Universal Electronics 4868 Comcast XR8 RF4CE Serial Dongle 2012 User Manual

Universal Electronics Inc Comcast XR8 RF4CE Serial Dongle 2012

User Manual

Enjoy your
XFINITY® TV
right away!
Pair your XR8 and Xfinity
Remote to get started.
Your Xnity Remote can be paired
with the XR8, allowing you to control
your set-top box or DTA even when
the device is placed out of line-of-
sight (for example, in an entertainment
center or behind your TV). Xnity
Remotes can be identied by an XR
logo on the back of the remote.
See the “Compatible Devices” section
on the back of this user guide to verify
that your set-top box or DTA and
remote are compatible with the XR8.
To pair your XR8 and Xnity Remote,
follow the steps below:
HERE’S HOW:
1. Turn on your TV and set-top box
or DTA.
2. Plug the XR8 into the IR Input port*
located on the rear panel of your
set-top box or DTA.
*Note: This port may also be
labeled IR, IR-In, IR Receive, or
EXT IR IN.
3. Wait 3-5 seconds for the solid red
LED on top of the XR8 to turn off.
It’s simple to pair your XR8 with your
Xfinity Remote for Out-of-Sight control.
XR8
Xfinity Remote
Out-of-Sight Adapter
USER’S GUIDE
XR8
Xfinity Remote
Out-of-Sight Adapter
USER’S GUIDE
4. Press and release the PAIR button
on the back of the XR8. The LED on
top of the XR8 will start blinking.
5. Press and hold the Setup button on
your Xnity Remote until the LED
changes from red to green. Then,
press and release the Xnity button.
Note: You must press the PAIR
button on the XR8 before you press
the Xnity button on your Xnity
Remote.
6. If the LED on the Xnity Remote
blinks green twice, pairing was
successful. Press Channel Up to
verify that your set-top box or DTA
responds as expected.
7. If the LED on the Xnity Remote
blinks red, then green, and then red,
pairing was unsuccessful. Check
the “Compatible Devices” section to
verify that your set-top box or DTA
supports the XR8.
xfinity.com ©2013 Comcast Corporation. All rights reserved.
FCC Compliance Statement
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reason-
able protection against harmful interference
in a residential installation. This equipment
generates, uses, and can radiate radio fre-
quency energy and, if not used in accordance
with the instructions, may cause harmful
interference to radio communications.
There is no guarantee that interference will
not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase or decrease the separation
between the equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that which
the receiver is connected.
• Consult the dealer or an experienced
remote control/TV technician for help.
• It is strongly recommended that the TV
be plugged into a separate wall outlet.
The user is cautioned that changes and mod-
ications made to the equipment without the
approval of the manufacturer could void the
user’s authority to operate this equipment.
This device complies with part 15 of the FCC
rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
:QCan I pair more than one Xnity
Remote with the XR8?
:AYes, the XR8 supports pairing
with up to ve Xnity Remotes.
:QWhy can’t I use my other
remotes after pairing my Xnity
Remote with the XR8?
:ASome set-top boxes only
support Xnity Remotes when
using the XR8. Simply replace
your old remote with another
Xnity Remote if you need more
than one remote!
:QDuring pairing, why does the
LED blink red and then green on
the Xnity Remote?
:AEither a button other than the
Xnity button was pressed, or
the Xnity Remote timed out
before the Xnity button was
pressed. Repeat the pairing
steps.
COMPATIBLE
DEVICES:
DTA
uDTA
RNG100
RNG110
RNG150
RNG150N
RNG200N
DCX3200
DCX3200-M
DCX3400
DCX3400-M
DCX3501
FREQUENTLY ASKED
QUESTIONS ABOUT PAIRING
:QDuring pairing, why does the LED
blink red, then green, then red on
the Xnity Remote?
:AThe Xnity Remote you are trying
to pair with the XR8 cannot nd
the XR8. Unplug the XR8 and plug
it back in, making sure the red
LED on top of the XR8 comes on
for 3-5 seconds. Then, repeat the
steps to pair the XR8 and Xnity
Remote.
:QWhen paired, why does the LED
blink green, then red on the
Xnity Remote when a button is
pressed?
:AThe XR8 may have lost power or
may be out of communication
range. Try moving closer to your
set-top box or DTA and make sure
the XR8 is securely connected. If
this does not x the issue, follow
the steps to re-pair the XR8 and
Xnity Remote.
SET-TOP BOXES AND DTAS
The XR8 can be used for out-of-sight
control with the set-top boxes and
DTAs listed below:
XFINITY REMOTES
Xnity Remotes that can be paired
with the XR8 include:
XR2
XR5
XR11
XR13
For additional information
about Xnity Remotes visit
xnity.com/remotes.
