towers, traffic control devices, etc.), Signal Stalker might not find the

transmission

you are searching for, or it might find a

transmission other than the one you are

searching for. You can screen unwanted

transmissions by pressing FUNC + L/O to lock

them out. See “Locking Out Frequencies” on

Page 49 for more information.

. Signal Stalker cannot detect satellite dishes or

any transmitter with a frequency above or below

the frequency ranges listed under “Setting the

Signal Stalker Options” on Page 32.

. Signal Stalker works better with some types of

transmissions than others. It might not correctly

display frequency information for transmitters

using a highly directive antenna (such as an

amateur radio beam antenna), if there are many

transmitters operating at the same time in the

same area, or if the transmitter is a broadcast

television station.

Setting the Signal Stalker Options

Press FUNC then press and hold for 2

seconds. One of the following signal stalker

options appears.

S-S.bnd: Lets you select the signal stalker band.

S-S.ALt: Lets you select the signal stalker alert

settings.

“S-S.PS” : Setting of pager screen

Repeatedly press or to select the option

you want, then press E.

If you selected S-S.bnd, one of the following

band names appears.

bnd Lo: VHF Low Band (25.0000 - 54.0000 MHz)

bnd Air: AIR Band (108.0000 - 136.9875 MHz)

bnd Hi: VHF High Band (137.0000 - 174.0000

MHz)

bnd UHF: UHF Band (406.0000 - 512.0000 MHz)

bnd 800: 800MHz Band (806.0000 - 956.0000 MHz)

If you selected S-S.Alt, skip to Step .

Repeatedly press or until the band you

want to search appears, then press E to select it.

Otherwise, press ./CLR if you do not want to

select it.

The scanner displays the following options.

Lo On or Lo OFF

Air On or Air OFF

Hi On or Hi OFF

UHF On or UHF OFF

800 On or 800 OFF

Repeatedly press or until the option you

want appears, then press E to select it.

Otherwise, press ./CLR if you do not want to

select it. Then skip to Step .

Press E while S-S.Alt appears. One of the

following alert options appears.

ALt bEEP: The scanner beeps when a signal

stalker signal is detected.

ALt Light: The scanner flashes the display

backlight when a signal stalker signal is detected.

ALt bP-Lt: The scanner flashes the display

backlight and beeps when a signal stalker signal

is detected.

ALt OFF: The scanner does not provide any alert

when a signal stalker signal is detected.

Repeatedly press or until the option you

want appears, then press E to select it.

Otherwise, press ./CLR if you do not want to

select it.

When you select the option, press ./CLR to exit

the option mode. Otherwise, to continue normal

scanning, repeatedly press FUNC until

disappears then press SCAN.

Using Signal Stalker

To turn on Signal Stalker, turn SQUELCH fully

clockwise, then press FUNC + once except in

Weather service, band select, state select, or program mode.

appears. Every 2 seconds, the scanner searches

for frequencies in the range you specified in “Setting

the Signal Stalker Options” on Page 32.

Note: To continue scanning normally while Signal

Stalker is working, simply press SCAN.

When the scanner finds a frequency, it sounds the

alert you specified in “Setting the Signal Stalker

Options” on Page 32, and Found flashes. Press any

key to confirm the displayed frequency. Press SCAN

to resume scanning. Or press or while the

frequency and appear to select the band where

you are searching.

To turn on Signal Stalker and turn off normal

scanning, press FUNC + twice. and - - - - - -

flash.

To turn off Signal Stalker and turn on normal

scanning, press FUNC + three times.

disappears.

SKYWARN

Skywarn

The Skywarn function lets you jump directly to the

last channel in memory (Channel 200) from any

mode by pressing FUNC + . The scanner goes

into scan hold mode and starts receiving

transmissions in the last channel. If no frequency is

programmed in the last channel, No Prg appears

and the scanner sounds an error tone.

About Skywarn

Skywarn is an organized group of trained weather

observers. A Skywarn group exists in virtually every

US county with a significant population. During

inclement weather, reports made by Skywarn

observers include information about:

. pea-sized and larger hail

. wind and wind gusts 40 MPH and greater

. heavy rainfall

. lightning (cloud-to-cloud and especially

cloud-to-ground)

. wall clouds seen in severe thunderstorms

(which spawn tornadoes)

. severe lowering of a wall cloud

. turbulence in a wall cloud

. funnel clouds

. tornadoes

. high water areas

. downed power lines

. other emergency conditions that affect life or

property

Listening to Skywarn broadcasts makes it easy to

quickly find out about and prepare for inclement

weather conditions in your immediate area, even

before your local NOAA weather broadcast and

local TV or radio station can announce them.

Enter the local Skywarn frequency for your area into

Channel 200 on your scanner, then listen to Skywarn

first when severe weather threatens.

Listen to NOAA: for weather alerts and warnings,

watch box notices, and weather forecasts

Listen to Skywarn: to hear trained observers in your

vicinity call in official reports to a "net control"

station who relays those reports to NOAA and other

emergency agencies.

If you tune to a Skywarn frequency when the

Skywarn net is not active, you may hear nothing or

you may hear amateur radio operators talking on a

local repeater system.

Most importantly, you get Skywarn reports directly

from trained observers - that means you get them

several minutes before they can be relayed for

broadcast by NOAA and as much as 5 or 10 minutes

sooner than you will hear them on local TV or radio!

Those few minutes can be worth a lot when it

comes to deciding if your family needs to take cover.

PC INTERFACE

Wired Programming

You can transfer programming data to your scanner

using your PC and an optional interface cable

and software (available at your local RadioShack or

www.radioshack.com).

Note: If the scanner receives no data from the PC

for more than 20 seconds, T-Err appears and wired

programming stops.

Make sure your scanner is turned off.

Connect the interface cable to your computer

then connect the other end of the cable to PC/IF

on the side of the scanner.

Install the software to your computer and run the

program.

To set up the program, click on Tools, select

Configuration, and select PRO-83 (if necessary).

Turn on the scanner. The scanner automatically

goes into the wired programming mode. PGM

and WirEd appear. Then send the data from the

PC.

Data frame numbers being received appear.

When the scanner has successfully received all

data, End appears. If the scanner received an

error while receiving data, End, d-Err, and its

frame number appear. If the scanner received a

communication error while receiving data, C-Err

indicates the packet number where the error

occurred. If the scanner received a checksum

error while receiving data, S-Err indicates the

packet number where the error occurred. If the

scanner received a length field error while

receiving data, L-Err indicates the packet number

where the error occurred.

150 CH PREPROGRAMMED FREQUENCY

Follow these steps to restore the 150

preprogrammed frequencies stored in the

scanner.

The FCC Wants You to Know

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Consult your local RadioShack store or an experienced radio/TV

technician for help.

• If you cannot eliminate the interference, the FCC requires that you stop

using your scanner.

Changes or modifications not expressly approved by RadioShack may

cause interference and void the user’s authority to operate the equipment.

You must use shielded interface cables with this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Uniden America UB331 MOBLE TYPE SCANNER User Manual Precautions

Uniden America Corporation MOBLE TYPE SCANNER Precautions

USERS MANUAL

Navigation menu

Namespaces

Views

Navigation
